LR0025A-KIT

LRA1216A

DS3 Network Extender Kit

DS3 Provider Ba khaul Unit, 1-Port

Lnk Power 100 Act Lnk

Fast Ethernet Connection

S3 Provider

Backhaul Unit 1-Port

S3 Connection

Alm

FCC/IC RFI STATEMENTS, EU DECLARATION OF CONFORMITY

FEDERAL COMMUNICATIONS COMMISSION AND INDUSTRY CANADA

RADIO-FREQUENCY INTERFERENCE STATEMENTS

Class B Digital Device. This equipment has been tested and found to comply with

the limits for a Class B computing device pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful

interference in a residential installation. However, there is no guarantee that

interference will not occur in a particular installation. This equipment generates,

uses, and can radiate radio-frequency energy, and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio

communications. If this equipment does cause harmful interference to radio or

telephone reception, which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference by one of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

• Consult an experienced radio/TV technician for help.

Caution:

Changes or modifications not expressly approved by the party

responsible for compliance could void the user’s authority to operate

the equipment.

To meet FCC requirements, shielded cables are required to connect this device to

a personal computer or other Class B certified device.

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

EUROPEAN UNION DECLARATION OF CONFORMITY

This equipment has been tested and found to comply with the limits for a class B

device in accordance with the specifications in the European standard EN55022.

DS3 PROVIDER BACKHAUL UNIT AND DS3 NETWORK EXTENDER KIT

NORMAS OFICIALES MEXICANAS (NOM)

ELECTRICAL SAFETY STATEMENT

INSTRUCCIONES DE SEGURIDAD

1. Todas las instrucciones de seguridad y operación deberán ser leídas antes de

que el aparato eléctrico sea operado.

2. Las instrucciones de seguridad y operación deberán ser guardadas para

referencia futura.

3. Todas las advertencias en el aparato eléctrico y en sus instrucciones de

operación deben ser respetadas.

4. Todas las instrucciones de operación y uso deben ser seguidas.

5. El aparato eléctrico no deberá ser usado cerca del agua—por ejemplo, cerca

de la tina de baño, lavabo, sótano mojado o cerca de una alberca, etc..

6. El aparato eléctrico debe ser usado únicamente con carritos o pedestales que

sean recomendados por el fabricante.

7. El aparato eléctrico debe ser montado a la pared o al techo sólo como sea

recomendado por el fabricante.

8. Servicio—El usuario no debe intentar dar servicio al equipo eléctrico más allá

a lo descrito en las instrucciones de operación. Todo otro servicio deberá ser

referido a personal de servicio calificado.

9. El aparato eléctrico debe ser situado de tal manera que su posición no

interfiera su uso. La colocación del aparato eléctrico sobre una cama, sofá,

alfombra o superficie similar puede bloquea la ventilación, no se debe colocar

en libreros o gabinetes que impidan el flujo de aire por los orificios de

ventilación.

10. El equipo eléctrico deber ser situado fuera del alcance de fuentes de calor

como radiadores, registros de calor, estufas u otros aparatos (incluyendo

amplificadores) que producen calor.

11. El aparato eléctrico deberá ser connectado a una fuente de poder sólo del

tipo descrito en el instructivo de operación, o como se indique en el aparato.

NOM STATEMENT

12. Precaución debe ser tomada de tal manera que la tierra fisica y la polarización

del equipo no sea eliminada.

13. Los cables de la fuente de poder deben ser guiados de tal manera que no

sean pisados ni pellizcados por objetos colocados sobre o contra ellos,

poniendo particular atención a los contactos y receptáculos donde salen del

aparato.

14. El equipo eléctrico debe ser limpiado únicamente de acuerdo a las

recomendaciones del fabricante.

15. En caso de existir, una antena externa deberá ser localizada lejos de las lineas

de energia.

16. El cable de corriente deberá ser desconectado del cuando el equipo no sea

usado por un largo periodo de tiempo.

17. Cuidado debe ser tomado de tal manera que objectos liquidos no sean

derramados sobre la cubierta u orificios de ventilación.

18. Servicio por personal calificado deberá ser provisto cuando:

A: El cable de poder o el contacto ha sido dañado; u

B: Objectos han caído o líquido ha sido derramado dentro del aparato; o

C: El aparato ha sido expuesto a la lluvia; o

D: El aparato parece no operar normalmente o muestra un cambio en su

desempeño; o

E: El aparato ha sido tirado o su cubierta ha sido dañada.

DS3 PROVIDER BACKHAUL UNIT AND DS3 NETWORK EXTENDER KIT

1. Introduction

These instructions provide basic installation procedures for the DS3 Provider

Backhaul Unit, 1-Port (LRA1216A). This Backhaul Unit also serves as the Provider

Unit for the DS3 Network Extender Kit (LR0025A-KIT), which also includes a

Subscriber Unit.

The DS3 Network Extender Kit can be used to create a long-distance Ethernet

connection across a DS3 circuit. All you have to do is set the DIP switch once, cable

the units, and plug them in. No other configuration-—no muss, no fuss. Just a

reliable, high-speed connection that’s always on.

