INSTRUCTION MANUAL
Imported by Maranatha Import Export Pty Limited
13 Hoyle Avenue, Castle Hill, NSW 2154
Phone: 02 9846 0307
E-Mail: [email protected]
www.caffitalysystem.com.au
MODEL S14
z
Introduction:
• Welcome 2
• Safety Warnings 3
• Symbols Guide 4
Instructions:
• Machine Components 5
• First Time Use 6
• Correct Use Of The Buttons 7
• Dispensing Beverages - Using Factory Settings 8
• Turning On The Appliance 9
• Adjusting The Cup/Mug Height 9
• Programming The Quantity Of Beverage In A Cup 10
• General Operating Indications 11
Cleaning and Maintenance:
• Daily Maintenance 12
• Descaling 13
• Saving Energy 15
Miscellaneous:
• Restore Original Settings (RESET) 16
• Troubleshooting 17
• Technical Data 18
• Instructions for Use and Disposal 18
• Caffitaly System Care Contact 18
INDEX
1.
2.
CONGRATULATIONS
on the purchase of your New Caffitaly System S14 Machine.
Thank you for having chosen our product and for your confidence in
our company. You can savour your favourite hot beverages at any
time of the day with our appliance by choosing one of the capsules
that Caffitaly System offers you. For example: an espresso, hot
chocolate or a tea will be ready in just a few seconds.
z
• This appliance is intended to be used in domestic environments.
Not suitable for Professional use.
• Use ONLY Caffitaly System compatible capsules. Damage caused by using incorrect
capsules will void the guarantee.
• Use the TEA button (Blue) for Tea and Hot Water ONLY!
Incorrect use of this button will cause damage to the machine and void the guarantee.
• Use of the appliance in any manner other than as directed herein could cause harm to
persons and void the guarantee. The manufacturer will not be responsible for injury or
damage resulting from improper use of the appliance.
• After removing the packaging, check that the appliance is not damaged. If damage is
detected, or upon the first sign of a defect (unusual noise or odours), or if any other
problem is detected inside the appliance, do not use it and contact the Maranatha
Customer Service Line on 02 9846 0307.
• The packaging elements (plastic bags, etc.) must not be left within reach of children as
they are potential sources of danger.
• Only use the appliance if the power cord is intact, if the cord is damaged it must be
replaced by the manufacturer or qualified person, due to potential electrical safety risks.
Contact the Maranatha Customer Service Line on 02 9846 0307.
• Use and store the appliance indoors. Make sure the electrical elements, plug and cord
are dry. Never submerge the appliance in water. Protect the appliance from sprays and
drips. Water and electricity together constitute a risk of electrocution.
• Do not leave the power cord near hot surfaces, sharp edges or other sharp objects.
• Only connect the appliance to power outlets complying with the requirements of the law.
Make sure that the power supply voltage matches the rating shown on the data plate
on the bottom of the appliance.
• Do not pull on the power cord to disconnect it. Remove the plug carefully to avoid
damage to the outlet.
SAFETY WARNINGS
Carefully read the following instructions. In this way you will avoid the risk of personal
injury and damage to the appliance.
GUARANTEE
VOID
X
X
3.
Continued on next page... >>
• This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of the appliance by a person
responsible for their safety. Children should be supervised to ensure that they do not
play with the appliance
• Never place your hands inside the capsule compartment. There is a risk of injury.
• Do not open the lever while the appliance is operating. If the lever is raised during the
delivery of a product, the machine can emit jets of hot water. Risk of Burns!
• Do not remove parts of the appliance, OR insert objects into the openings. This could
cause electric shocks! Any operation that is not described in this instruction manual
should only be performed by an Authorised Support Centre. Please contact the
Maranatha Customer Service Line on 02 9846 0307.
• Install the appliance on a solid, stable, heat resistant surface with an incline no greater
than 2 degrees.
• When the Indicator Light blinks ORANGE and the machine emits 3 beeps, it is advisable
to perform the descaling cycle, as illustrated Page 13. If you do not, the appliance may
be damaged.
• Clean the appliance carefully and regularly with a soft cloth and a mild detergent, do
not use alkaline cleaning agents. If it is not cleaned, the build-up that forms may be
hazardous to your health. Unplug the appliance and allow it to cool before cleaning.
• Unplug the machine if you do not expect to use the appliance for a long period of time
(leaving on vacation, etc.).
SAFETY WARNINGS - Continued
SYMBOLS GUIDE
CAUTION: This is the safety warning symbol. It is used to call your attention
to possible risks of personal injury. Abide by the safety messages provided
in order to avoid possible injury or death.
