PLAYBACK

You can use the camera’s built-in monitor screen to view

images after you record them.

Basic Playback Operation

Use the following procedure to scroll through files stored in

the camera’s memory.

Press [ ] (PLAY) to

turn on the camera.

• This causes an image

or a message to appear

on the monitor screen.

• This enters the PLAY

mode.

Use [왘] (forward) or [왗] (back) to scroll

through files on the monitor screen.

[ ]

NOTES

•Holding down [왗] or [왘] scrolls images at high

speed.

•In order to allow for faster playback image scrolling,

the image that initially appears on the monitor screen

is a preview image, which is of somewhat lower

quality than the actual display image. The actual

display image appears a short while after the preview

image. This does not apply to images copied from

another digital camera.

PLAYBACK

Zooming the Display Image

Perform the following procedure to zoom the image

currently on the monitor screen up to four times its normal

size.

In the PLAY mode, use [왗] and [왘] to display

the image you want.

Slide the zoom

controller towards

to enlarge the image.

•This displays an

indicator that shows the

current zoom factor.

•You can toggle between

the zoomed image and

normal image by

pressing [DISP].

Use [왖], [왔], [왗], and [왘] to shift the image

up, down, left, or right.

Press [MENU] to return the image to its

original size.

IMPORTANT!

•You cannot enlarge a movie image.

•Depending on the original size of the recorded

image, you may not be able to zoom a display image

the full four times its normal size.

Current zoom factor

PLAYBACK

Resizing an Image

You can use the following procedure to change a snapshot

image to either SXGA size (1280 x 960 pixels) or VGA size

(640 x 480 pixels).

•VGA is the optimum image size for attachment to e-mail

messages or incorporation into Web pages.

In the PLAY mode, press [MENU].

Select the “PLAY”

tab, select “Resize”,

and then press [왘].

Use [왗] and [왘] to scroll through images and

display the one you want to resize.

IMPORTANT!

•Resizing an image creates a new file that contains

the image in the size you select. The file with the

original image also remains in memory.

•Images smaller than 640 x 480 pixels cannot be

resized.

•Note that you can resize snapshots recorded with

this camera only.

•If the message “This function is not supported for this

file.”appears, it means that the current image cannot

be resized.

•The resize operation cannot be performed if there is

not enough memory to store the resized image.

•When you display a resized image on the camera’s

monitor screen, the date and time that the image was

resized appears on the screen. Note, however, that

the EXIF data*accompanying the resized image is

the data for the original (pre-resize) image.

*EXIF data is information about recording conditions

that is stored along with the image data. See page

154 for more information.

Use [왖] and [왔] to select the setting you

want, and then press [SET].

To do this:

Resize to 1280 x 960 pixels (SXGA)

Resize to 640 x 480 pixels (VGA)

Cancel the resizing operation

Select this:

1280 x 960

640 x 480

Cancel

PLAYBACK

Cropping an Image

Use the following procedure when you want to crop a

portion of an enlarged image and use the remaining part of

the image as an e-mail attachment, Web page image, etc.

In the PLAY mode, use [왗] and [왘] to scroll

through images and display the one you want

to crop.

Press [MENU].

Select the “PLAY”

tab, select

“Trimming”, and then

press [왘].

•This causes a cropping

boundary to appear.

Use the zoom controller to make the cropping

boundary larger or smaller.

•The size of the cropping boundary depends on the

size of the image on the display.

Use [왖], [왔], [왗], and [왘] to move the

cropping boundary up, down, left, or right

until the area of the image you want to extract

is within the boundary.

Press [SET] to extract the part of the image

enclosed in the cropping boundary.

•If you want to cancel the procedure at any point,

press [MENU].

IMPORTANT!

•Cropping an image creates a new file that contains

the cropped image. The file with the original image

also remains in memory.

•A Movie mode image cannot be cropped.

•An image recorded using another camera model

cannot be cropped.

•If the message “This function is not supported for this

file.”appears, it means that the current image cannot

be cropped.

•The cropping operation cannot be performed if there

is not enough memory to store the cropped image.

•When you display a trimmed image on the camera’s

monitor screen, the date and time that the image was

trimmed appears on the screen. Note, however, that

the EXIF data*accompanying the trimmed image is

the data for the original (pre-trim) image.

