Black Box MX320A-HS Manuel utilisateur

NOVEMBER 2000

MX320A-HS MX320AE-HS

MX325A-HS MX325AE-HS

X.25 PAD-2

CUSTOMER SUPPORT INFORMATION

Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)

FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746

Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018

Web site: www.blackbox.com • E-mail: [email protected]

RESET

CH3

ERROR

POWER

CH2

CH1

SYNC DATA

FCC AND IC STATEMENTS, TRADEMARKS

FEDERAL COMMUNICATIONS COMMISSION AND

INDUSTRY CANADA

RADIO-FREQUENCY INTERFERENCE STATEMENTS

This equipment generates, uses, and can radiate radio frequency energy

and if not installed and used properly, that is, in strict accordance with the

manufacturer’s instructions, may cause interference to radio communication.

It has been tested and found to comply with the limits for a Class A computing

device in accordance with the specifications in Subpart J of Part 15 of FCC rules,

which are designed to provide reasonable protection against such interference

when the equipment is operated in a commercial environment. Operation of

this equipment in a residential area is likely to cause interference, in which case

the user at his own expense will be required to take whatever measures may be

necessary to correct the interference.

Changes or modifications not expressly approved by the party responsible

for compliance could void the user’s authority to operate the equipment.

This digital apparatus does not exceed the Class A limits for radio noise emission from

digital apparatus set out in the Radio Interference Regulation of Industry Canada.

Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites

applicables aux appareils numériques de classe A prescrites dans le Règlement sur le

brouillage radioélectrique publié par Industrie Canada.

EN 55022 warning: This is a Class A product. In a domestic environment, it

might cause radio interference. If it does, the user might be required to take

adequate measures to correct the interference.

TRADEMARKS USED IN THIS MANUAL

BLACK BOX and the logo are registered trademarks of Black Box

Corporation.

Any other trademarks mentioned in this manual are acknowledged to be the property of the

trademark owners.

X.25 PAD-2

EUROPEAN UNION DECLARATION OF CONFORMITY

The manufacturer declares that the X.25 PAD-2 conforms to the following

EMC and safety standards:

• EN55022 (1994): “Limits and methods of measurement of radio

disturbance characteristics of information technology equipment.”

• EN50082-1 (1992): “Electromagnetic compatibility: Generic

immunity standard for residential, commercial, and light industry.”

• EN 60950 (1992/3): “Safety of information technology equipment,

including electrical business equipment.”

The X.25 PAD-2 herewith complies with the requirements of

the EMC Directive 89/336/EEC. The product was tested in a typical

configuration.

Also, in accordance with EN 41003, the safety status of all ports on the

X.25 PAD-2 is declared to be SELV (Safety Extra Low Voltage).

UL STATEMENTS, SAFETY WARNING

UL Listing Requirements

IMPORTANT SAFETY INSTRUCTIONS

For North American Users

The X.25 PAD-2 is powered by an external power supply. To

reduce the risk of shock, fire, and injury, use it only with a

UL®listed and CSA Certified Class 2 power supply rated 12

VDC, 400 (or more) mA.

Exigences UL

INSTRUCTIONS IMPORTANTS DE SÉCURITÉ

Pour les utilisateurs Nord Americains

Le X.25 PAD-2 est renforcé par un transformateur extérieur.

Afin de réduire le risque d’électrocution, de feux ou de

blessure, utiliser seulement avec le UL listé et le CSA

Certifié

classe 2 le transformateur de 12 VDC, 400 mA ou plus.

Safety Warning

Always observe standard safety precautions when you install,

operate, and maintain the X.25 PAD-2. Only qualified and

authorized service personnel should attempt to adjust,

maintain, or repair it; this should never be done by untrained

or unauthorized persons.

X.25 PAD-2

NORMAS OFICIALES MEXICANAS (NOM)

ELECTRICAL SAFETY STATEMENT

INSTRUCCIONES DE SEGURIDAD

1. Todas las instrucciones de seguridad y operación deberán ser leídas antes

de que el aparato eléctrico sea operado.

2. Las instrucciones de seguridad y operación deberán ser guardadas para

referencia futura.

3. Todas las advertencias en el aparato eléctrico y en sus instrucciones de

operación deben ser respetadas.

4. Todas las instrucciones de operación y uso deben ser seguidas.

5. El aparato eléctrico no deberá ser usado cerca del agua—por ejemplo,

cerca de la tina de baño, lavabo, sótano mojado o cerca de una alberca,

etc..

6. El aparato eléctrico debe ser usado únicamente con carritos o pedestales

que sean recomendados por el fabricante.

