Caple C2220 Manuel utilisateur

Contact Caple on 0117 938 7420 or for spare parts www.caple.co.uk

Classic single oven

Instruction manual

C2220

Instruction manual C2220

Please keep this instruction manual for future reference

CONTENTS

Safety Warnings 3

Installation warnings 7

Environmental protection 10

Warranty 10

Installation 12

Oven dimensions 13

Electrical connection 14

Using your oven 15

Cooking guidelines 15

Oven functions 16

Touch control electronic timer 17

Telescopic runners (optional accessory) 20

Side racks 20

Care and maintenance 21

Replacing the oven lamps 22

Troubleshooting 23

Removing and reversing the oven door 24

Removing the glass panels 26

Technical ﬁche 27

Caple contact details 28

Instruction manual C2220

Please keep this instruction manual for future reference

SAFETY INSTRUCTIONS

Read these instructions carefully and completely

before using your appliance, keep it in a

convenient place for reference when necessary.

-This appliance can be used by children aged from 8 years

and above.

-Persons with reduced physical, sensory or mental

capabilities or lack of experience and knowledge

must be supervised and given appropriate instruction

concerning the use of the appliance in a safe way and

understand the hazards involved.

-Children shall not play with the appliance.

-Cleaning and user maintenance should not be carried

out by children without supervision.

-The appliance is not intended to be operated by means

of an external timer or separate remote control system.

Instruction manual C2220

Please keep this instruction manual for future reference

WARNING:

-The appliance and its accessible parts become hot

during use. Care should be taken to avoid touching

heating elements.

-Children less than 8 years of age should be kept away

unless continuously supervised.

-To prevent ﬁre hazards do not store items on the

cooking surfaces.

-During use, handles can get hot.

-Do not use harsh abrasive cleaners or sharp metal

scrapers to clean the oven door glass or any other

surface of the appliance as it can scratch the surface

which may result in the glass shattering or permanent

damage to the surface.

-Do not use steam cleaners for cleaning the appliance.

-Ensure the appliance is switched off before replacing the

lamp to avoid the possibility of electric shock.

Instruction manual C2220

Please keep this instruction manual for future reference

CAUTION:

-Accessible parts may be hot when the cooking or grilling

is in use. Young children should be kept away.

-Your appliance is produced in accordance with all

applicable local and international standards and

regulations.

-Maintenance and repair work must be made only

by authorised Caple service technicians. Installation

and repair work that is carried out by unauthorised

technicians may endanger you.

-It is dangerous to alter or modify the speciﬁcations of the

appliance in any way.

-Prior to installation, ensure that the local distribution

conditions (electricity voltage and frequency) and the

requirements of the appliance are compatible. The

requirements for this appliance are stated on the rating

label.

-This appliance is designed only for cooking food and is

intended for indoor use.

Instruction manual C2220

Please keep this instruction manual for future reference

-This product is not designed for commercial use, it is

a household appliance only. It is not intended to be

used in:

- Staff kitchen areas in shops, ofﬁces and other working

environments.

- Bed and breakfast type environments.

- By clients in hotels, motels and other residential type

environments.

-Do not try to lift or move the appliance by pulling the

door handle.

-All possible security measures have been taken to ensure

your safety. Since the glass may break, you should be

careful while cleaning to avoid scratching.

-Avoid hitting or knocking on the glass with accessories.

-Ensure that the supply cord is not wedged or trapped

during the installation. If the supply cord is damaged,

it must be replaced by a Caple service technician or

similarly qualiﬁed persons in order to prevent a hazard.

-While the oven door is open, do not let children climb on

the door or sit on it.

Instruction manual C2220

Please keep this instruction manual for future reference

INSTALLATION WARNINGS

-Do not operate the appliance before it is fully installed.

-The appliance must be installed by an authorised

technician.

-Caple is not responsible for any damage that may

be caused by defective placement and installation by

unauthorised persons.

-When unpacking the appliance, make sure that it is

not damaged during transportation. In the case of any

defect; do not use the appliance and contact your retailer

or Caple Service immediately.

-Materials used for packaging (nylon, staplers, styrofoam

etc) may cause harmful effects to children they should be

disposed of immediately.

-Protect your appliance against atmospheric effects. Do

not expose it to effects such as sun, rain, snow etc.

-The surrounding materials of the appliance (i.e. kitchen

cabinet or furniture) must be able to withstand a

minimum temperature of 120°C.

Instruction manual C2220

Please keep this instruction manual for future reference

DURING USAGE

-Before using the oven for the ﬁrst time, heat the empty

oven at max. temperature for 1 hour – removing any

unpleasant smells and smoke caused by working

residues and thermal insulation. Make sure you do this in

a well ventilated area.

-During usage, the outer and inner surfaces of the oven

get hot. While opening the oven door, step back to avoid

the hot steam coming out of the oven as there may be a

risk of burns.

-Do not put ﬂammable or combustible materials in or

near the appliance when it is operating.

-Always use oven gloves to remove and replace food in

the oven.

-Pay close attention to the oven while cooking with solid

or liquid oils as they could potentially catch ﬁre when

oven is hot.

-Never pour water on ﬂames that are caused by oil. Cover

the saucepan or frying pan with its lid in order to choke

the ﬂame and turn the oven off.

-If you know you will not be using the appliance for a

while switch it off from the mains supply.

-The oven shelves and trays incline when pulled out. Be

careful not to let hot liquid spill over.

Instruction manual C2220

Please keep this instruction manual for future reference

-When the door of the oven is open, do not leave

anything on it. It may unbalance your appliance or

damage the door.

-Do not put anything heavy, ﬂammable or ignitable

(nylon, plastic bag, paper or cloth etc) into the oven. This

includes cookware with plastic accessories (e.g. handles).

Do not hang towels, dishcloths or clothes from the

appliance or its handles.

-Do not use the oven for storage purposes.

-Do not touch the appliance with wet hands.

-Do not obstruct the ventilation openings.

-Do not allow supply cords from other small appliances to

come into contact with the oven.

DURING CLEANING AND MAINTENANCE

-Always switch off the appliance from the mains isolating

the electrical supply before any cleaning or maintenance.

-To maintain the efﬁciency and safety of your appliance,

we recommend you always use original spare parts and

to call only our authorised Caple Service agents in case

of need.

Instruction manual C2220

Please keep this instruction manual for future reference

ENVIRONMENTAL PROTECTION

Waste electrical products should not be disposed of with household waste.

Please recycle where facilities exist. Check with your Local Authority or retailer for

recycling advice.

This appliance is marked according to the European directive on Waste Electrical

and Electronic Equipment (WEEE). By ensuring this product is disposed of correctly,

you will help prevent potential negative consequences for the environment and

human health, which could otherwise be caused by inappropriate waste handling

of this product. The symbol on the product indicates that this product may not

be treated as household waste. Instead it shall be handed over to the applicable

collection point for the recycling of electrical and electronic equipment. Disposal

must be carried out in accordance with local environmental regulations for waste

disposal.

For more detailed information about treatment, recovery and recycling of this

product, please contact your local council, your household waste disposal service

or the retailer where you purchased the product.

WARRANTY

Your new appliance is covered by warranty. The warranty card is enclosed - if it is

missing, you must provide the following information to your retailer in order to

receive a replacement: date of purchase, model and serial number. Registration can

also be completed online by visiting www.caple.co.uk.

Ensure you keep your warranty card safe, you may need to show it to Caple Service

together with proof of purchase.

If you fail to show your warranty card you will incur all repair charges.

Spare parts are only available from Caple Service and spare parts authorised centres.
