Belimo CMU Series Manuel d'instructions

Ver. 2

Technical Databook

Damper Actuators

Version 4

Belimo Asia Pacific

V4. 12. 2010 . Subject to modification

Torque

General Damper Actuator

40Nm G

20Nm S

10Nm N

5Nm L

2Nm C

General Damper Actuator M

Power Supply

AC/DC 24V 24

AC 100...240V (AC 230 for Mechanical Fail-Safe Damper Actuator) 230

For customising types of Damper Actuators please contact your nearest Belimo sales representative.

New Generation General Damper Actuator for Asia Pacific

Damper Actuator standard type naming

Mechanical Fail-Safe Damper Actuator

20Nm S

10Nm N

4Nm L

2Nm T

Mechanical Fail-Safe Damper Actuator F

General Damper Actuator

Open/Close, 3-point

Open/Close (only for CMU230..) Blank

Modulating DC 2(0)...10V Control -SR

-RES

Auxiliary Switch -S

Form fit -F

Terminal Connection -T

Open/Close Blank

Modulating DC 2(0)...10V Control -SR

Auxiliary Switch -S, -S2

3-point -3

Mechanical Fail-Safe Damper Actuator

Product Naming L M U 24 -SR

V4. 12. 2010 . Subject to modification

Contents

The actuators listed in this catalogue are intended for the

operation of air dampers in HVAC systems.

The Damper Actuator is not allowed to be used outside the

specified field of application, especially in aircraft.

The enclosure of the actuator equipment may only be

opened by the manufacturer. It contains no components

which the user can replace or repair.

The device contains electrical and electronic

components and is not allowed to be disposed of as

household refuse. All locally valid regulations and

requirements must be observed.

When calculating the torque required to operate

dampers, it is essential to take into account all the data

supplied by the damper manufacturer concerning cross

sectional area, design, mounting and air flow condition.

Note:

LMU24(-S/-F/-T)

LMU24-SR

LMU230(-S/-F)

LMU230SR

NMU24(-S/-F/-T)

NMU24-SR

NMU230(-S/-F)

NMU230SR

SMU24(-S/-F/-T)

SMU24-SR

SMU230(-S/-F)

SMU230SR

GMU24

GMU24-SR

GMU230

Wiring diagrams

Auxiliary switch adjustment

Mechanical accessories

Replacement table (for Mechanical Fail-Safe Damper Actuators)

General Damper Actuator, 40Nm

LMQU24

LMQU24-SR

Fast Running Damper Actuator, 4Nm

NMQU24

NMQU24-SR

Fast Running Damper Actuator, 8Nm

SMQU24

SMQU24-SR

Fast Running Damper Actuator, 16Nm

General Damper Actuator, 20Nm

General Damper Actuator, 10Nm

General Damper Actuator, 5Nm

Product overview

CMU24(-F8/-F10)(-T)

CMU24-SR-R

CMU230(-F8/-F10)

CMU230(-F8/-F10)-RES

General Damper Actuator, 2Nm

Electrical accessories

Mechanical Fail-Safe Damper Actuator, 2Nm

Mechanical Fail-Safe Damper Actuator, 4Nm

Mechanical Fail-Safe Damper Actuator, 10Nm

TF24(-S)

TF24-3

TF24-SR

TF230(-S)

LF24(-S)

LF24-3

LF24-SR

LF230(-S)

NFU

NFU-S2

NFU24-SR

Mounting instructions 46

TF230-SR 35

Mechanical Fail-Safe Damper Actuator, 20Nm

SFU

SFU-S2

SFU24-SR

•

Using Belimo Damper Actuators:

Torque requirements:

V4. 12. 2010 . Subject to modification

Damper Actuator product overview

General Damper Actuator

Open/Close, 3-point

AC/DC 24V 50/60Hz

Auxiliary switch built-in 1 SPDT

AC 100...240V 50/60Hz

AC 230V 50Hz (Open/Close)

Auxiliary switch built-in 1 SPDT

Modulating

AC/DC 24V 50/60Hz

Control signal DC 2(0)...10V, feedback DC 2...10V

AC 100...240V 50/60Hz

Running time

Shaft diameter

Sound power level

Electrical connection

Direction of rotation

Angle of rotation

Position indication

Degree of protection

EMC

Ambient temperature

Non-operation temperature

Cable 1m (-T: Terminal)

Manual override Gear disengaging by pushbuttonGear disengaging by magnet

Selected by switch

Max. 95°, can be limited at both ends with mechanical adjustable end stops

Mechanical, plug-on

IP54 in any direction (-T: IP20)

CE according to 89/336/EEC

-30...+50°C

-40...+80°C

Humidity test 95% RH, non-condensing (to EN 60730-1)

* Only Open/Close, no 3-point.

