Bentel Security Academy8L Manuel utilisateur

BENTEL SECURITY srl reserves the right to modify the technical specifications of this product

without prior notice.

Digital Communicator Control Panel

Emission:

Immunity:

Low voltage:

Burglar alarm system:

EN 50081-1/1992

EN 50130-4/1995+A1/1999

EN 60950/1996 + A4/1997

CEI 79/2 2a Ed. 1993

TBR21-1/1993

complies to:

Terminal Equipment(TE):

BENTEL SECURITY declines all responsibility in the event of

unauthorized intervention on the control panel.

The control panel has been developed and made according to the highest

standards of quality, reliability and performance adopted by BENTEL

SECURITY srl.

Installation of the control panel must carried out strictly according to the

instructions, and in compliance with the safety laws in force.

To make sure your system continues to work as intended, you must test your

system every month. Consult the installer for testing and maintenance

instructions. If your system does not work correctly, call your installer for

service.

via Florida - Z.I. Valtesino - 63013 GROTTAMMARE (AP) - ITALY

Main Unit Manual: ACADEMY8L Control Panel and Digital Communicator

ISTR. UNIT. CENT. INGL. BENT.ACADEMY8L ISTUCBLEACADEM8L

TABLE OF CONTENTS

PARTS 5

The Main Unit . . . . . . . . . . . . . . . . . . . . . . . 5

INSTALLATION 6

Mounting the Panel . . . . . . . . . . . . . . . . . . . . 6

Terminal board . . . . . . . . . . . . . . . . . . . . . . . 6

Power supply connection . . . . . . . . . . . . . . . . . 7

Open Panel . . . . . . . . . . . . . . . . . . . . . . . . . 8

A Typical System . . . . . . . . . . . . . . . . . . . . . 9

NCDUEVOX voice board . . . . . . . . . . . . . . . . . . 12

Figure 1 Parts

4Security System Control Panel Academy8L

PARTS

The table below provides a brief description of each part (the numbers in

boldface refer to the parts illustrated in the figure 1), and the meaning of

the ON / OFF status of each indicator LED.

PARTS DESCRIPTIONS

14 screws

25 Indicator LEDs

34 holes (Ø 5 mm)

4NormVox2 voice board connector

5Protection fuse for sensor and auxiliary power supply (250 V - 5 A)

6Protection fuse against polarity inversion on battery (250 V - 8 A)

7DB9 connector for PC connection via serial cable

8-8a Tamper microswitch; 8a optional (see Installation Manual page 26)

9Connector for the 3 A switching power supply BAQ35 or BAW35

(optional)

10 3 holes for wires (Ø40 mm)

11 Mains connection terminals (230 V~ ±10% / 150 mA)

12 Housing for 13.8 V / 7 Ah standby battery (optional)

13 Service mode jumper. Connection of this jumper will disable the Alarm

outputs for maintenance purposes.

14 Battery connectors

15 Firmware Release: to be communicated to Service dealer

LEDs STATUS

ON:

OFF: Panel powered from mains

Mains failure----Panel powered by the battery

OFF:

ON: Battery OK

Battery low or battery trouble

OFF:

ON: Fuse 5 intact (power to sensors)

Fuse 5 blown

OFF:

ON: Communicator in standby status: telephone line free

Telephone line engaged by the communicator

OFF:

ON: Communication bus OK

Communication bus trouble

PARTS 5

INSTALLATION

Mounting the Panel

The Panel should be located in a dry area, preferably near the mains

power source and incoming telephone line.

Follow the installation instructions carefully, and refer to figure 1.

Step 1 Unfasten the screws (1) and remove the front.

Step 2 Check for cable conduits and water pipes before drilling. Use the back box

as a drill pattern (holes 3).

Step 3 Attach the NCDUEVOX voice board 8 (if used).

Step 4 Pull the wires through the hole (10) and mount the back box.

Terminal board

Below is a description of the Main Unit terminal board, keypads and key

readers.

ØThe Terminal column shows the terminal number and the identifier of each

terminal (in square brackets).

ØThe DESCRIPTION column provides a description of each terminal.

The V column shows the voltage on the corresponding terminal.

The Icolumn shows the maximum current for each terminal.

Where (1) or (2) is shown as the value in the I column refer to the footnote

below the terminal description table.

