Canon ImageCLASS MF449x Manuel utilisateur

FT6-2954 (000) XXXXXXXXXX Copyright CANON INC. 2022 PRINTED IN XXXXX

Getting Started

Quick Operation P.29

Quick Setup NEXT PAGE

Please read "Important Safety Instructions" before operating this product. After you finish

reading this guide, store it in a safe place for future reference.

The information in this document is subject to change without notice.

https://oip.manual.canon

Getting Started

Introducción

  



Bắt đầu

Langkah Permulaan

Getting Started

Please read "Important Safety Instructions" before operating

this product. P.34

After you nish reading this guide, store it in a safe place for

future reference.

The information in this document is subject to change

without notice.

Introducción

Lea las "Instrucciones de seguridad importantes" antes de usar

este producto. página 44

Cuando termine de leer esta guía, guárdela en un lugar

seguro para futuras consultas.

La información de este documento puede ser modicada sin

previo aviso.



  

 52

   

 

    

 

Bắt đầu

Vui lòng đọc "Các Chỉ dẫn An toàn Quan trọng" trước khi vận

hành sản phẩm này. Tr.60

Sau khi đọc xong cuốn hướng dẫn này, vui lòng lưu trữ sách

ở nơi an toàn để tham khảo trong tương lai.

Thông tin trong tài liệu này có thể được thay đổi mà không

cần thông báo.

Langkah Permulaan

Sila baca "Arahan Keselamatan Penting" sebelum

mengendalikan produk ini. P. 68

Selepas anda habis membaca panduan ini, simpan dalam

tempat yang selamat untuk rujukan masa akan datang.

Maklumat dalam dokumen ini tertakluk pada perubahan

tanpa notis.

You can access

https://oip.manual.canon to read the User's Guide that

describes all functions of this machine.

Puede acceder a

https://oip.manual.canon para leer la Guía de usuario donde

se describen todas las funciones de este equipo.

 

 





Bạn có thể truy cập vào

https://oip.manual.canon để đọc Hướng dẫn người dùng

trong đó có mô tả tất cả chức năng của máy này.

Anda boleh mengakses

https://oip.manual.canon untuk membaca Panduan

Pengguna yang menerangkan semua fungsi mesin ini.

Quick Setup

Before starting the installation

•Removeallofthetape.

•DonotremovethestickerthatcoverstheUSB

port.

Sticker

Installation requirements

Provide a space of 100 mm or more around the

machine.

371 mm 464 mm 48 mm

453 mm 29 mm

Handset

(optional)

272 mm392 mm131 mm

Cassette feeding

module (optional)

Toner cartridge (included with the machine)

* This item

may not be

included

depending

on the

model of the

machine.

Installation of the Machine

Installing the MachineItems Included with the Machine

Quick Setup

Installation of the Machine

Quick Setup

Up to here

Attach the handset (optional).

Quick Setup

Install the cassette feeding module

(optional).

Installation of the Machine

Quick Setup

Next, proceed to configure the machine.

Quick Setup

Conguring the Method of

Connecting to a Computer

About Application Library*

Application Library is an application

that allows you to use useful functions

for routine jobs or other convenient

functions in a one-touch operation

without necessity of making functional

settings every time. You can access each

registered function by simply pressing

the appropriate button displayed in

the Home screen. For the respective

function, see the description displayed in

the Setup Guide.

* This function may not be available, depending

on the model of the machine.

2. Configure the initial settings, according to the

screen.

•Setthelanguageandcountry/region.

•Setthetimezoneandcurrentdate/time.

•Configurethesettingstoprevent

unauthorizedaccess.

•Forthepurposeofconfirmation,enterthe

same PIN twice.

Before starting the configuration

•Themachinecannotbeconnectedto

both wired and wireless LANs at the

same time.

•Ifthemachineisconnectedtoan

unsecured network, your personal

information might be leaked to a third

party. Please be aware and careful of this.

•Themachinedoesnotcomewitha

router. Please have one ready, if necessary.

•Eveninanenvironmentwithoutwireless

LAN router, you can use Access Point

Mode to make a wireless connection to

the machine directly from your mobile

device(DirectConnection).

User's Guide

Specifying the connection method

•ToconnectviawirelessLAN:<Yes>

•ToconnectviawiredLANorUSB:<No>

To connect via wireless LAN

1. Make sure that the computer is connected to a

router properly.

2. Check the network settings on the computer.

Conguring the Machine

Conguring the Initial Settings of

the Machine

Configure the settings in the following order.

Quick Setup

For details

"Setting Up Using the Setup Guide" in the User's Guide

3. TakenoteoftheSSIDandnetworkkey.

•Checkthelabelontherouter. User's Guide

•Thesettingoperationiseasieriftherouteris

provided with a WPS mark. User's Guide

4. Set the access point and network key

according to the screen below.

1. Select<OK>.

2. Select<SSIDSettings>.

3. Select<SelectAccessPoint>.

4. Selecttheaccesspoint(SSID),andselect

<Next>.

5. Select<OK>.

6. Enteranetworkkey,andselect<Apply>.

7. Select<Yes>.

•Waituntilmessage<Connected.>is

displayed.

8. Select<Close>.

•TheIPaddresswillbeautomatically

configured in a few minutes.

5. Install the driver and software.

P.10 "Installing the software"

Now you are finished with the

configuration of the initial settings.

If your machine is provided with the fax

function, proceed to configuring

the fax settings. P.11

To connect via wired LAN

The machine does not come with a LAN cable.

Please have one ready, if necessary.

1. Make sure that the computer is connected to a

router properly.

2. Check the network settings on the computer.

3. Connect the LAN cable.

•Afterconnectingthecable,waitafewminutes

(until the IP address is set automatically).

•IfastaticIPaddresshasbeensetonthe

computer, set the machine's IP address

manually.

4. Install the driver and software.

P.10 "Installing the software"

Now you are finished with the

configuration of the initial settings.

If your machine is provided with the fax

function, proceed to configuring

the fax settings. P.11

Quick Setup

To connect via USB

DonotconnecttheUSBcablebeforeinstalling

the driver. If you did, disconnect the USB cable

from the computer, close the dialog box, and then

perform the following procedure from step 1.

1. Install the driver and software.

P.10 "Installing the software"

•Whenascreenwithinstructionsfor

connecting the USB cable to the machine is

displayed, remove the sticker that covers the

USB port.

Now you are finished with the

configuration of the initial settings.

If your machine is provided with the fax

function, proceed to configuring

the fax settings. P.11

Installing the software

•Theproceduredescribedhereisonlyapplicable

whenyourcomputerrunsontheWindowsOS.

For more details on the software installation

procedure, see the driver's manual.

•Fortheinstallationwhenyourcomputerrunson

themacOS,seethedriver'smanual.

•Yourmachinemaynotcomewiththedriverfor

themacOS,dependingonthetimeofpurchase.

New drivers are uploaded to the Canon website,

and you can download and use the latest one.

If the screen is not displayed properly, re-

inserttheCD-ROM/DVD-ROMorsearchfor

"D:\MInst.exe"ontheWindowsplatform(This

descriptionassumesthat"D:"istheCD-ROM/

DVD-ROMdrivename).

Using the scanner conveniently

Configuring the network settings with "Send

Function Setting Tool" allows you to directly

send scanned originals with e-mail or I-Fax

or store them in a shared folder or on the FTP

server.

In the screen displayed in step 2, select [Start

Software Programs] [Send Function Setting

Tool] to start the Send Function Setting Tool.

Conguring the Machine

Quick Setup
