DE FAULT SETTINGS

The switch’s default values are listed below:

IP Address: 192.168.1.1

Subnet Mask: 255.255.255.0

Default Gateway: 192.168.1.254

Username: admin

Password: <none> (Just press the Enter key.)

41. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM

NEED HELP?

LEAVE THE TECH TO US

LIVE 24/7

TECHNICAL

SUPPORT

1.877. 87 7. 2269

SAFETY INFORMATION

CAUTION: Circuit devices are sensitive to static electricity, which can damage their delicate electronics. Dry weather conditions

or walking across a carpeted floor may cause you to acquire a static electrical charge.

To protect your device, always:

Touch the metal chassis of your computer to ground the static electrical charge before you pick up the circuit device.

Pick up the device by holding it on the left and right edges only.

If you need to connect this device to an outdoor device, add an arrester on the cable between the outdoor device and this device.

NOTE: The switch is indoor device; if it will be used in an outdoor environment or connects with an outdoor device, you must use

a lightning arrester to protect the switch.

WARNING:

Self-demolition on the product is strictly prohibited. Damage caused by self-demolition will be charged repairing fees.

Do not place product at outdoor or sandstorm..

Before installation, make sure the input power supply and product specifications are compatible with each other.

To reduce the risk of electric shock, disconnect all AC or DC power cord and RPS cables to completely remove power from the unit.

Before importing/exporting a configuration, make sure the firmware version is always the same.

After a firmware upgrade, the switch will replace the configuration automatically with the latest firmware version.

WARNING: EYE HAZARD! The SFP modules are Class 1 laser devices. Do not look direcly at the beam coming from the transmit

port.

1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM

NEED HELP?

LEAVE THE TECH TO US

LIVE 24/7

TECHNICAL

SUPPORT

1.877. 87 7. 2269

RELATED PUBLICATIONS/REVISION HISTORY

RELATED PUBLICATIONS

The following publication gives specific information on how to operate and use the management functions of the switch:

GUI User Guide

To download the user guide from blackbox.com:

1. Go to www.blackbox.com

2. Enter the part number in the search box (for example, LGB2118A or LGB2126A).

3. Click on the product in the “Products” page.

4. Click on the “Support” tab on the product page and select the document you wish to download.

61. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM

NEED HELP?

LEAVE THE TECH TO US

LIVE 24/7

TECHNICAL

SUPPORT

1.877. 87 7. 2269

CHAPTER 1: SPECIFICATIONS

GBE WEB SMART SWITCH — 18-PORT (LGB2118A)

APPROVALS FCC Part 15 Class A, CE, RoHS

STANDARDS IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1q

HARDWARE PERFORMANCE

DISTANCE Copper: 100 m (328 ft.) maximum;

With optional SFP Optical Transceivers:

LFP411: Multimode fiber: 550 m (1804.4 ft.) maximum;

LFP413: Single-mode fiber: 10 km (6.2 mi.) maximum;

LFP414: Single-mode fiber: 30 km (18.6 mi.) maximum

MAC ADDRESSES 8 K

MECHANICAL

CONNECTORS (16) RJ-45, (2) SFP ports

INDICATORS LEDs: Per unit: (1) PWR, (1) CPU;

Per port: (1) LINK/ACT, (1) 10/100/1000 Mbps;

Also Ports 17–18: (1) SFP

USER CONTROLS (1) Mode button

POWER Voltage: 100–240 VAC:

Frequency: 50–60 Hz, autosensing

DIMENSIONS 1.45" H (1U) x 8.57" W x 5.86" D (3.7 x 21.8 x 14.9 cm)

WEIGHT 4.63 lbs. (2.1 kg)

ENVIRONMENTAL Operating Temperature: 32 to 104° F (0 to 40° C);

Humidity: 10to 90% noncondensing

1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM

NEED HELP?

