Canon WebView LivescopeMV Manuel utilisateur

High-performance Monitoring System

User's Manual

Contents

Introduction

Introduction ............................................................................... 4

Overview .................................................................................... 5

System Configuration ................................................................ 6

Hardware and Software Requirements ..................................... 8

WebView Livescope MV Manager ................................................. 8

WebView Livescope MV Station ..................................................... 8

WebView Livescope Viewer Software ............................................ 8

Chapter 1 Installation

Before Installing the Software.................................................. 10

Checking the System Configuration ............................................ 10

Monitoring with one server ....................................................................... 10

Using multiple MV stations ...................................................................... 10

Using multiple MV stations when the work folder is not held on

the MV Manager machine ........................................................................ 11

Setting up the Computer .............................................................. 11

Installing the Camera Server ........................................................ 11

Installation Procedure .............................................................. 12

Launching the Installer ................................................................. 12

Installing MV Manager ................................................................. 13

Installing MV Station ..................................................................... 15

Chapter 2 Registering Camera Servers

Launching MV Manager .......................................................... 20

Screen Configuration .................................................................... 20

Adding Camera Servers .......................................................... 22

Step 1: Launch the Add Camera Wizard ..................................... 22

Step 2: Enter the Camera Server Network Address .................... 22

Step 3: Enter the Camera Server Name and Comments ............ 23

Step 4: End Setup ........................................................................ 23

Step 5: Test the Display ................................................................ 24

Chapter 3 Creating Monitoring Screens

Create Monitoring Screen Wizard ........................................... 26

Step 1: Launch the Create Monitoring Screen Wizard ................ 26

Step 2: Select the Format ............................................................. 26

Step 3: Select the Camera Server ............................................... 27

Step 4: Set Auto Switch ................................................................ 28

Step 5: End Setup ........................................................................ 29

Step 6: Test the Display ................................................................ 29

Chapter 4 Editing Maps

Editing Maps ............................................................................ 34

Launching the Map Editor ............................................................ 34

Map Editor screen configuration ............................................................. 34

Changing the Background Image ............................................... 35

Positioning the Icons .................................................................... 35

Changing the Appearance of Icons ............................................ 36

Saving Edited Screens ................................................................. 37

Chapter 5 Monitoring

Launching MV Station ............................................................. 40

Screen Configuration .................................................................... 40

Using the Monitoring Screens ................................................. 41

Choose from List .......................................................................... 41

Choose from Map ......................................................................... 42

Choose from Previews .................................................................. 43

Displaying Multiple Locales ......................................................... 43

View 2 or 4 Locales with Map ...................................................... 45

View 6 Locales with Map .............................................................. 45

Large-screen Display ................................................................... 46

Using the Viewer ...................................................................... 47

Switching and Controlling Cameras ............................................ 47

Displaying the Status ................................................................... 47

Displays, Connections, etc. ......................................................... 48

Chapter 6 Managing Camera Servers

Setting Up and Managing Camera Servers ............................ 50

Updating the Firmware ............................................................ 51

Chapter 7 Advanced Operations

Setting Up Automatic Camera Operation ................................ 54

Running Automatic Operation ...................................................... 55

Recording and Displaying Pictures ......................................... 56

Setting Up Picture Recording ...................................................... 56

Displaying Recorded Pictures ..................................................... 57

Other Advanced Settings ......................................................... 59

Changing the Work Folder ........................................................... 59

Settings for Accessing Pages on a Camera Server .................... 59

Appendix

Troubleshooting ....................................................................... 62

Error Messages ....................................................................... 63

Installer Error Messages .............................................................. 63

MV Manager Error Messages ...................................................... 63

MV Station Error Messages .......................................................... 67

Thank you for choosing "WebView Livescope MV"

This manual describes how to set up and use the WebView Livescope MV Manager and

WebView Livescope MV Station software.

Read this manual carefully before you use the software to ensure that you make the best

possible use of this product.

Store this manual in a safe place after you finish reading it.

Introduction

Trademark Information

Microsoft Windows, Windows NT, and Microsoft Internet Explorer are trademarks of the Microsoft Corporation of the U.S.

registered in the U.S. and other countries.

Netscape is a trademark of Netscape Communications Corporation.

All other company or product names used in this document are trademarks or registered trademarks of their respective holders.

* In this manual, "Microsoft Windows" is abbreviated as simply "Windows".

Caution

Note

Conventions

Indicates important notes or restrictions that must be observed when using this product. Always read these items.

Indicates additional information or explanations for a procedure. You are advised to read these items.

Under copyright law, video or still images photographed by the client cannot be used for any purpose other than personal

enjoyment without prior permission from the copyright holder.

