Data Sheet

Cisco Model DPC2434 DOCSIS 2.0 Wireless

Residential Gateway with Two-Line Embedded

Media Terminal Adapter

The Cisco®Model DPC2434 DOCSIS 2.0 Wireless Residential Gateway with Two-Line

Embedded Media Terminal Adapter (DPC2434) is a high-performance home gateway

that combines a cable modem, two-line Voice over Internet Protocol (VoIP) terminal

adapter, router, and wireless access point in a single device to provide a cost-effective

voice and networking solution for both the home and small office.

The DPC2434 has been designed to meet PacketCable™ 1.5 and 1.0, CableHome®1.1, and

DOCSIS®2.0 specifications. In addition, the DPC2434 is fully backward compatible for use on both

DOCSIS 1.1 and DOCSIS 1.0 networks.

Designed for the active digital home or office, the DPC2434 features an integrated router along

with CableHome-ready Network Address Translation (NAT), a Dynamic Host Configuration

Protocol (DHCP) server, parental control, and firewall technology.

Figure 1. DPC2434 Wireless Home Gateway with Two-Line EMTA (image may vary from actual product

and specification)

Data Sheet

Features

DOCSIS

Compliant with DOCSIS 2.0, 1.1, and 1.0 standards along with PacketCable

specifications to deliver high-end performance and reliability

Enhanced packet processing technology to maximize performance

Connections

Four 10/100BASE-T auto-sensing/auto-MDIX Ethernet ports

802.11g wireless access point (WAP)

Two RJ-11 telephony ports for connecting to in-home wiring or directly to conventional

telephones or fax machines

USB 2.0 port

Design and Function

Attractive compact design and versatile orientation to stand vertically, lie flat on the

desktop or shelf, or mount easily on a wall

LED status indicators on the front-panel provide an informative and easy-to-understand

display that indicates the cable modem operational status

Rugged electronic components for long-term reliability

Dual antenna design - one internal and one detachable external

Optional backup battery capability

Management

Software upgradeable by network download

Remote manageability through Web interface, config file, or SNMP protocols

Advanced firewall technology deters hackers and protects the home network from

unauthorized access

User-configurable Parental Control blocks access to undesirable Internet sites

Software and Documentation

CD-ROM containing user guide and USB drivers

Data Sheet

Figure 2. DPC2434 Front Panel - antenna not shown (image may vary from actual product and

specification)

Table 1. Front Panel Features

Feature

Description

Indicators

POWER, DS, US, ONLINE, LINK (1 TO 4), USB, WIRELESS, TEL 1, TEL 2, BATTERY

Color

Black case, gray faceplate, white text, green LEDs

Branding

Model number

Figure 3. DPC2434 Back Panel (images may vary from actual product and specification)

Model with internal power supply

Model with external power supply

Table 2. Back Panel Switch and Connections

Feature

Description

POWER

Connector Color: Black

Connects wireless home gateway to the AC power cord or to the AC power the AC

power adapter

CABLE

Connector Color: White

F-connector connects to an active cable signal from your service provider

RESET

Resets the EMTA. Pressing this switch for more than 10 seconds resets the device to

factory default values and resets the EMTA.

USB

Color: Blue

USB 2.0 port connects to a USB port on select devices

ETHERNET (1-4)

Connector Color: Yellow

RJ-45 Ethernet port connects to the Ethernet port on your PC or your home network

TELEPHONE 1 and 2

Color: Gray

RJ-11 telephone ports connect to home telephone wiring and to conventional

telephones or fax machines

ANTENNA (Internal and

detachable external)

Provide a communication connection for the built-in WAP

Data Sheet

Product Specifications

Table 3. Product Specifications

Specification

Value

Voice Specifications

Call Signaling Protocol

MGCP/NCS including configurable IPsec encryption

Configurable to support RFC2833 event signaling

Supports Bell103 detection: Improves alarm panel and Point of Sale (POS) interoperability by

optimizing DSP for Bell103 protocol

Software upgradeable to support Session Initiation Protocol (SIP)

The following SIP standards are supported

●RFC 2617 HTTP Authentication: Basic and Digest Access Authentication

●RFC 2976 The SIP INFO Method

●RFC 3261 SIP: Session Initiation Protocol

●RFC 3262 Reliability of Provisional Responses in Session Initiation Protocol (SIP)

●RFC 3263 Session Initiation Protocol (SIP): Locating SIP Servers

●RFC 3264 An Offer/Answer Model with Session Description Protocol (SDP)

