Belkin P73965 Manuel utilisateur
P73965 F5U224
USB 2.0 Hi-Speed
4-Port Hub
User Manual
Congratulations and thank you for purchasing the Belkin
4-Port USB 2.0 Hub (the Hub). The Hub provides four
downstream USB ports that are compatible with both USB
1.1 (low- and full-speed) devices, as well as with USB 2.0
(high-speed) devices.
This means that the Hub is “backward-compatible” with all of
your current USB 1.1 devices and also works with the next
generation of “high-speed” USB 2.0 devices. This may
include such peripherals as scanners, printers, mass-storage
devices, and high-resolution cameras. The Hub is
self-powered, which allows the cascading of devices with
additional hubs, so that up to 127 USB devices can be
connected to a single port. The Hub also provides a
multicolored status LED for each individual port, and a
master power LED that indicates the Hub is powered and
ready to use. For additional information, refer to the
“Technical Specifications” section.
Introduction
1
Please read this manual thoroughly and follow the
procedures to prevent any damage to the 4-Port
USB 2.0 Hub and/or to the connected devices.
Features
2
•Compliant with Universal Serial Bus specification 2.0
(data rate 1.5/12/480Mbps)
•Backward-compatible with Universal Serial Bus Specification
1.1 (data rate 1.5/12Mbps)
•Compatible with Windows®98SE, Me, 2000, and XP
•USB Implementers Forum (USB-IF) approval
•Plug-and-Play technology
•Support for “hot swapping” of USB devices
•Per-port over-current detection and protection
•Individual port-status indicator LEDs
•Four 480Mbps downstream ports
•Fully compatible with USB 1.1 and USB 2.0 devices
Package Contents
(1) USB 2.0-compliant 4-Port Hub: F5U224
(1) USB Device Cable
(1) AC Power Adapter
(1) User Manual
Technical Specifications
3
Upstream Ports: (1)
Downstream Ports: (4)
Per-Port Voltage: DC +5V
Per-Port Current: 500mA (max.)
Power Mode: Self-powered
Operation Temperature: 5°C~40°C
Storage Temperature: -20°C~60°C
Enclosure: Plastic
Power Supply: Input: 120V AC
Output: DC 6V 2.5A
Plug Size: 5.5mm (outer)
2.1mm (center)
Plug Polarity: Center Positive
Technical Specifications (continued)
4
Main Power LED
ColorDefinitions:
Off Not operational
Steady Red Operational
Port-Status LED
Color Definitions:
Off Not operational
Amber Error condition
Steady Green Fully operational
Blinking Off/Green Software attention
Blinking Off/Amber Hardware attention
Product Detail
5
Figure 1
Per-Port Status LED
Power LED
DC 6V 2.5A
Power Jack
Upstream Port Downstream
Ports
Hardware Installation
6
1. Plug the AC adapter into a wall outlet or surge suppressor.
Plug the DC connector into the DC power jack found on the
back of the Hub (See Figure 1).
2. Plug the USB-A cable connector into the downstream port
of your computer, or downstream port of another hub.
(See Figure 2).
Important Note: The Hub must be connected to a USB
2.0-compliant host in order to function in high-speed mode
(480Mbps data rate). If connected to a USB 1.1-compliant
host, the Hub will operate only in low-or full-speed mode
(1.5/12Mbps).
3. Plug the USB-B cable connector into the upstream port of
the Hub (See Figure 3).
4. Windows will now detect your Hub and install the necessary
driver support. (The Windows “Install New Hardware
Wizard” may prompt you to provide your Windows
Installation CD to complete the driver installation process).
5. Plug the USB-A connector of the USB device, or an
additional hub, into any of the downstream ports of the Hub.
(See Figure 4).
Hardware Installation (continued)
7
Port 1 Port 2
Port 3
Upstream Port
Port 4
USB-A Connector
Figure 2 USB-B Connector
Figure 3
Figure 4
Information
FCC Statement
DECLARATION OF CONFORMITY WITH FCC RULES FOR
ELECTROMAGNETIC COMPATIBILITY
We, Belkin Components, of 501 West Walnut Street, Compton, CA 90220,
declare under our sole responsibility that the product:
F5U224
to which this declaration relates:
Complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may
cause undesired operation.
CE Declaration of Conformity
We, Belkin Components, declare under our sole responsibility that the F5U224, to which this
declaration relates, is in conformity with Generic Emissions Standard EN550022 1998 and
with Generic Immunity Standard EN550024 1998, EN61000-3-2, and EN61000-3-3.
Belkin Components Limited Lifetime Product Warranty
Belkin Components warrants this product against defects in materials and workmanship for
its lifetime. If a defect is discovered, Belkin will, at its option, repair or replace the product at
no charge provided it is returned during the warranty period, with transportation charges
prepaid, to the authorized Belkin dealer from whom you purchased the product. Proof of
purchase may be required.
This warranty does not apply if the product has been damaged by accident, abuse, misuse,
or misapplication; if the product has been modified without the written permission of Belkin;
or if any Belkin serial number has been removed or defaced.
THE WARRANTY AND REMEDIES SET FORTH ABOVE ARE EXCLUSIVE IN LIEU OF ALL OTHERS,
WHETHER ORAL OR WRITTEN, EXPRESSED OR IMPLIED. BELKIN SPECIFICALLY DISCLAIMS
ANY AND ALL IMPLIED WARRANTIES, INCLUDING, WITHOUT LIMITATION, WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
No Belkin dealer, agent, or employee is authorized to make any modification, extension, or
addition to this warranty.
BELKIN IS NOT RESPONSIBLE FOR SPECIAL, INCIDENTAL, OR CONSEQUENTIAL
DAMAGES RESULTING FROM ANY BREACH OF WARRANTY, OR UNDER ANY OTHER
LEGAL THEORY, INCLUDING BUT NOT LIMITED TO, LOST PROFITS, DOWNTIME,
GOODWILL, DAMAGE TO OR REPROGRAMMING, OR REPRODUCING ANY PROGRAM
OR DATA STORED IN OR USED WITH BELKIN PRODUCTS.
