Bosch 2 Manuel utilisateur

Access Modular Controller 2

ADS‑AMC2‑2WCF | APC‑AMC2‑2WCF

en Руководство по установке

Access Modular Controller 2 Table of contents | en 3

Bosch Security Systems B.V. Руководство по установке 2022-11 | V05 |

Table of contents

1Safety 5

2Short information 7

3Introduction 8

3.1 Description 8

3.2 Product overview 10

3.2.1 Mainboard 10

3.2.2 Status display 12

3.3 System overview 13

4Installing 14

4.1 Mounting the device on a mounting rail 14

4.2 Unmounting the device from a mounting rail 15

4.3 Opening the case 16

4.4 Closing the case 17

4.5 Cabling 18

4.5.1 Conductor data for powering the controller 18

4.6 Grounding and shielding 19

4.6.1 Grounding for host interface 19

4.6.2 Grounding for extension interface 20

4.7 Connecting the power supply to the controller 21

4.8 Ethernet host interface 22

4.9 RS-485 host interface 23

4.9.1 RS-485 Two Wire Connection 24

4.9.2 RS-485 Four Wire Connection 24

4.9.3 DIP switch selector 24

4.10 RS-485 for extension modules 26

4.11 Wiegand interface for card readers 27

4.12 Connecting relay outputs 27

4.13 Connecting analog input devices 30

4.14 Tamper protection 31

5Operating 32

5.1 Configuring Ethernet interface 32

6UL requirements 33

6.1 System requirements 34

6.1.1 Computer 34

6.2 UL 294 level descriptions 34

6.3 Installation instructions 34

6.4 Extended technical specification 37

6.4.1 RS-485 extension 37

6.4.2 Power consumption 37

7Troubleshooting 38

7.1 Resetting the software 39

7.2 Resetting the device to factory default 40

8Service and repair 41

9Disposal 42

10 Technical specifications 43

11 Appendices 45

11.1 Connecting diagrams 45

11.2 Status display 48

4en | Table of contents Access Modular Controller 2

2022-11 | V05 | Руководство по установке Bosch Security Systems B.V.

11.2.1 Bootloader V00.49 48

11.2.2 Firmware until 6x.45, 37.60 49

11.2.3 Firrmware xx.61, 37.71 50

11.2.4 Firmware xx.62, 37.72 51

Access Modular Controller 2 Safety | en 5

Bosch Security Systems B.V. Руководство по установке 2022-11 | V05 |

1 Safety

Warning!

Read instructions

Before working with the device, read these instructions carefully. Make sure you have

understood all information described in this document.

Caution!

Fire hazard and risk of electric shock due to unauthorized spare parts and accessories

Unauthorized spare parts and accessories might lack grounding wires or other safety

elements. External power supplies must be installed by qualified personnel. The service

technician must use replacement parts or accessories that are specified by the manufacturer.

Warning!

Risk of explosion of lithium battery

The battery can explode if it is replaced incorrectly. Pay attention to the correct polarity when

inserting.

Replace only with the same battery type, as recommended by the manufacturer.

Do not overheat or expose to fire, mechanical force, or unusual high/low air pressure

conditions.

Warning!

Risk of physical injury due to blocked escape routes

This product may block escape routes if not installed correctly. To keep escape routes free:

- Use locks in fail-safe mode, so that doors can be released if power fails.

- Install manual override switches, such as break-glass or lever stations, to unlock doors in an

emergency.

Notice!

Dispose used batteries according to the battery manufacturer’s instructions, local laws and

regulations. Batteries must be disposed of separately from household waste.

Notice!

Device damage due to incorrect mounting

Mount this product on the matching mounting rails.

If the device falls or is damaged, check it before the installation.

Notice!

Considerations on local regulations

When you install the device, consider any local fire, health and safety regulations.

Notice!

Device damage due to electrostatic discharge

Protect the hardware from electrostatic discharge, especially when the device is open and

exposed. Always disconnect the controller from the power source before modifying the

installation. This product does not support hot plugging.

6en | Safety Access Modular Controller 2

2022-11 | V05 | Руководство по установке Bosch Security Systems B.V.

Notice!

Unauthorized access

If this product is installed in an unprotected environment, unauthorized people may be able

to enter.

Install the product in a location with restricted access.

This device is not suitable for use in locations where children may be present.

Notice!

Some features and functions described in this document depend on the firmware loaded into

the device and host software. Make sure that the controller is updated to the firmware

version provided with the host system.

