Canon CANOSCAN D660U Manuel utilisateur

f o r M a c i n t o s h

Canon Plug-in Module CS-U 3.9

for CanoScan D660U Color Image Scanner

User's Guide

How to Make Best Use of the Manuals

Describes operating procedure from set up and

software installation to scanning and

confirmation of operation. Please read before

using the scanner for the first time.

Printed Manual

CanoScan D660U

Getting Started

Detailed information on how to use

Canon Plug-in Module CS-U.

Canon Plug-in Module CS-U

User's Guide

Electronic Manual

Tells you how to use ArcSoft PhotoStudio 2000,

ArcSoft PhotoBase and Caere OmniPage SE.

Electronic Manuals

Manual for Each

Application Software

After reading this guide and scanner

is set up and ready for use...

When using the

accompanying

application

software.

After you have read this book and mastered

the use of Canon Plug-in Module CS-U and

CanoScan Toolbox...

When you open the box

Detailed information on how to use

CanoScan Toolbox.

CanoScan Toolbox

User's Guide

Electronic Manual

This Guide

How to Use this Guide

This guide explains the operating procedures for Canon Plug-in Module CS-U

(hereafter referred to as Plug-in Module CS-U), the Macintosh driver (plug-in

software) used with Canon image scanners.

A plug-in is not an independent software program; it must be used within a plug-in

compliant application, such as CanoScan Toolbox or ArcSoft PhotoStudio 2000, to

expand the capabilities of that program. Adding scanning capabilities to your

computer is as easy as putting in a plug. Simply copy the Plug-in Module CS-U files

to your computer.

Please read this guide to perform the installation procedures and scan. Store this

manual in a handy location for future reference.

Where to Look

Quick Start Instructions p. 10

The Quick Start Instructions provide a brief summary of commands and

procedures that will assist in using Plug-in Module CS-U immediately.

Scanning Preparations (Required Reading) p. 13

All users should read this section. This section describes the procedures and

settings required before scanning, including positioning the original and

selecting the output device, resolution, magnification and scanning mode.

Scanning (Required Reading) p. 29

All users should read this section to learn the procedures for scanning images,

saving scanned images and scanning film.

Adjusting Scanned Images p. 37

Read this section for details about how to adjust image brightness, color

balance and other attributes. You can read this section as required.

Appendices

Read this section for troubleshooting tips, glossary terms and the index.

About the Conventions Used in this Guide

The following conventions are used in this guide to draw your attention to

important information.

Caution:

This symbol is used to highlight procedural precautions and limitations.

Always read these topics to avoid errors.

Hint:

This symbol is used to present helpful hints and supplemental information.

Reading these topics is recommended to enhance your enjoyment of

Plug-in Module CS-U.

Table of Contents

How to Make Best Use of the Manuals .................................................................. 2

How to Use this Guide ........................................................................................... 3

Table of Contents................................................................................................... 4

Installing Plug-in Module CS-U............................................................................... 6

Control Panel Features ........................................................................................... 7

Scanning Procedures .............................................................................................. 8

Plug-in Module CS-U Special Features .................................................................... 9

Quick Start Instructions............................................................................ 10

STEP 1

Scanning Preparations ................................................................. 13

Displaying the Plug-in Module CS-U Control Panel .............................................. 14

Positioning Originals ............................................................................................ 16

Previewing ........................................................................................................... 17

Selecting the Output Device ................................................................................. 18

Setting the Resolution and Magnification ............................................................ 19

Setting the Scan Mode ........................................................................................ 21

Verifying the Image before Scanning.................................................................... 23

Rotating the Image .............................................................................................. 24

Setting Preferences .............................................................................................. 25

Output Device................................................................................................. 25

Aspect Ratio ................................................................................................... 25

Unit ................................................................................................................ 26

Preview Window ............................................................................................. 26

Reset Default Settings ..................................................................................... 27

Close Plug-in After Scan ................................................................................. 27

Platen/Film Adapter ........................................................................................ 27

STEP 2

Scanning ....................................................................................... 29

Setting the Scan Area .......................................................................................... 30

Zooming .............................................................................................................. 31

Scanning .............................................................................................................. 33

Saving Scanned Images ........................................................................................ 34

Scanning Film ...................................................................................................... 35

STEP 3

Adjusting Scanned Images .......................................................... 37

Tone Adjustment.................................................................................................. 38

Histogram Settings ............................................................................................... 39

Tone Curve Settings ............................................................................................. 42

Brightness and Contrast Settings ......................................................................... 45

Adjusting the Color Balance................................................................................. 47

Gamma Value Settings ......................................................................................... 48

Adjusting the Threshold Value ............................................................................. 50

Auto Tone Correction ........................................................................................... 51

Unsharp Mask ...................................................................................................... 52

Descreen .............................................................................................................. 53

Saving/Recalling Settings ...................................................................................... 54

Scanning Techniques ............................................................................................ 56

Appendices................................................................................................ 57

Troubleshooting ................................................................................................... 58

Error Messages .................................................................................................... 62

Glossary ............................................................................................................... 63

Index .................................................................................................................... 68

Canon Customer Support Help Desk ................................................................... 70

Installing Plug-in Module CS-U

Please install Plug-in Module CS-U with the other application programs

according to the instructions in the “1. Installing the Software” section

of “Chapter 3, Using the Macintosh Platform,” of the Getting Started

guide supplied with the scanner.

