Bosch T10031 Manuel utilisateur

Support

T10031

en Original Instructions

de Originalbetriebsanleitung

ar   

bg Превод на оригиналното

ръководство за експлоатация

cs Překlad originálního návodu k

použití

da Oversættelse af de originale

brugsanvisninger

el Πρωτότυπο εγχειρίδιο χρήσης

en_us Original Instructions

es-es Traducción de las instrucciones

originales

es-mx Traducción de las instrucciones

originales

et Originaalkasutusjuhendi tõlge

fa   

fi Alkuperäisten ohjeiden käännös

fr Traduction des instructions

d'origine

he   

hr Prijevod izvornih uputa

hu Az eredeti útmutató fordítása

it Traduzione delle istruzioni originali

ja 元の手順の翻訳

ko 원래 지침의 번역물

lt Originalių instrukcijų vertimas

lv Oriģinālo norādījumu tulkojums

nl Vertaling van de originele

instructies

no Oversettelse av de opprinnelige

instruksjonene

pl Tłumaczenie oryginalnych instrukcji

pt-br Tradução das instruções originais

pt-pt Tradução das instruções originais

ro Traducerea instrucţiunilor originale

ru Перевод оригинальной

инструкции

sk Preklad pôvodného návodu

sl Prevod originalnih navodil za

uporabo

sr Prevod originalnih uputstava

sv Översättning av

originalinstruktionerna

tr Orijinal Talimatların Çevirisi

uk Переклад оригінальної інструкції

zh-cn 原始说明的翻译

zh-tw 原廠操作說明中譯本

Table of Languages

English 6

Deutsch 11

󰤕󰥵󰤒󰤯󰥍󰥠 17

Български 22

Čeština 28

Dansk 33

Ελληνικά 38

English-US 44

Español 49

Español-Mexicano 55

Eesti 61

󰛴󰤴󰤏󰥔 66

Suomi 71

Français 76

 82

Hrvatski 87

Table of Languages | 3 | T10031

2018-06-05 Bosch Automotive Service Solutions GmbH

Am Dörrenhof 1

85131 Pollenfeld-Preith

Germany

Magyar 92

Italiano 97

日本語 103

한국어 108

Lietuvių k. 113

Latviešu valoda 118

Македонски 123

Nederlands 129

Norsk 134

Polski 140

Português-Brasil 146

Português 152

Românǎ 158

Русский 164

Slovenčina 170

Slovenščina 176

Srpski 181

Table of Languages | 4 | T10031

2018-06-05 Bosch Automotive Service Solutions GmbH

Am Dörrenhof 1

85131 Pollenfeld-Preith

Germany

Svenska 186

Türkçe 191

Українська 197

简体中文 203

繁體中文 208

Table of Languages | 5 | T10031

2018-06-05 Bosch Automotive Service Solutions GmbH

Am Dörrenhof 1

85131 Pollenfeld-Preith

Germany

Table of Contents English

General Information .............................. 7

General Safety Instructions .................. 8

Operating Instructions .......................... 9

Inspection and maintenance .................. 9

Declaration of Conformity .................... 10

en | 6 | T10031

2018-06-05 Bosch Automotive Service Solutions GmbH

Am Dörrenhof 1

85131 Pollenfeld-Preith

Germany

1 General Information

Product name: Support

Product type: Load holding device

Product number: T10031

Weight: 11.6 kg

Max. load capacity: 100 kg

Static test coefficient: 3.0

Intended Use:

The support T10031 serves for holding vehicle

components when demounting and installing in

accordance with the workshop manuals of the

Volkswagen Group brands.

Only for qualified workshop personnel.

Only use the load holding device for work approved

by the Volkswagen Group.

Use only for loads up to 100 kg.

Only use in connection with a suitable engine and

gearbox jack (e.g. VAS 6931/V.A.G. 1383A) (see

workshop manuals of the Volkswagen Group

brands).

Do not hold or lift any persons or animals.

Do not hold or lift articles other than described in

the workshop manuals of the Volkswagen Group

brands.

Do not stand under suspended loads.

Only use on level, horizontal and weight-bearing

ground.

Only use in connection with the approved

accessories (see workshop manuals of the

Volkswagen Group brands).

