Blendtec DESIGNER 625 Manuel utilisateur

DESIGNER SERIES

OWNER’S MANUAL AND USER GUIDE

TABLE OF CONTENTS

SECTION 1 - IMPORTANT SAFEGUARDS ��1

SECTION 2 - UNPACKING��3

SECTION 3 - GETTING TO KNOW YOUR BLENDER��3

SECTION 4 - INSTALLATION��4

SECTION 5 - OPERATIONAL OVERVIEW��6

SECTION 6 - CARE AND CLEANING��15

SECTION 7 - TROUBLESHOOTING��16

SECTION 8 - WARRANTY ��17

SECTION 1: IMPORTANT SAFEGUARDS

IMPORTANT INFORMATION

Read all instructions carefully before using your Designer series blender�

Following these instructions will help prevent injuries and damage to the machine and will

ensure that you have the best possible experience with your Designer series blender�

1.1 AVOID CONTACT WITH MOVING PARTS

• ALWAYS keep ﬁngers, hands, hair and clothing away from all moving parts�

• ALWAYS keep all utensils away from the drive socket and blender jar blades

during operation as utensils may damage blades or the blender jar�

• NEVER put hands into the blender jar or add substances by hand when the

blender jar is on the motor base�

• NEVER touch the blade with your ﬁngers whether it is on or off the motor base�

• NEVER place jar into drive socket if blender motor is operating�

• DO NOT rock or remove the blender jar during operation�

These precautions will prevent personal injury and/or damage to the blender�

1.2 NEVER OPERATE THE BLENDER IF IT APPEARS DAMAGED

If the blender malfunctions, call your service agent ﬁrst� If it is dropped or damaged

in any way, return the blender to a Blendtec service agent immediately for

examination, repair, electrical or mechanical adjustment, or possible replacement�

1.3 NEVER OPERATE BLENDER IN LIQUID

To protect against the risk of electrical shock do not put the motor base in

water or other liquid� Do not use the blender outdoors where it is subject to

precipitation� Doing so will also void the warranty�

1.4 NEVER PUT NON-FOOD ITEMS INTO JAR

Utensils, rocks, and glass are dangerous if placed in jar� Damage caused by such

foreign objects will void the warranty� Keep hands and utensils out of jar while

blending to reduce the risk of severe injury to persons or damage to the blender�

Utensils may only be used when the blender is not running�

1.5 NEVER OPERATE THE BLENDER WITHOUT THE LID IN PLACE

1.6 NEVER OPERATE THE BLENDER USING ATTACHMENTS NOT

SOLD BY BLENDTEC

The use of any unauthorized attachments may cause ﬁre, electric shock, and/or

injury and will void the warranty�

1.7 BLENDER JAR MUST BE PROPERLY IN PLACE WHILE

APPLIANCE IS OPERATING

1.8 BLADES ARE SHARP! HANDLE CAREFULLY!

1.9 WARNING, DO NOT BLEND HOT LIQUIDS OR OTHER

HOT INGREDIENTS

Starting blend cycles with boiling or very hot liquids may result in burns or cause

the lid to blow off�

1.10 USE CAUTION WHEN BLENDING ON THE SOUP CYCLE

When blending on the Hot Soup cycle, friction of the blade will heat the contents�

The vented lid will allow pressure relief� Be careful not to come in contact with any

steam coming from the clear center lid�

1.11 POWER CORD PRECAUTIONS

• NEVER operate with a damaged cord or plug� If the supply cord is damaged it

must be replaced by the manufacturer or authorized service agent to avoid a

hazard�

• DO NOT permit the cord to hang over the edge of the work surface�

• NEVER use an extension cord with the unit�

• Unplug the blender motor when not in use, before changing blender locations, or

cleaning�

1.12 NEVER ATTEMPT TO REPAIR THE POWER UNIT

Never remove the blender motor cover� The blender motor does not contain self-

adjustable or serviceable parts� A qualiﬁed service agent must make all service

adjustments� Removing the cover or attempting to service the blender will void

the warranty�

1.13 TURN THE BLENDER OFF WHEN NOT IN USE

1.14 AVOID TOUCHING THE BLENDER DRIVE SOCKET AFTER

EXTENSIVE USE

The blender drive socket may become hot after numerous cycles�

1.15 SAFETY

This appliance is not intended for use by persons (including children) with reduced

