Black Box Mini Driver-15 Manuel utilisateur
APRIL 1994
ME770A
Mini Driver-15
CUSTOMER SUPPORT INFORMATION
Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)
FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746
Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018
Mini Driver-15
S/N
1
FCC STATEMENT
FEDERAL COMMUNICATIONS COMMISSION
AND
INDUSTRY CANADA
RADIO FREQUENCY INTERFERENCE STATEMENTS
This equipment generates, uses, and can radiate radio-frequency energy,
and if not installed and used properly, that is, in strict accordance with the
manufacturer’s instructions, may cause interference to radio communication.
It has been tested and found to comply with the limits for a Class A computing
device in accordance with the specifications in Subpart B of Part 15 of FCC rules,
which are designed to provide reasonable protection against such interference
when the equipment is operated in a commercial environment. Operation of
this equipment in a residential area is likely to cause interference, in which case
the user at his own expense will be required to take whatever measures may be
necessary to correct the interference.
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
This digital apparatus does not exceed the Class A limits for radio noise emission from
digital apparatus set out in the Radio Interference Regulation of Industry Canada.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites
applicables aux appareils numériques de classe A prescrites dans le Règlement sur le
brouillage radioélectrique publié par Industrie Canada.
2
MINI DRIVER–15
NORMAS OFICIALES MEXICANAS (NOM)
ELECTRICAL SAFETY STATEMENT
INSTRUCCIONES DE SEGURIDAD
1. Todas las instrucciones de seguridad y operación deberán ser leídas antes
de que el aparato eléctrico sea operado.
2. Las instrucciones de seguridad y operación deberán ser guardadas para
referencia futura.
3. Todas las advertencias en el aparato eléctrico y en sus instrucciones de
operación deben ser respetadas.
4. Todas las instrucciones de operación y uso deben ser seguidas.
5. El aparato eléctrico no deberá ser usado cerca del agua—por ejemplo,
cerca de la tina de baño, lavabo, sótano mojado o cerca de una alberca,
etc..
6. El aparato eléctrico debe ser usado únicamente con carritos o pedestales
que sean recomendados por el fabricante.
7. El aparato eléctrico debe ser montado a la pared o al techo sólo como sea
recomendado por el fabricante.
8. Servicio—El usuario no debe intentar dar servicio al equipo eléctrico más
allá a lo descrito en las instrucciones de operación. Todo otro servicio
deberá ser referido a personal de servicio calificado.
9. El aparato eléctrico debe ser situado de tal manera que su posición no
interfiera su uso. La colocación del aparato eléctrico sobre una cama,
sofá, alfombra o superficie similar puede bloquea la ventilación, no se
debe colocar en libreros o gabinetes que impidan el flujo de aire por los
orificios de ventilación.
3
NOM STATEMENT
10. El equipo eléctrico deber ser situado fuera del alcance de fuentes de calor
como radiadores, registros de calor, estufas u otros aparatos (incluyendo
amplificadores) que producen calor.
11. El aparato eléctrico deberá ser connectado a una fuente de poder sólo del
tipo descrito en el instructivo de operación, o como se indique en el
aparato.
12. Precaución debe ser tomada de tal manera que la tierra fisica y la
polarización del equipo no sea eliminada.
13. Los cables de la fuente de poder deben ser guiados de tal manera que no
sean pisados ni pellizcados por objetos colocados sobre o contra ellos,
poniendo particular atención a los contactos y receptáculos donde salen
del aparato.
14. El equipo eléctrico debe ser limpiado únicamente de acuerdo a las
recomendaciones del fabricante.
15. En caso de existir, una antena externa deberá ser localizada lejos de las
lineas de energia.
16. El cable de corriente deberá ser desconectado del cuando el equipo no
sea usado por un largo periodo de tiempo.
17. Cuidado debe ser tomado de tal manera que objectos liquidos no sean
derramados sobre la cubierta u orificios de ventilación.
