AMC2 Modular Controller

AMC2‑4W_UL

en Installation Manual

AMC2 Modular

Controller Table of contents | en 3

Bosch Access Systems GmbH 2018-09 | AMC2-4W_UL |

Table of contents

1Safety Instructions 5

1.1 Important Safety Notes 5

1.2 FCC & ICES Information 8

1.3 Safety Precautions 9

1.4 Unpacking 11

2Important Information 12

2.1 Explanation of symbols in this document 12

2.2 Internet 13

3Introduction 14

3.1 Description 14

3.2 Equipment Configuration 16

3.3 Performance Characteristics 20

3.4 System Overview 21

4Installing 23

4.1 Mounting 23

4.2 Unmounting 24

4.3 Opening the Case 25

4.4 Closing the Case 26

4.5 Cabling 27

4.5.1 Conductor data for power to AMC2 27

4.6 Grounding and Shielding 29

4.6.1 Grounding for Extension Interface 30

4.7 Connecting Power Supply 31

4.8 Ethernet Host Interface 32

4.9 RS-485 for extension modules 34

4.10 Wiegand Interface for Card Readers 36

4.11 Connecting Relay Outputs 37

4.12 Connecting Analog Input Devices 41

4.13 Tamper Protection 44

5UL Requirements 45

5.1 System Requirements 46

5.1.1 Computer 46

5.1.2 Monitor 47

5.1.3 Printer 47

4en | Table of contents AMC2 Modular

Controller

2018-09 | AMC2-4W_UL | Bosch Access Systems GmbH

5.2 UL 294 Level Descriptions 47

5.3 Installation Instructions 48

6Operating 52

6.1 Status Display of the AMC2 52

6.2 Configuring the Ethernet Interface 55

6.3 Troubleshooting 56

6.3.1 Resetting the Software 56

6.3.2 Resetting the Device to Factory Default 58

7Technical Data 59

8Appendices 63

8.1 Connecting Diagrams 63

Index 67

AMC2 Modular

Controller Safety Instructions | en 5

Bosch Access Systems GmbH 2018-09 | AMC2-4W_UL |

1 Safety Instructions

1.1 Important Safety Notes

1. Read, follow, and retain instructions - All safety and

operating instructions must be read and followed properly

before putting the unit into operation. Retain instructions

for future reference.

2. Do not ignore warnings - Adhere to all warnings on the unit

and in the operating instructions.

3. Accessories - Use only accessories recommended by the

manufacturer or those sold with the product. Accessories

not recommended by the manufacturer must not be used,

as they may cause hazards.

4. Installation precautions - Do not place this unit on an

unstable stand, tripod, bracket, or mount. The unit may fall,

causing serious injury to persons and damage to the unit.

Mount the unit according to the manufacturer’s

instructions.

5. Service - Do not attempt to service this unit by yourself.

Opening or removing covers may expose you to dangerous

voltages or other hazards. Refer all servicing to qualified

service personnel.

6. Damage which requires service - Disconnect the unit from

the main AC or DC power source and refer servicing to

qualified service personnel under the following conditions:

– If the power supply cord or plug is damaged.

– If liquid has been spilled or an object has fallen into

the unit.

– If the unit has been exposed to water and/or inclement

weather (rain, snow, etc.).

– If the unit does not operate normally when following

the operating instructions. Adjust only those controls

specified in the operating instructions. Improper

6en | Safety Instructions AMC2 Modular

Controller

2018-09 | AMC2-4W_UL | Bosch Access Systems GmbH

adjustment of other controls may result in damage,

and require extensive work by a qualified technician to

restore the unit to normal operation.

– If the unit has been dropped or the cabinet damaged.

– If the unit exhibits a distinct change in performance.

7. Replacement parts - If replacement parts are required, the

service technician must use only replacement parts that are

specified by the manufacturer. Unauthorized replacements

may result in fire, electrical shock or other hazards.