This is the symbol
used to highlight some
actions that will optimise
the use of this appliance.
Not
Dishwasher
Safe
Maintenance
Tips
4.
z
Power Cord
MACHINE COMPONENTS
5.
Dispensing
Spout
Lever for
opening and
closing Capsule
Compartment
Water Tank
Water Tank
Cover
Capsule
Compartment
Used Capsule
Drawer
Power
On/Off
Switch
Drip Tray
Diagram 1:
Diagram 2:
TEA Button-120ml
(Tea & Hot Water)
(Blue)
Double Espresso
Button
60ml (White)
Single Espresso
Button
30ml (White)
Indicator Light
Orange=Descale
Red=Check System
FIRST TIME USE
We would also recommend following these steps after not
having used the machine for a long period of time.
Continued on next page... >>
Along with the
Button lights,
the Indicator
Light will also
alternately blink
RED.
4.
Plug in
appliance.
Switch machine
on using the
On/Off Switch.
2.
Fill the tank with
fresh, still water
(either by filling
through the
water tank cover
or removing
the water tank).
1.
Press any of the
buttons. The machine
will draw water
through the system.
(This will take about
30 sec). When done
the the Red Indicator
Light will switch off.
6.
7.
Place a large
empty container
(at least 250 ml)
under the coffee
dispensing spout.
!
6.
NOTE: If the Red
Indicator Light
continues to blink
and no water has
been extracted,
repeat step 6.
Make sure the
lever is closed.
*Ensure there is no
capsule in machine.
After Step 6
has successfully
completed all the
button lights will
continue to blink, the
machine is warming
up. (This will take
about 1 min)
ON
5.
3.
z
Tea or Hot Water Button - 120mL
(Lit in BLUE) should only be used for
tea capsules or to add hot water.
Do not use the Tea Button
for espresso coffee or
any other beverages except tea
(capsules appropriate for the Tea
Button will be indicated on the
packaging). Inappropriate use of this
button may damage the machine
and void your warranty.
BEFORE FIRST USE - Continued
CORRECT USE OF THE BUTTONS Single Espresso Button - 30ml
(Lit in WHITE). Use for dispensing a
single espresso shot.
When in doubt follow the
directions on the capsule box
regarding required button use.
Diagram 3:
7.
Double Espresso Button - 60ml
(Lit in WHITE). Use for dispensing
a double espresso coffee for a
stronger beverage. Also suitable
for Hot Chocolate, Chai Latte and
similar beverages (NOT TEA).
6.
8.
When all the
button lights
remain steadily
lit, rinse by
pressing the Tea
Button. Press
again to repeat
rinse cycle.
10.
At the end of this
operation, pull
draw forward and
empty any water
from the used
capsule draw.
All button lights
lit steadily, your
machine is now
ready to use.
9.
DISPENSING BEVERAGES - Using Factory Settings
MAINTENANCE TIP: Between uses, to ensure optimum product delivery, remove
used capsule from machine and rinse by pressing any button.
NOTE: The quantity of beverage dispensed can be programmed according to
personal taste and the size of the cups or mugs used. Please refer to chapter
“Programming the quantity of beverage in a cup” on Page 10.
8.
Raise the lever
to eject the used
capsule into the
drawer.
Close the lever.
Insert the
capsule, pressing
it gently into
place.
Close the lever
fully and place
a cup or mug
under the coffee
dispensing spout.
Raise the lever to
open the capsule
compartment.
Switch the
machine on
using the On/
Off Switch.
Wait about 1
min for machine
to warm up.
Press and release
the button
corresponding
to the type of
beverage you want
as per Diagram 3
on Page 7.
5.
The selected
beverage button will
blink and machine
will stop dispensing
on reaching the
programmed
quantity and emit
a beep.
6.
ON
7. 8.
4.
3.
2.
1.
z
TURNING ON THE APPLIANCE - DAILY USE
ADJUSTING THE CUP/MUG HEIGHT
Fill the tank with
fresh, still water.
The appliance
is initially set for
the use of large
cups or mugs.
The appliance can be adjusted for the use of mugs or espresso cups.
This raises the
height of the
cup towards
the dispensing
spout.
1.
3.
Switch the
machine on
using the On/Off
Switch.
Wait about 1 min
for machine to
warm up.
For best results
using espresso
cups, you can lift
and rotate the
grid placed over
the drip tray.
2.
4.
9.
When all the
button lights blink
continuously,
the machine is
warming up.
(This will take
about 1 min)
When all the
button lights are
lit steadily, your
machine is ready
to use.
ON
1.
3.
2.
4.
For very tall
mugs/latte
glasses the
drip tray can
be removed
completely.
