PLAYBACK

Use [왘] (forward) or [왗] (back) to scroll

through files on the monitor screen.

NOTES

•Holding down [왗] or [왘] scrolls images at high

speed.

•Note that the images produced on the monitor

screen of this camera are simplified versions of the

actual image stored in memory.

You can use the camera’s built-in monitor screen to view

images after you record them.

Basic Playback Operation

Use the following procedure to scroll through files stored in

the camera’s memory.

Press the power

button to turn on the

camera.

•This causes an image

or a message to appear

on the monitor screen.

Align the mode

selector with “PLAY”.

•This enters the PLAY

mode.

Power button

RECPLAY

Mode selector

ON/OFF

PLAYBACK

RECPLAY

DISP

REC

PLAY

DISP

Flipping the Display

The following procedure flips the image 180 degrees. This

comes in handy when you want to show someone standing

in front of you an image on the monitor screen.

In the PLAY mode, use [왗] and [왘] to scroll

through images on the monitor screen and

display the one you want.

Press the shutter release button and [SET] at

the same time.

•This flips the image 180 degrees. The histogram or

any other display information you had displayed is

cleared automatically whenever you flip the image.

•While an image is flipped, you can use [왗] and [왘] to

scroll to another image, if you want.

To return the image to its normal orientation,

press any button other than [왖], [왔], [왗], or

[왘].

IMPORTANT!

•Note that you cannot play a movie on the monitor

screen while a flipped image is displayed.

•You cannot use the above procedure to flip an image

while a zoomed image, or calendar screen is on the

display, or while a movie is playing.

[SET]

Shutter release

button

PLAYBACK

To scroll the image

on the display, press

[SET] and then press

[왖], [왔], [왗], or [왘].

•To display the indicator

for further zooming,

press [SET] again.

Press [MENU] to return the image to its

original size.

IMPORTANT!

•You cannot enlarge a movie image.

•Depending on the original size of the recorded

image, you may not be able to zoom a display image

the full four times its normal size.

Zooming the Display Image

Perform the following procedure to zoom the image

currently on the monitor screen up to four times its normal

size.

In the PLAY mode, use [왗] and [왘] to display

the image you want.

Press [왖] ( ) to

enlarge the image.

•This displays an

indicator that shows the

current zoom factor.

Current zoom factor

PLAYBACK

Resizing an Image

You can use the following procedure to change a snapshot

image to either SXGA size (1280 x 960 pixels) or VGA size

(640 x 480 pixels).

•VGA is the optimum image size for attachment to e-mail

messages or incorporation into Web pages.

In the PLAY mode, press [MENU].

Select the “PLAY”

tab, select “Resize”,

and then press [왘].

Use [왗] and [왘] to scroll through images and

display the one you want to resize.

IMPORTANT!

•Resizing an image creates a new file that contains

the image in the size you select. The file with the

original image also remains in memory.

•Images smaller than 640 x 480 pixels cannot be

resized.

•Note that you can resize snapshots recorded with

this camera only.

•If the message “The function is not supported for this

file.”appears, it means that the current image cannot

be resized.

•The resize operation cannot be performed if there is

not enough memory to store the resized image.

Use [왖] and [왔] to select the setting you

want, and then press [SET].

To do this:

Resize to 1280 x 960 pixels (SXGA)

Resize to 640 x 480 pixels (VGA)

Cancel the resizing operation

Select this:

1280 x 960

640 x 480

Cancel

PLAYBACK

Cropping an Image

Use the following procedure when you want to crop a

portion of an enlarged image and use the remaining part of

the image as an e-mail attachment, Web page image, etc.

In the PLAY mode, use [왗] and [왘] to scroll

through images and display the one you want

to crop.

Press [MENU].

Select the “PLAY”

tab, select

“Trimming”, and then

press [왘].

•This causes a cropping

boundary to appear.

Use [왖] and [왔] to make the cropping

boundary smaller or larger.

•The size of the cropping boundary depends on the

size of the image on the display.