*EXIF data is information about recording conditions

that is stored along with the image data. See page

154 for more information.

PLAYBACK

Playing a Movie

Use the following procedure to play back a movie that was

recorded in the movie mode.

In the PLAY mode,

press [왗] and [왘] to

scroll through images

until the movie you

want to play is

displayed.

Press [SET].

•This starts playback of the movie.

IMPORTANT!

•You cannot repeat play a movie. To play a movie

more than once, repeat the steps of the above

procedure.

•You can perform the following operations while a

movie is playing.

To do this:

Fast forward or fast reverse

the movie

Pause and unpause movie

playback

Skip forward or back one

frame while paused

Cancel playback

Do this:

Hold down [왗] or

[왘].

Press [SET].

Press [왗] or [왘].

Press [MENU].

Movie icon

PLAYBACK

Displaying the 9-image View

The following procedure displays nine images on the

monitor screen at the same time.

In the PLAY mode, slide the zoom controller

towards ( ) briefly, and then release it.

•This displays the 9-image screen with the image that

was on the monitor screen in step 2 in the center,

with a selection boundary around it.

•Sliding the zoom controller twice towards ( )

displays the calendar screen.

•When there are nine or fewer images, they are

displayed in order with Image 1 in the upper left

corner, with the selection boundary around it.

Use [왖], [왔], [왗], and [왘] to move the

selection boundary to the image you want.

Pressing [왘] while the selection boundary is

in the right column or [왗] while it is in the left

column scrolls to the next full screen of nine

images.

Pressing any button besides [왖], [왔], [왗], or

[왘] displays the full-size version of the image

where the selection boundary is located.

2 3

17 18 19

20 1 2

345

678

91011

12 13 14

15 16 17

18 19 20

Example: When there are 20 images in memory, and

Image 1 is displayed first

PLAYBACK

Selecting a Specific Image in the 9-

image View

Display the 9-image view.

Use [왖], [왔], [왗], and

[왘] to move the

selection boundary

up, down, left, or right

until it is located at

the image you want to

view.

Pressing any button

besides [왖], [왔], [왗],

or [왘] displays the

selected image.

•This displays the full-

size version of the

image you selected.

Selection boundary

Displaying the Calendar Screen

Use the following procedure to display a 1-month calendar.

While the calendar is on the display, you can select a date,

which displays the first image recorded on that date. This

helps to make it easy to find the images you want.

In the PLAY mode, slide the zoom controller

twice towards ( ).

•You can also display the calendar screen (in the

PLAY mode) by pressing [MENU], selecting the

“PLAY”tab, selecting “Calendar”, and then pressing

[왘].

Use [왖], [왔], [왗], and

[왘] to move the date

selection cursor.

•Use the procedure

under “Changing the

Date Format”on page

124 to specify the date

format.

•The image displayed on

the calendar for each

date is the first image

that was recorded on

that date.

Month/Year

Date selection cursor

PLAYBACK

•Pressing [왖] while the date selection cursor is

located anywhere in the top line of the calendar

causes the previous month to appear.

•Pressing [왔] while the date selection cursor is

located anywhere in the bottom line of the calendar

causes the next month to appear.

•To exit the calendar screen, press [MENU] or slide the

zoom controller towards ( ) briefly, and then

release it.

•appears in place of the image when the date

contains data that cannot be displayed by this

camera.

To view the large version of a date’s image,

move the date selection cursor to the date,

and then press [SET].

•This displays the first image that was recorded on

the selected date.

Rotating the Display Image

Use the following procedure to rotate the image 90 degrees

and register the rotation information along with the image.

After you do this, the image is always displayed in its

rotated orientation.

In the PLAY mode, press [MENU].

Select the “PLAY” tab, select “Rotation”, and

then press [왘].

Use [왗] and [왘] to scroll through images until

the one you want to rotate is on the monitor

screen.

Select “Rotate”, and

then press [SET].

•This rotates the image

90 degrees to the right.

After you are finished configuring settings,

press the [MENU] button to exit the setting

screen.

100

PLAYBACK

IMPORTANT!

•You cannot rotate an image that is protected. To

rotate such an image, first unprotect it.

