Canon LASER SHOT LBP-1210 Manuel utilisateur

SERVICE

MANUAL

REVISION 0

JUN. 2002 RY8-13A3-000

Printed in Japan

Imprimé au Japon

Prepared by

PERIPHERAL PRODUCTS QUALITY ADVANCEMENT DIV.

PERIPHERAL PRODUCTS TECHNICAL DOCUMENTATION DEPT.

CANON INC.

4202, Fukara, Susono-shi, Shizuoka 410-1196, Japan

Use of this manual should

be strictly supervised to

avoid disclosure of confi-

dential information.

PREFACE

This Service Manual contains basic information required for after-sales service of the laser beam

printer LBP-1210 (hereinafter referred to as the printer ). This information is vital to the serv-

ice technician in maintaining the high print quality and performance of the printer.

This manual consists of the following chapters:

Chapter 1: Product information

Features, specifications, operation, and installation

Chapter 2: Operation and Timing

A description of the operating principles and timing sequences of the electrical and

mechanical systems.

Chapter 3: The Mechanical System

Explanation of mechanical operation, disassembly, reassembly and adjustment

procedures

Chapter 4: Troubleshooting

Troubleshooting procedures, reference values and adjustments, maintenance and

servicing, etc.

Appendix: General timing chart, general circuit diagram, etc.

Information in this manual is subject to change as the product is improved or redesigned. All

relevant information in such cases will be supplied in the Service Information Bulletins.

A thorough understanding of this printer, based on information in this Manual and Service

Information bulletins, is required for maintaining its performance and for locating and repairing

the causes of malfunctions.

PREFACE

P - 1

PREFACE

P - 2

DTP system

This manual was produced on an Apple PowerMacintosh G4/500MHz personal computer and output by a

Canon COLOR LASER SHOT LBP-2260PS laser beam printer; final pages were printed on AGFA Selectset

avantra 25.

All graphics were produced with Macromedia FreeHand (J), and all documents and page layouts were

created with QuarkXPress (E).

The video images were captured with SONY degital video camcorder and Radius PhotoDV capture board

system, and modified with Adobe Photoshop(J).

CONTENTS
CHAPTER 1 PRODUCT INFORMATION
PREFACE
P - 3
I. FEATURES................................ 1-1
II. SPECIFICATIONS ...................... 1-2
A. Printer ................................. 1-2
III. SAFETY INFORMATION........ 1-4
A. Handling t e Laser/Scanner
Unit ..................................... 1-4
B. Toner Caution...................... 1-4
C. Ozone Safety ....................... 1-4
IV. PARTS OF THE PRINTER .......... 1-5
A. External View ...................... 1-5
B. Cross Section....................... 1-6
V. INSTALLATION ......................... 1-7
A. Outline ................................ 1-7
B. Selecting a Location ............ 1-7
C. Notes for Storing and
Handling t e EP cartridge.... 1-9
VI. MAINTENANCE AND CHECKS
BY THE CUSTOMER ................. 1-11
VII. OPERATION .............................. 1-12
A. Canon Advanced Printing
Tec nology (CAPT)............... 1-12
B. Microsoft Windows NT4.0 .... 1-14
C. Microsoft Windows
2000/XP .............................. 1-50
D. Microsoft Windows
95/98/Me ............................ 1-61
E. Printing Environment Setting
and Test Printing................. 1-73
I. BASIC OPERATION ................... 2-1
A. Functions ............................ 2-1
B. Basic Operation Sequence.... 2-2
C. Power-ON Sequence ............. 2-3
II. ENGINE CONTROL SYSTEM ...... 2-4
A. Outline ................................ 2-4
B. Engine Controller ................ 2-5
III. VIDEO CONTROL SYSTEM ........ 2-20
A. Outline ................................ 2-20
B. Video Interface signal .......... 2-22
C. Operation ............................ 2-24
D. Interface Controller PCB...... 2-25
E. Ot er Functions .................. 2-27
IV. LASER/SCANNER SYSTEM ....... 2-28
A. Outline ................................ 2-28
B. Laser Control Circuit ........... 2-30
C. Scanner System................... 2-33
V. IMAGE FORMATION SYSTEM.... 2-35
A. Outline ................................ 2-35
B. Print Process ....................... 2-36
VI. PICK-UP/FEED SYSTEM ........... 2-44
A. Outline ................................ 2-44
B. Pick-up/Delivery.................. 2-46
C. Paper Jam Detection ........... 2-47
I. PREFACE.................................. 3-1
II. EXTERNALS ............................. 3-2
A. Locations............................. 3-2
B. External Covers ................... 3-3
III. MAIN UNITS ............................. 3-7
A. Laser/Scanner Unit.............. 3-7
B. Pick-up Unit ........................ 3-8
C. Fixing Unit .......................... 3-9
D. Left Side Plate Unit ............. 3-11
E. Rig t Side Plate Unit ........... 3-11
IV. MAIN PARTS............................. 3-12
A. Locations............................. 3-12
CHAPTER 2 OPERATION AND TIMING
CHAPTER 3 THE MECHANICAL SYSTEM