LEAVE THE TECH TO US

LIVE 24/7

TECHNICAL

SUPPORT

1.877. 87 7. 2269

CHAPTER 1: SPECIFICATIONS

GBE WEB SMART SWITCH - (24) RJ-45, (2) SFP (LGB2126A)

APPROVALS FCC Part 15 Class A, CE, RoHS

HARDWARE PERFORMANCE

FILTERING/FORWARDING RATE 38.688 Mpps

SWITCHING CAPACITY 52 Gbps

MAC TABLE 8 K

JUMBO FRAMES 9216 bytes

MECHANICAL

CONNECTORS (24) 10/100/1000BASE-T RJ-45; (2) SFP; (1) DB9 console

INDICATORS (1) System LED;

(18) Port Status LEDs

USER CONTROLS (1) Reset Pushbutton

POWER Voltage: 100–240 VAC:

Frequency: 50–60 Hz

DIMENSIONS 1.75 (1U)”H x 11”W x 6.5”D (4.4 x 28 x 16 cm)

WEIGHT 5.5 lb. (2.5 kg)

ENVIRONMENTAL Operating Temperature: 32 to 104° F (0 to 40° C):

Storage Temperature: -4 to +158° F (-20 to +70° C);

Operating Humidity: 10 to 90% noncondensing

SOFTWARE FEATURES

LAYER 2 SWITCHING Spanning Tree Protocol, Link Aggregation Control Protocol, VLAN, DHCP Relay, IGMP Snooping, IGMP Querier, IGMP Proxy,

MLD v1/v2 Snooping, multicast VLAN

MANAGEMENT Port mirroring, IEEE 802.1ab (LLDP) web GUI interface, dual image, UPnP, DHCP server, remote monitoring, SNMP, firmware upgrade,

NTP, HTTP/HTTPs, DHCP client, cable diagnostics, Syslog, Telnet client, SSH, IPv6

PORT MIRRORING Traffic on a port can be mirrored to another port for analysis with a network analyzer or RMON probe. Up to N-1 (N is Switch’s Ports)

ports can be mirrored to single destination port. A single session is supported

QOS Hardware queue, scheduling, classification, rate limiting

SECURITY Secure Shell (SSH) Secure Sockets Layer (SSL), IEEE 802.1X, Layer 2 Isolation Private VLAN Edge, port security, IP source guard,

RADIUS/TACACS+, storm control, DHCP snooping, loop protection ACLs

VLAN SUPPORT Supports up to 4K VLANs simultaneously (out of 4096 VLAN IDs), Port-based VLAN, 802.1Q tag-based VLAN, MAC-based VLAN,

Management VLAN, Private VLAN Edge (PVE), Q-in-Q (double tag) VLAN, Voice VLAN, GARP VLAN Registration Protocol (GVRP)

81. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM

NEED HELP?

LEAVE THE TECH TO US

LIVE 24/7

TECHNICAL

SUPPORT

1.877. 87 7. 2269

CHAPTER 2: OVERVIEW

2.1 INTRODUCTION

This user guide describes how to install, configure, and troubleshoot the 18- or 26-Port GbE Web Smart Switch.

By reading this user guide, users can perform the following tasks:

Check the switch status by reading the LED behavior

Reset the switch or to restore the switch to factory defaults

Install the switch

Use a Web browser to initially configure the switch

Troubleshoot the switch functions

2.2 FRONT VIEW OF THE SWITCH

10/100/1000

RJ-45 ports

Reset

button

System

LED

Port Status

LEDs

100/1000

SFP ports

FIGURE 2-1. FRONT PANEL OF THE LGB2126A SWITCH

NOTE: The LGB2118A looks similar, but it has 16 10/100/1000 RJ-45 ports and 2 100/1000 SFP ports.

2.3 REAR VIEW OF THE SWITCH

100–240 VAC

power connector

FIGURE 1-2. BACK PANEL OF THE LGB2118A OR LGB2126A SWITCH

1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM

NEED HELP?

LEAVE THE TECH TO US

LIVE 24/7

TECHNICAL

SUPPORT

1.877. 87 7. 2269

CHAPTER 2: OVERVIEW

2.4 LED DESCRIPTIONS

The LEDs on the front panel provide users with switch status checking and monitoring. There are two types of LEDs as follows:

System LED: indicates if the switch is powered up correctly or not.

Port Status LEDs: indicate the current status of each port. Users can check these LEDs to understand the port status.

