For current speciﬁcation sheets and other information, go to www.bunn.com.

Patents Apply 09/07 E2

5 Gallon Hot Water Machine

• Dispensesupto18gallons(68.14liters)ofboilingwater(H5X)perhourfor

foodprepandcleaning.

• Precisetemperature(72º–212ºF)(22.2ºC-100ºC)ensuresconsistent,high

qualityresults.

• Locatehotwateratpreparationsitetoincreasespeed,safetyandefciency

ofkitchenstaff.

• Preparelargeamountsofmashedpotatoes,gravy,cheesesauce,gelatin,

oatmeal,&manymorefoods.

• Internationalelectricalcongurationsavailable.

• Availablewith3”and8”faucetextensions.

Model H5E/H5X*

Dimensions:28.5”Hx7.1”Wx17.5”D

(72.4cm H x 18.03cm W x 44.5cm D)

* International models may vary in appearance.

Model Agency Listing

H5E

H5X

5 Gallon Hot Water Machine

Easy Clear®EQ-11-TL

ProductNo.:30344.1001

Dimensions:

⁄

"Hx

⁄

"Wx

⁄

"D

40.3cmHx9.2cmWx11.5cmD

Easy Clear®ED-11-TL

ProductNo.:30244.1001

Dimensions:

⁄

"Hx

⁄

"Wx

⁄

"D

36cmHx12.9cmWx12.9cmD

1. Wall Mount Bracket (side)

ProductNo.:12542.0000

 Dimensions:30"Hx131⁄2"Wx41⁄2"D

 76.2cmHx34.29cmWx11.43cmD

2. Wall Mount Bracket (front)

ProductNo.:13125.0001

 Dimensions:301⁄2"Hx81⁄2"Wx151⁄4"D

 77.47cmHx21.59cmWx38.74cmD

3. Container Holding Shelf

ProductNo.:12599.0000

 Dimensions:63⁄4"Wx21"D

 17.15cmWx53.34cmD

4. Drip Tray

ProductNo.:02597.7998

E9006.7001B

BUNN®practicescontinuousproductresearchandimprovement.Wereservetherighttochangespecicationsandproductdesignwithoutnotice.Such

revisionsdonotentitlethebuyertocorrespondingchanges,improvements,additionsorreplacementsforpreviouslypurchasedequipment.

Alldimensionsshownininches. Bunn Corporation owns all copyrights relating to materials in this publication. Please contact Bunn Corporation to request permission to reproduce any portion of this publication.

Dimensions & Speciﬁcations

Bunn-O-MaticCorporationofCanada-280IndustrialPkwy.S.Aurora,OntarioL4G3T9•905-841-2866•Fax905-841-2775•www.bunn.com

CANADA

Model Product # Volts Amps Tank Total ˚F/˚C Capacity/Hr. Capacity/Hr. Cubic Weight Cord

Heater Watts Settings cold water hot water ft

lbs/kgAttached

Watts input 35˚F/1.7˚C input 140˚F/60˚C

H5E-15-120 12500.6031 120 12.5 1500 1500 155-200/68.3-93.3Varies with application 4.1/.116 34/15.4 Yes*

H5E-15-120 12500.6000 120 12.5 1500 1500 85-115/29.4-46.1Varies with application  4.1/.116 34/15.4 Yes*

H5E-40-208 12500.6008 208 19.2 4000 4000 200/93.3Varies with application 4.1/.116 34/15.4 No

H5X-40-240 12500.6004 240 16.7 4000 4000 212/100 7.3gal/27.6liter 14.7gal/55.7liter 4.1/.116 34/15.4 No

H5X-40-208 12500.6002 208 19.2 4000 4000 212/100 7.3gal/27.6liter 14.7gal/55.7liter 4.1/.116 34/15.4 No

H5X-15-120 12500.6001 120 12.5 1500 1500 212/100 3.7gal/14.0liter 8.1gal/30.7liter 4.1/.116 34/15.4 Yes*

H5X-60-240 12500.6005 240 25.0 6000 6000 212/100 9.9gal/37.5liter 18.6gal/70.5liter 4.1/.116 34/15.4 No

H5X-60-208 12500.6003 208 28.8 6000 6000 212/100 9.9gal/37.5liter 18.6gal/70.5liter 4.1/.116 34/15.4 No

*Power cord (NEMA 5-15P) 15 Amp-120V machine only.

Electrical: Models-15Modelshaveattachedcordsetandrequire2-wiregroundedservicerated120V,singlephase,60Hz.

Othermodelsrequire2-wiresplusgroundservice,single-phase.Suppliedstrainreliefonrearsideofmachine.

Plumbing: 20-90psi(138-621kPa).Machinesuppliedwith1⁄4"(6.3mm)ODmalearetting.

 





 



















7!4%23500,9

#/..%#4)/./$

45"%8&,!2%

342!).%2&,/7

#/.42/,-/5.4%$

).4%2.!,,9

0/7%23500,9

#/..%#4)/.
