Black Box MD1650A-JP Manuel utilisateur

To order: Call 03-5471-8800 • Fax: 03-5471-8822

Mailing address: 6-1-1 Heiwajima, Ota-ku, Tokyo, 143-6501, Japan

Web site: www.blackbox.co.jp • E-mail: [email protected]

CUSTOMER

SUPPORT

INFORMATION

SEPTEMBER 2006

MD1650A-JP

V.92 Dialup 2-Wire or 4-Wire

Leased-Line Data/Fax Modem

Quick Start Guide

V.92 DIALUP 2-WIRE OR 4-WIRE LEASED-LINE DATA/FAX MODEM QUICK START GUIDE

FEDERAL COMMUNICATIONS COMMISSION

AND

INDUSTRY CANADA

RADIO FREQUENCY INTERFERENCE STATEMENTS

This equipment generates, uses, and can radiate radio-frequency energy, and if not installed and used

properly, that is, in strict accordance with the manufacturer’s instructions, may cause interference to radio

communication. It has been tested and found to comply with the limits for a Class A computing device in

accordance with the specifications in Subpart B of Part 15 of FCC rules, which are designed to provide

reasonable protection against such interference when the equipment is operated in a commercial

environment. Operation of this equipment in a residential area is likely to cause interference, in which

case the user at his own expense will be required to take whatever measures may be necessary to correct

the interference.

Changes or modifications not expressly approved by the party responsible for compliance could void the user’s

authority to operate the equipment.

This digital apparatus does not exceed the Class A limits for radio noise emission from digital apparatus set out in the Radio

Interference Regulation of Industry Canada.

Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques

de la classe A prescrites dans le Règlement sur le brouillage radioélectrique publié par Industrie Canada.

TRADEMARKS USED IN THIS MANUAL

BLACK BOX and the Double Diamond logo are registered trademarks of BB Technologies, Inc.

Windows and Windows NT are either trademarks or registered trademarks of Microsoft Corporation in the

United States and/or other countries.

UL is a registered trademark of Underwriters Laboratories, Inc.

Any other trademarks mentioned in this manual are acknowledged to be the property of the trademark owners.

V.92 DIALUP 2-WIRE OR 4-WIRE LEASED-LINE DATA/FAX MODEM QUICK START GUIDE

Getting Started

This Quick Start Guide will help you install and set up your modem. A User’s Guide containing detailed

configuration information and a separate AT Commands Reference Guide can be found on the CD-ROM that

was shipped with your modem.

Safety Warnings

• Use this product with UL®and cUL Listed computers only.

• To reduce the risk of fire, use 26 AWG or larger telephone wiring.

• Do not install telephone wiring during a lightning storm.

• Do not install a telephone jack in a wet location unless the jack is specifically designed for wet locations.

• Do not touch uninsulated telephone wires or terminals unless the telephone line has been disconnected at

the network interface.

• Use caution when installing or modifying telephone lines.

• Avoid using a telephone during an electrical storm; you might be shocked by lightning.

• Do not use a telephone in the vicinity of a gas leak.

V.92 DIALUP 2-WIRE OR 4-WIRE LEASED-LINE DATA/FAX MODEM QUICK START GUIDE

Modem Installation

Step 1: Connect the Modem to Your System

Power off your computer. Place the modem in a convenient location. Connect it to your computer’s serial port,

the telephone line, the leased line, AC power, and to your telephone (optional). See Figure 1 for an illustration

of this setup. Detailed information on each connection appears below the diagram and on the following pages.

Figure 1. Modem connections with V.92 transformer.

CONNECT TO YOUR PC

Plug one end of the serial cable into the RS-232 connector on the modem. Plug the other end into a serial port

connector on your computer, such as COM1 or COM2.

CONNECT TO THE TELEPHONE LINE (DIALUP CONNECTION)

Plug one end of the modular phone cable into the modem’s LINE jack. Plug the other end into a public

switched telephone network (PSTN) wall jack.

CAUTION

The LINE jack is not interchangeable with the PHONE jack. Do not plug the phone into

the LINE jack or the line cable into the PHONE jack.

NOTE

Regulatory agencies may impose certain restrictions on equipment connected to

public telephone systems.

Computer

V.92 Dialup 2-Wire or 4-Wire

Leased-Line Data/Fax Modem

PSTN wall jack

Power supply

Telephone

V.92 DIALUP 2-WIRE OR 4-WIRE LEASED-LINE DATA/FAX MODEM QUICK START GUIDE

CONNECT THE TWO-WIRE LEASED LINE

Plug one end of a two-wire phone cable into the modem’s LEASED jack. Connect the other end to a leased-line

wall jack or terminals.

CONNECT THE FOUR-WIRE LEASED LINE

Modems with a leased-line jack support the dial backup feature. For dial backup operation, plug one end of

your dialup modular phone cable into the modem’s LINE jack and the other end into a PSTN wall jack. Plug

one end of a two- or four-wire phone cable into the modem’s LEASED jack. Connect the other end to a leased-

line wall jack or terminals.