●RFC 3265 Session Initiation Protocol (SIP)-Specific Event Notification

●RFC 3420 Internet Media Type message/sipfrag

●RFC 3428 Session Initiation Protocol (SIP) Extension for Instant Messaging

●RFC 3515 The Session Initiation Protocol (SIP) Refer Method

●RFC 3842 A Message Summary and Message Waiting Indication Event

●Package for the Session Initiation Protocol (SIP)

●RFC 3892 The Session Initiation Protocol (SIP) Referred-By Mechanism

●RFC 3903 Session Initiation Protocol (SIP) Extension for Event State Publication

●Draft-ietf-mmusic-sdp-new-24 SDP: Session Description Protocol (Replacement for RFC 2327)

●Draft-ietf-sipping-cc-transfer-01 Session Initiation Protocol Call Control –Transfer

●Draft-ietf-sip-session-timer-08 The SIP Session Timer

●Draft-ietf-sipping-realtimefax-01 SIP Support for Real-time Fax: Call Flow

Examples And Best Current Practices

●Draft-ietf-mmusic-sdescription-09 Session Description Protocol Security

●Descriptions for Media Streams

●Draft-ietf-sip-replaces-02 The Session Initiation Protocol (SIP) "Replaces" Header

Provisioning Modes

Full PacketCable secure provisioning

Kerberos support with NVRAM ticket caching

Configurable PacketCable-lite (MTA config file provisioning without security)

Configurable for non-PacketCable (MTA configuration using DOCSIS config file)

CODECs

Standard: G.711, T.38 Fax Relay, iLBC and BV16

Software upgradeable to support other CODEC combinations including:

●G.711 and G.728

●G.711 and G.729

●G.711 and G.729 a/e

●G.711 and BV16 and BV32 (High fidelity –near CD quality)

●G.711 and G.723

●G.711 and G.726

CODEC Packetization

Intervals

10, 20, and 30 mS

CODEC Synchronization

CODEC synchronization to UGS time clock allows slip-free end-to-end sync to PSTN clock

(minimizes frame slips that can cause Fax/Analog Modem call failures)

CODEC Encryption

Configurable to support AES-128 encryption or no encryption modes

Hearing Impaired Services

Support

TDD support including detection of V.18 including Annex A

Fax and Analog Modem

support

DSP based Modem/Fax Tone detection and support for Voice Band Data Mode with auto-

CODEC negotiation and auto-control of echo canceller, jitter buffer, and VAD

Jitter Buffer Support

Adaptive dynamically controlled

Latency Control

Configurable min / max jitter buffer size

Audio Gain Levels

Independently configurable Tx and Rx audio gains

Data Sheet

Specification

Value

Silence Suppression

Configurable VAD with comfort noise generation

Packet Loss Concealment

ANSI T1.521-1999

Call Connection Quality

Monitoring

RTCP, RFC1889, RFC1890, SNMP MIB for last call quality statistics

Dialing Modes

DTMF and configurable pulse dial support

DTMF Relay

RFC2833 including fast (40mS) DTMF Relay for alarm system signaling compatibility

Layer 2 Quality of Service

●Full PacketCable secure DQOS with GateID including UGS and UGS/AD

●DQOS Lite support including UGS and UGS/AD

Layer 3 Quality of Service

Configurable DiffServe/TOS support for Signaling, RTP, and RTCP flows

Payload Header

Suppression (PHS)

●Supported for RTP and RTCP packet flows to reduce per-call network bandwidth

●Advanced support for Dynamic Payload Header Suppression using Propane Technology

Management

SNMPv3, SNMPv2, SNMPv1, Telnet with configurable user ID and password, internal log, and

external Syslog support

Echo Cancellation

G.168 with extended echo tail support

Call Feature Support

●Caller ID

●Call Waiting with Caller ID

●Cancel Call Waiting

●Call Conferencing (3-way calls)

●Configurable hook flash support

●Distinctive Ringing (Configurable for up to 11 ring patterns per phone line)

●Ring Splash

●Stutter Dial Tone

●Off hook warning tone

●Open Switch Interval support to enhance answering machine compatibility

●Configurable star codes

●Euro/US hook-flash type

●Call transfer

●Message Waiting Indicator

●Warm Line

●Call Forwarding Unconditional

●Call Forwarding on Busy

●Call Forwarding No Answer

●Call Return

●Redial Call

●Automatic redial

Other call features available with compliant CMS or gateway

Telephone Ring Loading

Full 5 REN support on each phone line (10 REN total)

