BIXOLON SRP-500 Instructions d'installation

Command Manual

SRP-500

Inkjet Printer

Rev. 1.02

http://www.samsungminiprinters.com

Rev. 1.02 - 2 -

SRP-500

1. EPSON Mode (TM-U200)

nCommand Description Hexadecimal

1 CR Print and carriage return 0D

2 HT Horizontal tab 09

3 LF Print and linefeed 0A

4 DLE EOT Transmit real-time status 10 04

5 DLE ENQ Real-time request to printer 10 05

6 ESC SP Set right-side character spacing 1B 20

7 ESC % Select/Cancel user defined characters 1B 25

8 ESC & Define user-defined characters 1B 26

9 ESC * Select bit-image mode 1B 2A

10 ESC ! Select print mode 1B 21

11 ESC ( A Control the memory switches 1B 28 41

12 ESC - Turn underline mode on/off 1B 2D

13 ESC = Select peripheral device status 1B 3D

14 ESC 2 Select default line spacing 1/6 lpi 1B 32

15 ESC 3 Set line spacing 1B 33

16 ESC < Return home 1B 3C

17 ESC ? Cancel user defined characters 1B 3F

18 ESC @ Initialize printer 1B 40

19 ESC D Set horizontal positions 1B 44

20 ESC E Turn emphasized mode on/off 1B 45

21 ESC G Turn double-strike mode on/off 1B 47

22 ESC J Print and feed paper <n> vertical units 1B 4A

23 ESC R Select an international character set 1B 52

24 ESC U Turn unidirectional printing mode on/off 1B 55

25 ESC a Select justification 1B 61

26 ESC c 3 Select paper sensor to output paper end signal 1B 63 33

27 ESC c 4 Select paper sensor to stop printing 1B 63 34

28 ESC c 5 Enable/disable panel button 1B 63 35

29 ESC d Print and feed <n> line 1B 64

30 ESC g <0> Start macro record (For logo) 1B 67 00

31 ESC g <n> Execute macro (For logo) 1B 67 <n>

32 ESC m Execute partial cut 1B 6D

33 ESC p Generate pulse 1B 70

34 ESC r Select color 1B 72

35 ESC t Select character code table 1B 74

36 ESC v Transmit paper sensor status 1B 76

37 ESC { Turn upside-down printing mode on/off 1B 7B

38 GS ( A Execute test print 1B 28 41

39 GS I Transmit printer ID 1D 49

40 GS V Select cut mode and cut paper 1D 56

41 GS a Enable/disable Automatic Status Back (ASB) 1D 61

42 GS j Enable/disable Automatic Status Back (ASB) for ink 1D 6A

43 GS r Transmit status 1D 72

Rev. 1.02 - 3 -

SRP-500

2. STAR Mode (SP-320)

n Command Descri

tion Hexadecimal

1 BEL Deferred drive command “A” for peripheral unit 1 07

2 FF Page feed (Form feed) 0C

3 CR Print and linefeed (same as LF) 0D

4 SO Select expanded character mode 0E

5 SI Select upside-down 0F

6 DC2 Cancel upside-down character 12

7 DC4 Cancel expanded character mode (Default setting) 14

8 CAN Cancel print data in buffer 18

9 EM Immediate drive command for peripheral unit2 19

10 SUB Immediate drive command for peripheral unit 2 1A

11 ESC BEL Adjust drive pulse width for peripheral unit

(Default setting)

1B 07

12 ESC - Set or Cancel underline mode 1B 2D

13 ESC 4 Red color print selection 1B 34

14 ESC 5 Red color print deselection 1B 35

15 ESC @ Initialize printer 1B 40

16 ESC C Set page length at n lines 1B 43

17 ESC E Emphasized print mode 1B 45

18 ESC F Emphasized print mode deselection (Default setting) 1B 46

19 ESC M Select 9 x 7(Half dots) character size 1B 4D

20 ESC R Select international character set 1B 52

21 ESC U Set or cancel uni-direction mode 1B 55

ESC W 1

ESC W <1>

Select expanded character mode

1B 57 31

1B 57 01

ESC W 0

ESC W <0>

Cancel expanded character mode (Default setting)

