OPERATING

INSTRUCTIONS UEZ – Intrusion Alarm

30.0221.9701A2

Introduction and Notes on Security 3. . . . . . . . . . . . . . . . . .

Explanation of Display and Operating Elements 4. . . . . . .

Display/operating panel 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Individual/group displays (LED) 5. . . . . . . . . . . . . . . . . . . . . . .

Message processing keys / softkeys with display 6. . . . . . . . .

Fixed function keys 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Cursor keys 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Key switch 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Sealed switch 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Message Display/Processing

Explanation of display messages 11. . . . . . . . . . . . . . . . . . . . .

Messages with message processing keys 12. . . . . . . . . . . . .

Calling up a list of all message types 13. . . . . . . . . . . . . . . . .

Alarm Verification: see page 48

continued on next page

Message Display/Processing

Resetting the central control unit 14. . . . . . . . . . . . . . . . . . . .

Resetting detector zones/message types 15. . . . . . . . . . . .

Resetting with “General Reset” 16. . . . . . . . . . . . . . . . . . . . .

Arming the System 17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Timer–Controlled Switching

Timer–controlled activation (TCA) 18. . . . . . . . . . . . . . . . . . .

Timer–controlled deactivation 19. . . . . . . . . . . . . . . . . . . . . .

Operation Authorisation

User Code 20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Basic/complete/maintenance operation 21. . . . . . . . . . . . .

Table of Contents

614–30.0212.0270–01 A2 2

Table of Contents

Operating the Functions in the Main Menu

Calling up/quitting the Main Menu and Submenus 24.

Viewing the Alarm Counter 24. . . . . . . . . . . . . . . . . . . . . . .

Areas (Status Interrogation)

–Interrogation of the zone status 25. . . . . . . . . . . . . . . . . . .

–Switch block type lock lamps on/off 26. . . . . . . . . . . . . . . .

–Skip detector zones and malfunctions 26. . . . . . . . . . . . .

Internal Program

–Switch internal program on/off 27. . . . . . . . . . . . . . . . . . . .

–Edit internal program 28. . . . . . . . . . . . . . . . . . . . . . . . . . . .

Switch Visual Test on/off 29. . . . . . . . . . . . . . . . . . . . . . . . .

Timer

–Switch timer channels on/off 30. . . . . . . . . . . . . . . . . . . . . .

–Change switching times 31. . . . . . . . . . . . . . . . . . . . . . . . .

Background Memory

–View background memory 32. . . . . . . . . . . . . . . . . . . . . . .

–Going to a certain event 33. . . . . . . . . . . . . . . . . . . . . . . . .

(event number, date, latest)

–Select/search events 34. . . . . . . . . . . . . . . . . . . . . . . . . . . .

–Print events 35. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

–Diagnosis 36. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Operating the Functions in the Main Menu

Changing the Operator Code 37. . . . . . . . . . . . . . . . . . . . . . .

Switching on/off

–Switch group list on/off 38. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

–Switch detector zones on/off 39. . . . . . . . . . . . . . . . . . . . . . .

–Switch detectors on/off 40. . . . . . . . . . . . . . . . . . . . . . . . . . . .

–Switch tableau points on/off 41. . . . . . . . . . . . . . . . . . . . . . . .

–Switch sounders/strobes on/off 42. . . . . . . . . . . . . . . . . . . . .

Maintenance 43. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Blocking

–Block zones 44. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

–Block detectors 45. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

System Parameters

–Change date/time 46. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

–Change PC interface 47. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Alarm Verification 48. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

614–30.0212.0270–01 A2 3

Introduction and Notes on Security

BOSCH Telecom Service Center:

Telephone:

The UEZ must only be operated by trained personnel!

For safety reasons and to prevent unauthorised

operation, only these personnel should know the

authorisation code required to operate the system.

What information is contained in these operating instruc-

tions?

These instructions contain all the information that you require

to operate the UEZ.

What information is not contained in these operating in-

structions?

The operating instructions do not contain any information re-

garding general or special security–related knowledge.

Therefore: Ensure that you are familiar with all of the

security–related procedures and regulations of your area (for

example, alarm procedures, plans of action, alarm

organisation, etc.).

Destruction of the UEZ display screen resulting from an exter-

nal source does not pose any direct risk for the user (for exam-

ple, explosion, implosion, dangerous gases, etc.).

Contact the Service Department if the UEZ is damaged.

When cleaning the surface of the UEZ (especially the operating

and display unit), do not use any corrosive or abrasive cleaning

materials and do not allow any liquid to leak into the interior of

the equipment.