This product is RoHS compliant. See Technical data for the full table of hazardous

components.

Access Modular Controller 2 Short information | en 7

Bosch Security Systems B.V. Руководство по установке 2022-11 | V05 |

2 Short information

This controller is able to control up to two Wiegand card readers.

It is designed to fully process the access logic at assigned access points. Access points

consist of doors, gates, barriers, turn stiles, revolving doors, mantraps, ID card readers, door

opening elements and sensors.

All the product versions use encrypted connections between the access modular controller

and the host system.

The controller stores all necessary information in a battery-buffered memory and in a compact

flash storage element. Even when the unit is offline, it is able to perform:

– Independent status and authorization checks on access points

– Take access decisions

– Activate and deactivate connected peripheral elements

– Detect and register all relevant events

The Access Modular Controller (AMC) is supported by the Access Professional Edition (APE),

BIS Access Engine (ACE) and the Access Management System (AMS).

For the latest information about our products, visit our online product catalog:

www.boschsecurity.com/xc/en/product-catalog/

Manufacturing dates

For product manufacturing dates, go to www.boschsecurity.com/datecodes/ and refer to the

serial number on the product label.

Remarks

This hardware is part of a security system.

Access should be granted to authorized people only.

Some states do not allow the exclusion or limitation of implied warranties, or limitation of

liability for incidental or consequential damages, hence the above limitation or exclusion might

not apply to you.

If you need further assistance or have any questions, contact:

Bosch Security Systems B.V.

Torenallee 49

5617 BA Eindhoven

Netherlands

www.boschsecurity.com

8en | Introduction Access Modular Controller 2

2022-11 | V05 | Руководство по установке Bosch Security Systems B.V.

3 Introduction

3.1 Description

The controller is equipped with two independent interfaces for Wiegand type readers. It is

able to control one door with one reader in each direction and up to two doors with a reader

in one direction only.

Figure3.1: Access Modular Controller

All necessary information for access verification is stored in a battery buffered on-board

memory and a Compact Flash (CF) memory card. This guarantees autonomous access

decisions and complete access registrations even if the management host system is offline.

The built in compact flash adapter provides adequate storage capability for cardholders and

events.

The electronics of the controller are completely covered by a plastic housing. The LCD (liquid

crystal display) provides all important status information.

Unsecured Area

Figure3.2: Example

Access Modular Controller 2 Introduction | en 9

Bosch Security Systems B.V. Руководство по установке 2022-11 | V05 |

The controller can communicate upstream to the host computer using one of the following

interfaces:

– Ethernet

– RS-485 multi-dropped, not supported by:

– BIS 4.9.1 and later

– AMS 4.0 and later.

The controller has four analog input devices and four relay outputs. With its analog input

devices, the controller verifies, for example, if a lock is closed or open. The relay outputs can

be used, for example, to activate lock mechanisms if access is granted, or activate the burglar

alarm system if an intrusion or system alert is detected. If the four inputs and four outputs on

the board are not enough to configure the system, up to three additional extension boards can

be connected. The extensions offer 8 or 16 additional inputs and outputs.

In the Bosch Access Host Systems, the setup procedure for a controller is made very simple

and fast by the use of door templates. Once selected, all the inputs and outputs are

predefined. These settings can be changed to choose every free contact of the controller or a

connected extension.

The product name and marking can be found on the backside of the product housing.

10 en | Introduction Access Modular Controller 2

2022-11 | V05 | Руководство по установке Bosch Security Systems B.V.

3.2 Product overview

3.2.1 Mainboard

Figure3.3: Upper circuit board with display (front)

1 DIP switch for RS-485 address and protocol selection.

2 Lithium battery for buffering of static RAM and real time clock (RTC). The battery life

is estimated at 10 years, nevertheless an error message is generated if the voltage

sinks below a preset minimum level.

NOTICE: In order to avoid an error message caused by an earlier voltage drop we

suggest to replace the battery every 8 years. Spare part: VARTA CR 2032 PCB.

3 Reset push button - reachable through the casing using a screwdriver

4 Liquid Crystal Display

5 Push button, available on top of the housing, to select different display modes

6 Jumper: Equalization of potential between different systems and earth ground

(shield)

7 Jumper: Interface selector RS-485 host connection, RS-485 two wire or RS-485 four

wire (depends on external wiring)

8 Configurable RS-485 host interface

9 Compact flash memory

10 Project-specific interface

11 Configurable 10/100 Mbit/s Ethernet host interface
