Bosch NPD-6001A Manuel utilisateur

High PoE Midspan 60W, Sin-

gle port, AC in

NPD-6001A

en Installation Manual

Table of contents

1Safety 4

1.1 Conventions in this Manual 4

1.2 About this Manual 5

1.3 Important Safety Instructions 5

1.4 Customer Support and Service 7

2Unpacking 9

2.1 Parts List 9

2.2 Additional Parts Required 9

2.3 Tools Required 10

2.4 Additional Parts Recommended But Not Required 10

3System overview 11

4Installation 12

5Connection 14

6Troubleshooting 16

High PoE Midspan 60W,

Single port, AC in Table of Contents | en 3

Bosch Security Systems Installation Manual 2013.03 | 1.2 | F.01U.279.929

Safety

Conventions in this Manual

In this manual, the following symbols and notations are used to

draw attention to special situations:

Danger!

This symbol indicates an imminently hazardous situation such as

“Dangerous Voltage” inside the product. If not avoided, this will

result in an electrical shock, serious bodily injury, or death.

Warning!

Indicates a potentially hazardous situation. If not avoided, this

could result in serious bodily injury or death.

Caution!

Medium Risk

Indicates a potentially hazardous situation. If not avoided, this

may result in minor or moderate injury. Alerts the user to impor-

tant instructions accompanying the unit.

Caution!

Indicates a potentially hazardous situation. If not avoided, this

may result in property damage or risk of damage to the unit.

Notice!

This symbol indicates information or a company policy that re-

lates directly or indirectly to the safety of personnel or protec-

tion of property.

1.1

4en | Safety High PoE Midspan 60W,

Single port, AC in

2013.03 | 1.2 | F.01U.279.929 Installation Manual Bosch Security Systems

About this Manual

This manual has been compiled with great care and the

information it contains has been thoroughly verified. The text

was complete and correct at the time of printing. Because of the

ongoing development of products, the content of the manual

may change without notice. Bosch Security Systems accepts no

liability for damage resulting directly or indirectly from faults,

incompleteness, or discrepancies between the manual and the

product described.

Important Safety Instructions

Read, follow, and retain for future reference all of the following

safety instructions. Heed all warnings on the unit and in the

operating instructions before operating the unit.

– The unit is intended only for installation in a Restricted

Access Location.

– Installation and removal of the midspan must be carried out

by qualified personnel only.

– Follow basic electricity safety measures whenever

connecting the midspan to its power source.

–AC Power Cord Set: Although the High PoE Midspan 60W,

Single port ships with one (1) 120 V power cord and one

(1) 230 V power cord, please note the following as it

applies to your region:

– The power cord must have regulatory agency approval

for the specific country in which it is being used (i.e.,

UL, CSA, VDE, etc.).

– The power cord must be a three-conductor type (two

current carrying conductors; one ground conductor)

terminated on one end by an IEC 60320 appliance

coupler (for connection to the midspan), and on the

other end by a plug containing a ground (earthing)

contact.

1.2

1.3

High PoE Midspan 60W,

Single port, AC in Safety | en 5

Bosch Security Systems Installation Manual 2013.03 | 1.2 | F.01U.279.929

– The power cord must be rated for a minimum of 250

VAC RMS operation, with a minimum rated current

capacity of 5 Amps (or a minimum wire gauge of 18

AWG (0.75mm2).

– Midspans installed in Australia require power cords

with a minimum wire gauge of 16 AWG (1.0 mm2).

– A voltage mismatch can cause equipment damage and may

pose a fire hazard. If the voltage indicated on the label is

different from the power outlet voltage, do not connect the

midspan to this power outlet.

– The AC wall socket-outlet must be near the midspan and

easily accessible. You can remove AC power from the

midspan by disconnecting the AC power cord from either

the wall socket-outlet or the midspan appliance coupler.

– The PoE injector "Data In" and "Data & Power Out" ports

are shielded RJ45 data sockets. They cannot be used as

Plain Old Telephone Service (POTS) telephone sockets.

