Bresser RAPTOR Manuel utilisateur
WARNING! • Hot surfaces! Do not touch the heat nozzle and the construction plat-
form in operation!
• Danger! Moving parts in printer may cause injury. Do not wear glo-
ves or other sources of entanglement in operation!
Quickstart Guide
3D printer
Art. No. 2010400
2
More informationen, updates or software
Visit our website using the following QR code or weblink to nd additional information, available
updates or software for this product or related accessories:
www.bresser.de/P2010400
After Sales Support / Service
We oer an individual service for this product beyond the purchase. If you have any problems with
the product, our support team will be happy to assist you.
For a smooth process, please keep the following information handy for possible inquiries:
• Warranty/Service card
• Article number and Product description
• Date of purchase and dealer
Contact details:
e-Mail: service.3d@bresser.de (preferred communication)
Internet: www.bresser.de/c/de/service
Phone*: 00 800 – 63 43 7000
Service hours:
Monday to Friday (except national public holidays) 9:00 a.m. to 3:00 p.m. (CET)
* free hotline throughout Europe
Warranty
Please refer to the separate warranty & service card for any warranty information.
3
3D printer Filament Quickstart guide Service card
Inhalt des Sets
3D-Drucker
Netzteil
Schraubendreher
Leim PTFE-Rohr Fett
Steckschlüssel
Reinigungsstiftwerkzeug Innensechskantschlüssel
Stromkabel USB-Kabel Fadenführungsrohr
Fadenspule Schnellstartanleitung Kundendienstkarte
Set contents
Power adapter
Glue stick
Power cable
Phillips screwdriver
USB cable
1.5/2/2.5mm
Hex wrench (3x)
microSD memory card
8mm wrench
Warranty & Service
After Sales Support / Service
Our customer service is available to help you with possible problems with or questions about our
products.
For a smooth process, please keep the following information handy for possible inquiries:
• Warranty/Service Card
• Article number and product description
• Date of purchase and dealer
Contact details:
e-Mail: service.3d@bresser.de (preferred way of communication)
Internet: www.bresser.de/c/en/service
Phone*: 00 800 – 63 43 7000
Service hours:
Monday to Friday (except national public holidays) 9:00 a.m. to 3:00 p.m. (CET)
*free hotline throughout Europe
4
Parts overview
1. microSD card slot
2. LCD screen
3. Top opening
4. Function rotary knob
5. Power port
6. USB port
7. Extruder with nozzle
8. Printing platform and
magnetic print pad
9. Filament spool holder
10. Spring lever
11. Pneumatic lament input
5
Unpacking and Assembling
4. Insert the Filament guide tube into the pneumatic connector on top of the extruder.
1. Remove the printer and accessories from the packaging and verify that you have all
the parts listed on page 3.
2. Remove the eggshell carton and
plastic bag from the printer and place
it on a table or desk.
3. Remove the carton block in the printer
6
Installation
7. Using a pair of scissors or side cutters, cut about an inch o the end of the lament,
then gently straighten the end of the lament. Squeeze the lever on the extruder,
insert the lament from the bottom until you encounter resistance, then release the
lever.
6. Flip the power switch on the AC power adapter to the ON position (I). After the printer
nishes booting, you will see the following wizard. Press the knob on top of the printer
to select [Next] on the Welcome screen, then again to select [Next] on the [STEP 1:
LOAD FILAMENT] screen.
5. Ensure that the power switch on the AC power adapter is in the OFF position (O). Plug
the DC barrel connector on the AC power adapter into the power port on the right side
of the printer. Plug the included AC power cable into the AC power adapter, then plug
the other end into a nearby AC power outlet.
7
10. Press the rotary knob to select [Print From SD] from the menue on the LCD screen.
Rotate the knob to highlight a .gcode le on the microSD card. Press the knob to begin
printing the highlighted object.
11. Once the print is nished, remove the magnetic print pad from the printing platform.
Bend it a little bit to remove the object. Replace the magnetic print pad onto the
printing platform.
Installation and rst print
8. Press the Knob to start loading lament. Once lament starts extruding from the nozzle,
press the Knob again to stop extrusion, then press the Knob to select the [Continue]
option.
9. Take the included microSD™ card out of the accessory box. Insert the card into the
microSD card slot to the left of the LCD Screen. Press the knob to select [Next] on the
wizard.
Bresser GmbH
Gutenbergstr. 2 · DE-46414 Rhede
Germany
www.bresser.de · [email protected]
Errors and technical changes reserved.
Quickstart_2010400_Raptor-3D-printer_en_BRESSER_092020a