CONNECT THE MODEM TO THE AC POWER OUTLET

Plug the power transformer into an AC power outlet or power strip. Plug the power transformer’s cable into the

POWER jack on the modem.

NOTE

Use only the power transformer supplied with the modem. Using any other transformer

can damage the modem.

CONNECT THE PHONE TO THE MODEM (OPTIONAL)

For voice-only calls, plug a telephone into the modem’s PHONE jack.

POWER-ONTEST

Test the modem by powering it on via the front-panel power switch. When you apply power, the modem

performs a diagnostic self-test. The TM LED lights for a few seconds, then the LCD lights. If this doesn’t

happen, make sure the power switch is on, the power transformer is solidly connected, and the AC outlet is live.

If these measures don’t work, see Chapter 8 in the User’s Guide.

Step 2: Install the Modem Driver

If you use Windows®98/Me/XP, Windows 2000, or Windows NT®, you must install the modem driver. The

drivers install easily since Windows supports plug-and-play operation.

WINDOWS 98/ME/XP AND WINDOWS 2000

1. Make sure your modem is connected properly, then power on your computer. Windows should detect your

new modem and open the Install New Modem wizard.

NOTE

If Windows can’t find a modem, your modem may be powered off, it may be plugged

into the wrong connector on your computer, or the serial cable may be faulty. See

Sections 8.1 and 8.2 of the User’s Guide.

2. Insert the modem’s system CD into your CD-ROM drive, then click OK.

V.92 DIALUP 2-WIRE OR 4-WIRE LEASED-LINE DATA/FAX MODEM QUICK START GUIDE

3. Windows installs and configures the modem.

4. Click Finish to exit.

WINDOWS NT

1. Make sure your modem is connected properly, then power on your computer. Windows should detect your

new modem and open the Install New Modem wizard.

NOTE

If Windows can’t find a modem, your modem may be powered off, it may be plugged

into the wrong connector on your computer, or the serial cable may be faulty. See

Sections 8.1 and 8.2 of the User’s Guide.

2. In the Install New Modem wizard, select Don’t detect my modem; I will select it from a list, then click

Next. A dialog box with a list of manufacturers and a list of modem models appears.

3. Insert the modem’s system CD into your CD-ROM drive, then click OK.

4. A list of modems appears. Select your modem and click Next.

5. Select the port that the modem is connected to, then click Next.

6. Windows installs and configures the modem.

7. Click Finish to exit.

REMOVING AN OLD MODEM DRIVER

When your new modem replaces another modem, the old modem driver remains in Windows, and the old

modem driver is still selected in HyperTerminal and other Windows applications. Though you can change the

application connection descriptions one at a time, it is easier to force Windows applications to use the new

modem by removing the old modem driver from Windows.

1. Click the Start button, point to Settings, and click Control Panel.

2. Double-click the Modems icon to open the Modems Properties dialog box.

3. In the list box, select the old modem.

4. Click Remove, then click Close.

5. The next time you dial a HyperTerminal connection, it will select your new modem and ask you to confirm

the selection.

V.92 DIALUP 2-WIRE OR 4-WIRE LEASED-LINE DATA/FAX MODEM QUICK START GUIDE

Step 3: Setting Your Country or Region Code

Countries or regions vary in their requirements for how a modem functions. Therefore, you must configure

your modem to match the defaults of your country or region. Choose from any of the three methods:

• Using the LCD panel to set your country or region code.

• Using the global wizard to set your country or region code.

• Using AT commands to set your country or region code.

USING THE LCD PANEL

1. Start at the Status LCD and use ↓to move down the menu tree to the Region Select LCD.

2. Use →to move from the Region Select LCD across the Region Settings Options LCD to the Current

Setting LCD.

3. If the current setting shown is not the one for your region, use the arrow keys to get to the Region Profile

LCD. The question mark represents the question: Is this the region you want? If B5 is the one you want,

press Enter; if it’s not the one you want, use the arrow keys to get to the code you want. The region code

for Japan is 00.

4. When you reach the region code you want, press Enter. You will then see the message Option Set.

5. After setting the region profile, you can cycle the power to the modem (turn the power off, and then back

on again) or use the arrows to move back and up the menu tree to return to the Status LCD.

V.92 DIALUP 2-WIRE OR 4-WIRE LEASED-LINE DATA/FAX MODEM QUICK START GUIDE

Figure 2. LCD panel steps for setting your country code.

USING THE GLOBAL WIZARD

We recommend the Global Wizard configuration utility for computers running Windows. The Wizard can

configure your modem for a specific country with just a few mouse clicks.