CAUTION

Excess static electricity can damage your Unit(s). Use proper static-

protection handling techniques when installing and handling this

equipment.

The DS3 Provider Backhaul Unit, 1-Port comes with a power supply and this

manual. The DS3 Network Extender Kit comes with a Provider Unit, a Subscriber

Unit, a power supply for each Unit, and this manual. (The power supplies are

identical; you can use either one with either Unit.) If you didn’t receive everything,

or if anything arrived damaged, contact Black Box right away.

CHAPTER 2: Installation

2. Installation

1. Unpack the DS3 Provider Unit and its power supply.

2. Plug the power supply into both the power source and the back of the Unit.

It doesn’t matter in which order you do this. Verify that the Unit’s Power LED

is lit.

NOTE

The Unit’s 100, Act, and Lnk LE s will also light until the S3 link has

been established. In addition, the Unit won’t present Ethernet Link when

the S3 line is not operational.

3. Make sure that the Provider Unit’s configuration DIP switch is set correctly

for your application:

• Switch position #1, on the left, controls the clock source: Leave it in the

default DOWN setting for Local (internal) clock, or move it to UP for Loop

clock. (When you set the same switch on the Subscriber unit, don’t set

position #1, because the Subscriber Unit always gets its clock from the

Provider Unit.)

• Switch position #2, on the right, controls the TX line build out: Leave it in

the default DOWN setting for 0 to 255 ft. (0 to 77.7 m) or move it to UP for

255 to 450 ft. (77.7 to 137.2 m).

4. Plug your DS3 cables into the DS3 TX and RX BNC ports on the back of the

Provider Unit. Verify this connection by looking at the DS3 Lnk LED on the

front of the Unit. If it’s pulsing steadily once per second, a DS3 connection is

established and operational.

5. The Provider Unit’s Ethernet port is 10/100-Mbps auto-negotiating. We

recommend that, if possible, you set the hub, switch, PC, etc., at the other end

of the Ethernet cable to auto-negotiate as well, before you connect the cable.

Plug your Ethernet cable into the Fast Ethernet RJ-45 port on the back of

the Provider Unit. Verify this connection by looking at the Fast Ethernet Lnk

LED on the Unit’s front panel. If it’s steadily lit, an Ethernet connection has

been established. Also check the 100 LED: If it’s lit, the link is operating at

100 Mbps; if it’s dark, the link is operating at 10 Mbps.

DS3 PROVIDER BACKHAUL UNIT AND DS3 NETWORK EXTENDER KIT

Table 2-1. Pinout of the Provider Unit’s Ethernet port.

Pin Number Signal

1 RX+

2 RX-

3 TX+

4 Not used

5 Not used

6 TX-

7 Not used

8 Not used

NOTE

For most applications, use a straight-through Ethernet cable when

plugging the Provider Unit into a PC, or a crossover cable when

plugging into a hub or a switch. Verify the pinout of the Ethernet device

to which you are connecting the Provider Unit in order to determine

which type of cable is required.

6. LR0025A-KIT only: Repeat steps 1 through 5 for the Subscriber Unit. Its

controls, indicators, and connectors work the same way as the Provider Unit’s,

except that it gets its clock source settings from the Provider Unit, so you

don’t need to set DIP-switch position 1.

Once the Provider Unit and a Subscriber Unit have established both DS3 and

Ethernet links on both sides of the connection, normal data communication will

flow through the Units. This will provide a very long Ethernet connection at DS3

or fractional DS3 speeds.

CHAPTER 3: Operation

3. Operation

While the Provider and Subscriber Units are plugged in and receiving power, they

will operate continuously. Each Unit’s front-panel LEDs (which are also described

on its bottom label) will show you how it’s operating:

NOTE

When a Provider or Subscriber Unit is in Red, Yellow, or Blue Alarm, its

Ethernet link will be disabled and the Fast Ethernet LE s (100, Act, and

Lnk) will be steadily lit.

•DS3 Lnk LED (green):

– If it’s flashing, the DS3 connection has been established and traffic is flowing

on the link.

– If it’s steadily lit, the DS3 connection has been established but no traffic is

currently flowing.

– If it’s dark, Red Alarm: The incoming DS3 connection has been lost and no

data is being received. If the outgoing connection from the Unit has also

been lost, the Unit at the other end will also be in Red Alarm.

•DS3 Alm LED (amber):

– If it’s dark, the DS3 connection is operating normally, unless the DS3 Lnk

LED is also dark, in which case a Red Alarm is occurring.

– If it’s steadily lit, Yellow Alarm: The outgoing DS3 connection has been lost

and no data is being transmitted. This means that the Unit at the other end

has lost incoming connection and is in Red Alarm.

– If it’s blinking once per second, Blue Alarm: An indirect connection has been

lost and the Unit might not be receiving data. This means that the Unit at

the other end has lost a connection with an intermediate device and is in

Red or Yellow Alarm.

•Power LED (green):

– If it’s steadily lit, the Unit is powered and operating.

