PLAYBACK

Use [왘] (forward) or [왗] (back) to scroll

through files on the monitor screen.

NOTES

• Holding down [왗] or [왘] scrolls images at high

speed.

• In order to allow for faster playback image scrolling,

the image that initially appears on the monitor screen

is a preview image, which is of somewhat lower

quality than the actual display image. The actual

display image appears a short while after the preview

image. This does not apply to images copied from

another digital camera.

You can use the camera’s built-in monitor screen to view

images after you record them.

Basic Playback Operation

Use the following procedure to scroll through files stored in

the camera’s memory.

Press the power button

to turn on the camera.

• This causes an image or a

message to appear on the

monitor screen.

Align the mode selector

with “ ” (PLAY).

• This enters the PLAY

mode.

Power button

Mode selector

ON/OFF

PLAYBACK

Playing an Audio Snapshot (EX-M20U Only)

Perform the steps below to display an audio snapshot

(indicated by a indicator) and play its audio.

In the PLAY mode, use [왗] and [왘] until the

image you want is displayed.

Press [SET].

• This plays back the

audio that accompanies

the displayed image.

• You can perform the

following operations

while audio is playing.

IMPORTANT!

• Audio volume can be adjusted only when playback is

being performed or is paused.

• When you have the LCD remote controller connected

to the camera, audio is output through the stereo

headphones (page 155) instead of the camera’s

speaker. Output through the headphones is

monaural.

• The volume of audio recorded with the camera

cannot be adjusted using the LCD remote controller.

Use the camera’s controller to adjust volume level in

this case.

To do this:

Fast forward or fast reverse

the audio

Pause and unpause audio

playback

Adjust audio volume

Cancel playback

Do this:

Hod down [왗] or [왘].

Press [SET].

Press [왖] or [왔].

Press [MENU].

PLAYBACK

DISP

Flipping the Display

The following procedure flips the image 180 degrees. This

comes in handy when you want to show someone standing

in front of you an image on the monitor screen.

In the PLAY mode, use [왗] and [왘] to scroll

through images on the monitor screen and

display the one you want.

Press the shutter release button and [SET] at

the same time.

• This flips the image 180 degrees. The histogram or

any other display information you had displayed is

cleared automatically whenever you flip the image.

• While an image is flipped, you can use [왗] and [왘] to

scroll to another image, if you want.

To return the image to its normal orientation,

press any button other than [왖], [왔], [왗], or

[왘].

IMPORTANT!

• Note that you cannot play an audio snapshot (EX-

M20U only), or a voice recording file (EX-M20U only)

on the monitor screen while a flipped image is

displayed.

• You cannot use the above procedure to flip an image

while a zoomed image, calendar screen image, an

audio snapshot (EX-M20U only), or a voice recording

file image (EX-M20U only) is on the display.

[SET]

Shutter release

button

PLAYBACK

To scroll the image

on the display, press

[SET], and then press

[왖], [왔], [왗], or [왘].

• To display the indicator

for further zooming,

press [SET] again.

Press [MENU] to return the image to its

original size.

IMPORTANT!

• Depending on the original size of the recorded

image, you may not be able to zoom a display image

the full four times its normal size.

Zooming the Display Image

Perform the following procedure to zoom the image

currently on the monitor screen up to four times its normal

size.

In the PLAY mode, use [왗] and [왘] to display

the image you want.

Press [왖] ( ) to

enlarge the image.

• This displays an

indicator that shows the

current zoom factor.

Current zoom factor

PLAYBACK

Resizing an Image

You can use the following procedure to change a snapshot

image to either SXGA size (1280 x 960 pixels) or VGA size

(640 x 480 pixels).

• VGA is the optimum image size for attachment to e-mail

messages or incorporation into Web pages.

In the PLAY mode, press [MENU].

Select the “PLAY”

tab, select “Resize”,

and then press [왘].

Use [왗] and [왘] to scroll through images and

display the one you want to resize.

IMPORTANT!

• Resizing an image creates a new file that contains

the image in the size you select. The file with the

original image also remains in memory.

• Images smaller than 640 x 480 pixels cannot be

resized.

• An image recorded using the 1600 x 1072 (3:2) pixel

size cannot be resized.

• Note that you can resize snapshots recorded with

this camera only.