When the cropping

boundary is the size

you want, press [DISP]

to lock it.

•After pressing [DISP] to

lock the size of the

cropping boundary, you

can press [DISP] again to

unlock it. After that, you

can repeat steps 4 and 5

to change the cropping

boundary size.

Use [왖], [왔], [왗], and [왘] to move the

cropping boundary up, down, left, or right

until the area of the image you want to extract

is within the boundary.

Press [SET] to extract the part of the image

enclosed in the cropping boundary.

•If you want to cancel the procedure at any point,

press [MENU].

PLAYBACK

Playing a Movie

Use the following procedure to play back a movie that was

recorded in the movie mode.

In the PLAY mode,

press [왗] and [왘] to

scroll through images

until the movie you

want to play is

displayed.

Press [SET].

•This start playback of the movie.

Movie icon

IMPORTANT!

•Cropping an image creates a new file that contains

the cropped image. The file with the original image

also remains in memory.

•A Movie mode image cannot be cropped.

•An image recorded using another camera model

cannot be cropped.

•If the message “The function is not supported for this

file.”appears, it means that the current image cannot

be cropped.

•The cropping operation cannot be performed if there

is not enough memory to store the cropped image.

PLAYBACK

IMPORTANT!

•You cannot repeat play a movie. To play a movie

more than once, repeat the steps of the above

procedure.

•Note that this camera cannot play back a movie’s

audio. You need to transfer the movie file to a

computer (page 112) to hear the audio.

•You can perform the following operations while a

movie is playing.

To do this:

Fast forward or fast reverse

the movie

Pause and unpause movie

playback

Skip forward or back one

frame while paused

Cancel playback

Do this:

Hold down [왗] or

[왘].

Press [SET].

Press [왗] or [왘].

Press [MENU].

Displaying the Calendar Screen

Use the following procedure to display a 1-month calendar.

While the calendar is on the display, you can select a date,

which displays the first image recorded on that date. This

helps to make it easy to find the images you want.

In the PLAY mode, press [MENU].

Select the “PLAY”tab, select “Calendar”, and

then press [왘].

Use [왖], [왔], [왗], and

[왘] to move the date

selection cursor.

•Use the procedure

under “Changing the

Date Format”on page

102 to specify the date

format.

•The image displayed on

the calendar for each

date is the first image

that was recorded on

that date.

Year/Month

Date selection cursor

PLAYBACK

•Pressing [왖] while the date selection cursor is

located anywhere in the top line of the calendar

causes the previous month to appear.

•Pressing [왔] while the date selection cursor is

located anywhere in the bottom line of the calendar

causes the next month to appear.

•To exit the calendar screen, press [MENU].

•appears in place of the image when the date

contains data that cannot be displayed by this

camera.

To view the large version of a date’s image,

move the date selection cursor to the date

and then press [SET].

•This displays the first image that was recorded on

the selected date.

Playing a Slide Show

Slide Show automatically plays back images in sequence

at a fixed interval.

In the PLAY mode, press [MENU].

Select the “PLAY”tab, select “Slideshow”,

and then press [왘].

PLAYBACK

Use [왖] and [왔] to select “Start”, and then

press [SET].

•This starts the slide show.

To stop Slide Show, press any button.

•The slideshow will also stop automatically after the

amount of time you specified for “Time”elapses.

Configure the slideshow settings.

•See the pages indicated below for more information.

For information about

configuring this setting:

Images

Time

Interval

Go here:

“To specify the slideshow

images”on page 79

“To specify the slideshow

time”on page 80

“To set the slideshow

interval”on page 80

IMPORTANT!

•Note that all buttons are disabled while an image

change is in progress. Wait until an image is stopped

on the monitor screen before performing a button

operation, or hold down the button until the image

stops.

•Images copied from another digital camera or a

computer may take longer time to appear than the

slideshow interval time you specify.

PLAYBACK

To specify the slideshow images

Use [왖] and [왔] to select “Images”, and then

press [왘].