PREFACE
P - 4
B. Pick-up Roller ...................... 3-13
C. Separation Pad .................... 3-13
D. Transfer C arging Roller...... 3-15
E. Fixing Film Unit .................. 3-15
F. Pressure Roller .................... 3-16
V. SENSORS/SWITCHES ............... 3-17
A. Locations............................. 3-17
B. Paper Out Sensor ................. 3-18
C. Delivery Paper Sensor.......... 3-18
D. Top of Page Sensor .............. 3-18
E. Power Switc ....................... 3-18
F. Test Print Switc ................. 3-18
G. Door Switc ......................... 3-18
VI. MOTOR / FAN / SOLENOID ...... 3-19
A. Locations............................. 3-19
B. Main Motor .......................... 3-20
C. Air Intake Fan Unit.............. 3-20
D. Pick-up Solenoid.................. 3-21
VII. PCBs......................................... 3-22
A. Locations............................. 3-22
B. Interface PCB Unit............... 3-23
C. Engine Controller PCB ......... 3-23
D. Delivery Paper Sensor PCB .. 3-25
E. Top of Page Sensor PCB ....... 3-25
I. PREFACE.................................. 4-1
A. Malfunction Diagnosis
Flowc art ............................ 4-1
B. Initial C eck........................ 4-4
II. IMAGE DEFECTS ...................... 4-5
III. JAMS........................................ 4-12
IV. TRANSPORT DEFECTS ............. 4-15
V. MALFUNCTION
TROUBLESHOOTING................. 4-16
VI. MALFUNCTION STATUS
TROUBLESHOOTING................. 4-17
VII. MEASUREMENT AND
ADJUSTMENT........................... 4-20
A. Mec anical Adjustment ....... 4-20
B. Electrical Adjustment .......... 4-20
C. LEDs, Test Pins, Jumpers,
and Switc es on PCBs.......... 4-21
VIII. MAINTENANCE AND
SERVICING ............................... 4-22
A. Periodic Replacement
Parts.................................... 4-22
B. Expected Servicing Lives of
Consumable Parts ................ 4-22
C. Periodic Service................... 4-22
D. Cleaning During a Service
Visit .................................... 4-23
E. Standard Tools..................... 4-24
F. Special Tools ....................... 4-25
G. List of Lubricants and
Cleaners .............................. 4-25
IX. LOCATION OF CONNECTORS.... 4-26
I. GENERAL TIMING CHART ........ A-1
II. GENERAL CIRCUIT DIAGRAM ... A-2
III. LIST OF SIGNALS ..................... A-3
A. Engine Controller PCB ......... A-3
IV. MESSAGES TABLE.................... A-5
A. Message List ........................ A-5
B. Status Window..................... A-5
APPENDIX
CHAPTER 4 TROUBLESHOOTING

CHAPTER 1

PRODUCT INFORMATION

I. FEATURES................................ 1-1

II. SPECIFICATIONS ...................... 1-2

III. SAFETY INFORMATION........ 1-4

IV. PARTS OF THE PRINTER .......... 1-5

V. INSTALLATION ......................... 1-7

VI. MAINTENANCE AND CHECKS

BY THE CUSTOMER ................. 1-11

VII. OPERATION .............................. 1-12

I. FEATURES

1. Small-Sized Printer with High Speed and High Resolution

This printer is compact enough to set on a desk and has realized high speed of 14 pages per

minute (A4) and high resolution of 600 dpi.

. Employment of Canon Advanced Printing Technology

With Canon Ad anced Printing Technology, data can be processed within a host computer. This

frees the printer from the PDL con ersion and image processing, increasing the speed perform-

ance and reducing the cost.

3. Shortened Wait Time & Low Power Consumption

By adopting an on-demand fixing method that dri es the heater only during printing, the print-

er has shorten the wait time and reduced the consumption power during standby.

4. Employment of USB Interface as a Standard

The printer employs an USB interface as a standard, allowing easy connection to peripherals.

5. Direct Connection to the Network

The printer enables the user to connect directly to the printer by utilizing a specified network

adapter.

