Canon Viewer Manuel utilisateur
User’s Manual
Viewer Software
Ve r. 3.6
E
ENGLISH
2
Introduction
Important ....................................................................................... 4
Copyright Information ................................................................... 4
Usage Notice of Audio .................................................................. 4
Trademark Information ................................................................. 4
Conventions .................................................................................. 4
WebView Livescope Overview ................................................. 5
Viewer Overview ....................................................................... 6
Viewer for Java ............................................................................. 6
Viewer for PC................................................................................ 7
Operating Environment............................................................. 8
Viewer for Java ............................................................................. 8
Viewer for PC................................................................................ 8
Chapter 1 Viewer for Java
Preparations for Using the Viewer for Java ............................ 10
Using Internet Explorer............................................................... 10
Using Netscape .......................................................................... 11
Starting Up the Viewer for Java .............................................. 15
Using the Viewer for Java....................................................... 16
“LiveApplet” Screen .................................................................... 16
Panorama Window ................................................................................ 17
Starting Camera Control ............................................................. 18
Controlling the Camera .............................................................. 19
Changing the Camera Angle ................................................................. 19
Changing the Camera Zoom Ratio ....................................................... 20
Selecting the Camera ............................................................................ 21
Using Presets ........................................................................................ 21
Adjusting Backlight ................................................................................ 22
Taking a Snapshot of the Video ............................................................ 23
“Glimpse” Screen ........................................................................ 24
Chapter 2 Viewer for PC
Preparations for Using the Viewer for PC .............................. 26
Installing the Viewer for PC ........................................................ 26
Using Browsers Other Than the Recommended
Products ................................................................................ 27
Starting Up the Viewer for PC ................................................ 28
Starting Up from the Web Browser ............................................ 28
Starting Up Independently .......................................................... 28
Connecting to the Camera Server .......................................... 29
Specifying a Connection Target and Connecting ....................... 29
Selecting a Registered Camera Server and Connecting ........... 30
Disconnecting ............................................................................. 30
Contents
3
Using the Viewer for PC ......................................................... 31
“Viewer for PC” Screen .............................................................. 31
Panorama Window ................................................................................ 32
Starting Camera Control ............................................................. 33
Controlling the Camera .............................................................. 34
Changing the Camera Angle ................................................................. 34
Changing the Camera Zoom Ratio ....................................................... 35
Selecting the Camera ............................................................................ 36
Using Presets ........................................................................................ 36
Changing the Video Source Size .......................................................... 37
Using Full-Screen Mode ........................................................................ 37
Adjusting Backlight ................................................................................ 38
Pausing and Restarting Video Display ................................................. 38
Registering a camera site during connection ....................................... 39
Playing back audio ................................................................................ 40
Saving and Printing Still Pictures ............................................... 40
Saving Still Pictures to Files ................................................................. 40
Printing Still Pictures ............................................................................. 41
Displaying Information ................................................................ 41
Video Information .................................................................................. 41
Connection Information ......................................................................... 42
Camera Information ............................................................................... 42
Network .................................................................................................. 42
Chapter 3 Viewer for PC Settings
Viewer for PC Settings ........................................................... 44
“Starting protocol” Setting ..................................................................... 44
“HTTP protocol” Setting ........................................................................ 45
“Display option” Setting ......................................................................... 46
Registering and Changing the Server .................................... 47
Registering in a Camera Site List .............................................. 47
Adding to a list ....................................................................................... 47
Changing or deleting registration details in the list .............................. 48
Appendix
Error Messages ...................................................................... 51
Index ....................................................................................... 54
4
Important
1Copyright © 2004 by Canon, Inc. All rights reserved. The unauthorized transfer of all or
any part of the contents of this manual is forbidden.
2The contents of this manual are subject to change without notice.
3Every effort has been made to ensure that content of this manual is free from errors.
If you encounter any errors, omissions or apparent inaccuracies, contact the
manufacturer.
4Notwithstanding the above, Canon accepts no liability for any results arising from the
operation of this product.
This manual describes how to use the WebView Livescope Ver. 3.6 Viewer Software.
There are two types of viewers, Viewer for Java and the Viewer for PC, and the video
sender can use one or the other as required. Both types provide the same basic
functions for viewing videos, but differ in terms of other features and functions. The
preparations for using the two viewer types and the required operating environment also
differ depending on the computer hardware and software used to run the viewer.
Read this manual carefully before you use the viewer to ensure that you make the best
possible use of this product.
Store this manual in a safe place after you finish reading it.
The latest information on the viewer is available at the following URL.
http://www.canon.com/webview
Introduction
Trademark Information
Canon and Canon logo are registered trademarks of Canon Inc.
Microsoft Windows and Microsoft Internet Explorer are registered trademarks of the Microsoft Corporation in the
United States and other countries.
Netscape is a trademark of Netscape Communications Corporation.
Java and all Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc. in the United
States and other countries.
All other company or product names used in this document are trademarks or registered trademarks of their
respective holders.
* In this document, “Microsoft Windows” is abbreviated as simply “Windows”.
Conventions
Indicates important notes or restrictions that must be observed when using this product. Always
read these notes.
Indicates additional information or explanations for a procedure. You should read these items.
Copyright Information
Under copyright law, video or still pictures photographed by the viewer cannot be used for any purpose other than
personal enjoyment without prior permission from the copyright holder.
c
Note
e
Tip
Usage Notice of Audio
1. Audio stream may be interrupted according to the performance of your PC and network environment.
2. If you use a proxy server, the audio may be interrupted.
3. If you use a PC on which anti-virus software is installed, the audio may be delayed or the audio stream may be
temporarily interrupted.