Ring Signal

Configurable balanced ring with configurable DC offset

Max Phone Line Distance

Supports up to 1000 ft of AWG26 wire (0.4 mm) on each phone line. Supports operation with

typical in-home telephone wiring

Country-Specific

Telephone Parameters

Supported

United States, Japan, United Kingdom, Germany, France, Belgium, Netherlands, Finland, Italy,

Switzerland, Sweden, Denmark, Brazil, ETSI 101 909-18

RF Downstream

Frequency Range

88 to 860 MHz

Demodulation

64 or 256 QAM

Maximum Data Rate

30 Mbps for 64 QAM

43 Mbps for 256 QAM

Bandwidth

6 MHz

Operating Level Range

-15 to +15 dBmV

Input Impedance

75 ohms

Data Sheet

Specification

Value

RF Upstream

Frequency Range

5 to 42 MHz

5 to 55 MHz (Japan)

Modulation

QPSK

8 QAM

16 QAM

64 QAM

128 QAM TCM

Maximum Data Rate

5.12 Mbps for QPSK

10.2 Mbps for 16 QAM

30.0 Mbps for A-TDMA and SCDMA

Bandwidth

200 kHz to 6.4 MHz

Operating Level Range

(all values +/- 0.5 dBµV )

TDMA

QPSK +8 to +58 dBmV

8QAM +8 to +55 dBmV

16QAM +8 to +55 dBmV

32QAM +8 to +54 dBmV

64QAM +8 to +54 dBmV

SCDMA

QPSK +8 to +53 dBmV

8QAM +8 to +53 dBmV

16QAM +8 to +53 dBmV

32QAM +8 to +53 dBmV

64QAM +8 to +53 dBmV

128QAM +8 to +53 dBmV

Output Impedance

75 ohms

Wireless Access Point

Frequency Range

2.412~2.462 GHz, 11 Channels (North America; FCC)

2.412~2.472 GHz, 13 Channels (Europe; CE/ETSI)

Modulation

DSSS

OFDM

CCK

DQPSK

DBPSK

Data Rate:

802.11g

54 Mbps with Auto Fall-Back

Security

WPA2, WPA and 64/128-bit WEP

Transmit Power

14 dBm (typical for 802.11g)

Antenna System

One (1) external, detachable

One (1) internal

Other

Input Voltage

100-240 VAC (internal power supply)

12 VDC (external power supply)

Power Consumption

(Modem Module)

7.5 Watts (battery backup configuration)

6 Watts(no battery backup capability)

Data Ports

Ethernet 10/100BASE-T (Auto-sensing with Auto-MDIX): RJ-45 Ethernet (4)

USB

Type 2 (1)

Female “F” type

Data Sheet

Specification

Value

Mechanical

Dimensions (W x D x H)

(approximate)

Not including “F” connector:

8.75 in. x 5.19 in. x 2.71 in. (22.2 cm x 13.2 cm x 6.9 cm)

Including “F” connector and wireless antenna:

8.75 in. x 5.75 in. x 2.71 in. (22.2 cm x 14.6 cm x 6.9 cm)

Weight (approximate)

No battery

8 hour

16 hour

1.4 lbs (.56 kg)

1.7 lbs (.76 kg)

2.04 lbs (.93 kg)

Battery Type and Capacity

8 hour

16 hour

1 cartridge, Li-Ion, 3 cells, 2200 mAh

2 cartridges, Li-Ion, 3 cells each, 2200 mAh per cartridge

Operating Temperature

32˚to 104˚F (0˚to 40˚C)

Operating Humidity

0% to 90% RH non-condensing

Storage Temperature

-4˚to 140˚F (-20˚to 60˚C)

Standards and Approvals

Designed to Comply with

the Following Standards

PacketCable 1.5 and 1.0

CableHome 1.1

DOCSIS 2.0, DOCSIS 1.1, DOCSIS 1.0

RFC 3261 SIP

IEEE 802.11g,

WPA, WPA2, WEP, IEEE 802.11i

USB 1.1

Regulatory and Safety

Approvals

As required per country where the DPC2434 will be used

Ordering Information

Table 4. Ordering Information

Description

Part Number

North American Tuning Plan –NTSC

DPC2434-2200 Wireless Home Gateway with 2-line EMTA. Includes:

802.11g wireless access point

Internal 100-240 VAC / 50-60 Hz universal power supply

Power cord, North America, NEMA 1-15 to C7

2200 mAh battery cartridge

Ethernet and USB cables

CD-ROM containing user guide and USB driver

4013345

DPC2434C2-2200 Wireless Home Gateway with 2-line EMTA. Includes:

