Canon Pixma G1110 Series Manuel utilisateur

Para Começar

Leia Informações Importantes e Sobre

Segurança (adendo) primeiro.

Guía de inicio

Lea primero Información de seguridad

e información importante (apéndice).

Getting Started

Read Safety and Important Information

(addendum) rst.

Instalando a impressora .................................................página 1

Conectando a um computador .......................................página 4

Como segurar

a impressora

Filmes explicativos

Instalación de la impresora.............................................página 1

Conexión con el ordenador ............................................página 4

Cómo sujetar

la impresora

Películas explicativas

Installing the Printer...........................................................page 1

Connecting with Computer ................................................page 4

How to Hold Printer Explanatory Movies

ENGLISH

1. Checking Included Items

□ Power cord

□ Safety and Important Information

□ Getting Started (this manual)

□ Setup CD-ROM for Windows PC

□ Cartridge □ Ink bottle

2. Removing Packing

Materials

1 Remove the packing materials (such as orange

tape) from outside the printer.

2 aOpen the top cover.

bRemove the orange tape and the protective

material and discard them.

3. Installing the Cartridge

1 Open the cartridge locking cover.

2 Take out each cartridge from the package and

remove the label.

3 Remove the protective tape.

Do not touch.

4 Insert the C (color) cartridge on the left and the B

(black) cartridge on the right.

Do not bump it against the

surrounding parts.

5 Close the cartridge locking cover and push it

down.

6 Press down both joint buttons completely.

4. Turning on Printer

1 Close the top cover.

2 Connect the power cord.

Back

Do not connect any cables except the power cord

yet.

3 Press the ON button.

Lit

If the Alarm lamp is ashing, refer to "When a lamp

is ashing" on page 3 to resolve the error.

Flashing

5. Pouring Ink

This product requires careful handling of ink. Ink may

splatter when the ink tanks are lled with ink. If ink gets

on your clothes or belongings, it may not come o󰀨.

1 Open the top cover.

2 Open the ink tank cover.

3 Grab and remove the tank cap of the ink tank.

4 Hold the ink bottle upright and remove the bottle

cap.

5 Insert the nozzle of the ink bottle into the inlet and

stand the ink bottle upside down.

ENGLISH

6 Pour all ink into the ink tank.

Conrm that the ink has been lled to the upper

limit line (A).

(A)

7 Replace the tank cap securely.

8 Close the ink tank cover.

9 Repeat steps 2 to 8 to pour all ink into the

corresponding ink tanks on the right according to

the label.

Conrm that the ink has been lled to the upper

limit line (A).

(A)

Close the top cover.

6. Preparing the Ink System

1 Press the RESUME/CANCEL button, and then

conrm that the ON lamp has changed from lit to

ashing.

Ink preparation takes about 5 to 6 minutes.

Proceed to the next page.

The Alarm lamp is ashing

Count the number of ashes to determine the cause

of the problem.

• 4 times

The cartridges are not installed correctly.

" 3. Installing the Cartridge" on page 1

• 5 times

No cartridges are installed.

" 3. Installing the Cartridge" on page 1

• 9 times

The protective materials are not removed.

" 2. Removing Packing Materials" on page 1

The ON lamp is ashing

Preparing the ink system. This may take about 5 to 6

minutes. Proceed to the next page.

The ON lamp and Alarm lamp ash alternately 8

times

Ink is not prepared normally.

Press the ON button to restart the printer, and then

redo the procedure from "5. Pouring Ink" on page 2.

For all other cases, refer to the Online Manual.

When a lamp is ashing

7. Connecting to Computer

Windows

You need a connection setup for each computer. Proceed with the setup from step 1 for each computer.

1 Start the setup le for either method or method .

Downloading from the Internet

aOpen a web browser ( etc.) on your computer.

bInput the following URL and access the Canon

website.

cSelect Set Up.

dInput the model name of your printer and click OK.

You can select a model name from the list.

eClick Setup.

The procedures for Windows are shown below. If

you are using a computer with an OS other than

Windows, do the setup according to the on-screen

instructions.

fClick Download and download the setup le.

gExecute the downloaded le.

Proceed to step on the next page to

continue.