The following table details the functions and descriptions of various LED indicators.

TABLE 2-1. SYSTEM LED

LED COLOR STATE DESCRIPTION

System Green ON The switch is powered on correctly

OFF The switch is not receiving power

TABLE 2-2. PORT STATUS LEDS

LED COLOR STATE STATUS

RJ-45 ports

Green ON The port is enabled and established a link to connected device, and the connection speed

is 1000 Mbps.

Green Blinking The port is transmitting/receiving packets, and the connection speed is 1000 Mbps.

Amber ON The port is enabled and established a link to connected device, and the connection speed

is 10/100 Mbps.

Amber Blinking The port is transmitting/receiving packets, and the connection speed is 10/100 Mbps.

—OFF The port has no active network cable connected, or it is not established a link to a connected

device. Otherwise, the port may have been disabled through the switch user interface.

SFP ports

Green ON The port is enabled and established a link to connected device, and the connection speed

is 1000 Mbps.

Green Blinking The port is transmitting/receiving packets, and the connection speed is 1000 Mbps.

Amber ON The port is enabled and established a link to connected device, and the connection speed

is 100 Mbps.

Amber Blinking The port is transmitting/receiving packets, and the connection speed is 100 Mbps.

—OFF The port has no active network cable connected, or it is not established a link to connected

device. Otherwise, the port may have been disabled through the switch user interface.

10 1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM

NEED HELP?

LEAVE THE TECH TO US

LIVE 24/7

TECHNICAL

SUPPORT

1.877. 87 7. 2269

CHAPTER 2: OVERVIEW

2.5 RESET BUTTON

By pressing the Reset Button for certain period of time, users can perform the following tasks.

Reset the Switch to reboot and get the switch back to the previous configuration settings saved.

Restore the Switch to Factory Defaults to restore the original factory default settings back to the switch.

NOTE: According to the table below, users can easily judge which task is being performed by reading the LED behaviors while

pressing the Reset button. Once the LED behaviors are correctly displayed, users may just release the button.

TABLE 2-3. RESET BUTTON

TASK TIME TO PRESS THE BUTTON SYS LED BEHAVIOR PORT STATUS LED BEHAVIOR

Reset the Switch 2–7 seconds Blinking Green All LEDs light OFF

Restore to Defaults 7–12 seconds Blinking Green All LEDs stay ON

Autres manuels pour LGB2118A

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Black Box Changer

Black Box

Black Box SW421A-R2 Manuel utilisateur

Black Box

Black Box KV6202A-R2 Manuel utilisateur

Black Box

Black Box ServSwitch II ACS250A Manuel utilisateur

Black Box

Black Box AVSC-0401H Manuel utilisateur

Black Box

Black Box ServSwitch KV752AE Manuel utilisateur

Black Box

Black Box LGB624A Manuel utilisateur

Black Box

Black Box PI750A Manuel utilisateur

Black Box

Black Box KV6224DPH Manuel utilisateur

Black Box

Black Box LPJ008A-T-R2 Manuel utilisateur

Black Box

Black Box LPB1305A Manuel utilisateur

Black Box

Black Box PSE518MA Manuel utilisateur

Black Box

Black Box 2 x 2 SCSI Matrix Switch SC121A Manuel utilisateur

Black Box

Black Box SM906C Manuel utilisateur

Black Box

Black Box LB8422A-US Manuel utilisateur

Black Box

Black Box LGB1126A Manuel utilisateur

Black Box

Black Box ServSwitch ACR9000A Manuel utilisateur

Black Box

Black Box ServSwitch ACU1006RA Manuel utilisateur

Black Box

Black Box MEG821AE Manuel utilisateur

Black Box

Black Box LE2425A Manuel utilisateur

Black Box

Black Box USB Single-Port Hub IC266A Manuel utilisateur

Black Box

Black Box 26633 Manuel utilisateur

Black Box

Black Box LB9019A Manuel utilisateur

Black Box

Black Box MT760A-232/232 Manuel utilisateur

Black Box

Black Box ServSelect IP VM KV2116A Instructions d'installation et d'entretien

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur
