SK420 & SK520
Single ovens
Installation, use and maintenance
2
Contents:
3 Important information
5 Safety instructions
8 First use of the oven
9 Control panel(s)
10 Functions
14 Using your oven
14 Setting the current time
15 Minute minder function
16 Semi-automatic cooking
17 Automatic cooking
18 Booster function
18 Safety key lock
20 Cleaning and maintenance
21 Removing the appliance door
22 Replacing the appliance door
23 Removing the inner door glass (SK420)
24 Changing the oven light bulb (SK420)
25 Removing the inner door glass (SK520)
26 Changing the oven light bulb (SK520)
28 Installation
30 Mains electrical connection
32 Troubleshooting
33 Energy Eciency Information
IMPORTANT: Please read the user instructions carefully before
using the appliance for the first time and before installing it. Failure
to install the oven, or to have it installed, as per the user manual
could invalidate the warranty.
3
Important
This appliance must only be used for the purpose for which it is
intended, i.e. domestic cooking. Any other use could be dangerous
and may lead to premature failure of the appliance.
The CDA Group Ltd cannot be held responsible for injuries or losses
caused by incorrect use or installation of this product. Please note that
CDA reserve the right to invalidate the guarantee supplied with this
product following incorrect installation or misuse of the appliance.
Under no circumstances should any external covers be removed for
servicing or maintenance except by suitably qualified personnel.
User information:
• Ovens become hot during and immediately after use.
•The oven door can become very hot during operation.
•After use, please ensure that the oven switches are in the ‘O’
position.
•Keep children away from the appliance when in use, and
immediately after use.
•Do not allow children to play with or on the appliance.
•Keep the oven door closed whilst grilling.
Appliance information:
Please enter the details from the appliance rating plate on to the
following page for reference, to assist CDA Customer Care in the
event of a fault with your appliance and to register your appliance for
guarantee purposes.
4
Appliance Model
Serial Number
EU Declarations of Conformity:
This oven has been designed, constructed and marketed in
compliance with safety requirements of EU Directive 2014/35/EU (Low
voltage) and requirements of EU Directive 2014/30/EU.
This appliance has been manufactured to the strictest standards and
complies with all applicable legislation, including Electrical safety (LVD)
and Electromagnetic interference compatibility (EMC). Parts intended
to come into contact with food conform to 1935/2004/EC.
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE
PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2012/19/EU.
At the end of its working life, the product must not be disposed
of as urban waste. It must be taken to a special local authority
dierentiated waste collection centre or to a dealer providing this
service.
Disposing of a household appliance separately avoids possible
negative consequences for the environment and health deriving from
inappropriate disposal and enables the constituent materials to be
recovered to obtain significant savings in energy and resources. As a
reminder of the need to dispose of household appliances separately,
the product is marked with a crossed-out wheeled dustbin.
5
Important
• Read the user instructions carefully before using the oven
for the first time.
• Follow the instructions for first use of the oven.
•Clean the oven regularly.
•Remove spills as soon as they occur.
•Always use oven gloves when removing shelves and trays
from the ovens.
•Do not allow children near the oven when in use.
•Do not allow fat or oils to build up on the oven shelves, grill
pan or oven base.
•Do not place any cooking utensils or plates directly on the
oven base.
•Always grill with the oven door closed.
•Do not grill food containing fat without using the grill pan
grid.
•Do not cover the grill pan grid, the oven walls or the base
with aluminium foil.
•Do not use the oven tray for roasting.
•Do not perform maintenance or cleaning of the oven
without first switching o the electricity supply. If the oven
has recently been used, allow to cool.
•Do not place hot enamel parts in water. Leave them to
cool first.
•Do not allow vinegar, coee, milk, saltwater, lemon or
tomato juice to remain in contact with enamel parts.
•Do not use abrasive cleaners or powders that will scratch
the surface of the enamel.
•Do not attempt to repair the internal workings of your oven.
6
• Do not dismantle any parts without disconnecting the oven
from the mains power supply.
•Do not use the appliance if any part is broken (e.g. door
glass). Disconnect it from the mains power supply and
contact CDA Customer Care.
•The cooling fan may run even long after the oven has
finished cooking.
•During use the appliance becomes very hot; do not touch
the heating elements inside the oven or the interior.
•Do not allow children near the oven when in use, nor to play
with it.
•This appliance is not intended for use by persons (including
children over the age of 8) with reduced physical, sensory
or mental capabilities, or lack of experience or knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for
their safety.
•Children may not perform cleaning and maintenance
unsupervised.
•Do not harsh abrasive cleaners or sharp metal scrapers to
clean the oven door glass since they can scratch the
surface, which may result in shattering of the glass.
•Abrasive detergents and steam cleaning equipment should
not be used for cleaning.
•The oven can require increased ventilation on pyrolytic
programmes. This can be achieved either from an open
window or the use of an extractor.
•Before any pyrolytic programme, remove all shelves, trays
and other accessories from the oven and clean up any
7
major spills to avoid the risk of fire or excessive smoke.
•Do not hang towels or cloths on the oven handle at any
time.
•Ensure that the oven is cool and power to the appliance
has been turned o before carrying out any cleaning or
maintenance including door removal.
•Always wear adequate PPE (Personal Protective Equipment)
when carrying out any handling, maintenance or cleaning.
8
First use of the oven
First use
•The metal casing of this appliance has been coated with a
preservative to protect it during transport and storage. This should
be removed during installation by using a non-abrasive stainless
steel cleaner. Always follow the instructions given with the cleaner
being used.
•Before using the oven for the first time we recommend that you
clean the oven with soapy water, rinse carefully. Set the current
time on the programmer as per page 14. Heat on each of the
below programmes at maximum temperature for the specified time.
A slightly unpleasant smell may be produced, caused by grease
remaining on the oven elements from the production process.
15 minutes full grill 60 minutes fan oven
60 minutes conventional oven
Please note:
•This oven has been fitted with a cooling fan to achieve maximum
eciency and to maintain low surface temperatures. The cooling fan
will switch on automatically when the oven switches on. It is normal
for the cooling fan to run for an hour or more after use, depending
on the duration, temperature and type of cooking programme used.
IMPORTANT - Always operate within the temperature ranges
stated for each function on pages 9 - 13.
9
Control panel - SK420
Control panel - SK520
Functions Auxiliary functions button
SK420
Cooking time Timer
End of cooking time
Time/Temperature
display
Time/Temperature
adjustment
ECO
Functions Auxiliary functions button
SK520
Time/Temperature
display
Time/Temperature
adjustment
ECO
Cooking time Timer
End of cooking time
Fig. 1
Fig. 2
10
Functions
Defrost - Default 60°C
Using the fan and mild heat, this oven function circulates
the air around the oven cavity, speeding up the natural
defrost process. The temperature can be set between
20°C and 60°C in 1°C increments. The temperature can
be adjusted at any time by using the “+” or “-” keys.
Full Grill - Default 220°C
This function radiates the heat from the grill element
and the top element. This fully temperature variable
grill is ideal for grilling a family meal. The temperature
can be set between 50°C and 250°C in 5°C increments.
The temperature can be adjusted at any time by using
the “+” or “-” keys.
Fanned Grill - Default 210°C
This function uses the fan to circulate the heat from the
grill element around the food. The temperature can be
set between 50°C and 250°C in 5°C increments. The
temperature can be adjusted at any time by using the
“+” or “-” keys.
Half Grill - Default 180°C
This grill function is the same as the full grill, but only
uses the centre of the element so is ideal for grilling
a small amount of food. The temperature can be set
between 50°C and 250°C in 5°C increments. The
temperature can be adjusted at any time by using the
