Canon ImageClass LBP320 Series Manuel utilisateur

FT6-2390 (000) XXXXXXXXXX Copyright CANON INC. 2019 PRINTED IN XXXXX

Getting Started

간단 설치 가이드

Quick Operation P.13

Quick Setup NEXT PAGE

https://oip.manual.canon

Please read "Important Safety Instructions" before operating this product. After you finish

reading this guide, store it in a safe place for future reference.

The information in this document is subject to change without notice.

Getting Started

Please read "Important Safety Instructions" before operating

this product.

P.18

After you nish reading this guide, store it in a safe place for

future reference.

The information in this document is subject to change

without notice.

간단 설치 가이드

본 제품을 작동하기 전에 "중요 안전 지침"을 읽으십시오.

24페이지의

본 가이드를 다 읽은 후 향후 참조할 수 있도록 안전한

장소에 보관하십시오.

이 문서의 내용은 예고 없이 변경될 수 있습니다.

You can access

https://oip.manual.canon to read the User's Guide that

describes all functions of this machine.

https://oip.manual.canon l에 액세스하여 본 기기의 모든

기능을 설명하는 사용자 안내서를 읽을 수 있습니다.

Quick Setup

Before starting the installation

• Remove all of the tape.

Installation requirements

Provide a space of 100 mm or more around the

machine.

409 mm

433 mm

376 mm

95 mm

390 mm 275 mm 55 mm

130 mm

Paper feeder (optional)

Toner cartridge (included with the machine)

Installation of the Machine

Installing the MachineItems Included with the Machine

Quick Setup

6Up to here

Installation of the Machine

Quick Setup

8Install the paper feeder (optional).

Quick Setup

Back side

Installation of the Machine

Quick Setup

Next, proceed to configure the machine.

Conguring the Method of

Connecting to a Computer

NOTE

Parts and functions of the operation panel.

P.14 "Start the Operation from the Operation

Panel"

2. Configure the initial settings, according to the

screen.

• Set the language and current date/time.

• Set the USB-Connected PC OS.

• Configure the settings to prevent unauthorized

access.

• For the purpose of confirmation, enter the

same PIN twice.

Before starting the configuration

• If the machine is connected to an

unsecured network, your personal

information might be leaked to a third

party. Please be aware and careful of this.

• The machine does not come with a

router. Please have one ready, if necessary.

User's Guide

To connect via wired LAN

The machine does not come with a LAN cable.

Please have one ready, if necessary.

1. Make sure that the computer is connected to a

router properly.

2. Check the network settings on the computer.

3. Connect the LAN cable.

• After connecting the cable, wait a few minutes

(until the IP address is set automatically).

• If a static IP address has been set on the

computer, set the machine's IP address

manually.

4. Install the driver and software.

P.9 "Installing the software"

Now you are finished with the

configuration of the initial settings.

Conguring the Machine

Conguring the Initial Settings of

the Machine

Configure the settings in the following order.

Quick Setup

To connect via USB

Do not connect the USB cable before installing

the driver. If you did, disconnect the USB cable

from the computer, close the dialog box, and then

perform the following procedure from step 1.

1. Install the driver and software.

P.9 "Installing the software"

Now you are finished with the

configuration of the initial settings.

Installing the software

• The procedure described here is only applicable

when your computer runs on the Windows OS.

For more details on the software installation

procedure, see the driver's manual.

• For the installation when your computer runs on

the macOS, see the driver's manual.

• Your machine may not come with the driver for

the macOS, depending on the time of purchase.

New drivers are uploaded to the Canon website,

and you can download and use the latest one.

If the screen is not displayed properly, re-

insert the CD-ROM/DVD-ROM or search for

"D:\MInst.exe" on the Windows platform (This

description assumes that "D:" is the CD-ROM/

DVD-ROM drive name).

Quick Setup

EnEn

컴퓨터 연결 방식 구성

참고

조작 패널의 부품 및 기능.

20페이지 "조작 패널에서 작업 시작"

화면에 따라 초기 설정을 구성합니다.

• 언어와 현재 날짜/시간을 설정합니다.

• USB 연결 PC OS를 설정합니다.

• 무단 액세스 방지 설정을 구성합니다.

• 확인을 위해 PIN 번호를 두 번 입력하

십시오.

구성을 시작하기 전에

•

기기가 비보안 네트워크에 연결될

경우 개인 정보가 타인에게 유출될

수 있습니다. 이 점을 유의하십시오.

• 본 기기에는 라우터가 제공되지 않

습니다. 필요한 경우 라우터를 준비

해두십시오.

사용자 안내서

유선 LAN을 통해 연결하려면

본 기기에는 LAN 케이블이 제공되지 않습니

다. 필요한 경우 LAN 케이블을 준비해 두십

시오.

컴퓨터가 라우터에 올바르게 연결되어 있

는지 확인합니다.

컴퓨터에서 네트워크 설정을 확인합니다.

LAN 케이블을 연결합니다.

• 케이블을 연결한 후 몇 분간 기다립니다

(IP 주소가 자동으로 설정될 때까지).

• 컴퓨터에 고정 IP 주소가 설정되어 있는

경우 기기의 IP 주소를 수동으로 설정하

십시오.

드라이버와 소프트웨어를 설치합니다.

11페이지 "소프트웨어 설치"

이제 초기 설정 구성이 완료되었습니다.

기기 구성

기기의 초기 설정 구성

다음 순서로 설정을 구성합니다 .

간편 설치
