Canon BJC-80 Manuel utilisateur

BJC-80

USER’S

MANUAL

Canon

Contents

1Introduction

Supplies and Accessories

BJ Cartridges and BJ Tanks

Canon Specialty Papers

Color Image Scanner Cartridge

Portable Kit, Battery Pack, and Universal Adapter

Getting Help From Canon

Servicing the Printer

2Using the Printer With Windows

Installing a Printer Driver

Printing a Document

Printer Setup Within Windows 95

Opening the Printer Properties Dialog Box in Windows 95

Using the Printer Driver in Windows 95

Printer Setup Within Windows 3.1

Accessing the Printing Options

The Windows Tab

Specifying Your Printing Options

Recommended Graphics Settings

Using the Setup Analyzer

Using Cartridge Detection

Printing Speed Versus Color

For Quick Color Printing

For High Quality Color Printing

For Monochrome Printing

Other Ways to Improve Print Speed in Windows

3Paper Handling

Selecting Paper Types

Paper Guidelines

Loading Paper

Automatically Feeding Paper

Auto Feed Guidelines

1 of 3 4/24/98 2:24 PM

Printing on Envelopes

Using Canon's Specialty Papers

Specialty Paper Guidelines

4Maintaining the Printer

Printer Guidelines

Cleaning the Printer

Printing the Test Pages

Starting the Test Pages From Windows

Starting the Test Pages From the Operator Panel

Cleaning the Print Head

Cleaning the Print Head From Windows

Cleaning the Print Head Using the Operator Panel

BJ Cartridge Guidelines

BJ Cartridge and BJ Tank Maintenance

Switching the BJ Cartridges

Replacing a BJ Tank

Storing a BJ Cartridge

Traveling With the Printer

Storing the Printer

5Installing and Using the Battery Pack

Battery Pack Guidelines

Examining the Battery Case

From the Front

From the Back

Attaching the Battery Case to the Printer

Charging the Battery Pack

Using the Printer with the Battery Pack

Battery Pack Capacity

Printing With a Low Battery

Discharging the Battery Pack

Removing a Battery Pack

Removing the Battery Case

6Installing the Color Image Scanner Cartridge

Removing the BJ Cartridge

Installing the Scanner Cartridge

Removing the Scanner Cartridge

2 of 3 4/24/98 2:24 PM

7Troubleshooting

Identifying Your Printer Problem

General Problems

Clearing Paper Jams

Appendix A Specifications

Appendix B Using the IrDA Wireless Interface

Glossary

Index

FCC Regulations

3 of 3 4/24/98 2:24 PM

Introduction

Congratulations on your purchase of the Canon BJC-80 Color Bubble Jet

Printer. We appreciate our choosing this printer to meet your printing needs.

The BJC-80 offers color printing, excellent print quality, and fast print speed

with the convenience of portability and low cost. We are certain you will be

satisfied with its advanced Bubble Jet technology.

This chapter:

Lists the supplies and accessories you can purchase for the printer

Describes Canon's customer support services

1 of 1 4/24/98 2:31 PM

Supplies and Accessories

Your BJC-80 printer supports excellent and unique print media options that will

allow you to produce dazzling, professional, and fun presentations. All of these

print media are specially designed and manufactured to work with your color

printer so you can produce the finest output possible.

Canon has an extensive dealer network equipped to offer you supplies as you

need them. To find a dealer near you, call the Canon referral service at

1-800-848-4123.

If supplies are not available from your local dealer, you can order directly from

Canon by calling 1-800-671-1090.

BJ Cartridges and BJ Tanks

You can use the following BJ cartridges and BJ tanks with the BJC-80 printer:

O BC-11e Color BJ Cartridge

O BCI-11 Color BJ tank

O BCI-11 Black BJ tank

O BC-10 Black BJ Cartridge

O BCI-10 Black BJ tank

O SB-10 Ink Cartridge Storage Box

BJ cartridges contain the Bubble Jet print head and BJ tank(s), while BJ tanks contain ink

only.

1 of 1 4/24/98 2:36 PM

Canon has more engineers dedicated to creating quality ink for providing the

best results for output on Bubble Jet printers than any other organization.