1B 57 30

1B 57 00

ESC _ 1

ESC _ <1>

Select over-line mode

1B 5F 31

1B 5F 01

ESC _ 0

ESC _ <0>

Cancel over-line mode

1B 5F 30

1B 5F 01

26 ESC a Feed paper n lines 1B 61

27 ESC d 0 Partial cut 1B 64 30

28 ESC d 1 Partial cut 1B 64 31

ESC e 1

ESC e <1>

Set the control panel switch invalid

1B 65 31

1B 65 01

ESC e 0

ESC e <0>

Set the control panel switch valid

1B 65 30

1B 65 00

ESC f 1

ESC f <1>

Set the ON LINE switch invalid

1B 66 31

1B 66 01

ESC f 0

ESC f <0>

Set the ON LINE switch valid

1B 66 30

1B 66 00

33 FS Immediate drive command “B” for peripheral unit 1 1C

34 ESC GS # Control the memory switches 1B 1D 23

35 GS I Transmit printer ID 1D 49

Rev. 1.02 - 4 -

SRP-500

3. CITIZEN Mode (iDP-3541)

n Command Description Hexadecimal

1 BEL First drawer drive command1 07

2 LF Paper feed command 0A

3 FF n “n”-lines paper feed command 0C n

4 SO Enlarged character command 0E

5 SI Normal character command 0F

6 DC1 Initial set command 11

7 DC2 Inverted character command 12

8 DC3 Red color print command 13

9 CAN Clear command 18

10 SUB Second drawer drive command 1A

11 ESC BEL Drive pulse setting command for the first drawer 1B 07

12 ESC - Underline command 1B 2D

13 ESC 1 1/9 inch paper feed preset command 1B 31

14 ESC 2 2/9 inch paper feed preset command 1B 32

15 ESC C Paper length set command 1B 43

16 ESC P <0> Paper partial cut command 1B 50 00

17 ESC P <1> Paper partial cut command 1B 50 01

18 FS First drawer quick drive command 1C

19 CR Printing ØD

20 ESC * n1 n2 Specifying the bit image mode 1B 2A n1 n2

21 ESC f <1> Form feed 1B 66 Ø1

22 GS I Transmit printer ID 1D 49

Rev. 1.02 - 5 -

SRP-500

4. Control Commands Details

4-1 Command Notation

[Name]

[Format]

[Range]

[Description]

The name of the command.

The code sequence. ASCII Indicates the ASCII equivalents.

Hex indicates the hexadecimal equivalents.

Decimal indicates the decimal equivalents.

[ ] k indicates the contents of the [ ] should be repeated k times.

Gives the allowable ranges for the arguments.

Describes the function of the command.

4-2 Explanation of Terms

LSB

Least Significant Bit

4-3 Control Commands Details

[Name] Horizontal tab

[Format] ASCII HT

Hex 09

Decimal 10

[Description] Moves the print position to the next horizontal tab position.

[Notes]

This command is ignored unless the next horizontal tab position has been set.

Horizontal tab positions are set with ESC D.

The default tab positions are at intervals of 8 characters (columns 9, 17, 25..) for the

font B (12 x 12).

[Reference] ESC D

[Name] Print and line feed

[Format] ASCII LF

Hex 0A

Decimal 10

[Description] Prints the data in the print buffer and feeds one line based on the

current line spacing.

[Note] This command sets the print position to the beginning of the line.

[Reference] ESC 2, ESC 3

Rev. 1.02 - 6 -

SRP-500

[Name] Print and carriage return

[Format] ASCII CR

Hex 0D

Decimal 13

[Description] This command prints the data in the print buffer and does not feed the

paper.

[Note] Sets the print starting position to the beginning of the line

[Reference] LF

DLE EOT n

[Name] Real-time status transmission

[Format] ASCII DLE EOT n

Hex 10 04 n

Decimal 16 4 n

[Range] 1 ≤n ≤4

[Description] Transmits the selected printer status specified by n in real time,

according to the following parameters:

n = 1: Transmit printer status

n = 2: Transmit off-line status

n = 3: Transmit error status

n = 4: Transmit paper roll sensor status

[Notes]

This command should not be used within the data sequence of another command that

consists of 2 or more bytes. For example, If you attempt to transmit ESC 3 n to the

printer, but DTR (DSR for the host computer) goes to MARK before n is transmitted

and then DLE EOT 3 interrupts before n is received, the code <10>H for DLE EOT 3 is

processed as the code for ESC 3

<10>H.

n = 1 : Printer status

Bit Off/On Hex Decimal Function

0 Off 00 0 Not used. Fixed to Off.

1 On 02 2 Not used. Fixed to On.

Off 00 0 Drawer kick-out signal is LOW (connector pin 3)2

On 04 4 Drawer kick-out signal is HIGH (connector pin 3)

Off 00 0 On-line.3

On 08 8 Off-line.

4 On 10 16 Not used. Fixed to On.

5 Off 00 0 Not used. Fixed to Off.

6 Off 00 0 Not used. Fixed to Off.

7 Off 00 0 Not used. Fixed to Off.

Rev. 1.02 - 7 -

SRP-500

n = 2 : Off-line status

Bit Off/On Hex Decimal Function

0 Off 00 0 Not used. Fixed to Off.

1 On 02 2 Not used. Fixed to On.

2 Off 00 0 Cover is closed (front & rear)

On 04 4 Cover is open (front or rear)

Off 00 0 Paper is not being fed by using the paper feed

button.

