Black Box LW6007A Manuel utilisateur

1000 Park Drive • Lawrence, PA 15055-1018 • 724-746-5500 • Fax 724-746-0746

CUSTOMER

SUPPORT

INFORMATION

Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)

FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746

Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018

Web site: www.blackbox.com • E-mail: [email protected]

JULY 2004

LW6007A

Pure Networking 802.11g Wireless

Mini USB Adapter

FCC AND IC RFI STATEMENTS

FEDERAL COMMUNICATIONS COMMISSION

and INDUSTRY CANADA

RADIO FREQUENCY INTERFERENCE STATEMENTS

Class B Digital Device. This equipment has been tested and found to comply with

the limits for a Class B computing device pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful

interference in a residential installation. However, there is no guarantee that

interference will not occur in a particular installation. This equipment generates,

uses, and can radiate radio frequency energy, and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio

communications. If this equipment does cause harmful interference to radio or

telephone reception, which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference by one of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

• Consult an experienced radio/TV technician for help.

CAUTION

Changes or modifications not expressly approved by the party

responsible for compliance could void the user’s authority to operate

the equipment.

To meet FCC requirements, shielded cables and power cords are required to

connect this device to a personal computer or other Class B certified device.

This digital apparatus does not exceed the Class B limits for radio noise emission from digital

apparatus set out in the Radio Interference Regulation of Industry Canada.

PURE NETWORKING 802.11G WIRELESS MINI USB ADAPTER

EUROPEAN UNION DECLARATION OF CONFORMITY

This equipment complies with the requirements of the European EMC Directive

89/336/EEC.

TRADEMARKS USED IN THIS MANUAL

Windows is either a registered trademark or a trademark of Microsoft Corporation

in the United States and/or other countries.

NetWare is a registered trademark of Novell, Inc.

Any other trademarks mentioned in this manual are acknowledged to be the property of the

trademark owners.

TRADEMARKS USED IN THIS MANUAL

PURE NETWORKING 802.11G WIRELESS MINI USB ADAPTER

Contents

Chapter Page

1. Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

2. Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

2.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

2.2 What’s Included . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

3. Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

3.1 Windows 98 SE/Me and Windows 2000 . . . . . . . . . . . . . . . . . . . . . . . . . 7

3.2 Windows XP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

3.2.1 Using the Windows XP Utility . . . . . . . . . . . . . . . . . . . . . . . . . . 10

3.2.2 Using the Card’s Utility. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

4. Configuration Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

4.1 Wireless Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

4.2 General Connection Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

4.3 WEP Encryption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

4.4 Advanced Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

5. Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

5.1 Frequently Asked Questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

5.2 Calling Black Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

5.3 Shipping and Packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

1. Specifications

Antenna: Internal antenna

Distance (Maximum): 328 ft. (100 m)

Frequency Band: 2.4000–2.4835 GHz

Modulation: OFDM with BPSK, QPSK, 16AQM, 64QAM (11g), BPSK, QPSK, CCK

(11b)

Operating System: Compatible with all major operating systems; Drivers included

for Windows®98 SE/Me/XP and Windows 2000

Security: 64-/128-bit WEP Data Encryption, WPA (TKIP with IEEE 802.1x), and

AES

Speed: 54, 11, 5.5, 2, 1 Mbps with auto fallback

Standards: IEEE 802.11g

Bus Type: USB Type A

Radio Technology: Direct-Sequence Spread Spectrum (DSSS)

Modulation: Orthogonal Frequency Division Multiplexing (OFDM)

Connectors: (1) USB Type A

Indicators: (1) Link/Activity LED

Temperature: 32 to 131°F (0 to 55°C)

Humidity: Up to 95%, noncondensing

Power: From the interface

Transmit Power: 16 dBm

Size: 0.3"H x 1"W x 3.5"D (0.8 x 2.5 x 8.9 cm)

CHAPTER 1: Specifications

PURE NETWORKING 802.11G WIRELESS MINI USB ADAPTER

2. Introduction

2.1 Overview

Connect your PC to another network device without cable. The Pure Networking

802.11g Wireless Mini USB Adapter installs in your notebook, laptop, or desktop

PC and uses wireless technology to transfer data. It also supports Windows OS

plug-and-play installation and USB hot swap, allowing you to plug it in or remove it

without rebooting your computer. The adapter complies with the IEEE 802.11g

2.4 GHz (DSSS) standard, which supports wireless network connections up to

54 Mbps. High throughput maximizes multimedia data bandwidth and 64-/128-bit

WEP data encryption for a high level of security. It also supports peer-to-peer

communication among wireless users, with no access point required. Automatic

fallback increases data security and reliability. The card works with Windows 98

SE/Me/XP and Windows 2000.

2.2 What’s Included

Before you begin the installation, check the contents of your package. The package

should include the following items:

• (1) Pure Networking 802.11g Wireless Mini USB Adapter

• (1) 3.2 ft. (1-m) USB extension cable

• (1) CD-ROM containing this users’ manual in PDF format and software drivers

If anything is missing or damaged, please contact Black Box at 724-746-5500.

CHAPTER 3: Installation

3. Installation

Before you proceed with the installation, read the following notes.

NOTES

Do not install the adapter in your PC’s USB port before installing the

software program from the CD.

The installation described in Section 3.1 was operated under Windows

2000. (Procedures are the same for Windows 98 SE/Me.)

If you have installed the Pure Networking 802.11g Wireless Mini USB

Adapter driver and utility before, please uninstall the old version first.

3.1 Windows 98 SE/Me and Windows 2000

1. Insert the CD into the CD-ROM drive and type Utility\setup.exe. The

InstallShield Wizard screen will appear (see Figure 3-1); click Next to

continue.

Figure 3-1. InstallShield Wizard screen.