802.11g wireless access point

120 VAC / 50-60 Hz, 15 VDC / 1 A wall-mount linear switching power supply

2200 mAh battery cartridge

Ethernet and USB cables

CD-ROM containing user guide and USB driver

4015327

DPC2434 Wireless Home Gateway with 2-line EMTA. Includes:

802.11g wireless access point

Internal 100-240 VAC / 50-60 Hz universal power supply

Power cord, North America

No battery provided

Ethernet and USB cables

CD-ROM containing user guide and USB driver

4028567

Data Sheet

Description

Part Number

DPC2434 Wireless Home Gateway with 2-line EMTA. Includes:

802.11g wireless access point

Internal 100-240 VAC / 50-60 Hz universal power supply

Power cord, North America

No battery provided

Ethernet and USB cables

CD-ROM containing user guide and USB drive

North America (Customer specific configuration)

4027663

DPC2434-2200 Wireless Home Gateway with 2-line EMTA. Includes:

802.11g wireless access point

Internal 100-240 VAC / 50-60 Hz universal power supply

Power cord, Europe

2200 mAh battery cartridge

Ethernet and USB cables

CD-ROM containing user guide and USB driver

4025715

DPC2434-2200 Wireless Home Gateway with 2-line EMTA. Includes:

802.11g wireless access point

Internal 100-240 VAC / 50-60 Hz universal power supply

Power cord, North America

2200 mAh battery cartridge

Ethernet and USB cables

CD-ROM containing user guide and USB driver

North America (Customer-specific configuration)

4027679

DPC2434C2 Wireless Home Gateway with 2-line EMTA. Includes:

802.11g wireless access point

120 VAC / 50-60 Hz, 15 VDC / 1 A wall-mount linear switching power supply

No battery provided

Ethernet and USB cables

CD-ROM containing user guide and USB driver

4021043

DPC2434X Wireless Home Gateway with 2-line EMTA. Includes:

802.11g wireless access point

220 VAC / 50-60 Hz, 15 VDC / 1 A desktop linear switching power supply, Argentina

No battery capability

Ethernet and USB cables

CD-ROM containing user guide and USB driver

Argentina

4028933

DPC2434X Wireless Home Gateway with 2-line EMTA. Includes:

802.11g wireless access point

120-240 VAC / 50-60 Hz, 15 VDC / 1 A desktop switching-regulated power supply

Power cord, Brazil

No battery capability

Ethernet and USB cables

CD-ROM containing user guide and USB driver

Brazil

4028618

DPC2434X Wireless Home Gateway with 2-line EMTA. Includes:

802.11g wireless access point

120 VAC / 50-60 Hz, 15 VDC / 1 A desktop linear switching power supply, North America

No battery capability

Ethernet and USB cables

CD-ROM containing user guide and USB driver

Brazil

4028611

Data Sheet

Description

Part Number

DPC2434X Wireless Home Gateway with 2-line EMTA. Includes:

802.11g wireless access point

100-120 VAC / 50-60 Hz, 15 VDC / 1 A desktop linear switching power supply

No battery capability

Ethernet and USB cables

CD-ROM containing user guide and USB driver

North America (Customer-specific configuration)

4021375

International Tuning Plan –PAL/NTSC

DPC2434X Wireless Home Gateway with 2-line EMTA. Includes:

802.11g wireless access point

230 VAC / 50 Hz, 15 VDC / 1 A desk-top linear power supply for Europe

No battery capability

Ethernet and USB cables

CD-ROM containing user guide and USB driver

Europe

4014308

DPC2434C2-2200 Wireless Home Gateway with 2-line EMTA. Includes:

802.11g wireless access point

230 VAC / 50-60 Hz, 15 VDC / 1 A wall-mount linear switching power supply

2200 mAh battery cartridge

Ethernet and USB cables

CD-ROM containing user guide and USB driver

Europe

4016289

Replacement Components

Table 5. Replacement Components

Description

Part Number

Power Supply - Class 2 Linear Switching

100-120 VAC / 50-60 Hz, 15 VDC / 1 A desktop-style linear switching power supply, North America

4018776

220 VAC / 50 Hz, 15 VDC / 1 A desktop-style linear switching power supply, Argentina

4023778

100-120 VAC / 50-60 Hz, 15 VDC /1 A wall-mount linear switching power supply North America and

Japan

4015454

230-240 VAC / 50-60 Hz, 15 VDC /1 A wall-mount linear switching power supply with Euro-style

connector

4015455

Power Supply - Class 2 Switching Regulated

100-240 VAC / 50-60 Hz, 15 VDC /1 A desktop-style switching-regulated power supply

