USER INSTRUCTIONS EN
OVEN
Table of Contents
https://brandt.com/
BVCert.6011825
Important: Before using your appliance, read this user guide carefully
to familiarise yourself more quickly with its operation.
The label "Origine France Garantie" assures the consumer the traceabi-
lity of a product by giving a clear and objective indication of the source.
Brandt brand is proud to ax this label on products from our French
factories based in Orléans and Vendôme.
Dear Customer,
You have just acquired a BRANDT product and we would like to thank you.
We have designed and made this product with you, your lifestyle and your
requirements in mind so that it meets your expectations. We have devoted our
know-how, our innovative spirit and the passion that has been guiding us for
over 60 years.
In an eort to ensure that our products meet your requirements in the best
possible way, our Customer Relations department is at your disposal, to answer
all your questions and to listen to all your suggestions.
Visit our website www.brandt.com where you will nd our latest innovations,
as well as useful and complementary information.
BRANDT is delighted to assist you every day and hopes you get the most out
of your purchase.
3
Table of Contents
SAFETY INSTRUCTIONS .................................................................4
ENVIRONMENT ...........................................................................6
Environment ....................................................................................... 6
Energy saving councils ...................................................................... 6
INSTALLATION ..............................................................................7
Choice of location and tting .......................................................... 7
Electrical connection......................................................................... 8
DESCRIPTION OF THE OVEN........................................................9
Presentation of the oven................................................................... 9
Display and buttons ........................................................................... 9
Accessories........................................................................................ 10
HOW TO USE YOUR APPLIANCE ................................................12
Setting .............................................................................................. 12
Setting menu ................................................................................... 12
Cocking mode................................................................................ 14
Starting cooking.............................................................................. 15
CLEANING..................................................................................17
Cleaning inside - outside................................................................ 18
ANOMALIES AND SOLUTIONS...................................................20
SERVICE CALLS ..........................................................................21
Service calls..................................................................................... 21
COOKING AID...........................................................................21
Cooking tables................................................................................ 22
Recipes with yeast.......................................................................... 24
Performance testing....................................................................... 25
Automatic combined steam functions ....................................... 26
4
Safety instructions
When you receive the appliance,
unpack it or have it unpacked
immediately. Check its general
appearance. Make a note of any
reservations on the delivery slip
and keep a copy.
Important:
This appliance may be used
by children aged 8 years and
older, and by persons with
impaired physical sensorial or
mental capacities, or without
experience or knowledge, if they
are supervised or have received
prior instructions on how to use
the appliance safely and have
understood the risks involved.
Children must not be allowed to
play with the appliance. Cleaning
and maintenance operations must
not be carried out by children
without supervision.
— Children must be supervised to
prevent them from playing with
the appliance.
WARNING:
— The appliance and its accessible
parts become hot during use. Be
careful not to touch the heating
elements inside the oven. Children
under 8 years old must not be
allowed near it unless they are
supervised at all times.
— This appliance is designed to
cook with the door closed.
— Before pyrolytic cleaning of
your oven, remove all accessories
and any thick deposits.
— During cleaning, the surfaces
may become warmer than under
normal conditions of use. It is
advisable to keep children away
from the appliance.
— Do not use a steam cleaner.
— Do not use abrasive cleaning
products or hard metal scrapers
for cleaning the oven’s glass door,
as they could scratch the surface
and cause the glass to shatter.
WARNING :
Make sure the appliance is
disconnected from the power
before replacing the lamp in order
to avoid the risk of electric shock.
Change the lamp only when the
appliance has cooled down. To
unscrew the view port and the
light, use a rubber glove, which
will make disassembly easier.
IMPORTANT - READ CAREFULLY AND RETAIN FOR
FUTURE USE.
This user guide is available for download on the brand’s web-
site.
5
Safety instructions Safety instructions
The electrical plug must
remain accessible after
installation.
— It must be possible to
disconnect the appliance from the
power supply, either using a plug
or by tting a switch on the xed
wiring system in accordance with
installation rules.
— If the power cable is damaged,
it should be replaced by the
manufacturer, its after-sales
service department or by a
similarly qualied person in order
to avoid danger.
— This appliance may be installed
either under a worktop or in a
cabinet column, as indicated on
the installation diagram.
— Centre the oven in the unit so
as to ensure a minimum distance
of 10 mm between the appliance
and the surrounding unit. The
material of the unit supporting the
appliance must be heat-resistant
(or covered with a heat-resistant
material). For greater stability,
attach the oven to the unit with 2
screws through the holes provided
on the side panels.
— In order to avoid overheating,
the appliance must not be installed
behind a decorative door..
— This appliance is designed to
be used for domestic and similar
applications such as:
Kitchen areas for the sta of shops,
offices and other professional
premises; Farms; Use by clients
of hotels, motels and other
residential type establishments;
guest house type environments.
— The oven must be turned o
when cleaning inside the oven.
Do not modify the characteristics
of this appliance; doing so could
be dangerous.
Do not use your oven as a larder
or to store any items after use.
Installation
6
Environment
Environment Installation
CARE FOR THE ENVIRONMENT
- This appliance’s packing materials are recyclable.
Please recycle them and help protect the environ-
ment by depositing them in municipal containers
provided for this purpose.
- Your appliance also contains many recyclable
materials. It is therefore marked with this logo to
indicate that used appliances must not be mixed
with other waste.
The appliance recycling organised by your manu-
facturer will therefore be conducted in optimum
conditions, in accordance with European directive
2002/96/EC on electrical and electronic equipment
waste.