Important

The unauthorized transfer of all or any part of the contents of this manual is forbidden.

The contents of this manual are subject to change without notice.

Every effort has been made to ensure that content of this manual is free from errors.

If you encounter any errors, omissions or apparent inaccuracies, contact the manufacturer.

E-mail: [email protected]

Notwithstanding above, the manufacturer accepts no liability whatsoever arising from the

results of using this product.

Introduction

Overview

The WebView Livescope MV software monitors video images shot using a Network Camera Server

VB101/VB100 (referred to hereafter simply as a camera server) and distributed via an intranet or

over the Internet.

This product consists of 2 software applications. These are the WebView Livescope MV Manager,

which can be used to create monitoring screens and collectively manage multiple camera servers,

and the WebView Livescope MV Station, which you can use to monitor camera images from

multiple locations.

The MV Manager does not require you to learn complex operation procedures since it uses a

simple interactive format to register camera servers and create monitoring screens (in HTML). The

MV Manager also allows centralized management of camera servers in multiple locations

(including setting modifications, operating status checks and batch firmware updates).

You can select and create monitoring screens from a wide range of styles, including screens with

maps, multi-locale screens and large-image screens, according to your requirements. You can

also perform tasks such as editing maps, modifying the placement of camera servers on maps,

and specifying automatic operation based on a schedule.

MV Station not only gives you access to monitoring screens created using MV Manager and

allows you complete control of the cameras, it can also display images from cameras in multiple

locations (up to 16) at the same time, providing you with a highly effective monitoring environment.

* To use VB100 camera servers, first upgrade the firmware to version 2.0.

Router

Transmission of

video and image

information

Pictures recorded

according to a schedule.

Video transmission

VC-C4R

VB101/VB100

VC-C4

COMMUNICATIONCAMERA

f:4-64mm1:1.4-2.8

VC-C4R

VB101/VB100

VC-C4

COMMUNICATIONCAMERA

f:4-64mm1:1.4-2.8

Transmission of settings data

camera angles and zoom sett

Monitoring also possible

via Internet

Monitoring via ISDN lines

VC-C4R

VB101/VB100

VC-C4

COMMUNICATIONCAMERA

f:4-64mm1:1.4-2.8

MV Station

Monitoring

INTERNET

ISDN lines

Router

System Configuration

MV Manager and MV Station use a TCP-IP connection to the camera servers.

The connection can be via a LAN or via a direct connection using ISDN Lines.

Introduction

MV Station

Web browser

Monitoring

Internet Explorer 5 or 5.01

Live video

MV Station

Web browser

Monitoring screen creation

and remote maintenance

Internet Explorer 5 or 5.01

Application Functions

WebView Livescope

MV Manager

■Application Types and Functions

Creates and edits the monitoring screens (HTML) used by MV Station. Also

allows remote central management of multiple camera servers.

WebView Livescope

MV Station

Monitors multiple camera servers from monitoring screens created using MV

Manager.

Transmission of settings data such as

camera angles and zoom settings

Transmission of

camera server settings

and modifications

such as

ngs

ETHERNET

* To use VB100 camera servers, first upgrade the firmware to version 2.0.

LAN

Helper Viewer Version 3.10

Windows 95, Windows 98, Windows NT 4.0 (IE 4.0 or later required) or Windows 2000

Netscape Navigator/Communicator 4.5 or later, or Internet Explorer 4.01 or

later recommended

Operating system

Web browser

Hardware and Software Requirements

WebView Livescope MV Manager

WebView Livescope MV Station

WebView Livescope Viewer Software

CPU

CPU 266 MHz Pentium II or better

Windows 95 (Service Pack 1 or later), Windows 98, Windows NT 4.0 (Service Pack 3 or

later) or Windows 2000 Professional or later

Internet Explorer 5 or 5.01 required

Operating system

Web browser

64 MB (128 MB or better recommended)

RAM

Minimum 150 MB of free space (50 MB required at installation and at least 100 MB required

in virtual memory)

Hard disk

XGA (1024 x 768) high-resolution monitor or better

Display

CPU

266 MHz Pentium II or better

Windows 95 (Service Pack 1 or later), Windows 98, Windows NT 4.0 (Service Pack 3 or

later) or Windows 2000 Professional or later

Internet Explorer 5 or 5.01 required

Operating system

Web browser

64 MB (128 MB or better recommended)

RAM

Minimum 150 MB of free space (50 MB required at installation and at least 100 MB required

in virtual memory)

Hard disk

XGA (1024 x 768) high-resolution monitor or better

Display

This is a basic viewer application provided as freeware.