Operating Environment

Hardware

• Power Macintosh or iMac with built-in USB ports (performance on Macintosh

compatibles is not guaranteed)

Main Memory

• 32 MB or more (64 MB or more recommended)

Application Software

• CanoScan Toolbox

• ArcSoft PhotoStudio 2000

• Other plug-in compatible application programs

Display

• 32,000 colors or more

System Software

• Mac OS 8.5 or higher (First-generation, Bondi blue iMacs may require a

system upgrade and an update to the system and firmware.*)

* For information about upgrades and updating for iMacs, refer to the

Troubleshooting menu on the CanoScan Setup Utility CD-ROM. Look for the

“Scanner won’t work on an iMac” item in the topic entitled “Problems with the

Scanner.”

Caution

• The ColorSyncTM Profiles file is installed along with Plug-in Module CS-U.

ColorSyncTM Ver. 2.0 or higher is required to use these profiles with the

automatic color matching system (p. 51).

• The following display profile files are available: CANON gamma 1.5

monitor, CANON gamma 1.8 monitor and CANON gamma 2.1 monitor. If

you wish to adjust the color balance of the display, double-click

[ColorSync™] in your Macintosh’s Control Panels folder and select one of

these display profiles.

Control Panel Features

When you need more information about a control panel button or menu, refer to

the illustration below and go to the referenced page number for more details.

• The illustration may differ slightly from the version of Plug-in Module CS-U

provided in your package.

Hint

In this guide, menu items are marked in the following manner:

Select [Load] from the [Setting File] menu.

➜p. 51

➜p. 38-50

➜p. 53

➜p. 52

➜pp. 25-28

➜p. 54

Tone Adjustment Button

➜pp. 38-50

Close Box

➜p. 14

Scan Mode

➜p. 21

Zoom In Button

➜p. 31

Zoom Out Button

➜p. 32

Output Device

➜p. 18

Resolution

➜pp. 19-20

Magnification

➜pp. 19-20

Image Size

➜pp. 19-20

Required/

Free memory

➜p. 21

Browser Button ➜p. 23

Scan Button ➜p. 33

Preview Button ➜p. 17

Preview Window ➜pp. 14, 26

RGB values

➜p. 14

Auto Tone Adjustment Button ➜p. 38

Rotation Button ➜p. 24

➜p. 35

Available when [Film

Adapter] is selected in

the Preferences menu.

Scanning Procedures

Follow these procedures to use Plug-in Module CS-U.

STEP 2

STEP 1

Is the scanner attached?

Prepare for Scanning ➜ p. 13

•Position the Original

•Preview

•Select the Output Device

•

Set the Resolution and Magnification

•Set the Scan Mode

p. 16

p. 17

p. 18

p. 19

p. 21

•Set the Scan Area

•Zoom

•Scan

•Save Scanned Images

•Scan Film

If the current brightness

and color pose no problem,

there is no need to adjust

these settings.

Scan ➜ p. 29

Adjust and Edit Scanned Images

➜ p. 37

Verify the Image before Scanning

(Browser Window) ➜ p. 23

Are the Brightness and Color Satisfactory?

p. 30

p. 31

p. 33

p. 34

p. 35

•Histogram

•Tone Curve

•Brightness and Contrast

•Color Balance

•Gamma Value

•Threshold Value

•Auto Tone (ColorSyncTM)

•Unsharp Mask

•Descreen

p. 39

p. 42

p. 45

p. 47

p. 48

p. 50

p. 51

p. 52

p. 53

Is Plug-in Module CS-U installed?

STEP 3

Refer to the scanner's

Getting Started guide

to attach it.

Refer to the scanner's

Getting Started guide

to install it.

Plug-in Module CS-U Special Features

•See the Results of Adjustments Immediately (Dynamic Preview)

Once in preview mode, the results of adjustments to scan mode settings and colors

are promptly reflected in the preview image.

Highly detailed adjustments can be performed easily because you can see the

results of your changes as they are executed.

•ColorSync™ (Ver 2.0 +) Compatible for Auto Tone Correction

Compatible with the Mac OS 8.5 ColorSync™ (Ver 2.0 +) color management

software. This function automatically matches the color profiles of various devices,

such as scanners, color displays and color printers, for optimal color reproduction.

•Browser Function Permits Confirmation of the Real Image

Before Scanning

The Browser function lets you check the image to be scanned in detail before

commencing the scan. This function presents a much higher quality image than the

preview function.

