Black Box ServSwitch II ACS250A Manuel utilisateur

MARCH 2002

ACS250A

ACS251A

FREE tech support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746.

Mailin address: Black Box Corporation, 1000 Park Dr., Lawrence, PA 15055-1018

World-Wide Web: www.blackbox.com • E-mail: in [email protected]

Customer Support In ormation:

THE SERVSWITCH™ FAMILY

Welcome to the ServSwitchTM Family!

Thank you for purchasing a BLACK BOX®ServSwitch™Brand KVM Extender

model! We appreciate your business, and we think you’ll appreciate the many ways

that your enhanced keyboard/video/mouse system will save you money, time, and

effort.

That’s because our ServSwitch family is all about breaking away from the

traditional, expensive model of computer management. You know, the one-size-

fits-all-even-if-it-doesn’t model that says, “One computer gets one user station, no

more, no less.” Why not a single user station (monitor, keyboard, and mouse) for

multiple computers—even computers of different platforms? Why not a pair of

user stations, each of which can control multiple computers? Why not multiple

user stations for the same computer?

With our ServSwitch products, there’s no reason why not. We carry a broad line

of robust solutions for all these applications. Do you have just two PCs, and need

an economical alternative to keeping two monitors, keyboards, and mice on your

desk? Or do you need to share dozens of computers, including a mix of IBM®PC,

RS/6000®, Apple®Macintosh®, Sun Microsystems®, and SGI®compatibles among

multiple users with different access levels? Does your switch have to sit solidly on a

worktable and use regular everyday cables? Or does it have to be mounted in an

equipment rack and use convenient many-to-one cables? No matter how large or

small your setup is, no matter how simple or how complex, we’re confident we

have a ServSwitch system that’s just right for you.

The ServSwitch™family from Black Box—the one-stop answer for all your KVM-

switching needs!

This manual will tell you all about your new ServSwitch™ Brand Fiber KVM

Extender II or II-SM, including how to install, operate, and troubleshoot it. For an

introduction to the Extender, see Chapter 2. The Extender product codes covered

in this manual are:

ACS250A

ACS251A

SERVSWITCH™ BRAND FIBER KVM EXTENDER II AND II-SM

TRADEMARKS USED IN THIS MANUAL

BLACK BOX and the logo are registered trademarks, and ServSwitch is a

trademark, of Black Box Corporation.

Apple and Macintosh are registered trademarks of Apple Computer, Inc.

IBM, PC/AT, and PS/2 are registered trademarks of International Business

Machines Corporation.

Microsoft and Intellimouse are registered trademarks or trademarks of Microsoft

Corporation in the United States and/or other countries.

Sun and Sun Microsystems are registered trademarks of Sun Microsystems, Inc. in

the United States and other countries.

Any other trademarks mentioned in this manual are acknowledged to be the property of the

trademark owners.

FCC/IC STATEMENTS

FEDERAL COMMUNICATIONS COMMISSION AND INDUSTRY CANADA

RADIO-FREQUENCY INTERFERENCE STATEMENTS

This equipment generates, uses, and can radiate radio-frequency energy, and if not

installed and used properly, that is, in strict accordance with the manufacturer’s

instructions, may cause interference to radio communication. It has been tested

and found to comply with the limits for a Class A computing device in accordance

with the specifications in Subpart B of Part 15 of FCC rules, which are designed to

provide reasonable protection against such interference when the equipment is

operated in a commercial environment. Operation of this equipment in a

residential area is likely to cause interference, in which case the user at his own

expense will be required to take whatever measures may be necessary to correct the

interference.

Changes or modifications not expressly approved by the party responsible for

compliance could void the user’s authority to operate the equipment.

This digital apparatus does not exceed the Class A limits for radio noise emission from digital

apparatus set out in the Radio Interference Regulation of Industry Canada.

Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites

applicables aux appareils numériques de la classe A prescrites dans le Règlement sur le

brouillage radioélectrique publié par Industrie Canada.

