Canon Color Bubble Jet BJC-5000 Series Mode d’emploi

mBJC-5.00.0

BJC-510’0 .,

PARTS

CATALOG ’

Canon .

0698 SE 0.55-0

mBJC-5.00.0

BJC-510’0 .,

PARTS

CATALOG ’

Canon .

Application

This manual has been issued by Canon Inc. for qualified

person to learn technical theory, installation, maintenance,

and repair of products. This manual covers all localities

where the products are sold. For this reason, there may be

information in this manual that does not apply to your

locality.

Corrections

This manual could include technical inaccuracies or

typographical errors due to improvements or changes in the

products. When changes occur in applicable products or in

the content of this manual, Canon will release technical

information as the need arises. In the event of major

changes in the contents of this manual over a long or short

period. Canon will issue a new editions of this manual.

The following paragraph does not apply to any countries

where such provisions are inconsistent with local low.

Trademarks

The product names and company names described in this

manual are the registered trademarks of the individual

companies.

the copyright laws, this manual may not be copied,

reproduced or translated into another language, in whole or

in part, without the written consent of Canon Inc.

CANON INC.

BJ Printer Technical Support Dept.

16-1, Shimonoge 3-chome, Takatsu-ku, Kawasaki-shi,

Kanagawa 213, Japan

DTP System

This manual was produced on an ApplePower Macintosh

7600/120 personal computer and Canon LBP-2030PS laser

beam printer, final pages were printed on Valityper4300J.

A Canon mo-5001SMagneto-optical Storage Subsystem

with mo-502MMagneto-Optical Storage Disk Cartridge

and mo-IF2Machitoshinterface kit were used for storing

large volumes of page layout, graphic and parts list data for

this manual.

Parts layout illustrations and Logotypes were created using

MACROMEDIAFreeHand7J.

Pattern drawing were scaned by EPSONGT-8000 scanner

with Adobephotoshop.

Documents and page layouts were created using

QuarkXpress3.3J.

Parts lists were created using Helix TecnologiesHerix

Xpressand converted to EPS files.

I. CONTENTS

A. ILLUSTRATION INDEX

B. PARTS LAYOUT & PARTS LIST

C. SCREWS & WASHERS LIST

D. TOOL

E. NUMERICAL INDEX

II. ABOUT THIS MANUAL

A. ILLUSTRATION INDEX

For illustration index, the parts layout

illustrations in this parts catalog are

listed in abbreviated form in order of

illustration number to identify the pages

they appear on. To find an illustration of

a part, see the ILLUSTRATION INDEX.

B. PARTS LAYOUT & PARTS LIST

Parts layout illustration

a) Parts search

Find a part from the parts layout

illustration and find its key number

from the parts list to identify the part

number and name. For screws, nuts,

washers, lock washers, pins, spacers,

see SCREWS &WASHERS LIST.

Note: If parts have the same or similar

shape but different specifications,

their key number is assigned to

several part numbers and names

in the parts list.

b) Parts replacement procedure

To replace parts, the parts layout

illustrations have figure numbers

according to the disassembly procedure

of the product. The parts that require

careful work are shown the illustration.

Parts list

a) FIGURE & KEY No.

The FIGURE & KEY No. column

corresponds to the key numbers

assigned to the parts in the parts

layout illustration.

It also corresponds to the part locations

printed on the PC board.

b) PART NUMBER

The PART NUMBER column gives the

part numbers corresponding to the key

numbers. To order a part, indicate the

part number clearly.

Note: Parts marked NPN are not

service parts.

c) RANK

The service parts with N in the RANK

column are order parts.

d) QTY

The QTY column gives the number of

parts in the corresponding components

layout illustration.

e) DESCRIPTION

The DESCRIPTION column gives the

part names in English.

To order a part, indicate the part

name, too.

C. SCREWS & WASHERS LIST

This is a list of screws, nuts, washers,

lock washers, pins, and spacers.

The QTY column does not give the

number of parts used.

D. TOOL LIST

This is a list of tools used for servicing

products.

E. NUMERICAL INDEX

All the parts listed in this parts catalog

are arranged in order of part number.

You can identify part locations and

names from the NUMERICAL INDEX.

III

Unlatch two claws on the left and the front claw

on the right first. Then, press the part shown by

the arrow to remove Key No. 7.

See Page

B - 3

COVER

FIGURE 2

See Page

B - 5

SHEET FEEDER UNIT

FIGURE 3 See Page

B - 7

FIGURE 1 TRAY & AC ADAPTER See Page

B - 1

A. ILLUSTRATION INDEX

A-1

FIGURE 4 LOGICBOARD&BOTTOMCASE

PURGE UNIT & STAY UNIT

MOTORS

S1 A

When assembling or disassembling Key No. 5,

its edge should not catch the gear.

Remove Key No. 5 by sliding A in

the direction shown by the arrow.

When assembling Key No. 5 use the tension

spring (QY9-0039-000). Remove the spring after

fasten the screw.

When removing the carriage unit,

1 lift up the lever,

2 holding down the stay,

3 pull out the carriage unit.

FIGURE 7 See Page

B - 13 FIGURE 8 See Page

B - 15

See Page

B - 11

CARRIAGE UNIT

FIGURE 6

See Page

B - 9

WASTE INK ABSORBER

FIGURE 5

A-2
