Bosch AMAX 2100 Manuel utilisateur
AMAX panel
AMAX panel 2100 | AMAX panel 3000 | AMAX panel
3000 BE | AMAX panel 4000
en Operation Manual
Table of contents
1Safety 5
2Short information 6
2.1 Introduction 6
2.2 Technical data 6
2.3 Keypads 6
2.4 Keypad indicators 8
2.5 Quick keypad operations instructions 12
2.6 User menu 17
3Arming and disarming areas 19
3.1 Arming areas 19
3.1.1 Arming in AWAY mode 19
3.1.2 Arming in STAY mode 21
3.1.3 Forced arming 23
3.2 Disarming areas 23
3.2.1 Disarming with a keypad 23
3.2.2 Disarming with a master keypad 23
3.2.3 Disarming with key switch 24
3.2.4 Disarming with RADION RF keyfob 24
4Changing the menu language 25
5Changing date, time and daylight saving time 26
6System test 28
6.1 Siren test 28
6.2 Communication test 28
6.3 Walk test mode 28
7Bypassing/isolating 29
7.1 Bypassing/unbypassing zones 29
7.1.1 How to bypass/unbypass a zone via text keypad 29
7.1.2 How to bypass/unbypass a zone via LED/LCD keypad 29
7.1.3 How to view bypassed zones 30
7.2 Bypassing faults or tamper conditions 30
7.3 Isolating zones 30
7.3.1 How to isolate/unisolate a zone via text keypad 30
7.3.2 How to isolate/unisolate a zone via LED/LCD keypad 30
AMAX panel Table of Contents | en 3
Bosch Sicherheitssysteme GmbH 2017.04 | 07 | F.01U.295.569
7.3.3 How to view isolated zones 31
8Schedules 32
9Macros 33
9.1 Recording macros 33
9.2 Playing macros 34
10 Codes 36
10.1 Add/change user codes 36
10.2 Change individual code 38
11 Keypad alarm operation commands 39
11.1 Keypad panic alarm 39
11.2 Keypad fire alarm 39
11.3 Keypad medical alarm 39
12 Domestic dialing 40
12.1 Domestic dialing alarm 40
12.2 Confirming the domestic call 40
13 Event log recall mode 41
13.1 How to select all event log recall mode 41
13.2 How to select EN event log recall mode 41
13.3 How to select dialer event log recall mode 41
14 Faults and tamper conditions 42
14.1 System fault or tamper analysis mode via text keypad 42
14.2 System fault or tamper analysis mode via LED/LCD keypad 42
15 Resetting the control panel 47
16 Troubleshooting 48
4en | Table of Contents AMAX panel
2017.04 | 07 | F.01U.295.569 Bosch Sicherheitssysteme GmbH
Safety
Danger!
Electricity
Injuries due to electricity are possible if the system is not
operated correctly or if the system is opened or modified.
– Never open or modify the system.
– Please contact your installer if you want to get your system
modified.
!
Caution!
Sensitive components
Damage of sensitive components is possible if the system is not
handled carefully or if the system is opened or modified.
– Always handle the system carefully.
– Never open or modify the system.
– Please contact your installer if you want to get your system
modified.
1
AMAX panel Safety | en 5
Bosch Sicherheitssysteme GmbH 2017.04 | 07 | F.01U.295.569
Short information
Introduction
This manual contains information on how to operate the system
easily and quickly. It describes the main steps required for
operation of the AMAX panel 2100 / 3000 / 3000 BE / 4000
together with a text and/or a LED/LCD keypad described in
Keypads, page 6. It is possible to add an optional text keypad
as a master keypad.
Detailed information about the installation of this and other
modules and devices, advanced settings and programming can
be found in the Installation Manual. Information on the main
steps required for basic system installation and setup can be
found in the Quick Installation Guide.
Technical data
Frequency bands of operation Power level for radio
equipment
GSM900 Class 4 (2W) - GPRS Class 33
GSM1800 Class 1 (1W) - GPRS Class 33
UMTS2100 Class 3 (0.25W)
Keypads
The following text keypad can be used for operating AMAX panel
2100 / 3000 / 3000 BE / 4000.
2
2.1
2.2
2.3
6en | Short information AMAX panel
2017.04 | 07 | F.01U.295.569 Bosch Sicherheitssysteme GmbH
IUI-AMAX4-TEXT
The following LED/LCD keypads can be used for operating AMAX
panel 2100 / 3000 / 3000 BE / 4000.
IUI-AMAX3-LED8 IUI-AMAX3-LED16
AMAX panel Short information | en 7
Bosch Sicherheitssysteme GmbH 2017.04 | 07 | F.01U.295.569
IUI-AMAX-LCD8
Notice!
Only IUI-AMAX4-TEXT can be used as a master keypad.
Keypad indicators
The following tables show an overview and a description of the
keypad indicator icons.
All keypad types
Keypad
Indicator
Icons
Status Definition
AWAY
on Area is armed in AWAY
mode.
off Area is not armed in
AWAY mode.
Slow flash (1 second
lights on/1 second
lights off)
Exit time.
2.4
8en | Short information AMAX panel
2017.04 | 07 | F.01U.295.569 Bosch Sicherheitssysteme GmbH
Fast flash (0.25
seconds lights on/0.25
seconds lights off)
System is in
programming mode or
code function mode.
STAY indicator flashes
simultaneously.
Or:
One or more areas but
not all are in AWAY
mode (master keypad)
STAY
on Area is armed in STAY
mode.
off Area is not armed in
STAY mode.
Slow flash (1 second
lights on/1 second
lights off)
Exit time.
Fast flash (0.25
seconds lights on/0.25
seconds lights off)
System is in
programming mode or
code function mode.
AWAY indicator flashes
simultaneously. When
bypass function is
performed, only the
STAY indicator flashes.
Or:
One or more areas but
not all are in STAY
mode (master keypad)
MAINS
on AC main power is
normal.
AMAX panel Short information | en 9
Bosch Sicherheitssysteme GmbH 2017.04 | 07 | F.01U.295.569
Slow flash (1 second
lights on/1 second
lights off)
AC main power supply
failed.
FAULTS
on System fault, tamper,
bypassed zone or
isolated zone condition
is present and has been
viewed but not
restored yet.
Or:
System is in service
mode.
off System is in normal
status.
Flashes System fault, tamper,
bypassed zone or
isolated zone condition
must be acknowledged.
All icons Flashing No communication to
the keypad.
Only for LED/LCD
Keypad
Indicator
Icons
Status Definition
1 2 3 ….
on Zone is triggered.
off Zone is normal.
10 en | Short information AMAX panel
2017.04 | 07 | F.01U.295.569 Bosch Sicherheitssysteme GmbH