7. El aparato eléctrico debe ser montado a la pared o al techo sólo como sea

recomendado por el fabricante.

8. Servicio—El usuario no debe intentar dar servicio al equipo eléctrico más

allá a lo descrito en las instrucciones de operación. Todo otro servicio

deberá ser referido a personal de servicio calificado.

9. El aparato eléctrico debe ser situado de tal manera que su posición no

interfiera su uso. La colocación del aparato eléctrico sobre una cama,

sofá, alfombra o superficie similar puede bloquea la ventilación, no se

debe colocar en libreros o gabinetes que impidan el flujo de aire por los

orificios de ventilación.

NOM STATEMENT

10. El equipo eléctrico deber ser situado fuera del alcance de fuentes de calor

como radiadores, registros de calor, estufas u otros aparatos (incluyendo

amplificadores) que producen calor.

11. El aparato eléctrico deberá ser connectado a una fuente de poder sólo del

tipo descrito en el instructivo de operación, o como se indique en el

aparato.

12. Precaución debe ser tomada de tal manera que la tierra fisica y la

polarización del equipo no sea eliminada.

13. Los cables de la fuente de poder deben ser guiados de tal manera que no

sean pisados ni pellizcados por objetos colocados sobre o contra ellos,

poniendo particular atención a los contactos y receptáculos donde salen

del aparato.

14. El equipo eléctrico debe ser limpiado únicamente de acuerdo a las

recomendaciones del fabricante.

15. En caso de existir, una antena externa deberá ser localizada lejos de las

lineas de energia.

16. El cable de corriente deberá ser desconectado del cuando el equipo no

sea usado por un largo periodo de tiempo.

17. Cuidado debe ser tomado de tal manera que objectos liquidos no sean

derramados sobre la cubierta u orificios de ventilación.

18. Servicio por personal calificado deberá ser provisto cuando:

A: El cable de poder o el contacto ha sido dañado; u

B: Objectos han caído o líquido ha sido derramado dentro del

aparato; o

C: El aparato ha sido expuesto a la lluvia; o

D: El aparato parece no operar normalmente o muestra un cambio en

su desempeño; o

E: El aparato ha sido tirado o su cubierta ha sido dañada.

X.25 PAD-2

Contents

Chapter Page

1. Specifications .............................................................. 7

2. Introduction ............................................................. 11

3. Installation ................................................................ 13

3.1 The Complete Package ..................................... 13

3.2 Site Requirements ............................................. 13

3.3 Setting the NOR/INI Jumper ........................... 14

3.4 Connecting Cables and Power .......................... 16

3.4.1 Channel 1 ................................................. 16

3.4.2 Channels 2 and 3 ..................................... 17

3.4.3 Power ........................................................ 18

4. Operation .................................................................. 19

4.1 The External Components ............................... 19

4.2 Operating Instructions ...................................... 22

4.2.1 Power ON .................................................. 22

4.2.2 Normal Operation .................................... 23

4.2.3 Power OFF ................................................ 23

5. Troubleshooting ....................................................... 24

5.1 Things to Check First ........................................ 24

5.2 Calling Black Box .............................................. 25

5.3 Shipping and Packaging .................................. 26

CHAPTER 1: Specifications

1. Specifications

Compliance — CE (EN55022, EN 50082-1, EN 60950)

Class A; FCC Class A, IC Class/classe A

Interfaces —

Channel 1 (to packet-switched synchronous link):

MX320 models: ITU V.35 proprietarily pinned on

DB25, DTE;

MX325 models: EIA/TIA RS-232/ITU V.24/V.28,

DTE;

Channels 2 and 3 (to local async devices): EIA/TIA

RS-232/ITU V.24/V.28 proprietarily pinned on RJ-45,

DCE

Protocols —

Channel 1: Synchronous 1988 ITU X.25 LAP-B or Frame

Relay; for Frame Relay, supports CCLM, LMI, and

ANSI PVC management protocols, as well as ANSI

T1.606, T1.617 Annex D, T1.618, and ITU Q.922

Annex A;

Channels 2 and 3: Asynchronous SLIP or X.28 (user-

selectable)

Clock Source — Channel 1: Internal or external for

receive and transmit paths, user-selectable

X.25 PAD-2

Data Rate —

Channel 1:

MX320 models: Up to 2 Mbps, user-selectable;

MX325 models: Up to 128 kbps, user-selectable;