• If the message “This function is not supported for this

file.” appears, it means that the current image cannot

be resized.

• The resize operation cannot be performed if there is

not enough memory to store the resized image.

Use [왖] and [왔] to select the setting you

want, and then press [SET].

To do this:

Resize to 1280 x 960 pixels (SXGA)

Resize to 640 x 480 pixels (VGA)

Cancel the resizing operation

Select this:

1280 x 960

640 x 480

Cancel

PLAYBACK

Cropping an Image

Use the following procedure when you want to crop a

portion of an enlarged image and use the remaining part of

the image as an e-mail attachment, Web page image, etc.

In the PLAY mode, use [왗] and [왘] to scroll

through images and display the one you want

to crop.

Press [MENU].

Select the “PLAY”

tab, select

“Trimming”, and then

press [왘].

• This causes a cropping

boundary to appear.

Use [왖] and [왔] to make the cropping

boundary smaller or larger.

• The size of the cropping boundary depends on the

size of the image on the display.

When the cropping

boundary is the size

you want, press [DISP]

to lock it.

• After pressing [DISP] to

lock the size of the

cropping boundary, you

can press [DISP] again to

unlock it. After that, you

can repeat steps 4 and 5

to change the cropping

boundary size.

Use [왖], [왔], [왗], and [왘] to move the

cropping boundary up, down, left, or right

until the area of the image you want to extract

is within the boundary.

Press [SET] to extract the part of the image

enclosed in the cropping boundary.

• If you want to cancel the procedure at any point,

press [MENU].

PLAYBACK

IMPORTANT!

• Cropping an image creates a new file that contains

the cropped image. The file with the original image

also remains in memory.

• An image recorded using the 1600 x 1072 (3:2) pixel

size cannot be cropped.

• Voice recording file images (EX-M20U only) cannot

be cropped.

• An image recorded using another camera model

cannot be cropped.

• If the message “This function is not supported for this

file.” appears, it means that the current image cannot

be cropped.

• The cropping operation cannot be performed if there

is not enough memory to store the cropped image.

Displaying the Calendar Screen

Use the following procedure to display a 1-month calendar.

While the calendar is on the display, you can select a date,

which displays the first image recorded on that date. This

helps to make it easy to find the images you want.

In the PLAY mode, press [MENU].

Select the “PLAY” tab, select “Calendar”, and

then press [왘].

Use [왖], [왔], [왗], and

[왘] to move the date

selection cursor.

• Use the procedure

under “Changing the

Date Format” on page

116 to specify the date

format.

• The image displayed on

the calendar for each

date is the first image

that was recorded on

that date.

Month/Year

Date selection cursor

PLAYBACK

• Pressing [왖] while the date selection cursor is

located anywhere in the top line of the calendar

causes the previous month to appear.

• Pressing [왔] while the date selection cursor is

located anywhere in the bottom line of the calendar

causes the next month to appear.

• To exit the calendar screen, press [MENU].

•is displayed in the calendar screen to indicate

voice recording file images (page 92, EX-M20U

only).

•appears in place of the image when the date

contains data that cannot be displayed by this

camera.

To view the large version of a date’s image,

move the date selection cursor to the date,

and then press [SET].

• This displays the first image that was recorded on

the selected date.

Playing a Slide Show

Slide Show automatically plays back images in sequence

at a fixed interval.

In the PLAY mode, press [MENU].

Select the “PLAY” tab, select “Slideshow”,

and then press [왘].

PLAYBACK

Use [왖] and [왔] to select “Start”, and then

press [SET].

• This starts the slide show.

To stop Slide Show, press [SET].

• The slideshow will also stop automatically after the

amount of time you specified for “Time” elapses.

Configure the slideshow settings.

• See the pages indicated below for more information.

For information about

configuring this setting:

Images

Time

Interval

Go here:

“To specify the slideshow

images” on page 85

“To specify the slideshow

time” on page 86

“To set the slideshow

interval” on page 86

IMPORTANT!

• Note that all buttons are disabled while an image

change is in progress. Wait until an image is stopped

on the monitor screen before performing a button

operation, or hold down the button until the image

stops.

• When the slideshow comes to an audio snapshot or

voice recording file, it plays the audio once and then

advances to the next file (EX-M20U only).

