Billion BIPAC-7402 Manuel utilisateur
BIPAC- 7402
ADSL Modem/Router
Features >>
Features >>Features >>
Features >> VPN with 3DES Accelerator,
QoS (Quality of Service) & -
port Switch!!
Quick Start Guide
Billion 7402 ADSL Modem/Router
1
IMPORTANT notice rom Billion...
This Quick Start Guide (QSG) is to guide user to connect to the Internet
in a very short time. Having Internet access will not be far away from
this oint of time.
This router, Billion 7402, has been customised for New Zealand users.
That is, its factory default rofile is re-configured for New Zealand.
Hence, less ste s in configuring your router.
There are 2 User's Manuals included in the ackage: (1) Quick Start
Guide (this booklet your are reading) (2) Billion 7402 Series ADSL
Router Universal User's Manual (File name: Universal Manual and it is
saved on the CD included in the ackage). Both manuals should be read
in conjunction with each other.
Why read QSG? Because it is designed for New Zealand users whereas
the Billion 7402 ADSL Router Universal Manual guides international
and/or advanced users.
Package Contents
• Billion 7402 ADSL Modem/Router
• Drivers & Utilities CD
• This Quick Start Guide
• One RJ-11 (A-Ty e) "ADSL Router-to-ADSL s litter"
tele hone cable [both ends are of square sha e]
• One RJ-11 (B-Ty e) "ADSL s litter-to-tele hone walljack"
tele hone cable [one end is of square sha e only]
• One RJ-45 (CAT-5) straight (standard) LAN cable
• One ADSL line filter/s litter (call “s litter” for short)
• One PS2/RS-232 cable (Console Port cable).
• One DC 12V 1A Power ada tor
Billion 7402 ADSL Modem/Router
2
WARNING!
The grant of a Tele ermit for any item of terminal
equi ment indicates only that Telecom has acce ted
that the item com lies with minimum conditions for
connection to its network. It indicates no endorsement
of the roduct by Telecom, nor does it rovide any
sort of warranty. Above all, it rovides no assurance
that any Tele ermitted equi ment of a different make
or model, nor does it im ly that any roduct is
com atible with all of Telecom’s network services.
Billion 7402 ADSL Modem/Router
3
To know about your ADSL Modem/Router…
The Front Panel LEDs o Billion 7402
LED Meaning
1
PPP/MAIL
Lit steady when there is a PPPoA / PPPoE
connection.
Lit and flashed eriodically when there is email in
the Inbox.
2
ADSL Lit when successfully connected to an ADSL DSLAM
(“linesync”).
3
LAN
Lit when connected to an Ethernet device.
Green for 100Mb s; Orange for 10Mb s.
Blinking when data is Transmitted / Received.
4
SYS Lit when the system is ready.
5
PWR Lit when ower is ON.
1
2
3
5
Billion 7402 ADSL Modem/Router
4
Please follow Billion’s
READY? & GO! Program
to complete the setup of the router and enjoy the high
speed of Internet!!
1. READY?
[Do you have the following installed on your PC?]
An Ethernet (LAN)
TCP/IP rotocol
A web browser. E.g. Internet Ex lorer 5.0 or Netsca e 6 or later.
Your Internet account details. i.e. username and assword su lied
by your Internet Service Provider (ISP)
2. GO!
2.1 [Hardware Chapter]
Please check out the ear Ports of 7402 on next page (page 5) to know what
to connect using what kind of cable.
Connect your router to your PC and to other devices using the accessories
provided according to the rear ports layout on next page.
Billion 7402 ADSL Modem/Router
5
The Rear Ports of 7402
LINE
[ J-11 A-
Type
Connector or
Modem Line
Port]
(3.1) Plug in J-11-A cable to this
LINE port and another end of
cable to the MODEM port on the
SPLITTE .
(3.2) Splitter’s tail will plug into
the walljack.
(3.3) Plug in J-11-B cable to
PHONE port on the SPLITTE
and another end of cable to any
Telephone device. Warning: ALL
telephone devices in the
residence MUST be connected
through splitters.
Console
Connect a PS2/ S-232 cable to
this port when connecting to a
PC’s S-232 port (9-pin serial
port).
LAN
No.1~4
[ J-45
Connector or
Ethernet Port]
Connect the supplied standard
cable to this port while another
end connects to the LAN port of
the PC.
This LAN port can AUTO-
DETECT standard and crossover
cables
Reset Button
Press it if you intend to restore the
factory default settings back.
Power
Socket
Connect the supplied power
adapter to this jack.
Power
Switch
ecommend turn it on AFTE
everything is connected properly.
Billion 7402 ADSL Modem/Router
6
2.2 [Software Chapter]
2.2.1 Connection Mode
LAN (Ethernet) port users:
Please follow the “Configuring the Network Pro erties on a PC”
section (Procedure 2.2.2) on the bottom of this age to
modify the network settings.
2.2.2 Con iguring the Network Properties on PC
Windows XP/2000 users
1. Click Start and go to
SettingsControl
PanelNetwork
Connections.
2. ight-click Network
Connections icon, choose
Properties.
3. Select Internet Protocol
(TCP/IP) and click
Properties.
4. Select the Obtain an IP
address automatically and
the Obtain DNS server
address automatically radio
buttons.
5. Click OK to finished the
configuration.
Please go to Procedure 2.2.3 on page 8 to continue.
Billion 7402 ADSL Modem/Router
7
Windows 95/98/Me users
1. Click Start and go to
Settings
Control
Panel
Network.
2. Select Internet Protocol
(TCP/IP)
[Name o Your
Network Card] and Click
Properties.
3. Select the IP Address tab. In
this page, click the Obtain an
IP address automatically
radio button.
4. Then select the DNS
Con iguration tab.
5. Select the Disable DNS radio
button and click OK to finish
the configuration then
prepare to Restart your
computer.
Billion 7402 ADSL Modem/Router
8
Windows NT 4.0 users
1.
Click Start and go to
Settings
Control
Panel
Network.
2.
Select Internet Protocol
(TCP/IP)
[Name o Your
Network Card] and Click
Properties.
3.
Select the Obtain an IP
address rom a DHCP
server radio button and click
OK.
2.2.3 Veri ying i your PC connects to the Router success ully
(This checking is OPTIONAL. Otherwise, go to 2.2.4)
To see if this ADSL outer is
visible on the local network, go to
Start / Run. In the un dialog box,
type “ping 192.168.1.254” then
press OK.
Billion 7402 ADSL Modem/Router
9
Snapshot of a Successful Connection
A command prompt window will
pop out. If your ping is successful
which means your local network is
able to reach to the device, then
the command prompt window will
close up automatically.
Snapshot of a Failed Connection
Connection fails, when you see
“Request timed out” in the
command prompt window. You
may need to check your set up.
2.2.4 Con iguring the ADSL Modem/Router
1. Open the web browser and
type http://192.168.1.254 in
the browser’s address field
and press Enter. This
number is the default IP
address for this router.
Enter the default
User name: admin
Password: admin
Then press OK to enter the router
setup page.
