Welcome to ScanGear CS-U

Welcome to Canon ScanGear CS-U 6.0 software for Windows.

ScanGear CS-U 6.0 (hereafter referred to as ScanGear CS-U) will provide

flexible, efficient image enhancement tools for scanning with your

CanoScan D646U Scanner by providing an interface with a variety of

TWAIN-compliant software applications. (TWAIN ☞p.97)

ScanGear CS-U has a number of powerful features that help you achieve

peak performance with your scanner. Using ScanGear CS-U, you can

preview and adjust an image before the image is scanned and acquired

by the parent software application.

Here is a quick summary of the important features of ScanGear CS-U:

• Two operation modes: Simple mode, which allows you to select all

optimum settings with one selection, and Advanced mode, which

allows you to create professional color and other enhancements for

artistic effects.

• Flexible, fully automatic image acquisition, and pre-scan image

manipulation prior to passing data to the image application

• TWAIN 1.6 compliant

• Text Enhanced mode for OCR applications

• Canon ColorGear (color matching software technology)

• Automatic preview or preview image cache

• ScanGear CS-U can run with or without its main window,

depending on the acquiring application.

chapter 1

BeforeYouBegin

Top Page

Glossary

Contents

Index

Normally when you start a scanning job, you will see the ScanGear CS-U

main window with its toolbar, Preview Area, and tabs.

However, some software applications may not open the ScanGear CS-U

main window. When this occurs you cannot use the settings described in

this user’s guide because the host software application will provide the

settings so you can change the image after it is acquired. When a

software application uses ScanGear CS-U without opening the ScanGear

CS-U main window, this is called the windowless mode.

chapter 1

BeforeYouBegin

Top Page

Glossary

Contents

Index

System Requirements

The hardware and software listed below is required to use ScanGear

CS-U.

Hardware

• You can use following scanner with ScanGear CS-U: CanoScan

D646U.

• IBM PC or its compatible on which Windows Me, Windows 98 or

Windows 2000 Professional can run

• Memory (RAM) required is determined by your system:

32 MB (64 MB or more recommended)

• 10 MB of free disk space for ScanGear installation

• Free disk space, at least 50 MB. The amount of space required

depends on the scanning area and the Color Mode or Resolution

settings (color images scanned at higher resolution require more

storage space).

Note

Before you scan an image, check the file size in the

status bar. You should have at least twice that amount

of free space available on the hard disk.

• Minimum requirement for monitor: 800 x 600 resolution

(minimum), High Color (16 bit) or greater.

chapter 1

BeforeYouBegin

Top Page

Glossary

Contents

Index

Software

• Microsoft®Windows®Me, Microsoft®Windows®98 or Microsoft®

Windows®2000 Professional

• TWAIN-compliant parent software application

chapter 1

BeforeYouBegin

Top Page

Glossary

Contents

Index

Getting Help in ScanGear CS-U

For information about using ScanGear CS-U, open the on-line Help by

clicking the Help button on the toolbar or in the dialog boxes.

Click the Contents or Index tab to see if the topic you are looking for is

covered elsewhere in on-line Help.