physical, sensory or mental capabilities, or lack of experience and knowledge,

unless they have been given supervision or instruction concerning use of the

appliance by a person responsible for their safety� Children should be supervised

to ensure that they do not play with the appliance�

1.16 DESIGNER SERIES BLENDERS ARE INTENDED FOR HOME

USE ONLY! ANY USE OF THE DESIGNER SERIES BLENDER

FOR COMMERCIAL PURPOSES VOIDS ALL WARRANTIES

1.17 NEVER OPERATE THE BLENDER WITH MORE THAN THE

MARKED CAPACITY OF THE JAR

SAVE THESE INSTRUCTIONS

SECTION 2: UNPACKING

SAVE ALL PACKAGING MATERIALS AND INSTRUCTIONS FOR FUTURE USE

2.1 UNPACKING YOUR BLENDER

You should have received the following items:

• Designer series blender motor base

• Blender jar with lid

• Blendtec 101 booklet

• Customer Service and Warranty Registration Card

Additional literature may be included depending on package conﬁguration

1� Remove blender motor base, blender jar, and lid from packaging�

2� Unwind the power cord�

3� Check for any packing material that may have blocked ventilation holes on the

underside of the blender motor base�

4� Inspect all items to ensure no damage occurred during shipment�

5� If any damage has occurred, contact your Blendtec service agent immediately�

2.2 RECORDING YOUR SERIAL NUMBER AND DATE OF

PURCHASE

Record your blender motor serial number and date of purchase in the space

below� You will need these when contacting Blendtec for service or questions�

Motor Serial #(Found on bottom of motor base):_______________________

Date of Purchase: ____________________________________________

Purchased From: _____________________________________________

2.3 REGISTRATION OF YOUR BLENDER

SECTION 3: GETTING TO KNOW YOUR BLENDER

(Refer to Figures 1 and 2)

3.1 BLENDER MOTOR BASE

• Smart Touch Interface: Consists of preprogrammed cycles, capacitive touch

slider, and various one-touch settings, depending on model�

• Hardened Metal Drive Socket: Where the jar couples with the motor to turn the

blade assembly; made of hardened metal�

• LED Information Center: Displays the number of times a blend cycle button has

been pressed, the time left to blend, and error messages�

• Power Unit: This unit is located within the blender motor base and contains the

computerized electronics that run the blender�

• Motor Base Cover: Houses the power unit in a durable, plastic material�

• Power Cord: Located at the back of the motor base cover�

3.2 BLENDER JAR ASSEMBLY

The blender jar assembly consists of the blender jar, blade assembly, and lid�

• Jar: Durable, BPA-free jar; easy to clean�

• Blade Assembly: Uniquely designed stainless steel blade provides fast,

consistent blending�

• Lid: Vented gripper lid seals liquids within the jar during blending�

NOTE: Filling the blender jar beyond the marked capacity is not recommended.

SECTION 4: INSTALLATION

1� Place the blender on a ﬂat, clean, and dry surface� Blender vents should be

unobstructed to allow proper cooling during use�

2� Make sure an outlet is available within two feet (61cm) of the blender motor�

3� Place appropriately ﬁlled blender jar, with lid in place, onto blender base�

4� We recommend that surge protection be placed between the receptacle and

the blender motor�

Smart Touch

Interface

Plunger-Free

Easy-Clean Jar

The jar shown above is the Wildside+™Jar

FIGURE 1: BLENDER JAR ASSEMBLY

FIGURE 2: MOTOR BASE

Hardened Metal

Drive Socket

LED Information Center

Power Cord

located in back

Motor Base Cover

Blade Assembly

Lid Clear Vented

Cap Insert

Power Unit

SECTION 5: OPERATIONAL OVERVIEW

5.1 QUICK RECIPE INSTRUCTIONS –

Use these steps to get started right away.