18. Servicio por personal calificado deberá ser provisto cuando:
A: El cable de poder o el contacto ha sido dañado; u
B: Objectos han caído o líquido ha sido derramado dentro del
aparato; o
C: El aparato ha sido expuesto a la lluvia; o
D: El aparato parece no operar normalmente o muestra un cambio en
su desempeño; o
E: El aparato ha sido tirado o su cubierta ha sido dañada.
4
MINI DRIVER–15
CONTENTS
Chapter Page
1.Specifications..........................................................5
2.Description .............................................................6
3.Installation..............................................................8
3.1 Using RJ-11 and RJ-45 Jacks .....................10
3.2 Installing the Strain-Relief Assembly.......13
Appendix..................................................................17
TRADEMARKS USED IN THIS MANUAL
AT&T®is a registered trademark of American Telephone and
Telegraph Company.
NCR®is a registered trademark of NCR Corporation.
Unisys®is a registered trademark of Unisys Corporation.
Any other trademarks mentioned in this manual are
acknowledged to be the property of the trademark owners.
5
CHAPTER 1: Specifications
1. Specifications
Protocol — Asynchronous
Speed — Up to 19.2 kbps (no strapping)
Distance — Wire Gauge
Speed (bps) 19 24 26
19,200 2.5 mi (4.0 km) 1.8 mi (2.9 km) 1.2 mi (1.9 km)
9600 5.5 mi (8.9 km) 3.7 mi (6.0 km) 2.5 mi (4.0 km)
4800 7.5 mi (12.0 km) 5.0 mi (8.0 km) 3.0 mi (4.8 km)
2400 8.5 mi (13.7 km) 5.6 mi (9.0 km) 3.7 mi (6.0 km)
1200 9.0 mi (14.5 km) 6.2 mi (10.0 km) 4.3 mi (6.9 km)
Surge Protection — 600W power dissipation at 1 ms and
response time less than 1.0 picoseconds
Control Signals — DSR and DCD follow DTR from the
terminal (DTE). CTS follows RTS from the terminal
(DTE)
Operation — 4-wire unconditioned twisted-pair, full
duplex
Transmit Level — -6 dBm
Connectors — (1) DB15 male or female; (1) S-screw
terminal block
Power — No power required; uses ultra-low power (5 volts
required) from EIA data and control signals: Pins 1, 2, 4,
10, and 12 in DCE mode (the Mini Driver does not
operate in DTE mode)
Size — 2.5"H x 1.2"W x 0.75"D (6.4 x 3 x 1.9 cm)
Temperature — 32 to 140°F (0 to 60°C)
Humidity — 95% non-condensing
6
MINI DRIVER–15
2. Description
The Mini Driver–15 lets you connect RS-232 devices
equipped with DB15 connectors, including Unisys®
(Sperry) 5000 and the NCR®“tower” series.
It features built-in transformers that eliminate noise
and ground loops, so you can link devices between
buildings.
At a range of 2.5 miles (4 km) on 19-AWG wire, the
Driver operates full-duplex at speeds up to 19.2 kbps
over two twisted-pair wires. Range can be extended
up to nine miles (14.5 km) at 1200 bps.
An external DCE/DTE switch lets you connect any
device without opening the Driver. Three enclosure
options allow terminations via RJ-11, RJ-45, or
terminal block. A strain-relief feature prevents thin
twisted-pair wires from breaking or pulling loose.
The MSP model features custom-made transformers
and transorbs for DC isolation and high-level surge
protection. It features the latest in bidirectional
clamping transient suppressors to protect itself and
connected equipment from harmful transient
discharges.
Note: The Line Driver 15 must be used in pairs.
7
CHAPTER 2: Description
Features
• Eliminates ground loops caused by ground-
potential differences in power systems.
• Features DC isolation between connected devices.
• Includes an external DCE/DTE switch.
• Housed in a small-size case (3/4-inch or 1.9-cm) for
closely spaced computer ports.
• Uses modular plugs or terminal posts.
• Supports speeds up to 19.2 kbps.
• Uses surface-mount technology.
• Made in the U.S.A.
8
MINI DRIVER–15
3. Installation
Note: These drivers work in pairs. You need one at each end of a 4-
wire telephone cable.
