SPECIFICATION SHEET

BEST BY BROAN P.O. BOX 140 HARTFORD, WISCONSIN 53027

REFERENCE QTY. REMARKS Project

Location

Architect

Engineer

Contractor

Submitted by Date

ISER222 SERIES

RANGE HOODS

Mount range hood so bottom of hood is

24” minimum above cooking surface.

70D 99042854E

Tubular, wrap-around utensil rail serves as both a

stunning accent and a practical addition to this

elegant angular design.

FEATURES

•Italian design

•Island mount

•Finishes: 304 Stainless Steel #4 Brushed, White, Black,

Polished Brass, Brushed Copper

•Utensil rail is chrome when ordering stainless steel finish,

brass rail with all other finishes

•Size: 70cm x 122cm (27-9/16” x 48”)

•Telescopic flue accommodates 8’ to 9’ ceilings

•8” round duct connector/backdraft damper

•Halogen lighting (4 x 20 watt, Type JC 12V 20W G4 Base

- bulbs included) with two-level lighting provides bright

cooktop illumination and a low nighttime setting

•Advanced, multispeed electronic push-button controls

with individual speed indicators

•Quiet variable speed centrifugal blower with high efficiency

motor produces 1000 CFM of exhaust

•Delay timer control automatically shuts off range hood after

ten minutes

•Special control indicates when it’s time to clean the filter

•Dishwasher-safe filter features a quick-release latch and

decorative cover plate

•Heat SentryTM - automatically turns blower to high speed

when excess cooking heat is detected

OPTIONS

•Flue extension for 10’ ceiling (Model FEXTISER222)

•Replacement grease filters available

•Replacement bulb (Part No. SB02300891)

•Exterior blower version available (IEX222)

SPECIFICATIONS

VOLTS AMPS CFM SONES DUCT

120 6.26 1000 10.0 8” round

HVI-2100 CERTIFIED RATINGS comply

with new testing technologies and

procedures prescribed by the Home

Ventilating Institute, for off-the-shelf

products, as they are available to

consumers. Product performance is rated

at 0.1 in. static pressure, based on tests

conducted in AMCA’s state-of-the-art test

laboratory. Sones are a measure of

humanly-perceived loudness, based on

laboratory measurements.

BEST BY BROAN P.O. BOX 140 HARTFORD, WISCONSIN 53027

ISER222 SERIES WIRING

7-13/16”

10-7/8”

Wiring Box

Air Outlet Ø 7-7/8”

Controls Side

ISER222 SERIES MOUNTING