1� Choose a recipe from the included Blendtec Blending 101 booklet�

2� Gather all of the ingredients�

3� Load the blender jar as indicated in the recipe�

4� Plug in the blender�

5� Press the power button located on the upper right hand side of the

smart touch interface�

6� A cycle count (indicating the number of cycles the blender has run) will

display on the LED Information Center for three seconds following power on�

7� Attach the blender lid to the jar; ensure that it sits on the jar completely�

8� Place the blender jar onto the base, making sure the jar is secure and fully seated

on the motor base�

9� Press the indicated icon from the recipe once (or as indicated in the recipe)

or use the slider for manual control�

10� When cycle is complete, remove the blender jar from the blender base�

11� Remove the jar lid and serve as indicated in the recipe�

12� For best cleaning results, clean immediately after blending�

(See CARE AND CLEANING, 6�1)

5.2 ALL ABOUT BLEND CYCLES

Blend cycles are timed cycles designed for speciﬁc types of blends� These

one-touch cycles speed up, slow down, and shut off automatically, so results

are perfect every time�

Each blender in the Designer series features a number of preprogrammed

cycles and settings that provide a wide range of recipes and functions*:

Smoothie — Fruit smoothies, green smoothies, milkshakes

Timed Cycles — hot soup, bread dough

Dips — dressings, dips, sauces, batters

Ice Cream — ice cream, frozen yogurt, sorbets

Hot Soup — soups, hot chocolate, syrups, fondues

Whole Juice — juices, green drinks

Clean — automatic cleaning cycle

Batters — sauces, dips, dressings, batters

Mixed Drinks — mixed drinks, milkshakes, crush ice

+10 — adds 10 seconds to your preprogrammed cycles

Pulse — used to quickly stir, chop, or mince at a high speed

Blend Rewards — the Designer 725 displays a code when blending milestones

are reached that can be redeemed online for prizes�

*Interfaces and cycles will vary depending on model number.

5.3 DESIGNER 600

SMOOTHIE

This cycle is designed speciﬁcally for various types of smoothies and thick

drinks that frequently use dense or frozen ingredients� It slows down and

speeds up automatically during the course of the cycle� This allows the blender

to draw the ingredients into the blending vortex, creating the desired texture�

To use the Smoothie cycle, load your jar as indicated in the recipe you are using,

secure the lid, and press the Smoothie icon� The blender will run the cycle and

automatically shut off�

ONE-TOUCH TIMED CYCLES

The Designer 600 comes equipped with three one-touch timed cycles: one

60-second, one 90-second, and one 180-second� These cycles free your

hands for other kitchen tasks and are ideal for recipes that require longer

blending times, such as hot soup or bread dough�

PULSE

The Pulse function is used for chopping, mincing, whipping, or other momentary

tasks that do not require a long blend cycle� You can also Pulse to quickly stir

a blend before serving�

The Pulse setting runs at speed 7 and will only run while the Pulse icon

remains pressed� When the icon is released, the motor shuts off�

CAPACITIVE TOUCH SLIDER

The capacitive touch slider allows you to ﬁne-tune the speed of your blender�

Simply slide your ﬁnger to the right to increase the blender’s speed or the left

to decrease speed�

5.4 DESIGNER 625

SMOOTHIE

This cycle is designed speciﬁcally for various types of smoothies and thick drinks

that frequently use dense or frozen ingredients� It slows down and speeds up

automatically during the course of the cycle� This allows the blender to draw the

ingredients into the blending vortex, creating the desired texture�

To use the Smoothie cycle, load your jar as indicated in the recipe you are using,

secure the lid, and press the Smoothie icon� The blender will run the cycle and

automatically shut off�

ICE CREAM

This cycle is designed speciﬁcally for frozen treats, including ice cream, sorbets,

and frozen yogurt� The cycle speeds up and slows down at the appropriate

moments to ensure your blends stay frozen�

To use the Ice Cream cycle, load your jar as indicated in the recipe you are using,