Proceed as follows to install the Mini Driver–15 units:
1. If your Driver features RJ-11 or RJ-45 modular jacks,
refer to Section 3.1. Be sure that the wiring between
the Drivers makes the connections shown in
paragraph 5. Now skip to paragraph 7.
2. If your Driver does not feature modular jacks,
open the unit and connect one pair of wires in the
telephone cable to XMT (Transmit) on the
terminal block. Be careful to observe polarity.
(The wire connected to XMT+ must be connected
to RCV+ in the other unit. The wire connected to
XMT- must be connected to RCV- in the other
unit.)
3. Connect the other pair of wires in the telephone
cable to RCV (Receive). Again, be careful to
observe polarity.
4. If there is a shield around the telephone cable, it
may be connected to G on the terminal block. We
recommend that you connect the shield only at
the computer end to avoid ground loops. A
ground wire is not necessary for proper operation.
5. When you finish connecting the telephone line to
units at both ends, it should look like this:
9
CHAPTER 3: Installation
6. Insert the connector hardware on each side of the
Driver. Snap the unit together. See Section 3.2.
7. Plug the Driver directly into a mating RS-232C
connector on your terminal or computer. Tighten
the two captive connector screws.
1 - Blue
2 - Orange
3 - Black
4 - Red
5 - Green
6 - Yellow
7 - Brown
8 - Slate
1 - Blue
2 - Yellow
3 - Green
4 - Red
5 - Black
6 - White
XMT+
XMT-
G
RCV-
RCV+
- - - - - - - - -
G
RCV-
- - - - - - - - - - - - - - - - - - - - -
- - - - - - - - - - - - - - - - - - - - - RCV+
To Shield (Optional)
- - - - - - - - - - - - - - - - - - - - - XMT-
- - - - - - - - - - - - - - - - - - - - - XMT+
One Pair
One Pair
G
Table des matières
Autres manuels Black Box Modem
Black Box
Black Box MicroNTU G.703 Series Manuel utilisateur
Black Box
Black Box ME109A Manuel utilisateur
Black Box
Black Box ME615A Manuel utilisateur
Black Box
Black Box SHM-NPR Plus Series Manuel utilisateur
Black Box
Black Box SME-422 Manuel utilisateur
Black Box
Black Box ME778C-RJ45 Manuel utilisateur
Black Box
Black Box Mini-Modem V.92 MD1626A Manuel utilisateur
Black Box
Black Box V.35 256/ST Series Manuel utilisateur
Black Box
Black Box 32144 Manuel utilisateur
Black Box
Black Box High Speed SHM-B Async Manuel utilisateur
Black Box
Black Box ME621A Manuel utilisateur
Black Box
Black Box ME760A-R2 Manuel utilisateur
Black Box
Black Box ME475A Manuel utilisateur
Black Box
Black Box ME251A-R3 Manuel utilisateur
Black Box
Black Box MT632A-ST35 Manuel utilisateur
Black Box
Black Box CSU/DSU MS/DBU Manuel utilisateur
Black Box
Black Box MPI Series Manuel utilisateur
Black Box
Black Box MD960A Manuel utilisateur
Black Box
Black Box ME657A-M/F Manuel utilisateur
Black Box
Black Box MD1650A-JP Manuel utilisateur
Manuels Modem populaires d'autres marques
Davicom
Davicom DM562AP Manuel utilisateur
EpiValley
EpiValley TATA indicom SXC-1080 Manuel utilisateur
Zte
Zte WiMAX Manuel utilisateur
Intelimax
Intelimax MA-2060 Manuel utilisateur
SMC Networks
SMC Networks D3CM1604V Manuel d'utilisation et d'entretien
Telstra
Telstra Wi-Fi 4G Advanced Pro X Manuel utilisateur
US Robotics
US Robotics 3453C Manuel utilisateur
MaxTech
MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Manuel utilisateur
Zte
Zte MF823 Manuel utilisateur
Four-Faith
Four-Faith F1403 Manuel utilisateur
Sierra Wireless
Sierra Wireless AIRLINK MP595W Manuel utilisateur
Gemtek
Gemtek WiMAX WIXFBR-103 Manuel utilisateur