SERVSWITCH™ BRAND FIBER KVM EXTENDER II AND II-SM

EUROPEAN UNION DECLARATION OF CONFORMITY

This is to certify that, when installed and used according to the instructions in this

manual together with the specified cables, the ServSwitch™ Brand Fiber KVM

Extender II and II-SM are shielded against the generation of radio interference in

accordance with the application of Council

Directive 89/336/EEC.

The Extenders were tested in a typical configuration.

LASER-SAFETY STATEMENT

To meet laser-safety requirements, the Extender operates its optical transceivers

within their maximum ratings. The transceivers must always be terminated with an

optical connector or dust cap. For full optical specifications, see Chapter 1.

CAUTION!

Using lenses, magnifying glasses, or other optical instruments with this

product could pose extreme eye hazards All necessary adjustments

have already been made at the factory prior to the shipment of the

Extender Even if it doesn’t result in damage or injury (which is likely),

tampering with or modifying the Extender, or changing the way it

performs, could void the Extender’s original certifications

NOM STATEMENT

NORMAS OFICIALES MEXICANAS (NOM)

ELECTRICAL SAFETY STATEMENT

INSTRUCCIONES DE SEGURIDAD

1. Todas las instrucciones de seguridad y operación deberán ser leídas antes de

que el aparato eléctrico sea operado.

2. Las instrucciones de seguridad y operación deberán ser guardadas para

referencia futura.

3. Todas las advertencias en el aparato eléctrico y en sus instrucciones de

operación deben ser respetadas.

4. Todas las instrucciones de operación y uso deben ser seguidas.

5. El aparato eléctrico no deberá ser usado cerca del agua—por ejemplo, cerca

de la tina de baño, lavabo, sótano mojado o cerca de una alberca, etc.

6. El aparato eléctrico debe ser usado únicamente con carritos o pedestales que

sean recomendados por el fabricante.

7. El aparato eléctrico debe ser montado a la pared o al techo sólo como sea

recomendado por el fabricante.

8. Servicio—El usuario no debe intentar dar servicio al equipo eléctrico más allá

a lo descrito en las instrucciones de operación. Todo otro servicio deberá ser

referido a personal de servicio calificado.

9. El aparato eléctrico debe ser situado de tal manera que su posición no

interfiera su uso. La colocación del aparato eléctrico sobre una cama, sofá,

alfombra o superficie similar puede bloquea la ventilación, no se debe colocar

en libreros o gabinetes que impidan el flujo de aire por los orificios de

ventilación.

10. El equipo eléctrico deber ser situado fuera del alcance de fuentes de calor

como radiadores, registros de calor, estufas u otros aparatos (incluyendo

amplificadores) que producen calor.

11. El aparato eléctrico deberá ser connectado a una fuente de poder sólo del

tipo descrito en el instructivo de operación, o como se indique en el aparato.

SERVSWITCH™ BRAND FIBER KVM EXTENDER II AND II-SM

12. Precaución debe ser tomada de tal manera que la tierra fisica y la polarización

del equipo no sea eliminada.

13. Los cables de la fuente de poder deben ser guiados de tal manera que no

sean pisados ni pellizcados por objetos colocados sobre o contra ellos,

poniendo particular atención a los contactos y receptáculos donde salen del

aparato.

14. El equipo eléctrico debe ser limpiado únicamente de acuerdo a las

recomendaciones del fabricante.

15. En caso de existir, una antena externa deberá ser localizada lejos de las lineas

de energia.

16. El cable de corriente deberá ser desconectado del cuando el equipo no sea

usado por un largo periodo de tiempo.

17. Cuidado debe ser tomado de tal manera que objectos liquidos no sean

derramados sobre la cubierta u orificios de ventilación.