Figure 1: Support T10031

1Cross beam

2Bolt with wing nut M12

3Support left

4Support right

5Support plate with rubber support

en | 7 | T10031

2018-06-05 Bosch Automotive Service Solutions GmbH

Am Dörrenhof 1

85131 Pollenfeld-Preith

Germany

2 General Safety Instructions

WARNING

Read and follow all safety notes and instructions!

Failure to follow the safety instructions may result in

serious injuries and material damages.

Observe and follow the safety notes below.

The load holding device has been specifically

constructed for its intended use. The safety of the

load holding device can no longer be ensured if it is

misused or modified in ways not expressly approved

by the manufacturer. Serious injuries or damage to

property can occur.

Ensure that each person using the load holding

device is familiar with these instructions and can

access them at all times.

Ensure that all users are also familiar with the

operating manuals of all tools and workshop

equipment, which are necessary for the work.

Observe and follow the basic information and safety

notes for vehicles with gas drive in the

corresponding Volkswagen Group information

materials.

Carefully read and adhere to the instructions in the

technical safety information of the Volkswagen

Group brands.

Wear safety shoes (according to ISO 20345, S2).

Wear protective gloves in order to avoid cuts.

Position hands and feet carefully to avoid potential

crushing hazards.

Use the load holding device only for work approved

by the Volkswagen Group.

Use the load holding device only with the

accessories approved by the Volkswagen Group.

Do not exceed the maximum load capacity of

100 kg.

Only use the support for engine and gearbox units in

accordance with the workshop manuals of the

Volkswagen Group brands.

Tighten the wing nuts (see workshop manuals of the

Volkswagen Group brands).

Only use in connection with a suitable engine and

gearbox jack (e.g. VAS 6931/V.A.G. 1383A) (see

workshop manuals of the Volkswagen Group

brands).

The engine and gearbox jack may only be operated

by one person.

The positioning of persons under the load and in the

dangerous area is prohibited during the movement

process.

Move the load slowly and carefully.

Observe the engine support and the load during all

movements.

Only move the load on the lowest setting.

Ensure that the track is clear and easily visible.

Do not work on suspended loads.

en | 8 | T10031

2018-06-05 Bosch Automotive Service Solutions GmbH

Am Dörrenhof 1

85131 Pollenfeld-Preith

Germany

3 Operating Instructions

1. Check the reception for completeness and visible

damages such as signs of wear, deformation,

breakages, cracks, and corrosion damages prior to

each use. Check all threads for damages and ease

of operation. Do no use the support when defects

are noted and discard it immediately.

2. Carry out the necessary preparation work for the

use of the support in accordance with the

workshop manuals.

3. Place the support on the engine and gearbox jack

and ensure that the support pin is inserted

completely into the receptacle of the engine and

gearbox jack and is secured.

4. Attach and secure the support to the vehicle

component in accordance with the workshop

manuals of the Volkswagen Group brands.

5. Mark the support elements in position with the

bolts and subsequently screw with the wing nut

WARNING

Danger through tilting or falling of the load!

Incorrect attachment of the reception to the load

may cause tilting or falling of the load! This could

cause serious personal injury or severe damage to

materials.

Fasten the support exactly as described in the

workshop manuals.

Position the locking pin exactly and secure with

wing nuts

WARNING

Risk of injury through moving loads!

Crushing of limbs between load and vehicle can result

from movements such as moving, lifting or lowering of

the load.

Position hands and feet in such a manner that

crushing hazards do not exist when moving the

gearbox.

Observe the engine and gearbox jack as well as the

load during all movements.

6. Carry out further work as described in the

workshop manuals.

7. Ensure that all parts of the special tool have been

removed after completing the repair work.

4 Inspection and maintenance

Check the reception for completeness and visible

damages such as signs of wear, deformation,

breakages, cracks, and corrosion damages prior to

each use. Check all threads for damages and ease of

operation. Do no use the support when defects are

noted and discard it immediately.

Spare parts are available on request. Only use

original replacement parts.

Please contact your 1st level support representative

with any queries.