4007274

Power Cord

Power cord, 2 conductor, NEMA 1-15P to C7P, 6 foot, North America (polarized) for internal power

supply

186750

Power cord, 2 conductor, CEE7/16 to C7, 6 foot, Europe (non-polarized)

503414

Power cord, 2 conductor, CEE7/16 to C7, INMETRO, Brazil (non-polarized)

4009115

Power cord, 2 conductor, Argentina (non-polarized)

4012938

Data Cable

Ethernet cable, 1.2 meter

740580

USB cable, 1.0 meter

740579

CD-ROM

CD-ROM with user guides and USB driver

4001911

Data Sheet

Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its affiliates in the U.S. and

other countries. A listing of Cisco's trademarks can be found at www.cisco.com/go/trademarks.

CableHome and DOCSIS are registered trademarks of Cable Television Laboratories, Inc. PacketCable is a

trademark of Cable Television Laboratories, Inc.

Other third party trademarks mentioned are the property of their respective owners.

The use of the word partner does not imply a partnership relationship between Cisco and any other company.

(1009R)

Specifications and product availability are subject to change without notice.

Cisco Systems, Inc.

800 722-2009 or 678 277-1120

www.cisco.com

Part Number 7009659 Rev D

January 2011

Autres manuels pour DPC2434

Table des matières

Autres manuels Cisco Porte

Cisco

Cisco Small Business SPA8800 Manuel utilisateur

Cisco

Cisco 3527 PRI G Manuel d'installation et d'exploitation

Cisco

Cisco WAG54G Manuel utilisateur

Cisco

Cisco DPC3825 Manuel utilisateur

Cisco

Cisco Linksys WAG325N Manuel utilisateur

Cisco

Cisco Comcast Xfinity DPC3939 Manuel utilisateur

Cisco

Cisco 545 Serial Manuel d'installation et d'exploitation

Cisco

Cisco VG224 - Analog Phone Gateway Manuel utilisateur

Cisco

Cisco Scientific Atlanta Explorer 4250 Manuel utilisateur

Cisco

Cisco AS5400 Series Manuel utilisateur

Cisco

Cisco Linksys SPA400 Manuel d'utilisation

Cisco

Cisco VG224 - Analog Phone Gateway Manuel

Cisco

Cisco VG248 - Gateway Manuel utilisateur

Cisco

Cisco ENH900EXT Manuel utilisateur

Cisco

Cisco T3 Manuel utilisateur

Cisco

Cisco Explorer 4250 Manuel utilisateur

Cisco

Cisco AS5350XM Manuel utilisateur

Cisco

Cisco RF Gateway 10 Manuel utilisateur

Cisco

Cisco IG21-VZ-K9 Manuel utilisateur

Cisco

Cisco VG202 Manuel utilisateur

Cisco

Cisco RF Gateway 1 Modules Manuel utilisateur

Cisco

Cisco Linksys WAG54GX2 Manuel utilisateur

Cisco

Cisco DPC Manuel utilisateur

Cisco

Cisco ASR 9000 Series Manuel d'installation

Manuels Porte populaires d'autres marques

LST

LST M500RFE-AS Manuel utilisateur

Kinnex

Kinnex Media Gateway Manuel utilisateur

2N Telekomunikace

2N Telekomunikace 2N StarGate Manuel utilisateur

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries Superlink SC-WBGW256 Manuel utilisateur

ZyXEL Communications

ZyXEL Communications ZYWALL2 ET 2WE Manuel utilisateur

Telsey

Telsey CPVA 500 - SIP Manuel utilisateur

RTA

RTA 460A-NNA4 Fiche technique

Shaw

Shaw Gateway HDPVR Manuel utilisateur

ABB

ABB VSN900 Guide de démarrage rapide

Commander

Commander Pulse Manuel utilisateur

2N Telekomunikace

2N Telekomunikace ATEUS EasyGate 501309E Manuel utilisateur

NETGEAR

NETGEAR C6300BD Manuel utilisateur

Amit

Amit CDW531AM Manuel utilisateur

HMS

HMS Netbiter EasyConnect EC150 Manuel utilisateur

Huawei

Huawei EchoLife HG620 Manuel utilisateur

AT&T

AT&T U-verse 3801 Manuel d'utilisation et d'entretien

Logic IO

Logic IO RTCU MX2 turbo Manuel utilisateur

Suttle

Suttle MediaMAX MXM-521 Manuel utilisateur