Use [왖] and [왔] to select the setting you

want, and then press [SET].

Use [왖] and [왔] to select “Start”, and then

press [SET].

•This starts the slideshow.

To do this:

Include all images in file memory in the

slideshow

Display a single image

Include all images in the FAVORITE

folder (page 93) in the slideshow

Select this setting:

All images

One Image

Favorites

■Selecting a Particular Image for a Slideshow

When you select “One image”as the slideshow type, the

slide show displays only one image, without changing it.

Use this setting when you want a particular image to

remain on the display while the camera is on the USB

cradle (Photo Stand feature). Perform the following steps to

specify which image you want displayed.

Select “One image”, and then press [왘].

Use [왗] and [왘] to scroll through the images

until the one you want to use is on the

monitor screen.

Press [SET] to

selection and return

to the menu screen.

•Pressing [MENU]

instead of [SET] returns

to the menu screen

without registering the

setting.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Casio Appareil photo numérique

Casio

Casio EX-M20 - 2 Manuel utilisateur

Casio

Casio EX-Z1080 - EXILIM Digital Camera Manuel utilisateur

Casio

Casio EXILIM EXS3DBA Manuel utilisateur

Casio

Casio EX-Z1080 - EXILIM Digital Camera Manuel utilisateur

Casio

Casio QV-5000SX Manuel utilisateur

Casio

Casio EX-G1 - Exilim 12.1 MP Endurance Digital... Manuel utilisateur

Casio

Casio Exilim EX-Z57 Manuel utilisateur

Casio

Casio EXILIM EX-Z370 Manuel utilisateur

Casio

Casio QV-4000 Manuel utilisateur

Casio

Casio EX-V8 - EXILIM Hi-Zoom Digital Camera Manuel utilisateur

Casio

Casio EX-Z21 - EXILIM Digital Camera Manuel utilisateur

Casio

Casio Exilim EX-S8 Manuel utilisateur

Casio

Casio QV-70C Guide de dépannage

Casio

Casio Exilim EX-S100 Guide de dépannage

Casio

Casio QV-R40 Guide de dépannage

Casio

Casio Exilim EX-ZR1000 Manuel utilisateur

Casio

Casio Exilim EX-Z300 Manuel utilisateur

Casio

Casio QV-7000SX Guide de dépannage

Casio

Casio EX-TR600 Manuel utilisateur

Casio

Casio QV-700 Manuel utilisateur

Casio

Casio EXILIM EX-ZR310 Mode d’emploi

Casio

Casio QV-4000 Guide de dépannage

Casio

Casio EX-Z16BK Manuel utilisateur

Casio

Casio EX-Z9 - EXILIM ZOOM Digital Camera Manuel utilisateur

Manuels Appareil photo numérique populaires d'autres marques

Mercury

Mercury 350K Manuel utilisateur

Pentax

Pentax Optio LS 465 Manuel utilisateur

Sanyo

Sanyo VPC-S1085 Manuel utilisateur

GE SMART A1255 Manuel utilisateur

Point Grey

Point Grey Gazelle Manuel utilisateur

Nikon

Nikon COOLPIX A Manuel utilisateur

Pentax

Pentax P-5 Manuel utilisateur

BlazeVideo

BlazeVideo A280 Manuel utilisateur

Sony

Sony MCA-20 Manuel utilisateur

Sony

Sony Alpha DSLR-A290 Manuel utilisateur

ATIK Cameras

ATIK Cameras One Manuel utilisateur

CohuHD Costar

CohuHD Costar 3930 Series Manuel utilisateur

Leica

Leica M10-R Manuel utilisateur

FujiFilm

FujiFilm FinePix A700 Manuel utilisateur

Lorex

Lorex LNZ81P25 Series Manuel utilisateur

GE J1470S Manuel utilisateur

Sony

Sony A6700 Guide de l'utilisateur

Canon

Canon EOS ELAN7 Manuel utilisateur