Channels 2 and 3: 75 bps to 115.2 kbps, user-selectable

Data Format — Channels 2 and 3: 5, 6, 7, or 8 data bits;

even, odd, mark, space, or no parity; 1, 1.5, or 2 stop

bits; user-selectable

Flow Control — Channels 2 and 3: Hardware (DTR/CTS)

or software (X-ON/X-OFF), user-selectable

Other Characteristics for Channels 2 and 3 —

Log-on messages: Herald and bulletin, user-definable;

Command modes: ITU X.28 (with proprietary

extensions) and X.29;

Terminal handling: Enhanced, beyond the requirements

of ITU X.3

Packet Size — Up to 4 KB for X.25 or 8 KB for Frame Relay

Maximum Distance —

Up to 50 ft. (15.2 m) to attached devices;

MX320 models: If unbalanced control leads aren’t

required, transmission across 500 ft. (152.4 m) or

more might be possible to/from Channel 1 only

CHAPTER 1: Specifications

Memory — 512 KB RAM

User Controls —

Top-mounted reset button;

(1) Internal board-mounted jumper for power-up

settings

Indicators — (6) Top-mounted LEDs:

(1) POWER (lights green while unit is powered);

(1) ERROR (lights red if a hardware malfunction is

detected);

(1) SYNC (lights or flashes green to show status of

synchronization between linked PAD-2s);

(3) DATA (one for each channel—these light or flash

yellow in response to data activity on the

corresponding ports)

Connectors —

(1) Left-side-mounted DB25 female for channel 1 (patch

cable provided to M/34 female on MX320 models);

(2) Right-side-mounted RJ-45 female for channels 2 and 3;

(1) Front-mounted barrel jack for power

Temperature Tolerance — 32 to 122˚F (0 to 50˚C)

Humidity Tolerance — Up to 90% noncondensing

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Black Box Modem

Black Box

Black Box 32457 Manuel utilisateur

Black Box

Black Box LD485S-MP Manuel utilisateur

Black Box

Black Box MDS932AE-10BT Manuel utilisateur

Black Box

Black Box SHM 128 Manuel utilisateur

Black Box

Black Box Short-Haul Modem-FSK Manuel utilisateur

Black Box

Black Box ME376A-R2 Manuel utilisateur

Black Box

Black Box 40418 Manuel utilisateur

Black Box

Black Box ME560A-V35-F Manuel utilisateur

Black Box

Black Box SHM-NPR Manuel utilisateur

Black Box

Black Box USR5686E Manuel utilisateur

Black Box

Black Box MiniModem USB Manuel utilisateur

Black Box

Black Box MPI Series Manuel utilisateur

Black Box

Black Box MD1970A Manuel utilisateur

Black Box

Black Box USB Director RS-232 Manuel utilisateur

Black Box

Black Box ME475A Manuel utilisateur

Black Box

Black Box ME475A Manuel utilisateur

Black Box

Black Box SME-422 Manuel utilisateur

Black Box

Black Box ME759C-RJ11 Manuel utilisateur

Black Box

Black Box ME758C-RJ11 Manuel utilisateur

Black Box

Black Box DESKTOP TELCO Manuel utilisateur

Black Box

Black Box ME605A-FST Manuel utilisateur

Black Box

Black Box MD1620A Manuel utilisateur

Black Box

Black Box Mini Driver 4W-S Manuel utilisateur

Black Box

Black Box MDR100A-R5 Manuel utilisateur

Manuels Modem populaires d'autres marques

Davicom

Davicom DM562AP Manuel utilisateur

EpiValley

EpiValley TATA indicom SXC-1080 Manuel utilisateur

Zte

Zte WiMAX Manuel utilisateur

Intelimax

Intelimax MA-2060 Manuel utilisateur

SMC Networks

SMC Networks D3CM1604V Manuel d'utilisation et d'entretien

Telstra

Telstra Wi-Fi 4G Advanced Pro X Manuel utilisateur

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 Manuel utilisateur

Samsung

Samsung AceLink SAM-335A Manuel utilisateur

Enfora

Enfora Enabler-G Guide de configuration rapide

iRZ

iRZ ATM2-232 Manuel utilisateur

Zhone

Zhone 6310 Manuel utilisateur

Paradyne

Paradyne Hotwire 7976 Manuel utilisateur

US Robotics

US Robotics 3453C Manuel utilisateur

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Manuel utilisateur

Zte

Zte MF823 Manuel utilisateur

Four-Faith

Four-Faith F1403 Manuel utilisateur

Sierra Wireless

Sierra Wireless AIRLINK MP595W Manuel utilisateur

Gemtek

Gemtek WiMAX WIXFBR-103 Manuel utilisateur