On 08 8 Paper is being fed by the paper feed button.

4 On 10 16 Not used.

Off 00 0 Fixed to On.5

On 20 32 No paper-end stop.

Off 00 0 Printing stops due to paper end.6

On 40 64 No error. Error occurs.

7 Off 00 0 Not used. Fixed to Off.

Bit 5 : On (printing stops due to paper-end) when printing stops due to paper-end detected

by the paper-end sensor or the paper near-end enabled by using the ESC c 4.

n = 3 : Error status

Bit Off/On Hex Decimal Function

0 Off 00 0 Not used. Fixed to Off.

1 On 02 2 Not used. Fixed to On.

Off 00 0 No mechanical error.2

On 04 4 Mechanical error occurred.

Off 00 0 No auto-cutter error.

3 On 08 8 Auto-cutter error occurs.

4 On 10 16 Not used. Fixed to On.

Off 00 0 No unrecoverable error.5

On 20 32 Unrecoverable error occurs.

Off 00 0 Automatic recover error.6

On 40 64 No automatic recover error.

7 Off 00 0 Not used. Fixed to Off.

Bit 2 : If these errors occur due to paper jams or the like, it is possible to recover by

correcting the cause of the error and executing DLE ENQ 2. If an error due to a

circuit failure (e.g. wire break) occurs, it is impossible to recover.

n = 4 : Continuous paper sensor status

Bit Off/On Hex Decimal Function

0 Off 00 0 Not used. Fixed to Off.

1 On 02 2 Not used. Fixed to On.

Off 00 0 Paper near-end sensor. Paper adequate.

2, 3

On 0C 12

Paper near-end is detected by the paper near-end

sensor.

4 On 10 16 Not used. Fixed to On.

Off 00 0 Paper end sensor. Paper adequate.5, 6

On 60 96 Paper end is detected by the paper end sensor.

7 Off 00 0 Not used. Fixed to Off.

Rev. 1.02 - 8 -

SRP-500

DLE ENQ n

[Name] Real-time request to printer

[Format] ASCII DLE ENQ n

Hex 10 05 n

Decimal 16 5 n

[Range] n = 2

[Description] The printer responds to a request from the host specified by n.

n = 2: Recovers from an error after clearing the receive and print

buffers.

[Notes]

This command should not be used within the data sequence of another command that

consists of two or more bytes. For example,

If you attempt to transmit ESC 3 n to the printer, but DTR (DSR for the host computer)

goes to MARK before n is transmitted, and DLE ENQ 2 interrupts before n is received,

the code <10>H for DLE ENQ 2 is processed as the code for ESC 3 <10>H.

This command n = 2 is valid only when a mechanical error or an auto-cutter error has

occurred.

DLE ENQ 2 enables the printer to recover from an error after clearing the data in the

receive buffer and the print buffer.

The printer retains the settings (by ESC !, ESC 3, etc.) in effect when the error

occurred. The printer can be initialized completely by using this command and ESC @.

This command is enabled only for errors that have the possibility of recovery

ESC SP n

[Name] Set right-side character spacing

[Format] ASCII ESC SP n

Hex 1B 20 n

Decimal 27 32 n

[Range] 0 ≤n ≤255

[Description] Sets the character spacing for the right side of the character to [ n x

0.122 mm {1/208 inches}] .

[Notes] The right-side character spacing for double-width mode is twice the

normal value.

[Default] n = 0

ESC ! n

[Name] Select print mode(s)

[Format] ASCII ESC ! n

Hex 1B 21 n

Decimal 27 33 n

[Range] 0 ≤n ≤255

[Description] Selects print mode(s) using n as follows:

Rev. 1.02 - 9 -

SRP-500

Bit Off/On Hex Decimal Function

Off 00 0 Character font A (12 x 14) selected.0

On 01 1 Character font B (12 x 12) selected.

1 - - - Undefined.

2 - - - Undefined.

Off 00 0 Emphasized mode not selected.3

On 08 8 Emphasized mode selected.

Off 00 0 Double-height mode not selected.4

On 10 16 Double-height mode selected.

Off 00 0 Double-width mode not selected.5

On 20 32 Double-width mode selected.

6 - - - Undefined.

Off 00 0 Underline mode not selected.7

On 80 128 Underline mode selected.

[Notes]

When both double-height and double-width modes are selected, quadruple size

characters are printed.

Underlining is added to the entire width of each character, including the space to the

right of a character, but is not added to portions of lines that were skipped by means of

an HT.

