SPP-C200/SPP-C300 Command Manual

Ver. 1.00

http://www.bixolon.com

SPP-C200/SPP-C300 Command Manual

Ver. 1.00BIXOLON

- 2 -

■Contents

1. Notice......................................................................................................................................................................................................3

2. SPP-C200/SPP-C300 Supported Commands.......................................................................................................................................4

2-1 Command Description Items ..............................................................................................................................................................5

2-2 Details of Control Commands.............................................................................................................................................................6

SPP-C200/SPP-C300 Command Manual

Ver. 1.00BIXOLON

- 3 -

1. Notice

This document contains proprietary information of BIXOLON Corporation and its affiliates. You may utilize the information solely for the

purpose of facilitating authorized sales and service of, or developing software and similar products for authorized use with, BIXOLON

products, provided that such proprietary information may not be used, reproduced, or disclosed to any other parties for any other purpose

without the prior written permission of BIXOLON Corporation. BIXOLON has no liability for loss or damage arising from or relating to your

use of or reliance on the information in the document.

We at BIXOLON maintain ongoing efforts to enhance and upgrade the functions and quality of all our products. In following, product

specifications and/or user manual content may be changed without prior notice.

SPP-C200/SPP-C300 Command Manual

Ver. 1.00BIXOLON

- 4 -

2. SPP-C200/SPP-C300 Supported Commands

No.

Command

Function

No.

Command

Function

EOT

Transmit status

FS &

Select Kanji character mode

Horizontal tab

FS .

Cancel Kanji character mode

Print and line feed

GS !

Select character size

Form feed (in page mode)

GS $

Set absolute vertical print position in page mode

Print and carriage return

GS ( A

Execute test print

DLE

Set real-time command mode

GS ( F

Set black mark control functions

CAN

Cancel the print data in page mode

GS ( k

Specify and print the symbol

8 ESC SP Set the character right space 39

GS ( L

GS 8 L

Select graphics data

ESC !

Set print mode

GS :

Start/end macro definition

ESC $

Set absolute print position

GS B

Turn white/black reverse print mode on/off

ESC *

Specify bit image mode

GS H

Select print position of HRI characters

ESC -

Turn underline mode on/off

GS I

Transmit printer ID

ESC 2

Select default line spacing

GS I b

Transmit battery status

ESC 3

Set line spacing

GS L

Set left margin

ESC =

Select peripheral device

GS T

Set print position to the beginning of print line

ESC @

Initialize printer

GS W

Set print area width

ESC D

Set horizontal tab positions

GS \

Set relative vertical print position in page mode

ESC E

Turn emphasized mode on/off

GS ^

Execute macro

ESC G

Turn double-strike mode on/off

GS a

Enable/disable Automatic Status Back (ASB)

ESC J

Print and feed paper

GS f

Select font for HRI characters

ESC L

Select page mode

GS h

Set bar code height

ESC M

Select character font

GS k

Print bar code

ESC R

Specify an international character set

GS r

Transmit status

ESC S

Select standard mode

GS v 0

Print raster bit image

ESC T

Select print direction in page mode

GS w

Set bar code width

ESC W

Set print area in page mode

BS L A

Execute automatic calibration in black mark mode

ESC \

Set relative print position

BS L L

Select black mark mode

ESC a

Set position alignment

BS L R

Select receipt mode

ESC d

Print and feed n lines

BS M

Select device font type

ESC t

Select character code table

FS D

Draw Line & Box

ESC {

Turn upside-down print mode on/off

SPP-C200/SPP-C300 Command Manual

Ver. 1.00BIXOLON

- 5 -

2-1 Command Description Items

Command

Function:

Command function outline

Code:

Command format expressed in ASCII, hexadecimal, and decimal codes

Range:

Argument value (Setting range) for the command

Default:

Initial argument value for the command

Description:

Detailed command function description

Remarks:

Additional information about using the command

Differences:

Example:

Variations depending on the printer model

Refer to example command code

SPP-C200/SPP-C300 Command Manual

Ver. 1.00BIXOLON

- 6 -

2-2 Details of Control Commands

EOT

Function:

Transmit status

Code:

ASCII

EOT

Hex

Decimal

Range:

1 ≤ n ≤ 4

Default:

None

Description:

This command transmits the printer-related status specified by n as follows:

Function

Transmit printer status

Transmit off-line status

Transmit error status

Transmit paper roll sensor status

■Printer transmits the following status n = 1: Printer status

Bit

Binary

Hex

Decimal

Status

Not used. Fixed to Off

Not used. Fixed to On

Not used. Fixed to Off

Online

Offline

Not used. Fixed to On

Not used. Fixed to Off

SPP-C200/SPP-C300 Command Manual

Ver. 1.00BIXOLON

- 7 -

n = 2: Off-line status

Bit

Off/On

Hex

Decimal

Status

Off

Fixed

Off

Cover is closed

Cover is open

Off

Paper is not being fed by using the paper FEED button

Paper is being fed by the paper FEED button

Fixed

Off

No paper-end stop

Printing is being stopped

Off

Fixed

Off

Fixed

n = 3: Error status

Bit

Binary

Hex

Decimal

Status

Not used. Fixed to Off

Not used. Fixed to On

Not used. Fixed to Off

Not used. Fixed to On

Not used. Fixed to Off

SPP-C200/SPP-C300 Command Manual

Ver. 1.00BIXOLON

- 8 -

n = 4: paper sensor status

Bit

Binary

Hex

Decimal

Status

Not used. Fixed to Off

Not used. Fixed to On

Not used. Fixed to Off

Not used. Fixed to On

5,6

Paper end sensor: paper present

Paper end sensor: paper not present

Not used. Fixed to Off

Remarks:

■

This command can be executed in a real time mode using DLE.

■In a real time mode, the status is transmitted to the host upon being requested that can check the printer operational

condition with it and takes appropriate measures accordingly.

Differences:

SPP-C200/SPP-C300 Command Manual

Ver. 1.00BIXOLON

- 9 -

Function:

Horizontal tab

Code:

ASCII

Hex

Decimal

Range:

None

Default:

None

Description:

This command moves the print position to the next horizontal tab position. If the next horizontal tab position is not

specified, this command will be void.

Remarks:

■

The horizontal tab position is set by <ESC> D.

■

With the underline mode turned on, the underline printing is not applied to the tab space created by this command.

Differences:

Example:

None

■

Input:

0x54 0x45 0x53 0x54 0x0a

0x54 0x09 0x45 0x09 0x53 0x09 0x54 0x0a

■

Output:

SPP-C200/SPP-C300 Command Manual

Ver. 1.00BIXOLON

- 10 -

Function:

Print and line feed

Code:

ASCII

Hex

Decimal

Range:

None

Default:

None

Description:

This command prints the data in the print buffer and feeds one line based on the current set line spacing in standard

mode.

Remarks:

■

In page mode, the printer does not perform actual printing, but moving only the print position to the next line.

Differences:

Example:

None

■

Input:

0x31 0x0a

0x32 0x0a 0x0a

0x33 0x0a 0x0a 0x0a

0x34 0x0a

■

Output:
