Canon CanoScan FB 320P Manuel utilisateur
CanoScan FB320P/FB620P
Colour Scanner
Product Guide
2
How to Make Best Use of the Manuals
Open the
Package
Briefly explains the procedures from setup and software
installation through to scanning. First-time users of this
scanner should definitely read this guide thoroughly.
Detailed explanation about the scanner and the
software CD-ROM.
iPhoto Express 1.1 and OmniPage Limited Edition
are accompanied by electronic manuals with
detailed instructions on their use.
Electronic Manuals
Electronic Manual
Printed Manual
The manuals that accompany each of the bundled software programs.
Want to know how to
achieve better scanning
results, read ...
Want to know more about how
to handle the scanner and the
software CD-ROM, read ...
When you have read this guide,
finished setting up the scanner and ...
Once you’ve read this and mastered the major elements of ScanCraft CS-P, read ...
Explains how to use the CanoCraft CS-P capture
and editing software and the CanoCraft CS-P
Copy software.
CanoScan FB320P/FB620P
Getting Started
CanoScan FB320P/FB620P
Product Guide
CanoCraft CS-P
Users Guide
Manual for Each
Application Program
Electronic Manual
This Guide
3
How to Use the Product Guide
This guide provides an in-depth explanation of individual topics related to CanoScan FB320P and FB620P
colour scanners and the accompanying software CD-ROM.
If you haven’t already read the Getting Started guide, we recommend that you follow its suggestions
first before consulting this guide.
Organization of this Guide
This guide tackles the scanner and software topics that could not be accommodated in the
Getting Started guide. Each topic is intended to be read as a discrete unit. You need only
read the topics that apply. The guide is divided into four sections.
Chapter 1 Placement and Connections
How to situate the scanner and connect it to your computer and printer.
Chapter 2 The Software CD-ROM
How to use the software CD-ROM and an introduction to the software and elec-
tronic manuals.
Chapter 3 How to Use the Scanner
How to position documents for scanning and how to run the software.
Appendices
Troubleshooting tips and care and maintenance.
*References to Windows in this guide refer to Windows
®
95, Windows
®
98 and Win-
dows NT
®
4.0.
4
Conventions Used in this Guide
This symbol indicates precautions that must be taken when operat-
ing the equipment. Ensure that you read all warnings.
This symbol indicates supplementary operating procedures and other
useful information. Read these notes at your own discretion.
Use of shielded cable is necessary to comply with the technical requirements of EMC Directive.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interfer-
ence will not occur in a particular installation. If this equipment dose cause harmful interference to
radio or television reception, which can be determg]ed by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
*Use of shielded cable is required to comply with Class B limits in Subpart B of Part 15 of FCC Rules.
Do not make any changes or modifications to the equipment unless otherwise specified in this
manual. If such changes or modifications should be made, you could be required to stop operation of
the equipment.
5
Table of Contents
Features of CanoScan FB320P/FB620P Colour Scanners ........................................ 8
Safety Precautions.................................................................................................. 10
Safe Locations ................................................................................................... 10
About the Power Supply .................................................................................. 12
General Handling Precautions ......................................................................... 13
Components Guide ................................................................................................ 15
Chapter 1 Placement and Connections .......................17
The Scanning Unit Lock ......................................................................................... 18
Unlocking the Scanning Unit ........................................................................... 18
Locking the Scanning Unit ............................................................................... 18
Scanner Placement ................................................................................................. 20
Locations to Avoid ............................................................................................ 20
Connecting to a Computer .................................................................................... 22
Connecting the Scanner to a Computer.......................................................... 22
Connecting a Printer to the Scanner ............................................................... 24
Connecting the Power Cord (Turning on the Power).......................................... 26
Chapter 2 The Software CD-ROM ................................27
How to Use the Software CD-ROM....................................................................... 28
Running the CD-ROM Menu Program ............................................................. 28
If the CD-ROM Menu Fails to Appear.............................................................. 29
About the Menu Window ................................................................................ 30
Exiting the CD-ROM Menu Program ............................................................... 31
6
Installing the Software .......................................................................................... 32
Software Titles................................................................................................... 32
Installing the Software ..................................................................................... 33
Starting the Scanner Tutorial ................................................................................ 35
Viewing Electronic Manuals .................................................................................. 36
What is an Electronic Manual? ........................................................................ 36
List of Electronic Manuals ................................................................................ 36
Software for Viewing Electronic Manuals ...................................................... 37
Viewing Electronic Manuals ............................................................................. 38
How to Operate Electronic Manuals ............................................................... 39
Displaying the CD-ROM Contents ......................................................................... 46
Troubleshooting ..................................................................................................... 48
Chapter 3 How to Use the Scanner .............................49
Positioning Documents .......................................................................................... 50
About CanoCraft CS-P............................................................................................ 52
CanoCraft CS-P as a Stand-Alone Application ................................................ 52
CanoCraft CS-P as a TWAIN Driver................................................................... 54
Appendices .....................................................................58
Troubleshooting ..................................................................................................... 59
Problems with Software Installation ............................................................... 59
Problems Starting Software Programs ............................................................ 60
Problems with Scanning ................................................................................... 63
Problems with Printing ..................................................................................... 67
Other Questions ................................................................................................ 68
7
Trademarks
• Adobe®and Acrobat®are trademarks of Adobe Systems Incorporated.
• IBM, IBM PC/AT Series are trademarks of International Business Machines Corp., USA.
• Windows is a registered trademark of Microsoft Corporation in the United States and/or other
countries.