secure the lid, and press the Ice Cream icon� The blender will run the cycle and

automatically shut off� After creating your frozen dessert, serve immediately and

store leftovers in the freezer�

WHOLE JUICE

This cycle is designed to completely blend tough and dense ingredients,

including carrots, celery, and seeds� Use the Whole Juice cycle if you are using

any fruits and/or vegetables with stems, seeds, or skins�

When blending carrot juice or other dense juices, you may need to repeat this

cycle once or twice until the desired texture and consistency are achieved�

HOT SOUP

This cycle is designed for hot recipes� The cycle’s length of time, combined with

the speed of the motor, heats the ingredients to a hot temperature� This cycle can

also be used for hot chocolate, syrups, and fondue�

When using fresh ingredients, remember that the speed of the blade generates

enough heat to warm the ingredients Do not add any liquids or ingredients over

115° F (46° C) to the jar when preparing soups or hot items�

PULSE

The Pulse function is used for chopping, mincing, whipping, or other momentary

tasks that do not require a long blend cycle� You can also Pulse to quickly stir a

blend before serving�

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Blendtec Mixer

Blendtec

Blendtec DESIGNER SERIES Mode d’emploi

Blendtec

Blendtec NITRO Blending Systems 2.0 Manuel utilisateur

Blendtec

Blendtec DESIGNER SERIES Mode d’emploi

Blendtec

Blendtec ES3 Manuel utilisateur

Blendtec

Blendtec Tom Dickson Extreme Blender Manuel utilisateur

Blendtec

Blendtec Total Blender Classic Combo Manuel utilisateur

Blendtec

Blendtec Total Blender Mode d’emploi

Blendtec

Blendtec Signature Series Manuel utilisateur

Blendtec

Blendtec Go 41-503 Manuel utilisateur

Blendtec

Blendtec Brawn Manuel utilisateur

Blendtec

Blendtec CHEF Manuel utilisateur

Blendtec

Blendtec Xpress Manuel utilisateur

Blendtec

Blendtec STEALTH 895 Mode d’emploi

Blendtec

Blendtec Mix n Blend II Guide rapide

Blendtec

Blendtec Stealth Manuel utilisateur

Blendtec

Blendtec Rapid Rinser Manuel utilisateur

Blendtec

Blendtec PROFESSIONAL 800 Mode d’emploi

Blendtec

Blendtec Classic Manuel utilisateur

Blendtec

Blendtec 625D Manuel utilisateur

Blendtec

Blendtec Classic Manuel utilisateur

Blendtec

Blendtec Q-SERIES Manuel utilisateur

Blendtec

Blendtec CLASSIC SERIES Mode d’emploi

Blendtec

Blendtec DESIGNER SERIES Mode d’emploi

Blendtec

Blendtec Mix n Blend II Guide rapide

Manuels Mixer populaires d'autres marques

ROTOR

ROTOR 1125.201 Manuel utilisateur

Braun

Braun Multiquick 5 Vario series Manuel utilisateur

ARENDO

ARENDO MIRA 305424 Manuel utilisateur

CHEF-BUILT

CHEF-BUILT CCB-3500 Manuel utilisateur

Viconte

Viconte VC-4406 Manuel utilisateur

Oster

Oster BLSTAB-CB0 Manuel utilisateur

HOFFEN

HOFFEN MC-3005 Manuel utilisateur

Black & Decker

Black & Decker BLC18750DM Manuel utilisateur

Sunbeam

Sunbeam 4182 Manuel utilisateur

Bialetti

Bialetti FMX35 Manuel utilisateur

Black & Decker

Black & Decker BL8000 Manuel utilisateur

Duronic

Duronic BL530 Manuel utilisateur

Exquisit

Exquisit MS 3002 wes Manuel utilisateur

Lumme

Lumme LU-KP1891A Manuel utilisateur

Binatone

Binatone HB-735 Manuel utilisateur

Moulinex

Moulinex LM936E10 Manuel utilisateur

Oster

Oster VERSA Manuel d'installation et d'exploitation

Ninja

Ninja NN210Q Manuel utilisateur