Using Setup CD-ROM (Windows Only)

■When using Windows 10 or Windows 8.1:

aLoad the Setup CD-ROM in your computer.

bWhen the following message appears on the

right side of your computer screen, click it.

When This Message Does Not Appear (or Has Disappeared)

1. Click File Explorer on the taskbar.

2. Click This PC on the left side of the opened window.

3. Double-click the CD-ROM icon on the right side of the

window.

If the contents of the CD-ROM appear, double-click

Msetup4.exe.

4. Proceed to step d.

ENGLISH

cIf the following screen appears, click Run Msetup4.exe.

dIf the User Account Control dialog box appears, click Yes.

Proceed to step to continue.

■When using Windows 7:

aLoad the Setup CD-ROM in your computer.

b When the AutoPlay screen appears, click Run

Msetup4.exe.

c If the User Account Control dialog box

appears, click Continue.

When AutoPlay Screen Does Not Appear

1. Click Computer from the start menu.

2. Double-click the CD-ROM icon on the right side of the

opened window.

If the contents of the CD-ROM appear, double-click

Msetup4.exe.

Proceed to step to continue.

2 Click Start Setup.If the following screen appears, click Exit.

Follow the on-screen

instructions to proceed

with the setup.

The setup is complete when the printer's ON lamp stops ashing and stays lit. You can

print from your computer.

Loading Paper

1 Open the paper support.

2 Slide the right paper guide to the end.

3 aLoad paper with the print side facing up.

bSlide the right paper guide to align it with the

side of the paper stack.

4 aPull out the paper output tray.

bOpen the output tray extension.

Transporting Your Printer

Check that both joint buttons are pressed down

completely to avoid ink leaks.

Pack the printer in a plastic bag in case ink leaks.

• Pack the printer in a sturdy box so that it is placed

with its bottom facing down, using su󰀩cient protective

material to ensure safe transport.

• Do not tilt the printer. Ink may leak.

• Please handle with care and ensure the box remains

at and NOT turned upside down or on its side, as the

printer may be damaged and ink in the printer may

leak.

• When a shipping agent is handling transport of the

printer, have its box marked "THIS SIDE UP" to keep

the printer with its bottom facing down. Mark also with

"FRAGILE" or "HANDLE WITH CARE".

When relocating the printer, make sure of the following. Refer to the Online Manual for details.

ESPAÑOL

1. Comprobación de los elementos

suministrados

□ Cable de alimentación

□ Información de seguridad e información importante

□ Guía de inicio (este manual)

□ CD-ROM de instalación para Windows PC

□ Cartucho □ Frasco de tinta

2. Retirar los materiales

de protección

1 Retire los materiales de empaquetado (como

la cinta naranja) del exterior de la impresora.

2 aAbra la cubierta superior.

bRetire la cinta naranja y el material

de protección y deséchelos.

3. Instalar el cartucho

1 Abra la tapa de bloqueo del cartucho.

Saque cada cartucho del paquete y retire la etiqueta.

3 Retire la cinta protectora.

No tocar.

4 Inserte el cartucho C (color) en la parte izquierda

y el cartucho B (negro) en la parte derecha.

No golpear contra los

objetos de alrededor.

5 Cierre la tapa de bloqueo del cartucho y presione

hacia abajo.

6 Presione hacia abajo ambos botones de unión

completamente.

4. Encender la impresora

1 Cierre la cubierta superior.

2 Conecte el cable de alimentación.

Atrás

No conecte ningún cable excepto el de

alimentación.

3 Pulse el botón ACTIVADO (ON).

Encendida

Si la luz de Alarma (Alarm) parpadea, consulte

"Si la luz parpadea" en la página 3 para resolver

el error.

Parpadeando

5. Verter la tinta

Este producto un tratamiento cuidadoso de la tinta,

ya que puede salpicar cuando se rellenan de tinta los

depósitos de tinta. Es posible que las manchas de tinta

no salgan de la ropa u otras pertenencias.

1 Abra la cubierta superior.

2 Abra la cubierta del depósito de tinta.

3 Agarre y retire la tapa del depósito del depósito

de tinta.

4 Sujete el frasco de tinta hacia arriba y retire

la tapa del frasco.

5 Inserte el inyector del frasco de tinta en la entrada

y coloque el frasco de tinta boca abajo.