1. Insert the modem CD into the CD-ROM drive. The Autorun dialog box appears.

2. Click Initial Setup and Country or Region Selection. The Global Wizard dialog box appears. Click Next.

3. The Global Wizard searches for your modem and identifies it. Click Next after your modem is identified.

4. Select the country or region in which the modem will be used. Click Next.

5. Review your choice. If it is correct, click Next to configure the modem.

6. When the Global Wizard announces that the parameters have been set, click Finish to exit.

Region Profile code

for Japan is 00 as

shown at left

V.92 DIALUP 2-WIRE OR 4-WIRE LEASED-LINE DATA/FAX MODEM QUICK START GUIDE

USING AT COMMANDS

If you are comfortable using AT commands, you can use them to configure your modem. You must enter these

commands in your communication program’s terminal window. You can use a communication program such as

PhoneTools.

How to change the country/region code

1. Set and save the country/region code (00) by typing the command AT+GCI=00<CR>.

2. An OK message displays onscreen.

3. The code 00 appears onscreen.

How to verify the code

Type AT +GCI?<CR> or use the command AT+00<CR>.

Step 4: Install PhoneTools

Data communications software gives you access to commands that govern how the modem operates.

The PhoneTools data communications software package is included on the product CD shipped with your

modem. In general, the modem will work with most data communications software packages.

1. Insert the CD into your CD-ROM drive. Allow Autorun to bring up the introductory screen.

2. Click on the PhoneTools icon and choose the appropriate language.

3. Follow the PhoneTools installation wizard. You may choose to view the readme file and whether or not to

run PhoneTools immediately.

NOTE

For Windows NT, Windows 2000, or Windows XP users: During installation, an

advisory screen may appear that reads “FAX capture driver installation.” This may

cause a delay in the installation. This is normal. The installation process has not failed

or stalled. Simply wait a few moments until this screen disappears.

4. After installation, you can launch PhoneTools either from a desktop icon or from the Start|Programs

menu. You do not have to reboot before using PhoneTools.

6-1-1 Heiwajima, Ota-ku, Tokyo, 143-6501, Japan • 03-5471-8800 • Fax 03-5471-8822

Autres manuels pour MD1650A-JP

Table des matières

Autres manuels Black Box Modem

Black Box

Black Box Mini-Modem V.92 MD1626A Manuel utilisateur

Black Box

Black Box LD485S-MP Manuel utilisateur

Black Box

Black Box ME251A-R3 Manuel utilisateur

Black Box

Black Box ME759C-RJ45 Manuel utilisateur

Black Box

Black Box 32457 Manuel utilisateur

Black Box

Black Box DESKTOP TELCO Manuel utilisateur

Black Box

Black Box MDS932AE-10BT-R2 Manuel utilisateur

Black Box

Black Box ME1240A-F Manuel utilisateur

Black Box

Black Box MT618A-ST-R2 Manuel utilisateur

Black Box

Black Box ME615A Manuel utilisateur

Black Box

Black Box MT632A-ST35 Manuel utilisateur

Black Box

Black Box ME738A-F Manuel utilisateur

Black Box

Black Box 325 Manuel utilisateur

Black Box

Black Box MDR24x Manuel utilisateur

Black Box

Black Box MD3400A Manuel utilisateur

Black Box

Black Box ME758C-RJ11 Manuel utilisateur

Black Box

Black Box LDM-MR 19.2 Manuel utilisateur

Black Box

Black Box ME801A-E Manuel utilisateur

Black Box

Black Box Industrial Modem RF115 Manuel utilisateur

Black Box

Black Box Mini Driver 4W-S Manuel utilisateur

Black Box

Black Box MDS931AE-10BT Manuel utilisateur

Black Box

Black Box Sync/Async Fiber Optic Modem Manuel utilisateur

Black Box

Black Box ME800A-R2 Manuel utilisateur

Black Box

Black Box MD885A-R4 Manuel utilisateur

Manuels Modem populaires d'autres marques

Davicom

Davicom DM562AP Manuel utilisateur

EpiValley

EpiValley TATA indicom SXC-1080 Manuel utilisateur

Zte

Zte WiMAX Manuel utilisateur

Intelimax

Intelimax MA-2060 Manuel utilisateur

SMC Networks

SMC Networks D3CM1604V Manuel d'utilisation et d'entretien

Telstra

Telstra Wi-Fi 4G Advanced Pro X Manuel utilisateur

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 Manuel utilisateur

Samsung

Samsung AceLink SAM-335A Manuel utilisateur

Enfora

Enfora Enabler-G Guide de configuration rapide

iRZ

iRZ ATM2-232 Manuel utilisateur

Zhone

Zhone 6310 Manuel utilisateur

Paradyne

Paradyne Hotwire 7976 Manuel utilisateur

US Robotics

US Robotics 3453C Manuel utilisateur

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Manuel utilisateur

Zte

Zte MF823 Manuel utilisateur

Four-Faith

Four-Faith F1403 Manuel utilisateur

Sierra Wireless

Sierra Wireless AIRLINK MP595W Manuel utilisateur

Gemtek

Gemtek WiMAX WIXFBR-103 Manuel utilisateur
