Casio QV-4000 Manuel utilisateur

PLAYBACK

E-109

PLAYBACK

You can use the camera’s built in monitor screen to play

back recorded images.

Basic Playback Operation

Use the following procedure to scroll through recorded im-

ages stored in the camera’s memory.

Align the power/function switch with .

: PLAY mode for playing back images

Rock the control button to the left or right, or

rotate the selector dial to scroll through im-

ages on the monitor screen.

NOTES

•Keeping the control button pressed toward the left or

right scrolls through images at high speed.

•In order to allow for faster playback image scrolling,

the image that initially appears on the monitor screen

is a preview image, which is of somewhat lower quality

than the actual display image. The actual display im-

age appears about two seconds after the preview im-

age. Note that a fully detailed actual display image

may not be available in the case of some images cop-

ied from certain digital camera models.

If you want to do this:

Scroll forward

Scroll backward

Do this:

Rock the control button to the right.

Rock the control button to the left.

PLAYBACK

E-110

Playing a Movie

Use the following procedure to play back a movie recorded

in the Movie Mode.

Align the power/function switch with .

Rock the control button to the left or right, or

rotate the selector dial to scroll through the im-

ages on the monitor screen until the movie you

want to play is displayed.

Click the control button to start movie play-

back.

•The following describes operations that are available

during movie playback.

Movie

Mode icon

If you want to do this:

Toggle the movie between

full screen and quarter

screen view

Playback forward

Playback in reverse

Pause playback

Skip to the next frame while

playback is paused

Skip to the previous frame

while playback is paused

Exit movie playback

Do this:

Press DISP.

Rock the control button to

the right.

Rock the control button to

the left.

Click the control button.

Rock the control button to

the right.

Rock the control button to

the left.

Press MENU.

PLAYBACK

E-111

Playing a Panorama

Use the following procedure to play back a panorama re-

corded in the Panorama Mode.

Align the power/function switch with .

Rock the control button to the left or right, or

rotate the selector dial to scroll through the

images on the monitor screen until the pan-

orama you want to play is displayed.

Click the control button to start panorama

playback.

•The following describes operations that are available

during panorama playback.

Panorama

Mode icon

If you want to do this:

Toggle the panorama

between full screen and

compressed view

Scroll forward

Scroll backword

Pause playback

Skip to the next image while

playback is paused

Skip to the previous image

while playback is paused

Exit panorama playback

Do this:

Press DISP.

Rock the control button to

the right.

Rock the control button to

the left.

Click the control button.

Rock the control button to

the right.

Rock the control button to

the left.

Press MENU.

PLAYBACK

E-112

Enlarging the Playback Image

Use the following procedure to enlarge the playback image

on the screen. You can enlarge the image up to 3.2 times its

normal size.

Align the power/function switch with .

Rock the control button to the left or right, or

rotate the selector dial to display the image

you want to enlarge.

Push the zoom controller upwards towards

(telephoto) to zoom in on the imge.

•Push the zoom controller downwards towards

(wide-angle) to zoom back out.

•The following describes operations that are available

while an enlarged image is on the playback screen.

IMPORTANT!

•You cannot enlarge movie or panorama images.

NOTE

•Pushing the zoom controller downwards towards

(wide-angle) while a normal size (1X) image is on

the display switches to the 9-image view.

If you want to do this:

Shift the view right

Shift the view left

Shift the view upwards

Shift the view downwards

Exit the enlargement screen

Do this:

Rock the control button to

the right.

Rock the control button to

the left.

Rock the control button up.

Rock the control button down.

Press any button besides

the control button.

PLAYBACK

E-113

Displaying the 9-image View

The following procedure displays nine images on the monitor

screen at the same time.

Align the power/function switch with .

Push the zoom controller downwards towards

(wide-angle) .

•This displays the 9-image view, starting with the last

image you recorded.

Rock the control button to the left or right to

scroll through images.

26 27

123

456

789

10 11 12

13 14 15

16 17 18

19 20 21

22 23 24

•The following describes operations that are available

while the 9-image view is on the monitor screen.

If you want to do this:

Scroll forward

Scroll backward

Display the selection pointer

(See following section. )

Exit the 9-image view

Do this:

Rock the control button to

the right.

Rock the control button to

the left.

Press DISP.

Press any button besides

the control button or DISP.

PLAYBACK

E-114

Selecting a Specific Image in the 9-image

View

Display the 9-image view.

Press DISP.

•This causes a pointer to appear in the upper left cor-

ner of the monitor screen.

Rock the control button left, right, up, or down

to move the pointer to the image you want to

select, and then click the control button.

•This displays the single-image view of the selected

image.

PLAYBACK

E-115

Displaying the Histogram and

Other Image Information

The camera saves the histogram and other image informa-

tion along with the image itself. Use the following procedure

to view this other information.

Align the power/function switch with .

Press DISP to display the histogram and other

image information.

Histogram

Shutter

Speed

Light

Metering

Drive mode

Exposure

mode

Flash

White

balance

File size

Aperture

Use the histogram to check exposure when

recording.

• Exposure conditions indicated by the

histogram may not be accurate when

using the flash, when using multi-pattern

metering, or under certain other

conditions.

:Full Auto Mode

:Best Shot Mode

:Program AE Mode

:Aperture Priority AE Mode

:Shutter Speed Priority AE Mode

:Manual Mode

:1-Image Mode

:Continuous Shutter Mode

:AEB (Auto Exposure Bracketing) Mode

:Movie Mode

:Panorama Mode

:Multi-pattern metering

:Center-weighted metering

:Spot metering

:Flash on

:Flash off

1Histogram

Exposure mode

3Drive mode

4Light Metering

5Flash

6Aperture

7Shutter Speed

PLAYBACK

E-116

• Except for the histogram, “-----” is shown in place of

any item for which information is uncertain or other-

wise unavailable.