[Default] n = 1

[Reference] ESC E, ESC –

ESC ( A

[Name] Control the memory switches

[Format] ASCII ESC ( A pL pH fn [parameters]

Hex 1B 28 41

Decimal 27 40 65

[Range] 0 ≤pL ≤255

pH = 0

1 ≤fn ≤4

[Description] This command controls the memory switch setting modes. Each

function is classfied by fn as follow.

fn Function

1 Start the memory switch setting mode

2 Set the memory switch

3 End the memory switch setting mode

4 Transmitting the memory switch values

pL + pH x 256 ; The number of bytes for the parameters following pH.

[Notes]

It is non-volatile attribute which is not initialized by turning off the power or executing

ESC @.

Do not use these commands during normal printing opertion

Rev. 1.02 - 10 -

SRP-500

ESC ( A pL pH fn < fn = 1>

[Name] Start the memory switch setting mode.

[Format] ASCII ESC ( A pL pH fn [parameters]

Hex 1B 28 41 01 00 01

Decimal 27 40 65 1 0 1

[Range] pL + pH x 256 = 1 (pL = 1, pH = 0)

fn = 1

[Description] This command starts the memory switch setting modes.

[Notes]

After successfully entering to the setting mode, the printer sends a “success notice

packet” to host.

Notice packet Hex Decimal Data quantity

Header 37H 55 1 byte

Identifier 20H 32 1 byte

footer 00H 0 1 byte

If the host PC couldn’t obtain proper data, it has to terminate the setting mode by

function 3.

[Reference] ESC ( A

ESC ( A pL pH fn [a1 b18…b11] [ak bk8…bk1] < fn = 2>

[Name] Set the memory switch

[Format] ASCII ESC ( A pL pH fn [a1 b18...b11] [ak bk8...bk1]

Hex 1B 28 41 pL pH 02 [a1 b18...b11] [ak bk8...bk1]

Decimal 27 40 65 pL pH 2 [a1 b18...b11] [ak bk8...bk1]

[Range] fn = 2

1 ≤k ≤8

0x31 ≤a ≤0x38

b = 0x30 (OFF)

b= 0x31 (ON)

[Description] User can change the memory switch values with this command.

a ; the number of the memory switch

b ; the each bit value of the memory switch

[Notes]

This command only can be processed under the memory switch setting mode(function

1).

[Reference] ESC ( A

Autres manuels pour SRP-500

Autres manuels BIXOLON Imprimante

BIXOLON

BIXOLON SPP-R200II Manuel utilisateur

BIXOLON

BIXOLON Bixolon SRP-270 Instructions de montage

BIXOLON

BIXOLON SPP-R300 Manuel utilisateur

BIXOLON

BIXOLON SPP-R400 Manuel d'installation et d'exploitation

BIXOLON

BIXOLON SLP-D420 Manuel du propriétaire

BIXOLON

BIXOLON STP-103 Manuel utilisateur

BIXOLON

BIXOLON SRP-B300 Manuel utilisateur

BIXOLON

BIXOLON SRP-330II Manuel d'installation et d'exploitation

BIXOLON

BIXOLON SRP-380 Manuel utilisateur

BIXOLON

BIXOLON SRP-F312 Instructions d'installation

BIXOLON

BIXOLON SRP-332II Instructions d'installation

BIXOLON

BIXOLON SRP-B300 Instructions d'installation

BIXOLON

BIXOLON SRP-350 PlusA Manuel utilisateur

BIXOLON

BIXOLON SRP-382II Manuel d'installation et d'exploitation

BIXOLON

BIXOLON SPP-R200 Manuel utilisateur

BIXOLON

BIXOLON SRP-Q300 Manuel utilisateur

BIXOLON

BIXOLON SRP-350V Instructions d'installation

BIXOLON

BIXOLON SRP-350plusIII SRP-352plusIII Manuel utilisateur

BIXOLON

BIXOLON BGT-102P Manuel utilisateur

BIXOLON

BIXOLON SRP-350III Manuel utilisateur

BIXOLON

BIXOLON SRP-S3000 Manuel utilisateur

BIXOLON

BIXOLON SRP-350II Manuel utilisateur

BIXOLON

BIXOLON SRP-350III Manuel utilisateur

BIXOLON

BIXOLON SRP-350III Manuel utilisateur

Manuels Imprimante populaires d'autres marques

Lexmark

Lexmark 1400 Series Manuel

Canon

Canon i70 Series Manuel utilisateur

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Canon

Canon LASER SHOT LBP-1210 Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Canon

Canon PIXMA PRO-1 Series Manuel utilisateur

Canon

Canon PIXMA G3560 Guide de configuration

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Epson

Epson ET-7750 Mode d'emploi

Canon

Canon CLBR 460ps Manuel utilisateur

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Epson

Epson SC-F7100 series Manuel utilisateur

Epson

Epson Stylus C40UX Manuel utilisateur

Canon

Canon imagePASS-A2 Manuel utilisateur

Canon

Canon S820D Manuel utilisateur