** CMU24-SR-R: Control signal 2(0)V at the right side, and the left side is available on request.

CMU..

2Nm

CMU24(-F8/-F10)(-T)

CMU230(-F8/-F10)

CMU230(-F8/-F10)-RES*

CMU24-SR-R**

75s 150s

6...12.7mm

Max. 35dB(A)

LMU..

5Nm

LMU24(-F/-T)

LMU24-S

LMU230

LMU230-S

LMU24-SR

LMU230SR

6...20mm

Max. 35dB(A)

NMU..

10Nm

NMU24(-F/-T)

NMU24-S

NMU230

NMU230-S

NMU24-SR

NMU230SR

8...26mm

Max. 35dB(A)

SMU..

20Nm

SMU24(-F/-T)

SMU24-S

SMU230

SMU230-S

SMU24-SR

SMU230SR

10...20mm

Max. 48dB(A)

GMU..

40Nm

GMU24*

GMU230*

GMU24-SR

14...26mm

Max. 48dB(A)

LMQU..

8…26.7mm

NMQU.. SMQU..

Open/Close

AC 24V 50/60Hz, DC 24V

Modulating

AC 24V 50/60Hz, DC 24V

Control signal DC 2(0)…10V, feedback signal DC 2…10V

Running time

Shaft diameter

Sound power level

Manual override

Electrical connection

Direction of rotation

Angle of rotation

Position indication

Degree of protection

EMC

Ambient temperature

Non-operation temperature

Humidity test

4Nm

LMQU24

LMQU24-SR

2.5s

8Nm

NMQU24

NMQU24-SR

4.0s

16Nm

SMQU24

SMQU24-SR

7.0s

12…25.5mm

Max. 52dB(A)

Disengaging the gearing latch by means of a pushbutton, self-resetting

Cable 1m

Selected by switch

Max. 95°, can be limited at both ends with mechanical adjustable end stops

Mechanical, plug-on

IP54 in any direction

CE according to 2004/108/EC

-30…+40°C (without restrictions); +40…+50°C (with restrictions)

-40…+80°C

95% RH, non-condensing (to EN 60730-1)

V4. 12. 2010 . Subject to modification

Mechanical Fail-Safe Damper Actuator

Open/Close

AC/DC 24V 50/60Hz

Auxiliary switch built-in 1 SPDT

AC 230V 50/60Hz

Auxiliary switch built-in 1 SPDT

3-point

Modulating

AC/DC 24V 50/60Hz

Control signal DC 2(0)...10V, feedback DC 2...10V

Running time -Motor

-Spring return

Shaft diameter

Sound power level -Motor

-Spring return

Electrical connection

Mechanical limiter

Position indicator

Degree of protection

EMC

Ambient temperature

Non-operation temperature

Cable 1m

Selected by mounting L/R

Max. 95°

YES

YES IP54

CE according to 89/336/EEC

* LF24-3 and all -SR types are 150s.

TF..

2Nm

TF24

TF24-S

TF230

TF230-S

TF24-3

TF24-SR

< 75s*

< 25s

6...12mm

IP42

LF..

4Nm

LF24-S

LF230

LF230-S

LF24-3*

LF24-SR

40-75s*

~20s

8...16mm

Max. 50dB(A)

62dB(A)

-30...+50°C

Humidity test 95% RH, non-condensing (to EN 60730-1)

-40...+80°C

** TF24-3 nominal voltage is AC 24V, TF230 nominal voltage is AC 100...240V.

Damper Actuator product overview

Direction of rotation

Angle of rotation

Machanical Fail-Safe Damper Actuator

Open/Close

AC 24...240V DC 24...125V

Auxiliary switch built-in 2 SPDT

Modulating

AC/DC 24V 50/60Hz

Control signal DC 2(0)...10V, feedback DC 2...10V

Running time -Motor

-Spring return

Shaft diameter

Sound power level -Motor

-Spring return

Electrical connection

Mechanical limiter

Position indicator

Degree of protection

EMC

Ambient temperature

Non-operation temperature

Cable 1m

Selected by mounting L/R

Max. 95°

YES

IP54

CE according to 2004/108/EEC

NFU..

10Nm

NFU

NFU-S2

NFU24-SR

Open/Close 75s; modulating 150s

10...12mm / 14...25.4mm

SFU..

20Nm

SFU

SFU-S2

SFU24-SR

<20s

Open/Close Max. 50dB(A)/Modulating Max. 40dB(A) Open/Close Max. 50dB(A)/Modulating Max. 40dB(A)

Max. 62dB(A)

-30...+50°C

Humidity test 95% RH, non-condensing (to EN 60730-1)

-40...+80°C

Direction of rotation

Angle of rotation