Rock the control button to the left or right, or

rotate the selector dial to scroll through im-

ages on the monitor screen.

• It may take some time for the image data to appear

after you select an image.

After you are finished, press DISP to clear dis-

play information.

8White balance

9File size

None:Auto

:Daylight

:Shade

:Tungsten

:Fluorescent

:Manual

IMPORTANT!

• The histogram does not appear during movie play-

back (page E-110).

• In the case of a panorama image (page E-111), the

histogram is displayed for the first image of the pan-

orama only.

PLAYBACK

E-117

IMPORTANT!

•Auto Power Off (page E-35) is disabled whenever

Slide Show is being used. This means you should not

leave Slide Show running when using batteries to

power the camera. Doing so can rundown batteries.

Be sure to stop Slide Show and turn off the camera

after you are finished.

•Note that all buttons are disabled while an image

change is in progress. Wait until an image is stopped

on the monitor screen before performing a button op-

eration, or hold down the button until the image stops.

•Images copied from another digital camera or a com-

puter may take longer time to appear than the Slide

Show interval time you select.

Using the Slide Show Feature

Slide Show automatically plays back images in sequence at

a fixed interval.

Align the power/function switch with .

Press MENU.

Select “Slide Show”and then click the control

button to apply it.

•This starts the slide show.

•Pressing MENU at this point displays a screen for set-

ting the interval between image changes within the

range of five to 30 seconds.

To stop Slide Show, press any button besides

MENU.

PLAYBACK

E-118

Resizing an Image

You can use the following procedure to change an image to

VGA size (640 x 480 pixels).

•VGA is the optimum image size for attachment to e-mail

messages or incorporation into Web pages.

Align the power/function switch with .

Rock the control button to the left or right, or

rotate the selector dial to display the image

you want to resize.

Press MENU.

Select “Resize”and then rock the control but-

ton to the right.

Select “Yes”and then click the control button.

•Select “No”to exit the procedure without resizing the

image.

IMPORTANT!

•The resized version of the image is saved as a new

file.

•The original, pre-resized image is also retained in

memory.

•2256 x 1504 (3:2) size images are resized for 640 x

427 pixels.

•Images smaller than 640 x 480 pixels cannot be

resized.

•

MovieMode,PanoramaMode,andTIFF(uncompressed)

images cannot be resized.

•Resizing of an image cannot proceed if the message

“MEMORY FULL Delete unneeded images”appears.

Autres manuels pour QV-4000

Table des matières

Autres manuels Casio Appareil photo numérique

Casio

Casio QV-10C Instructions d'installation et d'entretien

Casio

Casio EXILIM EX-ZR100 Manuel utilisateur

Casio

Casio Exilim EX-Z10 Manuel utilisateur

Casio

Casio EX-100F Manuel utilisateur

Casio

Casio EX-FR10 Manuel utilisateur

Casio

Casio QV-70C Guide de dépannage

Casio

Casio EX-ZR2000 Manuel utilisateur

Casio

Casio EX-S3 - 2 Manuel utilisateur

Casio

Casio EX-Z150 - EXILIM ZOOM Digital Camera Manuel utilisateur

Casio

Casio QV-R80 Manuel utilisateur

Casio

Casio EX-S1 - EXILIM Digital Camera Manuel utilisateur

Casio

Casio EX-Z1080 - EXILIM Digital Camera Manuel utilisateur

Casio

Casio EX Z55 - EXILIM Digital Camera Manuel utilisateur

Casio

Casio EX-F1 - EXILIM Pro Digital Camera Manuel utilisateur

Casio

Casio EXILIM EX-ZS150 Manuel utilisateur

Casio

Casio Exilim EX-ZS6 / EX-Z28 Manuel utilisateur

Casio

Casio Exilim EX-Z3000 Manuel utilisateur

Casio

Casio Exilim EX-Z50 Manuel utilisateur

Casio

Casio EXILM EX-Z70 Manuel utilisateur

Casio

Casio EX-Z4 - EXILIM Digital Camera Manuel de l'opérateur

Casio

Casio EX-TR600 Manuel utilisateur

Casio

Casio QV-770 Manuel utilisateur

Casio

Casio EXILIM K860PCM1DMX Manuel utilisateur

Casio

Casio Exilim EX-FC200S Manuel utilisateur

Manuels Appareil photo numérique populaires d'autres marques

Mercury

Mercury 350K Manuel utilisateur

Pentax

Pentax Optio LS 465 Manuel utilisateur

Sanyo

Sanyo VPC-S1085 Manuel utilisateur

GE SMART A1255 Manuel utilisateur

Point Grey

Point Grey Gazelle Manuel utilisateur

Nikon

Nikon COOLPIX A Manuel utilisateur

Pentax

Pentax P-5 Manuel utilisateur

BlazeVideo

BlazeVideo A280 Manuel utilisateur

Sony

Sony MCA-20 Manuel utilisateur

Sony

Sony Alpha DSLR-A290 Manuel utilisateur

ATIK Cameras

ATIK Cameras One Manuel utilisateur

CohuHD Costar

CohuHD Costar 3930 Series Manuel utilisateur

Leica

Leica M10-R Manuel utilisateur

FujiFilm

FujiFilm FinePix A700 Manuel utilisateur

Lorex

Lorex LNZ81P25 Series Manuel utilisateur

GE J1470S Manuel utilisateur

Sony

Sony A6700 Guide de l'utilisateur

Canon

Canon EOS ELAN7 Manuel utilisateur