614–30.0212.0270–01 A2 4

Explanation of Display and Operating Elements

Display/OperatingPanel

Message processing keys/

softkeys

code

stop

102

ABC

DEF

GHI

JKL 5

MNO 6

PQR

reset

STU 8

VWX 9

enter

CE 0+1

./:

inter–

nation help ? test

Display

panel

Key switch Cursor keys

Keys for character input

and fixed function keys

Individual/group

displays (LED)

Quit or cancel

function

Sounders/strobes off

Buzzer off

∑

Individual zone display

(LED)

red = alarm

Sealed switch for

“General reset”

Maintenance

Continue

System

Malfunction

Message

Internal alarm

External alarm

Alarm

Internal on

Code operation

Operation

Transmission unit

Control

Signal unit

Tableau

Switch Off

614–30.0212.0270–01 A2 5

Alarm (red) illuminates when an external or internal alarm, a pre–alarm, or a fault in the external alarm system

occurs. The alarm is stored and signalled by a buzzer.

External Alarm (red) illuminates if an alarm is reported to an external emergency position or if external

sounders and strobes are triggered.

Internal Alarm (red) illuminates if an internal alarm is triggered but not reported to an external emergency

position.

Message (red) illuminates if a message is issued. The message is stored and the buzzer is activated.

Explanation of Display and Operating Elements

Individual/groupdisplays (LED)

Maintenance

Continue

System

Malfunction

Message

Internal Alarm

External Alarm

Alarm

Internal on

Code operation

Operation

Transmission unit

Control

Signal unit

Tableau

Switch Off

Malfunction (yellow) illuminates when any kind of malfunction occurs. The appropriate malfunction message

is usually stored (not, for example, in case of a network malfunction) and the buzzer is activated. If the

type of malfunction cannot be reset by the authorised operating personnel, contact the Service Department.

System (yellow) illuminates when a system malfunction (logic malfunction) occurs.

Continue (yellow) illuminates if a triggered or malfunctioning zone or a ring or stubline malfunction has

been removed from the surveillance system to arm a detector area. After disarming the detector area, con-

tact the Service Department.

Operation (green) illuminates when the central control unit is ready for operation.

Code operation (yellow) flashes when the correct operator code has been entered.

Internal on (green) illuminates if one internal program has been switched on.

Maintenance (yellow) illuminates during a system maintenance.

Control (yellow) illuminates when a system function is triggered.

Transmission unit (red) illuminates if the transmission unit has been triggered. External emergency per-

sonnel (for example, police or surveillance personnel) have been alerted.

Switch Off (yellow) illuminates if detectors, zones, tableau items, or sounders/strobes are deactivated. The

indicator switches off when all devices are reactivated.

Tableau (yellow) illuminates if central or zone tableau items are deactivated. In this case, the tableau items

are not triggered.

Signal Unit (yellow) illuminates if a connected sounder/strobe is deactivated. The sounders/strobes do

not transmit any alarm in this case. The indicator switches off when all devices are reactivated.

Indicator illuminates

Indicator flashes

614–30.0212.0270–01 A2 6

Explanation of Display and Operating Elements

Message processing keys / softkeys with display

Message processing keys/softkeys:

Using the 4 message processing keys/softkeys, the messages/functions shown

above the keys in the display can be called up.

The text shown in the display above each key indicates the operation of each key.

Pressing the key displays further messages/functions with notes regarding

the additional operating steps.

Quiescent condition:

If the central control unit is in the quiescent condition, e.g. no messages have appeared and no functions have been called up from

the main menu, the screen saver appears in the display.

MESSAGES DETECTOR MESS.TYPE ACTIONS

Display:

In the clear text display, all existing messages, such as

intrusion, malfunction and switchoff, as well as notes re-

garding operation are displayed in the main menu.

1INTRUS. INT ZONE 0035 –16

Storage room entrance 1st floor

2INTRUS. INT ZONE 0040 –07

Offfice building south 1st floor

614–30.0212.0270–01 A2 7

Explanation of Display and Operating Elements

Fixed function keys

Switch on/off

sounders/strobes

Switch off buzzer The indicator flashes and the buzzer sounds when the following messages occur:

–Alarm

–Message

–Malfunction

–Maintenance alarm

When this key is pressed, the buzzer is deactivated and the flashing indicator is switched

off.

This key returns to the previous level or interrupts a function that has been started.

Return to the

operating level stop

code

Start/quit operation

authorisation

FThis key calls up the main menu containing the submenus and their additional functions.

Call up the

main menu

Enter the operator code. When this key is pressed, the optical/acoustic signal transmit-

ters and the buzzer are deactivated.

The flashing indicator is switched off.

This key starts code input or quits code operation.

For a detailed description, see the section Operation Authorisation, page 20.

614–30.0212.0270–01 A2 8

reset

Reset

Display individual/groups

(LEDs), check display and

buzzer

test

This key triggers the reset processes. After successful reset of all messages, the

system returns to the quiescent condition.

For a detailed explanation, see the section Resetting, pages 14 and 15.