18. Servicio por personal calificado deberá ser provisto cuando:

A: El cable de poder o el contacto ha sido dañado; u

B: Objectos han caído o líquido ha sido derramado dentro del aparato; o

C: El aparato ha sido expuesto a la lluvia; o

D: El aparato parece no operar normalmente o muestra un cambio en su

desempeño; o

E: El aparato ha sido tirado o su cubierta ha sido dañada.

TABLE OF CONTENTS

Contents

Chapter Page

1. Specifications ............................................................................................. 8

2. Introduction ............................................................................................. 11

2.1 Overview ............................................................................................ 11

2.2 Key Features ...................................................................................... 12

2.3 The Complete Package ..................................................................... 12

3. Compatibility and Signal Processing ...................................................... 13

3.1 Video Processing ................................................................................ 13

3.2 Mouse Compatibility ......................................................................... 14

3.3 Sound Processing .............................................................................. 14

4. Installation ................................................................................................ 15

4.1 Guidelines and Limitations for Attaching Equipment ................... 15

4.1.1 CPU .......................................................................................... 15

4.1.2 Monitor .................................................................................... 15

4.1.3 Keyboard and Mouse .............................................................. 15

4.2 An Extender Installation Illustrated ................................................ 16

4.3 Installing the Local Unit and Local Devices ................................... 17

4.4 Installing the Remote Unit and Remote Devices ............................ 19

4.5 Finishing Your Installation ............................................................... 21

5. Operation ................................................................................................. 22

6. Troubleshooting ...................................................................................... 23

6.1 Calling Black Box ............................................................................... 23

6.2 Shipping and Packaging ................................................................... 23

SERVSWITCH™ BRAND FIBER KVM EXTENDER II AND II-SM

1. Specifications

Cable Required: ACS250A: 50/125-µm or (to lesser distances) 62.5/125-µm

multimode duplex fiberoptic cable;

ACS251A: 9/125-µm single-mode duplex fiberoptic cable

Compliance: CE; FCC Part 15 Subpart B Class A, IC Class/classe A

Interfaces: Extension:

ACS250A: Duplex multimode fiberoptic;

ACS251A: Duplex single-mode fiberoptic;

Video: VGA compatible (DOS mode, VGA, SVGA, XGA,

SXGA); Plug-and-Play for monitors and DDC not

supported;

Keyboard and mouse: IBM PS/2 compatible;

Sound: 3.5-mm stereo audio

Resolution and

Refresh Rate: Supports resolutions up to 1280 x 1024 and refresh rates

up to 75 Hz; maximum pixel clock (bandwidth) is

108 MHz

Optical Type and

Wavelength: ACS250A: 850-nm multimode;

ACS251A: 1300-nm single-mode

Transmitter

Launch Power: ACS250A: Into either 50-µm or 62.5-µm cable: From –4.5 to

–9 dBm;

ACS251A: Into 9-µm cable: From –3 to –9 dBm

Receiver

Sensitivity: ACS250A:

With 62.5-µm cable: –12.5 dBm;

With 50-µm cable: –13.5 dBm;

ACS251A: –14.4 dBm

Optical

Budget: ACS250A:

With 62.5-µm cable: 6.7 dB maximum;

With 50-µm cable: 7.5 dB maximum;

ACS251A: 10.5 dB maximum

CHAPTER 1: Specifications

Maximum

Distance: Between Extender’s Local and Remote Units:

ACS250A:

Over 62.5-µm cable: 220 m (720 ft.);

Over 50-µm cable: 400 m (1310 ft.);

ACS251A: 10 km (6.2 mi.)