8. Safety check - Upon completion of service or repair work

on the unit, ask the service technician to perform safety

checks to ensure that the unit operates properly

9. Power sources - Operate the unit only from the type of

power source indicated on the label. If unsure of the type

of power supply to use, contact your dealer

– For units intended to operate on battery power, refer

to the operating instructions.

– For units intended to operate with external power

supplies, use only the recommended approved power

supplies corresponding to norm EN/UL 60950.

– For units intended to operate with a limited power

source, this power source must comply with EN/UL

60950. Unsuitable replacements may damage the unit

or cause fire or shock.

– For units intended to operate at 12V DC normal input

voltage is 12V DC. Voltage input must never exceed

15V DC.

– For UL installations, the Bosch APS-PSU-60 power

supply may be used, and must be located in the same

room as the connected AMC2 device. Recommended

maximum distance between power supply unit and

AMC2 is 3 m (9.84 ft).

10. Lightning - For added protection during electrical storms

external lightning conductors can be installed. This

prevents power surges from damaging the unit.

AMC2 Modular

Controller Safety Instructions | en 7

Bosch Access Systems GmbH 2018-09 | AMC2-4W_UL |

– For UL installations, lightning protection used must be

UL listed.

11. The units should be installed in locations with restricted

access.

8en | Safety Instructions AMC2 Modular

Controller

2018-09 | AMC2-4W_UL | Bosch Access Systems GmbH

1.2 FCC & ICES Information

This device complies with part 15 of the FCC rules. Operation is

subject to the following two conditions: (1) This device may not

cause harmful interference, and (2) this device must tolerate

any interference received, including interference that may cause

undesired operation.

This equipment has been tested and found to comply with the

limits for a Class B digital device, pursuant to part 15 of the FCC

rules. The limits are designed to provide reasonable protection

against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio

communications. However, there is no guarantee that

interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or

television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

1. Reorient or relocate receiving antenna

2. Increase the separation between the equipment and the

receiver

3. Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected

4. Consult the dealer or an experienced radio/TV technician

for help

AMC2 Modular

Controller Safety Instructions | en 9

Bosch Access Systems GmbH 2018-09 | AMC2-4W_UL |

1.3 Safety Precautions

Read instructions!

Before working with the AMC2 device, read these instructions

carefully. Make sure you have understood all information

described in this document.

Warning!

Risk of electric shock

External power supplies must be installed and put into service

by qualified personnel.

Ensure compliance with the relevant regulations.

Ground the controller.

Disconnect both AC and battery power supply before working

on the controller.

Warning!

Risk of fire

Installation of the AMC2 device must comply with any local fire,

health, and safety regulations. A secured door that may be part

of an escape route from an area must be installed with:

Install a fail-safe lock (A), so that the door will be released if

power fails. Ideally, use a magnetic lock.

Install a normally-closed break glass or a manual pull (B) in the

lock supply wiring, so that in an emergency the fail-safe lock

can be immediately powered down.

Warning!

Risk of explosion of Lithium battery

The battery can explode if it is replaced incorrectly.

Replace only with the same type as recommended by the

manufacturer.

Dispose used batteries according to the battery manufacturer’s

instructions.

10 en | Safety Instructions AMC2 Modular

Controller

2018-09 | AMC2-4W_UL | Bosch Access Systems GmbH

Notice!

Risk of damage to equipment

Protect the hardware from electrostatic discharge by observing

ESD instructions before unpacking of touching connectors of

electronics.

Always switch off power of the AMC2 device before modifying

the installation.

Do not connect or disconnect plug connectors, data cables, or

screw connectors while power is on.

Rules and Conditions

There are no specific requirements as for selling and delivery. As

for storage and safe operation, the environmental temperature

should not exceed the range of 0°C to 50°C.

Disposal

Your Bosch product is designed and manufactured with high-

quality materials and components which can be recycled and

reused.

This symbol means that electrical and electronic equipment, at

their end-of-life, should be disposed of separately from your

household waste.

In the European Union, there are separate collection systems for

used electrical and electronic products. Please dispose of this

equipment at your local community waste collection/recycling

center.