Only RJ45 data connectors can be connected to these

sockets.

– The Data In and Data & Power Out interfaces are qualified

as SELV (Safety Extra-Low Voltage) circuits according to

IEC 60950-1. These interfaces can only be connected to

SELV interfaces on other equipment.

Recycling and Disposal:

6en | Safety High PoE Midspan 60W,

Single port, AC in

2013.03 | 1.2 | F.01U.279.929 Installation Manual Bosch Security Systems

Your Bosch product was developed and manufactured with high-

quality material and components that can be recycled and

reused. This symbol means that electronic and electrical

appliances, which have reached the end of their working life,

must be collected and disposed of separately from household

waste material. Separate collecting systems are usually in place

for disused electronic and electrical products. In the United

States, please dispose of these units at your local communal

waste collection point or at a recycling center. In the EU, please

dispose of these units at an environmentally compatible

recycling facility, per European Directive 2002/96/EC.

Customer Support and Service

If this unit needs service, contact the nearest Bosch Security

Systems Service Center for authorization to return and shipping

instructions.

Service Centers

USA

Repair Center

Telephone: 800-566-2283 / Fax: 800-366-1329

E-mail: [email protected]

Customer Service

Telephone: 888-289-0096 / Fax: 585-223-9180

E-mail: [email protected]

Technical Support

Telephone: 800-326-1450 / Fax: 585-223-3508 or 717-735-6560

E-mail: [email protected]

Canada

Telephone: 514-738-2434 / Fax: 514-738-8480

Europe, Middle East, Africa Region

Repair Center

Telephone: 31 (0) 76-5721500 / Fax: 31 (0) 76-5721413

E-mail: [email protected]

Asia Region

Repair Center

1.4

High PoE Midspan 60W,

Single port, AC in Safety | en 7

Bosch Security Systems Installation Manual 2013.03 | 1.2 | F.01U.279.929

Telephone: 65 63522776 / Fax: 65 63521776

E-mail: [email protected]

Customer Service

Telephone: 86 (0) 756 7633117 or 86 (0) 756 7633121 / Fax: 86

(0) 756 7631710

E-mail: [email protected]

Warranty and additional information

For additional information and warranty queries, please contact

your Bosch Security Systems representative or visit our website

at www.boschsecurity.com.

8en | Safety High PoE Midspan 60W,

Single port, AC in

2013.03 | 1.2 | F.01U.279.929 Installation Manual Bosch Security Systems

Unpacking

Parts List

The package containing the High PoE Midspan 60W, Single port

should include the following items:

Quantity Part

1 High PoE Midspan 60W, Single port, AC in

1 120 V power cord

1 230 V power cord

1 Installation Manual (this document)

Additional Parts Required

The following table lists additional parts (not supplied by

Bosch) required to install the midspan:

Quantity Part Size Notes

2 Mounting

screws;

Select either

size

(but not both).

Head diameter:

5.8 mm

(0.23 in.)

1.5 mm (0.059 in.)

clearance from mounting

surface

Head diameter:

7 mm

(0.27 in.)

Head height:

2 mm

(0.08 in.)

2.5 mm (0.098 in.)

clearance from mounting

surface

2 CAT5 cables Not to exceed

100 m (333 ft)

each

1 cable to connect to the

“Data & Power

Out“ port.

1 cable to connect to the

“Data In” port.

2.1

2.2

High PoE Midspan 60W,

Single port, AC in Unpacking | en 9

Bosch Security Systems Installation Manual 2013.03 | 1.2 | F.01U.279.929

Tools Required

Screwdriver

Additional Parts Recommended But Not

Required

The following table lists additional parts (not supplied by

Bosch) recommended to install the midspan:

Quantity Part

1 Surge suppressor

1 Splitter

1 Universal Power Supply (UPS)

2.3

2.4

10 en | Unpacking High PoE Midspan 60W,

Single port, AC in

2013.03 | 1.2 | F.01U.279.929 Installation Manual Bosch Security Systems
