The Micrographics Range
Image ling solutions
The Undeniable
Advantage of Microlm
With a life expectancy of over 100 years, microlm
provides a long-term archival medium that
withstands the test of time.
The Canon MS-Series Digital Microlm Scanners deliver a reliable,
low-cost way to view, scan, print, and, distribute high-quality
microlm images. Designed to meet today’s digital imaging needs,
the Canon MS-Series devices offer great versatility, easy
connectivity, and user-friendly operation.
Renowned for optimized performance and reliability, the Canon line
of digital microlm scanners–including the MS-800II, MS-350II,
and MS-300II models–offers the following advantages:
• Easy Operation — Helps ensure that dedicated or walk-up
users and those with disabilities can use the MS-Series Scanners
to conveniently access microlm or microche.
• Reader-Printer Capabilities — Provide exibility for scan-to-
print applications. These devices can be congured to connect
directly to a Canon Fileprint laser printer, without the need for a
PC connection or an existing local/network printer.
• Interchangeable Film Carriers — Enable the MS-Series
Scanners to handle all lm/che formats, including 16mm/35mm
open reels, 16mm cartridges, microche, and aperture cards.
• Bundled Software — Includes ISIS®/TWAIN drivers and
Canon CapturePerfect software for MS-300II/350II/800II and
Scanning Utility 800 Software for MS-800II.
Specications
Type: Desktop Digital Microlm Reader/Scanner
Item Number: MS-300II
MS-350II
Film Formats: Universal with Interchangeable Carriers
Film Types: Both Negative and Positive Images of Silver or Diazo 16mm/35mm Film,
Aperture Cards, and Microche
Lens Magnication: 7x, 9.5-16x, 16-32x, 30-55x, 10-24x (MS-300II only), 20-48x (MS-350II only)
Screen Size (H x W): 300mm x 300mm
Scan Resolution: Up to 600 dpi
Scan Modes: Black and White, Error Diffusion, Text Enhanced, Grayscale
Scan Size: 279mm x 356mm, 216mm x 280mm
Scan Speed: 5.5 Seconds (216mm x 280mm)
Scan Options: Trimming, Auto Border Erasure
Image Adjustment: Rotation, Focus, Zoom
MS-300II (Manual)
MS-350II (Motorized)
Interface: SCSI-II and Hi-Speed USB 2.0
Dimensions (H x W x D): 668mm x 442mm x 541mm
Weight: 26kg
Electrical Requirements 240v, 50Hz
Bundled Software: ISIS/TWAIN Drivers, Canon CapturePerfect 1.0
Other Features: Auto Exposure with Manual Override
Motorized Zoom Lens (MS-350II only)
Automatic 90° Rotation (MS-350II only)
Automatic Bimode Sensing with Manual Override (N-P/P-P)
Automatic Border Erasure
Options: Fileprint 270, Fileprint 470, DMP Board, Lenses (7x, 9.5-16x, 16-32x, 30-55x,
10-24x, 20-48x), Fiche Carrier 190RII, Roll/Fiche Carrier 200, Autocarrier
100C, FS Controller I, Installation Kit Q, Framing Kit for MS300II/350II
Microlm Scanner 300II/350II
Cost-effective desktop microlm scanning
• Fast, 5.5-second scanning
• Standard motorized remote control (MS-350II only)
• Hi-Speed USB Connection
Specications
Type: Desktop Digital Microlm Reader/Scanner
Item Name: MS800II
Film Formats: Universal with Interchangeable Carriers
Film Types: Both Negative and Positive Images of Silver or Diazo 16mm/35mm Film,
Aperture Cards, and Microche
Lens Magnication: 7-7.5x, 9-16x, 14-30x, 20-50x, 57x
Screen Size (H x W): 300mm x 432mm
Scan Resolution: Up to 600 dpi
Scan Modes: Black and White, Black and White Fine, Black and White Photo, Grayscale