CHAPTER 1

1 - 1

II. SPECIFICATIONS

A. Printer

1. Printer Engine

1) Type Desktop page printer

2) Printing method Electrophotography

3) Printing speed (Note1) 14 pages/minute (A4)

4) First print time (Note )

•Face-down 10 seconds or less

•Face-up 9.4 seconds or less

5) Wait time (Note3) 8 seconds or less

6) Resolution

•Horizontal 600 DPI

•Vertical 600 DPI

7) Image formation system

•Laser Semiconductor laser

•Scanning system Rotating four-sided prism mirror

•Photosensiti e drum OPC

•Charging Roller charging

•Exposure Laser scanning

•Toner Magnetic single-component dry toner

•De elopment Toner projection de elopment system

•Toner supply (Note4) Replaceable EP toner cartridge (able to print approx. 2,500 A4-

sized print sheets: with image density set in the middle, and 4 %

dot density ratio)

•Image transfer Roller transfer

•Separation Cur ature separation

•Cleaning Blade

•Fixing method On-demand fixing

8) Pick-up Cassette

Multi-purpose tray

•Pick-up method Pad separation method

•Paper types Plain paper, thick paper, colored paper labels, transparencies,

index cards, and en elopes

•Paper size 76.2 (W) x 127 (L) mm - 216 (W) x 356 (L) mm sized plain paper

(60 - 90 g/m2recommended paper), thick paper (91 - 163 g/m2

recommended paper), and abo e mentioned paper

•Multi-purpose tray

capacity 10 sheets

•Cassette capacity Stack height 25 mm (approx. 250 sheets of 64 g/m2paper)

9) Deli ery Face-down/face-up

•Face-down tray capacity Approx. 125 sheets (64 g/m2)

•Face-up tray capacity One sheet (Paper is to be remo ed manually one by one.)

10) Duplex printing

Manual duplex printing

(Note5) Plain paper (60 - 90 g/m2recommended paper), thick paper (91 -

163 g/m2recommended paper), and colored paper can be printed

duplex.

11) Operating en ironment

Temperature 10 ~ 32.5 ˚C

Humidity 20 ~ 80 % RH

Air pressure 747 ~ 1013 hPa (560 ~ 760 mmHg)

CHAPTER 1

1 - 2

Autres manuels pour LASER SHOT LBP-1210

Table des matières

Autres manuels Canon Imprimante

Canon

Canon 8580A001 Manuel utilisateur

Canon

Canon iP1800 - PIXMA Color Inkjet Printer Manuel utilisateur

Canon

Canon iR1018 Manuel utilisateur

Canon

Canon IMAGECLASS LBP654CDW Manuel utilisateur

Canon

Canon LASER SHOT LBP-750 Manuel utilisateur

Canon

Canon Mobile Printing Guide d'installation

Canon

Canon BJC-55 Series Manuel utilisateur

Canon

Canon DS700 - Selphy Compact Photo Printer Manuel utilisateur

Canon

Canon N 1000 Manuel utilisateur

Canon

Canon iP2600 - PIXMA Color Inkjet Printer Manuel utilisateur

Canon

Canon imageCLASS MF5950dw Instructions de montage

Canon

Canon LBP6020 Manuel utilisateur

Canon

Canon imagePRESS C7000VP Series Manuel technique

Canon

Canon Laser Shot LBP-2900 Manuel utilisateur

Canon

Canon iP1700 - PIXMA Color Inkjet Printer Manuel utilisateur

Canon

Canon iP4200 - PIXMA Photo Printer Manuel utilisateur

Canon

Canon imageCLASS LBP6780x Manuel utilisateur

Canon

Canon iPF610 - imagePROGRAF Color Inkjet Printer Manuel utilisateur

Canon

Canon imagePROGRAF TM-305 Manuel utilisateur

Canon

Canon G2000 series Manuel utilisateur

Canon

Canon MG3560 Guide de configuration

Canon

Canon PRO-6000 Guide de configuration

Canon

Canon TR4600 Series Manuel utilisateur

Canon

Canon Pixma MG3500 Series Manuel utilisateur

Manuels Imprimante populaires d'autres marques

Lexmark

Lexmark 1400 Series Manuel

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Epson

Epson ET-7750 Mode d'emploi

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Epson

Epson SC-F7100 series Manuel utilisateur

Epson

Epson Stylus C40UX Manuel utilisateur

IRA3D

IRA3D POETRY4 Manuel utilisateur

Ricoh

Ricoh Aficio AP400 Manuel utilisateur

BIXOLON

BIXOLON SRP-352plusV Manuel utilisateur

Epson

Epson Stylus Photo PX700W Instructions de montage

Ricoh

Ricoh SP204SF Manuel utilisateur

Star Micronics

Star Micronics futurePRNT TSP100 Manuel utilisateur

Epson

Epson TM-TM88V-i Manuel d'utilisation et d'entretien
