Cabletron Systems SmartSwitch 9000 Document technique

9034041

SmartSwitch 9000

9X4XX Series

Local Management Appendix

(FW Version 1.12.00 or Greater)

Appendix

9X4XX Series Local Management

This appendix supplements the SmartSwitch 9000 Local Management User’s Guide,

part number 9032089-01.

The latest firmware version (1.12.00) features new Local Management screens that

are described in this appendix. For further information about Cabletron Product

User’s Guides, refer to http://www.cabletron.com/manuals.

9X4XX Series Local Management

Access Control Screen

The Access Control Screen, Figure 1, allows a user to assign up to 16 IP addresses,

in order to limit remote management access of the SmartSwitch 9000 modules.

This feature can be enabled or disabled, and it does not operate when a user

accesses it locally through the Environmental Module EPIM port or through a

module front panel port.

To access the Access Control Screen, go to the Module Configuration Menu

Screen, Then, select the SNMP Configuration option. Finally, select the Access

Control List option.

Figure 1. Access Control Screen

SmartSwitch 9000 Local Management

Access Control

Module Name: 9F426-02 Firmware Revision: 01.12.00

Slot Number: 10 BOOTPROM Revision: 01.01.01

Access Control Lists: [DISABLED]

IP Addresses

0.0.0.0 0.0.0.0

SAVE EXIT RETURN

9X4XX Series Local Management

Access Control Screen Fields

The following information briefly explains each Access Control Screen field:

Access Control Lists (Toggle)

This field can be either of the following:

• DISABLED

• ENABLED

IP Addresses (Modifiable)

These fields allow a user to input up to 16 specific IP addresses that are allowed to

access the management feature.

Saving Modifications

To save your modifications of the values on the Access Control Screen:

1. Use the arrow keys to highlight SAVE at the bottom of the screen, then press

the Return key.

2. When the message “SAVED OK” displays, the edits you have made are saved.

If you exit without saving, the message “NOT SAVED -- PRESS SAVE TO

KEEP CHANGES” displays. If you exit without saving, your edits will be lost.

Exiting the Access Control Screen

To exit the Access Control Screen, use the arrow keys to highlight RETURN,and

then press the Return key.

9X4XX Series Local Management

Flash Download Configuration Screen

The Flash Download Configuration Screen, Figure 2, allows a user to replace the

informationstoredintheFlashmemorywithanewimagefiledownloadedfrom

a TFTP server. Before downloading an image to the device, copy the image to the

network TFTP server. Additionally, NVRAM parameters can be downloaded to a

designated configuration server or uploaded to a module using this feature.

To access the Flash Download Configuration Screen from the Module

Configuration Menu Screen, use the arrow keys to highlight the FLASH

DOWNLOAD CONFIGURATION menu item, and then press the Return key.

The Flash Download Configuration Screen displays.

Note: This feature is supported in firmware versions greater than 1.12.00.

Figure 2. Flash Download Configuration Screen

SmartSwitch 9000 Local Management

Flash Download Configuration

Module Name: 9F426-02 Firmware Revision: 01.12.00

Slot Number: 10 BOOTPROM Revision: 01.01.01

Download Method: [RUNTIME]

Reboot After Download: [YES]

TFTP Gateway IP Addr: xxx.xxx.xxx.xxx

Download Server IP: xxx.xxx.xxx.xxx

Download File Name: C:\IMAGES\SSX\11011.FLS

Last Image Server IP: xxx.xxx.xxx.xxx

Last Image File Name: C:\IMAGES\SSX\11011.FLS

Transfer Status: Transfer Successful

SAVE EXIT RETURN

9X4XX Series Local Management

Flash Download Configuration Screen Fields

The following information briefly explains each Flash Download Configuration

Screen field:

Download Method (Selectable)

This field indicates the download or upload method used by the device, and can

be one of the following:

• RUNTIME - The module attempts a TFTP download based on the IP address

and file name entered in the fields at the bottom of the Flash Download

Configuration screen. With the RUNTIME method, these additional fields are

displayed:

- Download Server IP (Modifiable) - This field is used to select the IP address

of the TFTP server to be used for the Flash download.