• All other brand names and product names used in this manual are trademarks or registered
trademarks of their respective holders.
Caution
1. No part of this document may be reproduced or transmitted in any form or by any means, elec-
tronic or mechanical, for any purpose, without the express written permission of Canon Inc.
2. The equipment and software described in this guide are subject to change without notice.
3. Notwithstanding the considerable care taken in preparing this guide, please note that Canon Inc.
does not accept liability for any results arising from the operation of the equipment or software
mentioned herein.
4. Please note that scanning copyrighted materials, including documents and images, without permis-
sion from the copyright holder is prohibited by law, except for personal or household use.
5. Portions of this guide are reproduced herein with the permission of Abode Systems Incorporated.
Precautions with Printers....................................................................................... 69
The Scanner and the Pringer Cannot Be Operated at the Same Time ......... 69
Using Windows Printing System (WPS) Printers ............................................. 69
What to Do if a Printer is Not Operating Correctly........................................ 69
Care and Maintenance .......................................................................................... 72
Major Specifications............................................................................................... 74
Index ....................................................................................................................... 76
Customer Support Help Desk ................................................................................ 78
8
Features of CanoScan FB320P/FB620P Colour Scanners
You have purchased one of the world’s finest flatbed colour scanners. The 300-dot-per-
inch (dpi) optical resolution CanoScan FB320P and 600-dpi optical resolution CanoScan
FB620P incorporate the following special features.
Compact Footprint
Ultra compact body [256.0 x 372.5 x 63 millimeters (10.1 x 14.7 x 2.5 inches)]
for an A4/Letter-size scanner. Weighing only 2.0 kilograms (4.4 pounds),
this scanner is so light that it can easily be placed or moved to suit your
convenience.
Simple Connection to a Parallel Port
Easily connected to your computer’s parallel (printer) port with a single
cable (supplied). Your existing printer connects to the scanner’s second
parallel port, creating a daisy chain configuration. See Precautions with
Printers, p.69 of this guide.
Standby Power and Energy-Saving Features
Convenient standby power feature means that the scanner is always ready
to use. On continuous standby operation, it consumes a mere 2.5 watts per
hour and only 5 watts per hour in full operation.
9
Fine Colour Tones and High Resolution
Scanning method employs proprietary Canon LIDE scanning technology in
an ultrahigh-sensitivity CIS (contact image sensor). Reading 10 bits (1,024
colors) per red, green and blue (RGB) channel, the scanner offers 8-bit
output that reproduces brilliant tones at high resolution.
•It is illegal to reproduce currency, bills, negotiable securities and other
documents prohibited by law. Reproduction of such items may be subject
to criminal action.
•It is illegal to reproduce legal certificates, licenses, travel tickets, and
certain public and private documents prohibited from reproduction by
law. Reproduction of such items may be subject to criminal action.
•Please noted that intellectual property protected by copyright may not be
reproduced without the express permission of the copyright holder except
for personal or household use under limited circumstances.
10
Safety Precautions
The following precautions should be observed in handling the equipment described in
this guide.
Safe Locations
• Place the equipment on a flat, level and stable surface.
• Operate the equipment within the following parameters.
Temperature range: 5-35°C (41-95°F)
Humidity range: 10%-90% relative humidity (without condensation)
• Do not place the equipment in places subject to direct sunlight or high
temperatures, which may raise the interior heat level and lead to equip-
ment damage or degraded performance. Use curtains if locations subject
to direct sunlight are unavoidable.
• The parallel cable provided with the scanner is 1.2 meters (3.9 feet) long.
Place the scanner within reach of the computer using this cable. Use this
cable only. Do not substitute other cables.
• Do not place the equipment in areas subject to rapid changes in tempera-
ture or humidity. Refrain from moving the equipment between such
environments to avoid the formation of interior condensation, which
degrades performance. Allow scanner to adjust slowly to the new envi-
ronment before using it if it is moved between temperature extremes.
Ce manuel convient aux modèles suivants
1
Table des matières
Autres manuels Canon Scanner
Canon
Canon 4400F - CanoScan - Flatbed Scanner Manuel utilisateur
Canon
Canon DR 7090C - imageFORMULA - Document Scanner Instructions d'utilisation
Canon
Canon imageFORMULA P-215 Manuel utilisateur
Canon
Canon imageCLASS MF6500 Series Manuel d'installation et d'exploitation
Canon
Canon CanoScan LiDE 220 Guide de configuration
Canon
Canon imageFORMULA CR-80 Manuel utilisateur
Canon
Canon Microfilm Scanner 800II Manuel utilisateur
Canon
Canon DR-4080U Manuel utilisateur
Canon
Canon IMAGE FORMULA DR-6010C Manuel utilisateur
Canon
Canon CanoScan N676U Manuel utilisateur
Canon
Canon imageFORMULA CR-135i High-Volu Manuel d'utilisation
Canon
Canon irispen air 7 Manuel d'instructions
Canon
Canon DR 7090C - imageFORMULA - Document Scanner Manuel utilisateur
Canon
Canon CR-25 - imageFORMULA Desktop Check Scanner Manuel utilisateur
Canon
Canon imageFORMULA DR-7580 Manuel utilisateur
Canon
Canon DR-3010C - imageFORMULA - Document Scanner Instructions d'utilisation
Canon
Canon D1250U2F - CanoScan USB Flatbed Scanner Manuel utilisateur
Canon
Canon imageFormula DR-6010C Manuel utilisateur
Canon
Canon CanoScan 9950F Manuel utilisateur
Canon
Canon imageFORMULA DR-2050SP Manuel utilisateur
