VIP X1600 B

Network Video Server – Base

en Installation and Operating Manual

VIP X1600 B Table of Contents | en 3

Bosch Security Systems Installation and Operating Manual F.01U.081.492 | V4.0 | 2008.04

Table of Contents

1Preface 5

1.1 About this Manual 5

1.2 Conventions in this Manual 5

1.3 Intended Use 5

1.4 EU Directives 6

1.5 Rating Plate 6

2 Safety Information 7

2.1 Electric Shock Hazard 7

2.2 Installation and Operation 7

2.3 Maintenance and Repair 7

3 Product Description 9

3.1 Scope of Delivery 9

3.2 System Requirements for Setup 9

3.3 Configuration and Operation 9

3.4 Overview of Functions 10

3.5 Connections and Displays 11

4 Installation 13

4.1 Preparations 13

4.2 Installing Modules 13

4.3 Installing in a Switch Cabinet 14

4.4 Connections 16

4.5 Power On/Power Off 17

5 Maintenance and Upgrades 19

5.1 Testing the Network Connection 19

5.2 Unit Reset 19

5.3 Repairs 19

5.4 Transfer and Disposal 19

6 Appendix 21

6.1 Troubleshooting 21

6.2 LEDs 21

7 Specifications 23

7.1 VIP X1600 B Base 23

4en | Table of Contents VIP X1600 B

F.01U.081.492 | V4.0 | 2008.04 Installation and Operating Manual Bosch Security Systems

VIP X1600 B Preface | en 5

Bosch Security Systems Installation and Operating Manual F.01U.081.492 | V4.0 | 2008.04

1Preface

1.1 About this Manual

This manual is intended for persons responsible for the installation and operation of the

VIP X1600 B. International, national and any regional electrical engineering regulations must

be followed at all times. Relevant knowledge of network technology is required. The manual

describes the installation and operation of the VIP X1600 B base.

1.2 Conventions in this Manual

In this manual, the following symbols and notations are used to draw attention to special

situations:

1.3 Intended Use

The VIP X1600 B network video server is intended for use with CCTV systems and serves to

transfer video and control signals via data networks (Ethernet LAN and Internet). The optional

modules for installation determine the range of functions. Encoder modules (senders) and

decoder modules (receivers) are available. The encoder modules each contain RAM memory

for short-term recording of connected cameras. Audio signals can also be transmitted with the

audio versions of the encoder modules. Various functions can be triggered automatically by

incorporating external alarm sensors. Other applications are not permitted.

In the event of questions concerning the use of the unit which are not answered in this

manual, please contact your sales partner or:

Bosch Sicherheitssysteme GmbH

Robert-Koch-Straße 100

85521 Ottobrunn

Germany

www.boschsecurity.com

CAUTION!

This symbol indicates that failure to follow the safety instructions described may endanger

persons and cause damage to the unit or other equipment.

It is associated with immediate, direct hazards.

NOTICE!

This symbol refers to features and indicates tips and information for easier, more convenient

use of the unit.

6en | Preface VIP X1600 B

F.01U.081.492 | V4.0 | 2008.04 Installation and Operating Manual Bosch Security Systems

1.4 EU Directives

The VIP X1600 B network video server complies with the requirements of EU Directives 89/

336 (Electromagnetic Compatibility) and 73/23, amended by 93/68 (Low Voltage Directive).

1.5 Rating Plate

For exact identification, the model name and serial number are inscribed on the rating plate

on the bottom of the VIP X1600 B base and on the rating plates on the circuit boards of the

modules. Please make a note of this information before installation, if necessary, so as to have

it to hand in case of questions or when ordering spare parts.

VIP X1600 B Safety Information | en 7

Bosch Security Systems Installation and Operating Manual F.01U.081.492 | V4.0 | 2008.04

2SafetyInformation

2.1 Electric Shock Hazard

– Never attempt to connect the unit to any power network other than the type for which it

is intended.

– Use only power supply units approved by Bosch Security Systems.

– Never open the housing of the power supply unit.

– Always install a module in the appropriate VIP X1600 B base housing only.

– If a fault occurs, disconnect the VIP X1600 B from the power supply and from all other

units.