NOTICE

Modifications to this product which have not been

expressly approved by the manufacturer will void any

warranty. The manufacturer assumes no liability for

personal injuries or damages to materials which occur

as the result of improper use of this product.

en | 9 | T10031

2018-06-05 Bosch Automotive Service Solutions GmbH

Am Dörrenhof 1

85131 Pollenfeld-Preith

Germany

Declaration of Conformity with the Machinery Directive 2006/42/EC,

Annex II 1A

Manufacturer: Bosch Automotive Service Solutions GmbH

Am Dörrenhof 1

85131 Pollenfeld-Preith

Germany

Authorised to Compile the

Technical Documents:

Bosch Automotive Service Solutions GmbH

Am Dörrenhof 1

85131 Pollenfeld-Preith

Germany

Product name: Support

Product type: Load holding device

Product number: T10031

We hereby declare that each product described above complies with the relevant clauses of the 2006/42/EC

Machinery Directive.

Any modification to a product not expressly approved by the manufacturer will void the validity of this declaration.

The following harmonised standards have been applied:

EN ISO 12100:2010 Safety of machinery - General principles for design - Risk assessment and risk

reduction

EN 13155:2003+A2:2009 Cranes - Safety - Non-fixed load lifting attachments

Pollenfeld, 23 May 2018

Place, Date Matthias Wagner, Managing Director

en | 10 | T10031

2018-06-05 Bosch Automotive Service Solutions GmbH

Am Dörrenhof 1

85131 Pollenfeld-Preith

Germany

Table des matières

Autres manuels Bosch Support et étagère

Bosch

Bosch FRK 0019 A Manuel utilisateur

Bosch

Bosch ISN-GMX-W0 Manuel utilisateur

Bosch

Bosch GTA 600 Professional Instructions de fonctionnement

Bosch

Bosch PTA1000 Manuel utilisateur

Bosch

Bosch S 500 A PROFESSIONAL Manuel utilisateur

Bosch

Bosch MSS 300 Guide de démarrage rapide

Bosch

Bosch Professional GTA 560 Manuel utilisateur

Bosch

Bosch FMH 0000 A Manuel utilisateur

Bosch

Bosch MSGZWML Manuel utilisateur

Bosch

Bosch UB-10DB Manuel d'installation et d'exploitation

Bosch

Bosch FLEXIDOME NDA-FMT-MICDOME Manuel utilisateur

Bosch

Bosch FBH 0000 A Manuel utilisateur

Bosch

Bosch D55 Manuel utilisateur

Bosch

Bosch FBH 0000 A Manuel utilisateur

Bosch

Bosch TS2000 Instructions de montage

Bosch

Bosch LTC 9349MK Manuel utilisateur

Bosch

Bosch PTA 2400 Manuel utilisateur

Bosch

Bosch GTA 60 W Professional Manuel utilisateur

Bosch

Bosch B12 Manuel utilisateur

Bosch

Bosch GTA 3800 Professional Instructions de montage

Bosch

Bosch GTA 2500 W Professional Manuel utilisateur

Bosch

Bosch VG4-A-9543 Manuel utilisateur

Bosch

Bosch NDA-FMT200-DOME Manuel utilisateur

Bosch

Bosch GTA 2500 W Professional Manuel utilisateur

Manuels Support et étagère populaires d'autres marques

Salamander

Salamander Acadia AC/W/L400/WH Manuel utilisateur

Fohhn

Fohhn VAT-09 Guide de l'utilisateur

ricoo

ricoo FS0522 Manuel utilisateur

AMSOIL

AMSOIL BMK-22 Guide rapide

Kargo Master

Kargo Master 48220 Manuel utilisateur

Milestone AV Technologies

Milestone AV Technologies SIMPLICITY SLF2 Manuel utilisateur

ricoo

ricoo S1222 Manuel utilisateur

Ready-Set-Mount

Ready-Set-Mount RSMCM602 Manuel utilisateur

VidaBox

VidaBox VB MNT FFS2 Manuel utilisateur

Welch Allyn

Welch Allyn 48960 Manuel utilisateur

Arkon

Arkon CM035-ST-2 Manuel utilisateur

PROEL

PROEL PLWIN60C Manuel utilisateur

Agilent Technologies

Agilent Technologies E2609B Manuel utilisateur

Mustang

Mustang MV-ARM4 Manuel utilisateur

Mounting Solutions

Mounting Solutions WRM-320 Manuel utilisateur

Pyle

Pyle PMKSPAD1 Manuel utilisateur

ShelterIt

ShelterIt 21208 Manuel utilisateur

SPL

SPL RackPack?4 1040 Manuel utilisateur
