Quick Start Guide

BJC-8200

Color Bubble Jet™Photo Printer

A Universe of Creative Projects.

IMPORTANT

Follow the steps in

this Quick Start Guide

to unpack and set up

your new BJC-8200

Color Bubble Jet

Photo Printer.

IMPORTANT

Follow the steps in

this Quick Start Guide

to unpack and set up

your new BJC-8200

Color Bubble Jet

Photo Printer.

Unpack

Carefully remove all items from

the box.

Note: You will need a parallel or

USB cable.

Remove and discard all shipping

tape and materials.

Important! Always lift the printer by gripping

both sides.

Extend the Paper Support

and Paper Output Tray

Important! Before moving on to Step 3,make

sure your computer is turned off.

Connect the Printer to

the Computer

First, connect the cable to

the printer.

Then, connect the cable to

your computer.

Note: The USB port may be on

the front and/or back of the

computer.

Plug In and Turn On

Plug in the power cord.

Press the POWER button to turn

on the printer.

USB Connection Parallel Connection

High Resolution

Paper HR-101 (3)

Printer

Quick Start Guide

BJ Print Head

BC-50 (1)

Roller Cleaning Plate

Ink Tanks (6)

Install the Cartridge

Lift the front cover. The cartridge holder

moves to the center of the printer.

Remove the shipping material from

the cartridge holder.

Remove the cartridge from the

packaging.

Remove and discard the orange

protective cap.

Important! Do NOT touch the printhead or

metallic contacts.

Raise the blue lock lever until it

snaps into place.

Set the cartridge into the slot.

Lower the blue lock lever until it

snaps into place.

Press down until the BJ tank

snaps into place.

Insert the remaining BJ tanks.

The BJ tanks must be inserted

in the order shown on the color

guide label.

Close the front cover. The

printer automatically performs

the print head cleaning. This

procedure takes approximately

40 seconds.

Insert the BJ Individual Tanks

Pick up the yellow ink tank (BCI-5Y).

Pull up the orange tab and remove and

discard the plastic film.

Twist off and discard the orange

plastic cap.

Insert the ink tank into the correct

slot. (Refer to the color guide on the

blue lever.)

Align the Print Head

Place one sheet of High

Resolution Paper (included in

the box) in the sheet feeder.

Start the alignment procedure.

Windows:

a. Click the Start button,

point to Settings then

select Printers.

b. Right-click the Canon BJC-

8200 icon and select Properties.

c. Click the Maintenance tab

then click the (Print Head

Alignment) icon.

Macintosh:

a. In the software application,

from the File menu, select

Page Setup.

b. Click the Utilities button.

c. Click the down-arrow to select

Test Print.

Install the Printer Software

Windows:

Make sure that the printer is con-

nected, then turn on the computer.

If you see the New Hardware Wizard,

insert the Canon Creative CD-ROM

into your CD-ROM drive and follow

the on-screen instructions. If you

do not see the New Hardware

Wizard, wait until Windows com-

pletes booting up. Then, insert the

CD-ROM into your CD-ROM drive.

If Setup does not start auto-

matically, click on the Start

button on the Windows taskbar

and choose Run. Type X:\Setup

(where "X" is the drive letter of

your CD-ROM drive). Click OK.

Follow the on-screen instructions

to complete installation.

Note: If you do not see the

screen shown above, eject the

CD-ROM and reinsert. Then

repeat the steps above.

Macintosh:

Make sure that the printer is con-

nected, then turn on the computer.

Double-click on the

Canon BJC-8200 icon.

Follow the on-screen instructions

to complete installation.

Click!

d. Click the (Print Head

Alignment) icon.

To print an alignment page, click OK

when prompted.

Compare the different patterns for

each color of your printout.

In the Print Head Alignment panel,

enter the numbers that corresponds

to the pattern that looks smoothest.

Click Send when finished.

For more information about Canon Products,

call 1-800-OK-CANON or visit our Web site at:

www.ccsi.canon.com

Canon Computer Systems, Inc.

2995 Redhill Avenue • Costa Mesa,California 92626 U.S.A.

ENERGY STAR® Compliant

are registered trademarks, BCI,Bubble Jet,Canon Think Tank System,Drop

Modulatio Technology, PhotoRealism,“See What We Mean” and WebRecord

are trademarks and Select Exchange is a service mark of Canon Inc. All other

product and brand names are registered trademarks or trademarks of their

respective owners. Specifications subject to change without notice.All print

speeds based on high-speed draft mode. Print speed will vary depending on

system configuration,software, document complexity, print mode and page

coverage. As an Energy Star® partner,Canon U.S.A.,Inc. has determined that

this product meets the Energy Star® guidelines for energy efficiency.

Printed in U.S.A.

CST-6282-000 CST-5226-000

Canon Technical Support

Canon Printers

Canon Computer Systems, Inc. offers a full range of

customer technical support* options including:

• 24-hour, 7–day-a-week, toll-free automated support for

troubleshooting issues on most current products

(1-800-423-2366)

• Speak to a technician free of service charge (currently

Monday–Friday, 8:00 a.m.-10:00 p.m. and Saturday,

12:00 p.m.–6:00 p.m. EST, excluding holidays) for

products still under warranty** (1-757-413-2848)

• Speak to a technician (currently $24.99 per call) during

holidays and days/hours not listed above regarding urgent

product questions or for products no longer under

warranty** (1-800-423-2366) or for a charge of $2.50 per

minute, to a maximum of $25.00 per call (1-900-246-1200)

• E-mail support and driver downloads via Canon Computer

Systems, Inc. Web site (www.ccsi.canon.com)

• 24-hour, toll-free Fax Retrieval System (1-800-526-4345)

Your device drivers for Windows 98 are included on the

CD-ROM labeled Canon Creative Image and Scanner Setup.

If you do not have a CD-ROM drive, you can obtain the

software as follows:

• Download it from our Web site at www.ccsi.canon.com

• Download it from our Bulletin Board Service at

1-757-420-2000

* Support program specifics subject to change without notice.

**Refer to individual product information for warranty details.

Click!

Uneven

Most even

Uneven

White streaking

obvious

No white

streaking

White streaking

obvious
