Intrusion Alarm Systems | B926F Fire keypad, SDI2
B926F Fire keypad, SDI2
www.boschsecurity.com
uFire keypad with fire function keys: ACK, SILENCE,
RESET, and DRILL
u2-line LCD display with up to 32 character point,
user, and area names
uSimple menu-style user interface with dedicated
function buttons for common commands, including
status indication
uQuickly identifiable, visual indicators for critical
system statuses
uSimple installation with self-locking base and
chassis design, plus built-in bubble level
The B926F Fire Keypad is a fully supervised SDI2
device for fire applications.
Each keypad has user-adjustable backlit keys, a display
that shows system messages, and a sounder. The
sounder emits distinct condition tones to alert you to
a fire alarm, a fire trouble, or fire supervisory events as
they occur. The keypad includes fire status indicators
and fire function keys.
Functions
LCD display
The keypad uses words, numbers, and symbols to
show the status of the security system. When several
events occur, the keypad shows each event in order of
priority.
Keys
Each keypad has 10 number keys and 5 navigation
keys.
When pressed, keys turn on keypad backlighting and
emit the keypress tone (short beep). The keypad has 4
Fire function keys:
• ACK. Press to acknowledge the system alarm or
trouble condition.
• SILENCE. Press to silence fire alarms or troubles.
• RESET. Press to reset devices such as smoke
detectors, and clear restored points.
• DRILL. Press and hold to initiate a fire drill.
Audible tones
The keypad has a built-in sounder that produces
several distinct warning tones. The tones are
differentiated so that the user can recognize an event
simply by hearing its associated tone.
Status indicators
The status indicators on the keypad provide a quick
visual reference for system status.
The indicator lights when the system is ready to turn on (arm).
The indicator lights when the system is on (armed).
GAS
The indicator lights when dangerous gases are present
including carbon monoxide (NFPA 720).
The indicator lights when the system has power.
Fire status indicators
In conjunction with the display and status indicators,
the fire keypad includes Fire status indicators.
The indicator lights when a fire alarm condition exists.
The indicator lights when a user silenced a fire alarm condition.
The indicator lights when a supervisory point is not normal.
The indicator lights when there is a trouble condition
Certifications and approvals
Region Regulatory compliance/quality marks
USA ANSI-
SIA
CP-01-2010-Control Panel Standard -
Features for False Alarm Reduction
UL UL 365 - Police Station Connected Bur-
glar Alarm Units
UL UL 609 - Standard for Local Burglar
Alarm Units and Systems
UL UL 636 - Holdup Alarm Units and Sys-
tems
UL UL 864 - Standard for Control Units and
Accessories for Fire Alarm Systems
UL UL 985 - Household Fire Warning Sys-
tem Units
UL UL 1023 - Household Burglar Alarm Sys-
tem Units
UL UL 1076 - Proprietary Burglar Alarm
Units and Systems
UL UL 1610 - Central Station Burglar Alarm
Units
UL [B9512G, B9512G-E, B8512G,
B8512G-E, B299, B600, B901, B925F,
B926F]
UL UL 294 - Standard for Access Control
Units and Systems
UL UL 1635 - Standard for Digital Alarm
Communicator System Units
CSFM California Office of The State Fire Mar-
shall
Canada ULC CAN/ULC S303 - Local Burglar Alarm
Units and Systems
ULC CAN/ULC S304 - Standard for Signal Re-
ceiving Center and Premise Burglar
Alarm
ULC CAN/ULC S545 - Residential Fire Warn-
ing System Control Units
ULC ULC-ORD C1023 - Household Burglar
Alarm System Units
ULC ULC-ORD C1076 - Proprietary Burglar
Alarm Units and Systems
Region Regulatory compliance/quality marks
ULC [B9512G, B9512G-E, B8512G,
B8512G-E, B299, B600, B901, B925F,
B926F]
IC ICES-003 - Information Technology
Equipment (ITE)
Installation/configuration notes
Mounting considerations
Mount in indoor, dry locations.
Power supply
A compatible control panel supplies the power and
data requirements to the keypad through a four-wire
connection.
Enclosure and wiring
The sliding self-locking enclosure has an integrated
bubble level and custom gap-free, lift-gate style
terminal blocks to make installation easier.
Compatible control panels
B9512G/B9512G-E
B8512G/B8512G-E
Parts included
Quan
tity
Component
1Keypad
1 Hardware pack
1 Installation Guide
1 User’s Quick Reference Guide
Technical specifications
Power requirements
Current Standby: 35 mA
Alarm: 70 mA
Voltage (input) 12 VDC nominal
Materials and hardware features
Dimensions 158 mm x 120 mm x 26 mm (6.2 in x
4.7 in x 1 in)
Weight 0.32 kg (11.3 oz)
Material Acrylonitrile butadiene styrene (ABS)
Poly(methyl methacrylate) (PMMA)
Display window 2 line display
18 characters per line
Indicators Illuminated keys
Status indicators
Warning and indicating tones
2| B926F Fire keypad, SDI2
Wiring
Terminal wire size 1.02 mm (18 AWG) to 0.65 mm (22
AWG)
SDI2 wiring Maximum distance - wire size:
260 m (850 ft) - 0.65 mm (22 AWG)
305 m (1000 ft) - 1.02 mm (18 AWG)
Environmental considerations
Relative humidity 5% to 93% at +32°C (+90°F)
Temperature (operating) 0°C to +49°C (+32°F to +120°F)
Ordering information
B926F Fire keypad, SDI2
Two-line alphanumeric fire keypad
Order number B926F
Accessories
B56 Keypad surface mount box
Surface mount box for mounting a keypad to concrete
or block.
Order number B56
B96 Trim plate for keypad
Cover the wall footprint of previous keypads when
replacing them with the new, slim design of B Series
keypads. The white trim bezel is 8.6 in x 6.3 in x 0.12
in (22 mm x 16 mm x 3 mm).
Order number B96
3| B926F Fire keypad, SDI2
Represented by:
Europe, Middle East, Africa: Germany: North America: Asia-Pacific:
Bosch Security Systems B.V.
P.O. Box 80002
5600 JB Eindhoven, The Netherlands
Phone: + 31 40 2577 284
emea.boschsecurity.com
Bosch Sicherheitssysteme GmbH
Robert-Bosch-Ring 5
85630 Grasbrunn
Germany
www.boschsecurity.com
Bosch Security Systems, Inc.
130 Perinton Parkway
Fairport, New York, 14450, USA
Phone: +1 800 289 0096
Fax: +1 585 223 9180
www.boschsecurity.us
Robert Bosch (SEA) Pte Ltd, Security Systems
11 Bishan Street 21
Singapore 573943
Phone: +65 6571 2808
Fax: +65 6571 2699
www.boschsecurity.asia
© Bosch Security Systems 2019 | Data subject to change without notice
18689434123 | en, V18, 14. Jun 2019
