Bunn H5E Manuel utilisateur

Features

Related Products

ITEM#

PROJECT

DATE

For current speciﬁcation sheets and other information, go to www.bunn.com.

Patents Apply

INTERNATIONAL

12/06 E2

18.9 Litre (5 Gallon) Hot Water Dispenser

• Dispenses up to 21 gallons (79 litres) of boiling water (H5X) per hour for

food prep and cleaning.

• Precise temperature 72º–212ºF (22.2ºC-100ºC) ensures consistent, high

quality results when preparing large amounts of mashed potatoes, gravy,

cheese sauce, gelatin, oatmeal and many more foods.

• Locate hot water at preparation site to increase speed, safety and efﬁciency

of kitchen staff.

• Can be mounted for space savings.

H5E/H5X

Dimensions: 28.5”H x 7.1”W x 17.5”D

(72.4cm H x 18.03cm W x 44.5cm D)

*International models may vary in appearance.

Hot Water Dispenser

Easy Clear® EQHP-10

Product No. : 39000.0004

Easy Clear® EQHP-10L

Product No. : 39000.0001

1. Wall Mount Bracket (side)

Product No. : 12542.0000

2. Wall Mount Bracket (front)

Product No. : 13125.0001

3. Container Holding Shelf

Product No. : 12599.0000

4. Drip Tray

Product No. : 02497.0000

BUNN® practices continuous product research and improvement. We reserve the right to change speciﬁcations and product design without notice. Such

revisions do not entitle the buyer to corresponding changes, improvements, additions or replacements for previously purchased equipment.

All dimensions shown in centimeters. Bunn-O-Matic Corporation owns all copyrights relating to materials in this publication. Please contact BUNN to request permission to reproduce any portion of this publication.

Dimensions & Speciﬁcations

Bunn-O-Matic® Corporation - 1400 Stevenson Drive Springﬁeld, Illinois 62703 • USA • +1-217-529-6601 • Fax +1-217-529-2827 • www.bunn.com

varies with application

Model Product # Volts Amps Tank Heater Total Temp Gal./Hr. Gal./Hr. Shipping Cord Agency

Watts Watts Settings cold water hot water Weight Attached

input 35˚F input 140˚F

(1.6˚C) (60˚C)

H5MA 12500.0056 230 16 3670 3700 200˚F 9.1 gal 25 gal. 32 lbs. No

93.3˚C (39.4 L) (94.6 L) (14.5 kg)

H5EA 12500.0062 230 16 3670 3700 204˚F 8.9 gal. 23.5 gal. 32 lbs. No

95.5˚C (33.7 L) (89 L) (14.5 kg)

H5EA 12500.0063 230 16 3670 3700 85˚/105˚F 32 lbs. No

29.4˚C/40.6˚C (14.5 kg)

H5XA 12500.0064 230 16 3670 3700 212˚F 8.5 20.9 gal. 32 lbs. No

100˚C (32.2 L) (79.1 L) (14.5 kg)

H5EA 12500.0067 230 17.4 3675 4000 90˚F 32 lbs. No

32.2˚C (14.5 kg)

Electrical: All models require 2-wires plus ground service rated 220-240V, single-phase, 50/60 Hz.

Note: Supplied strain relief on rear side of machine.

Plumbing: 20-90 psi (138-621 kPa). Machine supplied with 1⁄4" OD male ﬂare ﬁtting.