• While audio is playing, you can use [왖] and [왔] to

adjust the volume level (EX-M20U only).

• Images copied from another digital camera or a

computer may take longer time to appear than the

slideshow interval time you specify.

PLAYBACK

To specify the slideshow images

Use [왖] and [왔] to select “Images”, and then

press [왘].

Use [왖] and [왔] to select the setting you

want, and then press [SET].

Use [왖] and [왔] to select “Start”, and then

press [SET].

• This starts the slideshow.

• With the EX-M20U, the audio of audio snapshot and

voice recording files is also played back.

To do this:

Include all files in file memory in the

slideshow

Display a single file

Include all files in the FAVORITE

folder (page 137) in the slideshow

Select this setting:

All images

One Image

Favorites

■Selecting a Particular Image for a Slideshow

When you select “One image” as the slideshow type, the

slide show displays only one image, without changing it.

Use this setting when you want a particular image to

remain on the display while the camera is on the USB

cradle (Photo Stand feature).

Select “One image”, and then press [왘].

Use [왗] and [왘] to scroll through the images

until the one you want to use is on the

monitor screen.

Press [SET] to

selection and return

to the menu screen.

• Pressing [MENU]

instead of [SET] returns

to the menu screen

without registering the

setting.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Casio Appareil photo numérique

Casio

Casio EX-Z30/EX-Z40 Manuel utilisateur

Casio

Casio Exilim EX-Z850 Manuel utilisateur

Casio

Casio EX-S3 - 4 Manuel d'instructions et de sécurité

Casio

Casio EX-S1 - EXILIM Digital Camera Manuel utilisateur

Casio

Casio Exilim EX-Z4U Manuel d'instructions et de sécurité

Casio

Casio EX S12 - EXILIM CARD Digital Camera Manuel utilisateur

Casio

Casio Exilim EX-FH100 Manuel utilisateur

Casio

Casio K823PCM1DMX Manuel utilisateur

Casio

Casio ExilimEX-Z280 Manuel utilisateur

Casio

Casio Exilim EX-S600 Manuel utilisateur

Casio

Casio EX-Z550 - EXILIM Digital Camera Manuel utilisateur

Casio

Casio EXILIM EX-FC300S Manuel utilisateur

Casio

Casio EX-S3 - Exilim 3MP Digital Camera Manuel d'instructions et de sécurité

Casio

Casio EX Z77 - EXILIM ZOOM Digital Camera Manuel utilisateur

Casio

Casio EX-FR10 Manuel utilisateur

Casio

Casio EX-10 Manuel utilisateur

Casio

Casio QV-10A Guide de dépannage

Casio

Casio EX-ZS5SR Manuel utilisateur

Casio

Casio Exilim EX-ZR500 Manuel utilisateur

Casio

Casio GV-10 Manuel utilisateur

Casio

Casio EX-Z115 - EXILIM Digital Camera Manuel utilisateur

Casio

Casio EXILIM EX-Z88 Manuel utilisateur

Casio

Casio EXILIM K1190PCM1DMX Manuel utilisateur

Casio

Casio ex-zr50 Manuel utilisateur

Manuels Appareil photo numérique populaires d'autres marques

Mercury

Mercury 350K Manuel utilisateur

Pentax

Pentax Optio LS 465 Manuel utilisateur

Sanyo

Sanyo VPC-S1085 Manuel utilisateur

GE SMART A1255 Manuel utilisateur

Point Grey

Point Grey Gazelle Manuel utilisateur

Nikon

Nikon COOLPIX A Manuel utilisateur

Pentax

Pentax P-5 Manuel utilisateur

BlazeVideo

BlazeVideo A280 Manuel utilisateur

Sony

Sony MCA-20 Manuel utilisateur

Sony

Sony Alpha DSLR-A290 Manuel utilisateur

ATIK Cameras

ATIK Cameras One Manuel utilisateur

CohuHD Costar

CohuHD Costar 3930 Series Manuel utilisateur

Leica

Leica M10-R Manuel utilisateur

FujiFilm

FujiFilm FinePix A700 Manuel utilisateur

Lorex

Lorex LNZ81P25 Series Manuel utilisateur

GE J1470S Manuel utilisateur

Sony

Sony A6700 Guide de l'utilisateur

Canon

Canon EOS ELAN7 Manuel utilisateur