Scan Size: 279mm x 432mm, 279mm x 356mm, 216mm x 279mm, 216mm x 140mm
Scan Position: Center, Left, Two Consecutive Pages
Scan Speed: 3 Seconds (216mm x 279mm)
3.9 Seconds (279mm x 432mm)
Scan Options: Trimming, Auto Border Erasure
Interface: SCSI-II, Hi-Speed USB 2.0 and Video Printer I/F Standard
Dimensions (H x W x D): 762mm x 610mm x 610mm
Weight: 47.3kg
Electrical Requirements: 240v, 50Hz
Bundled Software: ISIS/TWAIN Drivers, Scanning Utility 800,
Canon CapturePerfect 1.0
Other Features: Auto Focus with Manual Override
Auto Exposure with Manual Override
Motorized Zoom Lens with Programmable Memory Keys
Automatic 90° Rotation
Automatic Bimode Sensing with Manual Override (N-P/P-P)
Automatic Border Erasure
Automatic Centering
Options: Fileprint 470, Lenses (7-7.5x, 9-16x, 14-30x, 20-50x, 57x),
Fiche Carrier 190R-II, Roll Fiche Carrier 200, Autocarrier 100C,
FS Controller I, Installation Kit Q, Foot Switch II, Keyboard,
Framing Kit for M8800II
Microlm Scanner 800II
High-Performance Digital Microlm Scanning
• High-speed, three-second scanning
• Easy-to-read, ledger-sized screen
• User-friendly control panel with motorized zoom lens
and image rotation
• Hi-Speed USB Connection
Options and Accessories
Fileprint 470
Type: Desktop Laser Printer
Print Speed (A4): 12 ppm on MS-300II/350II
15 ppm on MS-800II
Resolution: 600 dpi
Stacker Capacity: 250 Sheets
Paper Size: A4/A3
Dimensions (H x W x D): 277mm x 518mm x 439mm
Weight: 19.3kg
Power Consumption: Average 360W or Less
(Energy-Saving Mode:
36W or Less)
Note: DMP Board required for use
with MS-300II/350II
Fileprint 270
Type: Desktop Laser Printer
Print Speed (A4): 13 ppm
Resolution: 600 dpi
Stacker Capacity: 100 Sheets
Paper Size: A4
Dimensions (H x W x D): 216mm x 371mm x 251mm
Weight: 5.7kg.
Power Consumption: Average 266W or Less
(Energy-Saving Mode:
3.4W or Less)
Note: DMP Board required for use
with MS-300II/350II
Put History at Your Fingertips
Sydney
1 Thomas Holt Drive
North Ryde NSW 2113
Ph (02) 9805 2600
Fax (02) 9887 3137
Melbourne
33 Lakeside Drive
Burwood East VIC 3151
Ph (03) 9881 0000
Fax (03) 9881 0316
Brisbane
Southgate Corporate Park
18 Southgate Avenue
Cannon Hill QLD 4170
Ph (07) 3909 5000
Fax: (07) 3909 5068
Adelaide
1 South Road
Thebarton SA 5031
Ph (08) 8201 9100
Fax (08) 8352 5365
Perth
68 Hasler Road
Osborne Park WA 6017
Ph (08) 9347 2222
Fax (08) 9242 4120
Canberra
98 Barrier Street
Fyshwick ACT 2609
Ph (02) 6206 5999
Fax (02) 6206 5933
Auckland
Akoranga Business park
Akoranga Drive
Northcote
Ph (09) 489 0300
Fax (09) 489 0380
canon.com.au
NEW ZEALANDAUSTRALIA
Lenses
MS-800II
GZ7X - 7-7.5x Zoom
GZ9X - 9-16x Zoom
GZ14X - 14-30x Zoom
GZ20X - 20-50x Zoom
GZ57- 57x Zoom
MS-300II
EX7 - Fixed 7x Lens
EZ01 - 9.5-16x Zoom
EZ02 - 16-32x Zoom
EZ03 - 30-55x Zoom
EZ04 - 10-24x Zoom
MS-350II
HX7 - Fixed 7x Lens
HZ01 - 9.5-16x Zoom
HZ02 - 16-32x Zoom
HZ03 - 30-55x Zoom
HZ04 - 20-48x Zoom
Additional Accessories
FP Cartridge 270 for FP270
FP Cartridge 470 for FP470
Sensor Unit 1 for FS Controller I
Sensor Unit 2 for FS Controller I
Sensor Unit 1C for FS Controller I
Sensor Unit 2C for FS Controller I
Installation Kit Q for RFC200/AC100C/FSC-1 3672A004
Foot Switch II
Keyboard for MS-800II
DMP Board for MS-300II/350II
Framing Kit for 800II
Zooming Kit for 300II/350II