•You may not be able to rotate a digital image that

was recorded with another type of digital camera.

Using Image Roulette

Image Roulette cycles images like a slot machine on the

display, before stopping at one of them. When you start an

Image Roulette operation, images scroll randomly on the

screen. At first, images scroll at high speed. Then the

scrolling gradually slows down until a single image is

stopped on the screen. The image that finally appears is

random, and subject to no rules or system.

While the camera is turned off, hold down [왗]

as you press [ ] (PLAY) to turn it on.

•Keep [왗] held down until images appear on the

monitor screen.

•This starts the Image Roulette operation, scrolling

images on the display, finally stopping at one.

Press [왗] or [왘] to restart the Image Roulette

operation.

To turn off Image Roulette, press [ ](REC) to

enter the REC mode or press the power

button to turn off the camera.

101

PLAYBACK

IMPORTANT!

•Image Roulette does not play movie files.

•Image Roulette is disabled when there is only one

snapshot image available.

•Note that Image Roulette works only with images

recorded with this camera. Image Roulette may not

operate properly when other types of images are in

memory.

•If you do not start another Image Roulette operation

for about one minute after the final image appears,

the camera enters its normal PLAY mode.

Autres manuels pour QV-R40

Table des matières

Autres manuels Casio Appareil photo numérique

Casio

Casio EX-Z200RD - EXILIM ZOOM Digital Camera Manuel utilisateur

Casio

Casio ex-zr50 Manuel utilisateur

Casio

Casio Exilim EX-Z120 Manuel utilisateur

Casio

Casio Exilim EX-Z60 Guide de dépannage

Casio

Casio Exilim EX-FH100 Manuel utilisateur

Casio

Casio QV-3EX Guide de dépannage

Casio

Casio Exilim EX-Z3000 Manuel utilisateur

Casio

Casio EX-M1 - EXILIM Digital Camera Manuel de programmation

Casio

Casio Exilim EX-ZR1200 Manuel utilisateur

Casio

Casio QV-R40 Manuel utilisateur

Casio

Casio QV-770 Manuel utilisateur

Casio

Casio Exilim EX-Z280 Manuel utilisateur

Casio

Casio GV-20 Manuel utilisateur

Casio

Casio QV-4000 Manuel utilisateur

Casio

Casio Exilim EX-S880 Manuel utilisateur

Casio

Casio Exilim EX-Z4U Manuel d'instructions et de sécurité

Casio

Casio EX-Z22 - EXILIM Digital Camera Manuel utilisateur

Casio

Casio EX-H5BK Manuel utilisateur

Casio

Casio EXILIM Exilim EX Z 100 Manuel utilisateur

Casio

Casio EX-100F Manuel utilisateur

Casio

Casio QV-70 Manuel utilisateur

Casio

Casio EX-ZR5100 Manuel utilisateur

Casio

Casio Exilim EX-H10 Manuel utilisateur

Casio

Casio QV-3000Ir Manuel utilisateur

Manuels Appareil photo numérique populaires d'autres marques

Mercury

Mercury 350K Manuel utilisateur

Pentax

Pentax Optio LS 465 Manuel utilisateur

Sanyo

Sanyo VPC-S1085 Manuel utilisateur

GE SMART A1255 Manuel utilisateur

Point Grey

Point Grey Gazelle Manuel utilisateur

Nikon

Nikon COOLPIX A Manuel utilisateur

Pentax

Pentax P-5 Manuel utilisateur

BlazeVideo

BlazeVideo A280 Manuel utilisateur

Sony

Sony MCA-20 Manuel utilisateur

Sony

Sony Alpha DSLR-A290 Manuel utilisateur

ATIK Cameras

ATIK Cameras One Manuel utilisateur

CohuHD Costar

CohuHD Costar 3930 Series Manuel utilisateur

Leica

Leica M10-R Manuel utilisateur

FujiFilm

FujiFilm FinePix A700 Manuel utilisateur

Lorex

Lorex LNZ81P25 Series Manuel utilisateur

GE J1470S Manuel utilisateur

Sony

Sony A6700 Guide de l'utilisateur

Canon

Canon EOS ELAN7 Manuel utilisateur