Canon does not prohibit the use of third-party inks and the use of third-part

inks does not invalidate the product's limited warranty. However, Canon cannot

guarantee the quality or performance of your printer when you are using inks

from other suppliers.

Canon's limited warranty does not cover damage caused to Canon's Bubble Jet

products that is attributable to the use of third party parts or supplies, including

inks. The limited warranty remains in effect for its life once that particular

damage has been properly repaired.

For optimum printing results, Canon recommends that you use only Canon BJ

cartridges and BJ tanks.

Canon Specialty Papers

Canon manufactures numerous specialty papers, including:

O Glossy Photo Paper GP-201

O High Resolution Paper HR-101

O Transparencies CF-102

O T-Shirt Transfers TR-101

O Greeting Cards GC-101

O Bubble Jet Paper LC-301 (water resistant)

O Fabric Sheet FS-101

O Back Print Film BF-102

O High Gloss Film HG-101

See Chapter 3, Paper Handling, for details on Canon's Specialty Papers.

1 of 1 4/24/98 2:36 PM

Color Image Scanner Cartridge

This option instantly turns your printer into a high-quality, color sheet fed

scanner. All you have to do is replace the BJ cartridge in the BJC-80 with the

IS-12 Color Image Scanner Cartridge. For this option, you must use an

IEEE-1284-compatible, bi-directional parallel interface cable to connect the

BJC-80 to your computer. Also you must be using Windows 95.

See Chapter 6, Installing the Color Image Scanner Cartridge, for details.

Portable Kit, Battery Pack, and Universal Adapter

To enhance the printer's portability, Canon offers the following items for

supplying power to your printer.

Portable Kit NK-300

The portable kit includes one NiMH battery pack NB-300 and an attachment

unit, which allow you to operate the printer when AC power is not available.

When attached to the printer, this nickel-metal hydride battery pack charges

when the printer is not operating. The battery pack fully charges in about eight

hours. When fully charged, it enables you to continuously print about 200 pages.

NiMH Battery Pack NB-300

You can purchase additional battery packs to use with the Portable Kit NK-300.

Universal Adapter AD-350U/360U

The Universal Adapter supplies power to the printer from any power source

with an appropriate power cord. With the Universal Adapter, you can use the

BJC-80 in various countries where AC power differs from the U.S. standard.

See Chapter 5, Installing and Using the Battery Pack, for details.

1 of 1 4/24/98 2:45 PM

Getting Help From Canon

Canon Computer Systems, Inc. offers a full range of customer technical support

options including*:

24-hour, 7-day-a-week, toll-free automated support for troubleshooting

issues on most current products (1-800-423-2366)

Speak to a technician free of service charge (currently Monday through

Friday, 8:00 a.m. to 10:00 p.m. EST and Saturday, 12:00 p.m. to 6:00

p.m. EST, excluding holidays) for products still under warranty**

(1-757-413-2848)

Speak to a technician (currently $24.99) during holidays and days/hours

not listed above regarding urgent product questions or for products no

longer under warranty (1-800-423-2366)

E-mail support via Canon Computer Systems, Inc. Web site

(www.ccsi.canon.com)

24-hour, toll-free Fax Retrieval System (1-800-526-4345)

24-hour Bulletin Board Service (1-757-420-2000)

*Support program specifics subject to change without notice.

**Refer to individual product information for warranty details.

Canon Canada

Customer support for Canadian residents is available 24 hours a day (seven days a week) at

1-800-263-1121.

In other countries, please contact your Canon dealer.

1 of 1 4/24/98 2:46 PM

Servicing the Printer

The Canon BJC-80 Color Bubble Jet Printer is designed with the latest

technology to provide trouble-free operation. The Warranty Card that comes

with the printer describes Canon's one-year limited warranty for your Bubble Jet

printer. Be sure to read the warranty information to find out about the different

service options available to you.

Save your sales receipt for proof of purchase. In the event that your printer needs service, you will need

your proof of purchase to obtain warranty service.

If you feel your BJC-80 Color Bubble Jet Printer needs servicing, contact Canon

on the World Wide Web to locate the Canon Authorized Service Facility (ASF)

nearest you. If you do not have access to the Web, you can call Canon (see page

1-5 for details).

1 of 1 4/24/98 3:22 PM