●When installing Internet Explorer, use the "Full" or "Standard" installation. If

you select the "Minimum configuration" installation option, required modules

are not installed and the software will not run correctly.

●After installing Internet Explorer, nominate it as your default browser.

●If you are using a Network Camera Server VB100, upgrade the firmware to

version 2.0 before using the server. For the latest information on new firmware

updates, visit our web page:

http://www.x-zone.canon.co.jp/WebView/index.htm

Caution

Chapter 1

Installation

First, install the WebView Livescope MV Manager and MV Station software.

Before Installing the Software

Monitoring with one server

Using multiple MV stations

Install the MV Manager software. This automatically installs the MV Station software also

(➡P.13).

Install both MV Manager (➡P.13) and MV Station (➡P.15) on each of the machines.

Files such as monitoring screen pages and information on the camera servers set by the MV

Manager are placed in the work folder. To view a monitoring screen in MV Station, access and

display the "index.htm" file in the work folder.

MV Manager

Monitoring screen creation and

remote maintenance

MV Station

Monitoring

VB101/VB100

Checking the System Configuration

MV Manager

Monitoring screen creation

and remote maintenance

MV Station

Monitoring

Video reception and camera

control signal transmission

File sharing

VB101/VB100

Reference to camera server information

and monitoring screen settings

Camera server settings

and modifications

Work folder

MV Station

Monitoring

Autres manuels pour WebView LivescopeMV

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Canon Logiciel

Canon

Canon HV10 - Camcorder - 1080i Manuel utilisateur

Canon

Canon Microfilm Scanner 800II Manuel utilisateur

Canon

Canon REALIS WUX10 MARK II D Manuel utilisateur

Canon

Canon 3508B001 - PowerShot D10 Digital Camera Guide de sécurité

Canon

Canon Powershot Pro90 IS Manuel utilisateur

Canon

Canon Optura Pi Instructions de montage

Canon

Canon VIXIA HF11 Manuel utilisateur

Canon

Canon REALiS SX80 Mark II D Mode d’emploi

Canon

Canon WEBVIEW LIVESCOPE 3.2 Manuel utilisateur

Canon

Canon PowerShot A520 Manuel utilisateur

Canon

Canon VB-M40 Manuel d'utilisation et d'entretien

Canon

Canon ELURA 100 - Camcorder - 1.3 MP Manuel utilisateur

Canon

Canon 1236B001 - EOS Digital Rebel XTi Camera SLR Manuel utilisateur

Canon

Canon POWERSHOT A75 Guide de sécurité

Canon

Canon PowerShot SX1 IS Guide de démarrage rapide

Canon

Canon FS10 Manuel utilisateur

Canon

Canon PowerShot ELPH 100 HS IXUS 115 HS Guide de démarrage rapide

Canon

Canon CR-DGi Manuel utilisateur

Canon

Canon CANOSCAN N650U Manuel utilisateur

Canon

Canon Powershot S2 IS - Powershot S2 IS 5MP Digital... Manuel utilisateur

Canon

Canon SD400 - PowerShot Digital ELPH Camera Guide de sécurité

Canon

Canon 3508B001 - PowerShot D10 Digital Camera Instructions de montage

Canon

Canon 2055B001 - DC 50 Camcorder Manuel utilisateur

Canon

Canon Pull Print Service Provider Version 1.0... Manuel utilisateur

Manuels Logiciel populaires d'autres marques

COMPRO

COMPRO COMPROFM Manuel utilisateur

Muratec

Muratec OFFICEBRIDGE ONLINE Manuel utilisateur

Oracle

Oracle Contact Center Anywhere 8.1 Manuel utilisateur

Adobe

Adobe 65007312 - Photoshop Lightroom Manuel

Avaya

Avaya NULL One-X for RIM Blackberry Manuel utilisateur

HP ProLiant BL420c Manuel utilisateur

PS Audio

PS Audio PowerPlay Manuel du propriétaire

Brady

Brady LOCKOUT PRO 3.0 Manuel de service

Avaya

Avaya Interaction Center Manuel utilisateur

Texas Instruments

Texas Instruments TI-83 Plus Silver Edition Manuel

Novell

Novell GROUPWISE 8 - INTERNET AGENT Manuel utilisateur

Oracle

Oracle Application 9i Manuel utilisateur

Acer

Acer RDM Manuel utilisateur

Samsung

Samsung Auto Backup Manuel utilisateur

Polycom

Polycom Vortex EF2201 Instructions d'installation et d'utilisation

Brocade Communications Systems

Brocade Communications Systems Brocade 8/12c Manuel utilisateur

Novell

Novell SP2 - S Mode d’emploi

Lexmark

Lexmark Apps Manuel de service