Consult your local authority or your retailer to lo-
cate your nearest used appliance drop-o points.
- We thank you for your help in protecting the
environment.
ENERGY SAVING COUNCIL
Keep the oven door closed during baking.
Installation Environment
Environment
7
Installation
CHOICE OF LOCATION AND FITTING
The diagrams show the dimensions of a cabinet
that will be able to hold your oven.
This appliance may be installed either under a
worktop (A) or in a column (B). If the cabinet
is open, its opening at the back must be 70 mm
maximum.
Install the oven in the furniture. To do this,
remove the rubber stops and pre-drill a 2-mm
diameter hole in the wall of the furniture to
avoid splitting the wood. Attach the oven with
the two screws. Re-position the rubber stops.
Tip
To be certain that you have properly in-
stalled your appliance, do not hesitate to
call on a household appliance specialist.
Warning :
If the electrical installation in your residence
requires any changes in order to hook up
your appliance, contact a professional elec-
trician.If the oven malfunctions in any way,
unplug the appliance or remove the fuse cor-
responding to the sector where the oven is
hooked up.
560
585
583
558
592
544
545
50
20
50
20
A
583
558
560
585
545
592
544
50
20
50
20
C
B
D
Description of the oven
8
Installation Installation
Description of the oven
Neutral
(N)
Phase
(L)
bleu
green yellow
Black,brown or
red
Warning
The safety wire (green-yellow) is connected
to the appliance’s terminal and must be
connected to the earth terminal of the elec-
trical set-up.
The fuse in your set-up must be 16 amperes.
ELECTRICAL CONNECTION
Your oven must be connected with a (standard)
power cable with 3 conductors of 1.5mm2(1 live
+ 1 neutral + earth) which must be connected to
a 220-240V~single-phase grid by means of a 1
live + 1 neutral + earth CEI 60083 standard power
socket or via an all-poles cut-o device in compli-
ance with the installation rules.
We cannot be held responsible for any accident resulting
from inexistent, defective or incorrect earthing.
• Prior to rst use
Before using your oven for the rst time, heat it
with the door closed for about 15 minutes on the
highest temperature. to break in the appliance.
The mineral wool surrounding the oven cavity may
initially give o a particular odour due to its com-
position. You may also notice smoke development.
This is normal.
Terminal
Description of the oven
Installation Installation
9
Description of the oven
PRESENTATION OF THE OVEN
This oven has 6 positions for the accessories: shelf supports 1 to 6.
Control panel
Light
Door
Handle
A
B
C
D
DISPLAY AND BUTTONS
• Display
Cooking time
End of cooking
Keypad lock
Timer
Temperature indicator
Pre-heating indicator
Door lock
Set clock and cooking time
Set temperature
- button
+ button
1
1 2 3 4
• Buttons
2
3
4
1
2
3
4
5
6
A
B
C
D
10
Description of the oven Description of the oven
Warning :
Under the eect of heat, the accessories
may become deformed without aecting
their function. They will return to their origi-
nal shape when cooled.
Warning :
Remove the accessories and supports
from the oven before beginning pyrolysis
cleaning.
ACCESSORIES
• Anti-tip safety grid
• Multi-purpose 45mm drip pan
The grid can be used to hold all dishes and moulds
containing foodstus to be cooked or browned. It
can be used for barbecues (to be placed directly
on the grid).
Insert the anti-tip safety grid towards the back of
the oven.
When inserted in the supports under the grid with
the handle towards the oven door, it collects juice
and fat from grilling, and can be used half-lled
with water as a double-boiler.
When inserted in the supports with the handle
towards the oven door, it is ideal for baking cookies,
shortbread and cupcakes. Its tilted surface makes
it practical and easy to use. Can also be inserted
into the supports under the grid to collect juice and
fat from grilling.
• 20mm pastry dish
The new sliding rail system makes food more
practical and easier to handle as the trays can be
eortlessly pulled for simpler handling. The trays
can be completely removed, providing full access.
Their stability ensures that food can be handled
safely, reducing the risk of burns. This means that
you can take food out of the oven far more easily.
•Sliding rail system
Ce manuel convient aux modèles suivants
4
Table des matières
Autres manuels Brandt Four
Brandt
Brandt BOH1325X Manuel utilisateur
Brandt
Brandt BKS7131BB Manuel utilisateur
Brandt
Brandt FE 200 Manuel utilisateur
Brandt
Brandt FC609MUB Manuel utilisateur
Brandt
Brandt FC405MH Manuel utilisateur
Brandt
Brandt BKV6132X Manuel utilisateur
Brandt
Brandt FC265MHB Manuel utilisateur
Brandt
Brandt FC-26MEB Manuel utilisateur
Brandt
Brandt BOP7537LX Manuel utilisateur
Brandt
Brandt BOP7568 BB Manuel utilisateur
Brandt
Brandt FE 210 Manuel utilisateur
Brandt
Brandt BOH7534BB Manuel utilisateur
Brandt
Brandt FV1245X Manuel utilisateur
Brandt
Brandt FV200 Manuel utilisateur
Brandt
Brandt FC 222 Manuel utilisateur
Brandt
Brandt BXP6555W Manuel utilisateur
Brandt
Brandt FP667XS1 Mode d’emploi
Brandt
Brandt BKV7132LX Manuel utilisateur
Brandt
Brandt FC405MB Manuel utilisateur
Brandt
Brandt BOE1000X Manuel utilisateur