– If it’s dark, and all other LEDs are also dark, the Unit isn’t receiving any

power or isn’t receiving enough power to operate. If any other LEDs are lit,

the Power LED is probably defective.

DS3 PROVIDER BACKHAUL UNIT AND DS3 NETWORK EXTENDER KIT

•Fast Ethernet 100 and Lnk LEDs (both green):

– If they’re both steadily lit, a 100-Mbps Fast Ethernet connection has been

established, unless the Act LED is also steadily lit and the DS3 Lnk LED is

dark, in which case a DS3 alarm is occurring.

– If Lnk is steadily lit and 100 is dark, a 10-Mbps Fast Ethernet connection has

been established.

– If they’re both dark, the Ethernet connection is down or has been lost.

•Fast Ethernet Act LED (amber):

– If it’s flashing, traffic is flowing normally, indicating typical Ethernet activity.

– If it’s steadily lit, traffic is very heavy, unless the other Fast Ethernet LEDs are

also lit and the DS3 Lnk LED is dark, in which case a DS3 alarm is occurring.

– If it’s dark, there is no traffic flow. This means that the Ethernet connection

is either down, lost, or not being used.

CHAPTER 4: Troubleshooting

4. Troubleshooting

4.1 Calling Black Box

If you determine that your DS3 Provider Unit or Network Extender Kit is

malfunctioning, do not attempt to alter or repair it. It contains no user-serviceable

parts. Contact Black Box Technical Support at 724-746-5500.

Before you do, make a record of the history of the problem. We will be able to

provide more efficient and accurate assistance if you have a complete description,

including:

• the nature and duration of the problem;

• when the problem occurs;

• the components involved in the problem;

• any particular application that, when used, appears to create the problem or

make it worse; and

• the results of any testing you’ve already done.

4.2 Shipping and Packaging

If you need to transport or ship your DS3 Provider Unit or Network Extender Kit:

• Package it carefully. We recommend that you use the original container.

• Before you ship the DS3 Provider Unit or Network Extender Kit back to Black

Box for repair or return, contact us to get a Return Authorization (RA)

number.

Autres manuels pour LR0025A-KIT

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Black Box Extenseur

Black Box

Black Box LB401A Manuel utilisateur

Black Box

Black Box AC555A Manuel utilisateur

Black Box

Black Box LWE100A Manuel utilisateur

Black Box

Black Box ME0006A-V35 Manuel utilisateur

Black Box

Black Box ServSwitch ACU4001A Manuel utilisateur

Black Box

Black Box AVX-HDMI2-FO-HDB-KIT Manuel utilisateur

Black Box

Black Box VX-VGA520-TA Manuel utilisateur

Black Box

Black Box AC602A Manuel utilisateur

Black Box

Black Box AC1031A-R2-2 Manuel utilisateur

Black Box

Black Box ServSwitch ACU2500A Manuel utilisateur

Black Box

Black Box ServSwitch ACU5114A Manuel utilisateur

Black Box

Black Box ServSwitch ACU2001A Manuel utilisateur

Black Box

Black Box ServSwitch II ACS250A Manuel utilisateur

Black Box

Black Box Abeo G.703 LAN Instructions d'installation et d'utilisation

Black Box

Black Box IC244A-R2 Manuel utilisateur

Black Box

Black Box MT330A Manuel utilisateur

Black Box

Black Box KVM2016A Manuel utilisateur

Black Box

Black Box LC100 SERIES Instructions d'utilisation

Black Box

Black Box ServSwitch ACUR004A Manuel utilisateur

Black Box

Black Box LWE120UK Manuel utilisateur

Black Box

Black Box ACUREM Manuel utilisateur

Black Box

Black Box VX-VGA520-TA Manuel utilisateur

Black Box

Black Box LB401A Manuel d'instructions

Black Box

Black Box KVX HP Series Manuel utilisateur

Manuels Extenseur populaires d'autres marques

SY HDBT-60T Manuel utilisateur

Appsys ProAudio

Appsys ProAudio ADX-16 Manuel utilisateur

Atlona

Atlona RS232 Manuel utilisateur

IDK

IDK OPF-TH1000-A Manuel utilisateur

Enable-IT

Enable-IT 824WP Manuel utilisateur

Worx

Worx Landroid RadioLink WA0864 Fiche technique

TP-Link

TP-Link TL-WA730RE Manuel utilisateur

Camplex

Camplex CMX-HDMI-SFPL Manuel utilisateur

SC&T

SC&T HE03-4K Manuel utilisateur

Marmitek

Marmitek MegaView70 Manuel utilisateur

Samsung

Samsung SCS-26UC4 Manuel utilisateur

Foxun

Foxun SX-GES24 Manuel utilisateur

MuxLab

MuxLab 500771 Manuel utilisateur

foxunhd

foxunhd SX-AEX01 Manuel utilisateur

TERK Technologies

TERK Technologies LFIRX2 Manuel utilisateur

Devolo

Devolo Audio Extender Manuel

Edimax

Edimax EW-7438RPn V2 Manuel utilisateur

Shinybow USA

Shinybow USA SB-6335T5 Manuel utilisateur