When this key is pressed, all the LED indicators, the display of the operating panel and

the buzzer are verified for correct functioning. The indicator test finishes automatically

after 3 seconds. Then the “Software version”is displayed for 3 seconds.

enter

Confirm input This key is used to confirm the input of characters.

Call up the

message list

When this key is pressed, the display shows a list of all message types with the asso-

ciat–ed message counters.

For a detailed explanation, see the section Call up a List of all Messages, page 13.

∑

Call up help texts help? If this key is pressed, an explanatory text appears in the display. This text provides

further information regarding the menu in which the operator is currently located;

however, the text does not contain any alarm information.

Explanation of Display and Operating Elements

Fixed function keys

614–30.0212.0270–01 A2 9

Entering digits If digits have to be entered (e.g. entering the detector zone number), they can be entered

at the position indicated by the cursor .

Incorrect inputs (e.g. digits) can be deleted with this key.

Correcting inputs

ABC

JKL

MNO

DEF

Increase the

number value by 1 +1 This function has not yet been realised.

Language toggling inter–

natio–

nal

This function has not yet been realised.

Explanation of Display and Operating Elements

Fixed function keys

614–30.0212.0270–01 A2 10

Explanation of Display and Operating Elements

Cursor keys / key switch / sealed switch

Move to the next position by

pressing the appropriate key

up/down

left/right

Cursor keys

The requested position of

the cursor within the display

can be selected using the

appropriate cursor keys

(e.g. when selecting

detectors, detector zones or

functions).

Additional information is

displayed.

123456

78 9101112

Storage room entrance 1st floor

102

Key switch The assigning of operating functions to the position of the key switch can be programmed,

e.g. –internal program on/off

–code operation on/off

Sealed switch

“General Reset”If the operator cannot reset the system (e.g. after a sabotage alarm), resetting can be per–

formed without entering an operator code by actuating the sealed switch. This should only

be done after prior consultation with the Service Department. (“General Reset”is only pos-

sible if programmed).

Table des matières

Autres manuels Bosch Système de sécurité

Bosch

Bosch Solution 16plus Manuel utilisateur

Bosch

Bosch Security System Manuel utilisateur

Bosch

Bosch DS938Z Manuel utilisateur

Bosch

Bosch FMC-210-DM-G-B Manuel utilisateur

Bosch

Bosch DIP-3042-2HD Manuel utilisateur

Bosch

Bosch Plena Power Amplifier Manuel utilisateur

Bosch

Bosch Security Systems Manuel utilisateur

Bosch

Bosch DINION 4000 Instructions d'utilisation

Bosch

Bosch Plena LBB 1965 Manuel utilisateur

Bosch

Bosch SE3000 Series Manuel du produit

Bosch

Bosch B926F Manuel utilisateur

Bosch

Bosch LTC 5136/61 Manuel utilisateur

Bosch

Bosch LTC 8016/90 Manuel utilisateur

Bosch

Bosch DS304 Manuel utilisateur

Bosch

Bosch LTC 1311/20 FlexiDome I Manuel utilisateur

Bosch

Bosch MAP 5000 Series Manuel utilisateur

Bosch

Bosch Security Systems Manuel utilisateur

Bosch

Bosch PRAESENSA Comment utiliser

Bosch

Bosch NDA-U-PA0 Manuel utilisateur

Bosch

Bosch ICP-CP508 Manuel utilisateur

Bosch

Bosch ND 200 LSN Manuel utilisateur

Bosch

Bosch FW5.50 Instructions de montage

Bosch

Bosch ISW-BMC1-M82X Manuel utilisateur

Bosch

Bosch D9000 Series Guide de configuration

Manuels Système de sécurité populaires d'autres marques

Inner Range

Inner Range Concept 2000 Manuel utilisateur

Climax

Climax Mobile Lite R32 Instructions de montage

CADDX

CADDX NX-6 Manuel utilisateur

FBII

FBII XL-31 Series Manuel utilisateur

Johnson Controls

Johnson Controls PENN Connected PC10 Manuel utilisateur

Aeotec

Aeotec Siren Gen5 Manuel utilisateur

Blaupunkt

Blaupunkt SA 2700 Manuel utilisateur

IDEAL

IDEAL Accenta Manuel du propriétaire

AJAX

AJAX DoubleButton Manuel utilisateur

Swann

Swann SW-P-MC2 Manuel utilisateur

Ecolink

Ecolink Siren+Chime Manuel utilisateur

Digital Monitoring Products

Digital Monitoring Products XR150 Manuel utilisateur

EDM

EDM Solution 6+6 Wireless-AE Manuel utilisateur

Highway Safety Group

Highway Safety Group EA401 Manuel utilisateur

Siren

Siren LED GSM Manuel utilisateur

Detection Systems

Detection Systems 7090i Instructions de montage

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 Manuel utilisateur

Siemens

Siemens FDM273 Manuel utilisateur