6Security System Control Panel Academy8L

Terminal DESCRIPTION VI

5-8-11-14

17-20-23-26 [+F] Sensor power-supply terminals 13.8 (1)

6-9-12-15-18

21-24-27 [L1……L8] Alarm Zones programmable as NC, NO, Balanced or

Double Balanced - -

7-10-13-16-19-22

25-28-30-36 [ ] Ground and Negative 0-

1 [+] Power supply to additional devices (keypads and key

readers) 13.8 (1)

2 [C] Connection terminal for standard BPI control devices

(keypads and key readers) - -

3 [R] Connection terminal for standard BPI control devices

(keypads and key readers) - -

4 [-] Power supply (negative) (keypads and key readers)

29 [AS] Balanced Tamper line - -

38[+A] Terminal for indoor sirens

Standby status èterminal open

Alarm status èvoltage on terminal 13.8 (2)

37 [+N] Terminal for self-powered sirens

Standby status èvoltage on terminal

Alarm status èterminal open 13.8 (1)

34-35-36

[NC-COM-NO]

Voltage free alarm-relay contacts

Standby status èNC connected to COM and NO open

Alarm status èNO connected to COM and NC open -3

31 [K] Auxiliary terminal to Arm / Disarm the Panel by means

non-standard BPI devices

(keylock switch, digital key, proximity key, etc.) 13.8 -

39-40-41-42

[O1] [O2] [O3] [O4] Programmable open-collector output 00.5

33 [+B] Auxiliary power supply 13.8 (1)

45-46 [LE] Incoming telephone line connection terminals - -

47-48 [LI] Terminals for line sharing devices

(switchboard, telephone, fax, modem, etc.) - -

49 []Earth - -

(1) The total current absorbed by terminals [+F], [+B], [+] and [+N] must not

exceed 1 A.

(2) Terminal [+A] can absorb up to 2.5 A for short periods.

INSTALLATION 7

Power supply connection

The Panel is powered by the Mains source (230 V/50 Hz) through an on-

board power supply. The Mains wires must be connected to the terminals (11)

and the battery must be plugged into the connectors (14).

On power up----the green LED Main (on the Panel) will go ON.

The red LEDs:

Battery

Fuse

Communicator

Communication Bus ---- will all go OFF.

+On power up (Open Panel) the OPEN LED on the keypad will go ON but the

Panel will not generate a Tamper Alarm. However, once the Panel is closed

a Tamper Alarm will be generated if the Panel is reopened.

The battery (13.8 V, 7 Ah max. not supplied) will supply power during mains

failure. Mains failure will be signalled as follows:

ØMAIN LED on the Panel will go OFF.

ØTROUBLE LED on the Control Keypad will go ON.

ØActivation of one of the auxiliary outputs: 39[O1], 40[O2], 41[O3], 42[O4]----if

programmed to signal TROUBLE.

The cause of trouble must always be eliminated before the battery empties. To-

tal power failure (mains and battery) will not affect the configuration, as the non-

volatile memory will save any changes made during Armed status.

Open Panel

Access the programming phase before opening the Panel for servicing,

testing etc., as this will disable the Tamper microswitch.

Step 1 Enter INSTALLER PIN.

Step 2 Press to access programming.

Step 3 Open the Panel.

Step 1 Enter MAIN USER PIN.

Step 2 Press .

8Security System Control Panel Academy8L

Step 3 Press to access programming.

Step 4 Open the Panel and service as required.

The OPEN LED on the keypads will stay ON until the Panel is closed

again. No alarms will be generated during this phase.

Step 5 Close the Panel.

Step 6 Press to exit the programming phase.

A Typical System

Figure 2 illustrates a typical system.

ØIncoming telephone line connection

ØSignalling device connections----indoor siren and self-powered siren

ØConnection of a burglar sensor to line L1

ØConnection of three fire sensors to line L8

ØTamper line connection

ØConnection of additional devices (Keypad and Key reader) to the BPI bus

Please note:

ØLine L1 must be programmed as Double Balanced. This configuration

provides tamper detection, and requires two wires only.

ØLine L8 must be programmed as Fire and the auxiliary output (terminal

42[O4]) as Fire GND ---- Normally Closed.

Not all Alarm line connections are illustrated, however, burglar sensors

must be connected as per line L1, and fire sensors as per line L8.

+Use shielded cable----one end must be connected to the Panel ground and

the other to the device ground.

INSTALLATION 9

Figure 2 A Typical System