User Controls: None

Indicators: (1) Front-mounted green LED on each Unit:

Local Unit: LED is steadily lit during normal operation,

flashes if Unit is powered but no video signal is present

at VGA input;

Remote Unit: LED is steadily lit during normal

operation, flashes if no fiber connection is detected or

Local Unit is outputting no signal

Connectors: On Local Unit:

Front-mounted:

(4) 6-pin mini-DIN female:

(1) for CPU’s keyboard port;

(1) for CPU’s mouse port;

(1) for optional local keyboard;

(1) for optional local mouse;

(1) HD15 female for CPU’s video port;

(1) HD15 female for optional local monitor;

(1) 3.5-mm stereo audio jack (~0.7 Veff/~2 Vpp) for

CPU’s audio-out port;

Rear-mounted:

(1) Duplex SC female for fiber link (transmitter on

left, receiver on right);

(1) 2.1-mm barrel jack for power;

(1) 8-pin mini-DIN for service (reserved for

manufacturer use);

On Remote Unit:

Front-mounted:

(2) 6-pin mini-DIN female:

(1) for remote keyboard;

(1) for remote mouse;

(1) HD15 female for remote monitor;

(1) 3.5-mm stereo audio jack (~0.7 Veff/~2 Vpp) for

remote audio device (outputs mono on both stereo

channels);

Autres manuels pour ServSwitch II ACS250A

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Black Box Extenseur

Black Box

Black Box IC443A Manuel utilisateur

Black Box

Black Box ServSwitch ACU2500A Manuel utilisateur

Black Box

Black Box ACU5050A Manuel utilisateur

Black Box

Black Box ACS2001A Manuel utilisateur

Black Box

Black Box LS900A Manuel utilisateur

Black Box

Black Box ACU1700A Manuel utilisateur

Black Box

Black Box AC555A Manuel utilisateur

Black Box

Black Box MTU9230 Manuel utilisateur

Black Box

Black Box ACS1009A series Manuel utilisateur

Black Box

Black Box 4KDPKVMXT-100M-R2 Manuel utilisateur

Black Box

Black Box LBNC01A-KIT Manuel utilisateur

Black Box

Black Box Emerald Series Manuel utilisateur

Black Box

Black Box CampusLIGHT LCL114A-FEMM Manuel utilisateur

Black Box

Black Box ServSwitch ACU5200A Manuel utilisateur

Black Box

Black Box ICS02A Manuel utilisateur

Black Box

Black Box KV1002A-R2 Manuel utilisateur

Black Box

Black Box ServSwitch ACX310F Manuel utilisateur

Black Box

Black Box ICU544A Manuel utilisateur

Black Box

Black Box IC280A-R2 Manuel utilisateur

Black Box

Black Box ServSwitch Agility ACR1000A Manuel utilisateur

Black Box

Black Box LB300A-R3 Instructions d'installation et d'utilisation

Black Box

Black Box EHN250-0050 Manuel utilisateur

Black Box

Black Box SDSL Network Extender 2000 Manuel utilisateur

Black Box

Black Box ACX1MT Series Manuel utilisateur

Manuels Extenseur populaires d'autres marques

SY HDBT-60T Manuel utilisateur

Appsys ProAudio

Appsys ProAudio ADX-16 Manuel utilisateur

Atlona

Atlona RS232 Manuel utilisateur

IDK

IDK OPF-TH1000-A Manuel utilisateur

Enable-IT

Enable-IT 824WP Manuel utilisateur

Worx

Worx Landroid RadioLink WA0864 Fiche technique

TP-Link

TP-Link TL-WA730RE Manuel utilisateur

Camplex

Camplex CMX-HDMI-SFPL Manuel utilisateur

SC&T

SC&T HE03-4K Manuel utilisateur

Marmitek

Marmitek MegaView70 Manuel utilisateur

Samsung

Samsung SCS-26UC4 Manuel utilisateur

Foxun

Foxun SX-GES24 Manuel utilisateur

MuxLab

MuxLab 500771 Manuel utilisateur

foxunhd

foxunhd SX-AEX01 Manuel utilisateur

TERK Technologies

TERK Technologies LFIRX2 Manuel utilisateur

Devolo

Devolo Audio Extender Manuel

Edimax

Edimax EW-7438RPn V2 Manuel utilisateur

Shinybow USA

Shinybow USA SB-6335T5 Manuel utilisateur
