Chamberlain 893LM Manuel utilisateur

Single Button Remote Control

Model 891LM

3-Button Remote Control

Model 893LM

TO ERASE ALL CODES FROM MEMORY

REMOTE CONTROLS

MODELS 891LM & 893LM

To prevent possible SERIOUS INJURY or DEATH from a moving gate or garage door:

• ALWAYS keep remote controls out of reach of children. NEVER permit children to operate,

or play with remote controls.

• Activate gate or door ONLY when it can be seen clearly, is properly adjusted, and there are

no obstructions to door travel.

• ALWAYS keep gate or garage door in sight until completely closed. NEVER permit anyone to

cross path of moving gate or door.

Press and hold the button

on the remote control

that you wish to use.

“click”

Release the button

when the garage

door opener lights

blink or two clicks

are heard.

If programming to

other products,

press the button a

second time to

activate the product.

Locate the

Learn button.

Press and

immediately release

the Learn button.

The Learn LED will glow

steadily for 30 seconds.

Within 30 seconds...

PROGRAM USING THE GARAGE DOOR OPENER

For use with Security+ 2.0™ products. All Security+ 2.0™ Garage Door Openers have a yellow Learn

button and two yellow antennas. The code between the remote control and the receiver changes

with each use, randomly accessing over a billion new codes. Refer to your product manual for the

location of the learn button.

NOTE: Your product may look different than the products illustrated in this manual.

When deactivating any unwanted remote

control code, all previous codes will be

erased. Press and hold the Learn button on garage door opener

or other product until the learn LED goes out

(approximately 6 seconds). All previous codes are

now erased. Reprogram each remote control you

wish to use.

LED LED

Press the LEARN button again,

the LED will flash once.

Press the LEARN button on

the door control to enter

Programming Mode.

The command LED

will flash once. The command LED

will flash once again.

Press and hold the button

on the remote control

that you wish to use.

“click”

Release the button when

the garage door opener

lights blink or two clicks

are heard.

If programming to other

products, press the

button a second time to

activate the product.

PROGRAM USING THE DOOR CONTROL

For more information, please visit www.devancocanada.com or call toll free at 855-931-3334

REPLACEMENT PARTS

3V CR2032 Lithium battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10A20

Visor Clip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29B137

ONE YEAR LIMITED WARRANTY

LiftMaster warrants to the first consumer purchaser of this product that it is free from defect in

materials and/or workmanship for a period of 1 year from the date of purchase.

3-BUTTON REMOTE CONTROLS

Press and hold the button down until the door or gate starts

to move. The remote control will operate from up to 3 car

lengths away on typical installations. Installations and

conditions vary, contact an installing dealer for more

information.

NOTICE: To comply with FCC and or Industry Canada rules (IC), adjustment or modifications of this

receiver and/or transmitter are prohibited, except for changing the code setting or replacing the battery.

THERE ARE NO OTHER USER SERVICEABLE PARTS.

Tested to Comply with FCC Standards FOR HOME OR OFFICE USE. Operation is subject to the following

two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

3V CR2032

Pry open the case ﬁrst

in the middle (1), then

at each side (2 and 3)

with the visor clip.

Remove the old battery.

Dispose of old batteries

properly.

Insert replacement

batteries positive side up.

Replace the batteries

with only 3V CR2032

coin cell batteries.

Replace cover.

THE REMOTE CONTROL BATTERY

The lithium battery should produce power for up to 3 years. If the battery is low, the remote control's LED will

not flash when the button is pressed. To replace battery: To prevent possible SERIOUS INJURY or DEATH:

• NEVER allow small children near batteries.

• If battery is swallowed, immediately notify doctor.

To reduce risk of fire, explosion or chemical burn:

• Replace ONLY with 3V CR2032 coin batteries.

• DO NOT recharge, disassemble, heat above 212° F (100° C) or incinerate.

1-800-528-9131

LiftMaster.com

HOW TO USE THE REMOTE CONTROL

Additional buttons on the remote control can be

programmed to operate up to 3 devices such as additional

garage door openers, light controls, gate operators or

access control systems.

TO CONTROL THE GARAGE DOOR OPENER LIGHTS

With the door closed,

press and hold

the remote

control button

that you want to

control the light.

Press and

hold the

LIGHT button

on the

door control.

Press and

hold the

LOCK button

on the

door control.

After the garage

door opener

lights flash,

release all

buttons.

“click”

This feature is only available on garage door openers equipped with a multi-function door control and a remote control with more than one button. Not available with external receiver.

A remote control button can be programmed to operate the garage door opener lights without opening the door.

Test by pressing the remote control button. The garage door opener lights should turn on or off but the door should not move.

HOW TO ORDER REPAIR PARTS

DEVANCO CANADA

19192 HAY ROAD, UNIT Q

SUMMERSTOWN, ON K0C 2E0

TOLL FREE: 855-931-3334

www.devancocanada.com

WHEN ORDERING REPAIR PARTS

PLEASE SUPPLY THE FOLLOWING INFORMATION:

3PART NUMBER

3DESCRIPTION

3MODEL NUMBER