Introduction
5
WebView Livescope Overview
■WebView Livescope is the system that allows camera control and live video distribution from a
remote location.
■The system is configured for a camera server and viewer software. The camera server distributes
live video taken by the video camera to the Internet or an Intranet. The viewer software can display
the video and remotely control the camera.
■The WebView Livescope system can be used in a wide range of applications such as distributing
live video from a Web site and monitoring.
The following types of camera servers are available:
•Network Camera Server VB150
•Network Camera VB-C50i/VB-C50iR
•Network Camera VB-C50Fi
The following types of Viewer Software are available:
•Viewer for Java (This manual: provided free of charge with camera server product)
•Viewer for PC (This manual: provided free of charge with camera server product)
•Network Video Recorder VK-64 (Sold separately)
•WebView Livescope MV Ver. 2.1/LE (Sold separately)
■The names of the viewers have been changed as follows:
Old Name
Helper Viewer
Java Viewer
New Name
Viewer for PC
Viewer for Java
Live
Active
WebView Livescope is a video distribution system that enables users to
actively (by performing operations by oneself) view live (showing now) video
from Web pages by allowing users to change camera angle and zoom magnification.
Video Sender Video Recipient
(Viewer software)
Sending the current video
Viewing by switching angle and zoom magnification
Offers an easy way
to provide live information contents.
Offers the advantage of
being able to actively select desirable
parts from live video according to
the user’s purposes.
(Camera server)
VB150
VB-C50Fi
VB-C50i
6
LiveApplet
Video display functions
Camera control functions
Glimpse
Video display functions
Viewer for Java
Viewer Overview
This is a viewer written using Java. This viewer allows the camera server’s videos to be
viewed on any computer with a Web browser that runs Java, regardless of the platform.
Because the Java applet is downloaded when the viewer starts up, the first video takes
some time to appear. The Viewer for Java provides two types of viewers: LiveApplet
containing video display and camera control functions, and Glimpse containing a video
display function.
Panorama picture
➤
Click
There are two types of WebView Livescope Viewer Software: the Viewer for Java and the Viewer for
PC.
c
Note
●To use the Viewer for Java, you need to install Java VM beforehand. See the
web site for more details.
WebView Product web site http://www.canon.com/webview
●Panorama pictures must be registered in advance at the camera server.
*Panorama pictures are not available with the VB-C50Fi.
Introduction
7
Viewer for PC
This is a viewer that runs as an application. This viewer provides video display and camera
control functions and appears in a separate window at startup. While the Viewer for PC has
to be pre-installed, it offers the advantage of displaying the first video quickly. At present,
only a Windows version of this viewer is available.
c
Note
●The Viewer for PC is provided on the CD-ROMs supplied with the Network
Camera Server VB150, the Network Camera VB-C50i/VB-C50iR and VB-
C50Fi packages. The viewer can also be downloaded free of charge from
the following web site.
URL : http://www.canon.com/webview
●The Viewer for PC needs to be pre-installed on your computer. (→p.26)
●Panorama pictures must be registered in advance at the camera server.
*Panorama pictures are not available with the VB-C50Fi.
●When playing back audio, please read carefully “Usage Notice of Audio”
(→ P.4).
*Audio input/output is not available with the VB-C50Fi.
➤
Click
Panorama picture
●Because the Viewer for Java is downloaded from the camera server every
time you access and displays video on the viewer screen, it starts up
slower than the Viewer for PC that is pre-installed on a PC.
●Use the Viewer for Java when you access the camera server and view video
for the first time. However, we recommend you to install and use the Viewer
for PC if you view video frequently.
e
Tip
8
Operating Environment
Viewer for Java Ver. 3.6
Viewer for PC Ver. 3.6
Windows 2000 (SP4)/ Windows XP (SP1a or SP2)
Netscape 7.1 or 7.2,
or Microsoft Internet Explorer 6.0 (SP1 or SP2)
Operating System
Web Browser
* Must be installed in advance from the CD-ROM supplied with the camera server. (→p.26)
Windows 2000 (SP4)/ Windows XP (SP1a or SP2)
Netscape 7.1 or 7.2,
or Microsoft Internet Explorer 6.0 (SP1 or SP2)
Operating System
Web Browser
MSVM Release 5.0.0.3810 (Java VM provided by Microsoft)
Java Plug-in 1.4.2 (Java VM provided by Sun Microsystems)
Java VM
* This viewer is installed in the camera server and automatically downloaded when it is connected to the camera
server.
* Operation is unstable when used with an OS or Web browser other than those noted above.
For the latest information, please refer to our WebView Product web page:
http://www.canon.com/webview
Chapter 1
Viewer for Java
This chapter describes the preparations required for using the Viewer for Java
and explains how to use the viewer.
10
Preparations for Using the Viewer for Java
The Viewer for Java is automatically downloaded from the camera server. There is no need to install
it in advance. However, depending on the type of Web browser you are using and your software
settings, you must change your Web browser settings.
Using Internet Explorer
* For Internet Explorer 6.0
Internet Explorer has a setting that specifies whether the use of Java is permitted.
From the “Tools” menu, select “Internet Options” and click the “Advanced” tab. Then set “JIT
compiler for virtual machine enabled” as the “Microsoft VM” setting.
In Windows XP, Java VM may not be installed. If this is the case, please install it. See the
web site for more details.
WebView Product web site http://www.canon.com/webview
Detailed settings below similar to the ones are displayed after settings.
* For Internet Explorer 6.0