•Histogram Function Realizes Beautiful Contrast

Simple operation allows you to achieve beautiful contrast with half-tone

gradations.

•Gamma Curve Adjusts Image Brightness

The Gamma Curve feature provides four methods you can use to refine in detail

the level of image brightness until you are satisfied with the results.

•Works within Image Processing Software

for Easy Image Editing

Plug-in Module CS-U can be used to extend the functions of plug-in compatible

image processing application programs.

•Supports the Scanner Film Adapter Unit

Scans 35 mm film using the film adapter unit built into the scanner. All you have to

do is specify whether the film is a positive or negative, color or black and white, to

automatically correct the saturation and color balance. Allows you to effortlessly

create color prints.

Quick Start Instructions

Folow the procedures below to start scanning immediately. If you require more

information at any stage, read the pages referenced at each step.

Install Plug-in Module CS-U

This step is not required if you have already installed Plug-in

Module CS-U following the instructions in the Getting Started

guide.

1. Place the CanoScan Setup Utility CD-ROM into the

computer's CD-ROM drive. The CanoScan Setup Utility will

start automatically. (If it doesn't, double click the [CD-ROM]

icon, followed by the [setup] icon.)

2. Click [Install the Software] to install Plug-in Module CS-U and

the other application programs.

Start Plug-in Module CS-U p. 14

1. Start ArcSoft PhotoStudio 2000 or other plug-in compatible

application.

2. Open the [File] menu, select [Acquire] and [CanonPI CS-U

3.9.0...].

Position materials for scanning and preview them.

p. 16

1. Position an item on the document glass (platen).

2. Click the Preview button.

•The entire scanable area of the document glass will be

previewed and displayed in the preview window.

Autres manuels pour CANOSCAN D660U

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Canon Logiciel

Canon

Canon SELPHY CP760 Guide de démarrage rapide

Canon

Canon VIXIA HF M30 Manuel utilisateur

Canon

Canon PowerShot G3 Manuel utilisateur

Canon

Canon ImageWare Manuel utilisateur

Canon

Canon 40MC - Elura MiniDV Digital Camcorder Manuel utilisateur

Canon

Canon imagePROGRAF W6400 Manuel utilisateur

Canon

Canon EOS-1D Mark II Digial Manuel utilisateur

Canon

Canon iR Series Manuel utilisateur

Canon

Canon Elura 60 - Elura 60 MiniDV Camcorder Manuel utilisateur

Canon

Canon DR 2580C - Document Scanner Manuel utilisateur

Canon

Canon PowerShot A530 Instructions de montage

Canon

Canon MultiPASS C50 Guide de sécurité

Canon

Canon VIXIA HF M32 Manuel utilisateur

Canon

Canon 3211B001 - PowerShot E1 Digital Camera Guide de sécurité

Canon

Canon PowerShot G10 - Digital Camera - Compact Guide de sécurité

Canon

Canon EOS 5D - Focusing Screen Ee-A Manuel utilisateur

Canon

Canon CAPTUREPERFECT 3.1 Manuel utilisateur

Canon

Canon PowerShot SD430 DIGITAL ELPH WIRELESS Instructions de montage

Canon

Canon EOS Rebel XS 18-55IS Kit Manuel utilisateur

Canon

Canon 40D - EOS 40D DSLR Manuel utilisateur

Canon

Canon D1250U2F - CanoScan USB Flatbed Scanner Manuel utilisateur

Canon

Canon 3508B001 - PowerShot D10 Digital Camera Instructions de montage

Canon

Canon iR2270 Series Caractéristiques techniques

Canon

Canon REALiS SX80 Mark II D Manuel utilisateur

Manuels Logiciel populaires d'autres marques

COMPRO

COMPRO COMPROFM Manuel utilisateur

Muratec

Muratec OFFICEBRIDGE ONLINE Manuel utilisateur

Oracle

Oracle Contact Center Anywhere 8.1 Manuel utilisateur

Adobe

Adobe 65007312 - Photoshop Lightroom Manuel

Avaya

Avaya NULL One-X for RIM Blackberry Manuel utilisateur

HP ProLiant BL420c Manuel utilisateur

PS Audio

PS Audio PowerPlay Manuel du propriétaire

Brady

Brady LOCKOUT PRO 3.0 Manuel de service

Avaya

Avaya Interaction Center Manuel utilisateur

Texas Instruments

Texas Instruments TI-83 Plus Silver Edition Manuel

Novell

Novell GROUPWISE 8 - INTERNET AGENT Manuel utilisateur

Oracle

Oracle Application 9i Manuel utilisateur

Acer

Acer RDM Manuel utilisateur

Samsung

Samsung Auto Backup Manuel utilisateur

Polycom

Polycom Vortex EF2201 Instructions d'installation et d'utilisation

Brocade Communications Systems

Brocade Communications Systems Brocade 8/12c Manuel utilisateur

Novell

Novell SP2 - S Mode d’emploi

Lexmark

Lexmark Apps Manuel de service