- Download File Name (Modifiable) - This field is used to select the complete

TFTP server path and file name of the new image.

• DOWNLOAD CONFIG - Saves all NVRAM parameters to a specified

Download server that can be accessed later using the UPLOAD CONFIG

option. With the DOWNLOAD CONFIG method, these additional fields are

displayed:

- Configuration Server IP (Modifiable) - This field is used to select the IP

address of the Configuration server to be used for the Flash download.

- Configuration File Name (Modifiable) - This field is used to select the

complete Configuration server path and file name of the new image.

• UPLOADCONFIG - Sends NVRAM parameters back to the module.To use the

UPLOAD CONFIG option, a user must first assign an IP address to the

module. With the UPLOAD CONFIG method, these additional fields are

displayed:

- Configuration Server IP (Modifiable) - This field is used to select the IP

address of the Configuration server to be used for the Flash download.

- Configuration File Name (Modifiable) - This field is used to select the

complete Configuration server path and file name of the new image.

9X4XX Series Local Management

Reboot After Download (Toggle) (Only available for the RUNTIME option)

This field notifies a user that the module will reboot after the download is

complete. This field toggles between the following:

• YES - The module reboots after the download is completed.

• NO - The module continues using the existing firmware image and stores the

new firmware image in Flash memory. When the module is reset or during the

next power up, the device boots from Flash memory using the new image.

TFTP Gateway IP Addr (Modifiable)

This field displays the IP address of the TFTP gateway server defined on the

General Configuration screen.

Last Image Server IP (Read-Only)

This field displays the IP address of the server used for the previous Flash

Download.

Last Image File Name (Read-Only)

This field displays the complete path and file name of the last image downloaded

to Flash.

Transfer Status (Read-Only)

This field displays the status of the current or most recent download or upload.

Using RUNTIME to Download an Image File

To download an image file using RUNTIME:

1. Use the arrow keys to highlight the Download Method field.

2. Press the Space Bar to select RUNTIME.

3. Use the arrow keys to highlight the Reboot After Download field.

4. Use the Space Bar to select either of the following:

• YES - A user wants the module to reboot after the download is completed.

• NO - A user wants the module to store the new image in Flash memory

until the module is manually reset.

5. Use the arrow keys to highlight the TFTP Gateway IP Addr field.

6. Set the IP address of the TFTP gateway server (this defaults to the same IP

address as that set in the TFTP Gateway IP Addr field on the General

Configuration Screen).

7. Use the arrow keys to highlight the Download Server IP field.

9X4XX Series Local Management

8. Enter the IP address of the TFTP server using the standard quad dotted octet

format.

9. Use the arrow keys to highlight the Download File Name field.

10. Enter the complete path and file name of the image stored on the download

server.

11. Use the arrow keys to highlight EXECUTE at the bottom of the screen and

press the Enter key. The message “RUNTIME DOWNLOAD. WILL COMMIT

TO FLASH.” displays in the event message line at the top of the screen. The

new image is downloaded into Flash memory.

9X4XX Series Local Management

PHY Configuration (Full Duplex FDDI)

The PHY Configuration Screen, Figure 3, provides support for the DEC (Digital

Equipment Corporation) Full Duplex FDDI option.

Note: This screen is used only on the 9F4XX-series modules.

To access the PHY Configuration Screen, go to the Module Configuration Screen.

Then, select the FDDI Configuration option. Finally, select the PHY

Configuration option.

Figure 3. PHY Configuration Screen

SmartSwitch 9000 Local Management

PHY Configuration

Module Name: 9F426-02 Firmware Revision: 01.12.00

Slot Number: 10 BOOTPROM Revision: 01.01.02

PORT # REQUESTED MODE OPERATION MODE LINK STATE PORT STATUS

1AUTONEGOTIATE HALF DUPLEX - DAS No Link ENABLED

2AUTONEGOTIATE HALF DUPLEX - DAS No Link ENABLED

SAVE SET ALL PORTS: AUTONEGOTIATE EXIT RETURN