– Install the power supply and the unit only in a dry, weather-protected location.

– If safe operation of the unit cannot be ensured, remove it from service and secure it to

prevent unauthorized operation. In such cases, have the unit checked by Bosch Security

Systems.

Safe operation is no longer possible in the following cases:

– if there is visible damage to the unit or power cables,

– if the unit no longer operates correctly,

– if the unit has been exposed to rain or moisture,

– if foreign bodies have penetrated the unit,

– after long storage under adverse conditions, or

– after exposure to extreme stress in transit.

2.2 Installation and Operation

– The relevant electrical engineering regulations and guidelines must be complied with at

all times during installation.

– Relevant knowledge of network technology is required to install the unit.

– Before installing or operating the VIP X1600 B, make sure you have read and understood

the documentation for the modules in use and for any other equipment connected to it,

such as cameras or monitors. The documentation contains important safety instructions

and information about permitted uses.

– Perform only the installation and operation steps described in this manual. Any other

actions may lead to personal injury, damage to property or damage to the equipment.

2.3 Maintenance and Repair

– Never open the housing of a VIP X1600 B base. The unit does not contain any user-

serviceable parts. Remove only the supplied cover when installing a module.

– Do not change any components in a VIP X1600 B base or a module. The units do not

contain any user-serviceable parts.

– Never open the housing of the power supply unit. The power supply unit does not contain

any user-serviceable parts.

– Ensure that all maintenance or repair work is carried out only by qualified personnel

(electrical engineers or network technology specialists).

8en | Safety Information VIP X1600 B

F.01U.081.492 | V4.0 | 2008.04 Installation and Operating Manual Bosch Security Systems

VIP X1600 B Product Description | en 9

Bosch Security Systems Installation and Operating Manual F.01U.081.492 | V4.0 | 2008.04

3 Product Description

3.1 Scope of Delivery

–VIPX1600Bbase

– Mounting kit for installation in 19-inch racks

– Self-adhesive elastic bumpers

– Quick Installation Guide

– Product CD with the following content:

– Quick Installation Guide

–Manual

– System Requirements document

– Further documentation on Bosch Security Systems products

– Configuration Manager

–MPEGActiveXcontrol

– Player and Archive Player

–DirectXcontrol

– Microsoft Internet Explorer

– Sun JVM

– Adobe Acrobat Reader

3.2 System Requirements for Setup

There are no additional requirements to be met for setting up the VIP X1600 B base after

installation is complete. Requirements for setting up the installed modules can be found in

the module manuals.

3.3 Configuration and Operation

The configuration and operation of a VIP X1600 B is carried out exclusively via the installed

modules. Furthermore, the VIP X1600 B base does not require any configuration.

The configuration and operation of the installed modules is described in the module manuals.

NOTICE!

Check that the delivery is complete and in perfect condition. Have your unit checked by Bosch

Security Systems if you detect any damage.

10 en | Product Description VIP X1600 B

F.01U.081.492 | V4.0 | 2008.04 Installation and Operating Manual Bosch Security Systems

3.4 Overview of Functions

3.4.1 Network Video Server Housing

The VIP X1600 B base is a special housing for the installation of up to four standalone

modules. Encoder modules (senders), for the connection of up to four cameras each, and

decoder modules (receivers), for the connection of up to four monitors each, are available.

For example, a VIP X1600 B with four encoder modules can make up to 16 independent video

channels available. Combinations of encoder modules and decoder modules are also possible.

The use of existing networks means that integration with CCTV systems or local networks can

be achieved quickly and easily.

The modules are designed for installation in the VIP X1600 B base. Installing the units is a

quick and easy operation that does not require any additional tools. All modules are hot

swappable and can be exchanged while the system is running.

3.4.2 Network Interfaces

The integrated switch functionality of the VIP X1600 B base allows the ETH1 and ETH2

interfaces to be used alternatively, redundantly or for cascading other units.

3.4.3 Redundant Power Supply

The VIP X1600 B base allows one or two power supply units to be connected, thereby offering

the option of a monitored redundant power supply. In the event of power supply unit failure,

the VIP X1600 B can be supplied by the second power supply unit without interruption.
